lcd
monitors
LCD Desktop Monitors
Model W2246T-BF W2246PM-BF E2210T-BN / E2210P-BN (LED-backlit) E1910T-BN (LED-backlit)
LCD ize / viewable 22" Class (22.0" Measured Diagonally) 22" Class (22.0" Measured Diagonally) 22" Class (22.0" Measured Diagonally) 19" Class (18.5" Measured Diagonally)
Pixel Pitch 0.248mm 0.248mm 0.282mm 0.294mm
creen Aspect Ratio 16:9 16:9 16:10 5:4
Maximum Resolution 1920 x 1080 1920 x 1080 1680 x 1050 1280 x 1024
Brightness 250 cd/m² 250 cd/m² 250 cd/m2 250 cd/m2
Contrast Ratio DFC 30,000:1 DFC 30000:1 DFC 5,000,000:1 DFC 10,000:1
Viewing Angle ( /V) 170° / 160° 170° / 160° 170° / 160° 170° / 160°
Response Time 5ms 5ms 5ms 5ms
Video Inputs D UB / DVI / HDMI™ D-Sub, DVI-D ( DCP) D-Sub ( DCP), DVI-D DVI-D ( DCP), D-Sub DVI-D ( DCP), D-Sub
PC Audio In -- Yes -- --
Headphone Out -- -- -- --
Power Consumption - On/ tandby 28W / Under 1W 26W / Under 1W 28W / Under 1W 25W / Under 1W
VE A™ Mounting (Screw Spacing) 75mm x 75mm 75mm x 75mm 75mm x 75mm 75mm x 75mm
tand Tilt, Base Detachable Tilt, Swivel, Pivot, eight Adjustable, Base Detachable Tilt, Base Detachable (E2210T) /
Tilt, Base Detachable, Swivel, Pivot, eight-Adjustable (E2210P) Tilt, Base Detachable
Features f-ENGINE f-ENGINE f-ENGINE f-ENGINE
Unit Dimensions w/ tand (WxDx ) 20.0" x 8.3" x 15.6" 20.0" x 8.8" x 18.3" 19.9" x 8.3" x 16.7" 16.1" x 8.2" x 16.9"
Unit Dimensions w/o tand (WxDx ) 20.0" x 2.4" x 12.0" 20.0" x 2.4" x 12.0" 19.9" x 2.4" x 13.1" 16.1" x 2.3" x 13.3"
Carton Dimensions (WxDx ) 22.6" x 17.8" x 5.0" 22.7" x 14.7" x 7.9" 22.1" x 4.6" x 15.1" (E2210T)
22.6" x 15.7" x 8.3" (E2210P) 22.3" x 17.4" x 4.2"
Weight (lbs.) w/stand | w/o stand |
hipping 7.93 lbs | 7.07 lbs | 11.57 lbs 13.0 lbs | 7.1 lbs | 16.8 lbs 7.87 lbs. (E2210T), 9.25 lbs. (E2210P) I 7.60 lbs. (E2210T), 6.83 lbs.
(E2210P) I 11.02 lbs. (E2210T), 11.68 lbs. (E2210P) 5.46 lbs. / 5.20 lbs. / 8.70 lbs.
afety UL(cUL), TUV-GS, SEMKO UL(cUL), TUV-GS, SEMKO TCO 5.0, UL(cUL), TUV-GS, SEMKO TCO 5.0, UL(cUL), TUV-GS, SEMKO
EPEAT®Certification GOLD GOLD GOLD GOLD
Environment Ro S Ro S Ro S Ro S
EMC FCC-B, CE FCC-B, CE FCC-B, CE FCC-B, CE
Power aving tandard ENERGY STAR®5.0 ENERGY STAR®5.0 ENERGY STAR®5.0 ENERGY STAR®5.0
Limited Warranty 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight)
UPC 7 19192 90031 8 7 19192 90032 5 7 19192 18838 9 (E2210T)
7 19192 18837 2 (E2210P) 7 19192 18836 5
Model IP 231B-BN (IP Panel, LED-backlit) W2753VC-PF W2442PA-BF L2000CP-BF
LCD ize / viewable 23" Class (23.0" Measured Diagonally) 27" Class (27.0" Measured Diagonally) 24" Class (24.0" Measured Diagonally) 20" Class (20" Measured Diagonally)
Pixel Pitch 0.265mm 0.134mm
0.277mm 0.255mm
creen Aspect Ratio 16:9 16:9
16:9 5:4
Maximum Resolution 1920 x 1080 1920 x 1080 1920 x 1080 1600 x 1200
Brightness 250 cd/m² 300 cd/m² 300 cd/m² 300 cd/m²
Contrast Ratio DFC 5,000,000:1 DFC 50,000:1
DFC 10,000:1 800:1
Viewing Angle ( /V) 178° / 178° 170° / 160° 170° / 160° 178° / 178°
Response Time 5ms 2ms
2ms 8ms
Video Inputs DVI-D ( DCP), D-Sub D-Sub, DVI-D ( DCP), DMI D-Sub, DVI-D ( DCP), DMI D-Sub, DVI-D
PC Audio In -- -- Yes --
Headphone Out -- -- Yes --
Power Consumption - On/ tandby 35W / Under 1W 46W / Under 1W 42W / Under 1W 58W / Under 1W
VE A™ Mounting (Screw Spacing) 75mm x 75mm -- 100mm x 100mm 100mm x 100mm
tand Tilt, Swivel, Pivot, eight Adjustable, Base Detachable Tilt, Swivel, Base Detachable Tilt, Swivel, Pivot, eight Adjustable, Base Detachable Tilt, Swivel, eight Adjustable, Pivot, Base Detachable
Features Built-In Speakers f-ENGINE, ez-Zooming f-ENGINE, Built-In Speakers, 4:3 in wide f-ENGINE
Unit Dimensions w/ tand (WxDx ) 21.6" x 5.4" x 18.8" 25.7" x 8.3" x 19.2"
23.0" x 17.2" x 10.6" 17.6" x 9.6" x 17.6"
Unit Dimensions w/o tand (WxDx ) 21.6" x 2.2" x 13.2" 25.7" x 2.7" x 16.7"
23.0" x 14.0" x 2.4" 17.6" x 2.8" x 13.6"
Carton Dimensions (WxDx ) 24.6" x 7.9" x 16.2" 28.8" x 21.3" x 6.1"
25.4" x 16.1" x 8.7" 21.9" x 10.3" x 20.7"
Weight (lbs.) w/stand | w/o stand |
hipping 10.4 lbs |8.2 lbs | 14.1 lbs 15.0 lbs. I 14.0 lbs. I 20.8 lbs. 13.67 lbs | 10.36 lbs | 17.86 lbs 16.8 lbs | 12.8 lbs | 20.9 lbs
afety TCO 5.0, UL(cUL), TUV-GS, SEMKO UL(cUL), SEMKO
UL(cUL), TUV-GS, SEMKO UL(cUL), TUV-GS, SEMKO
EPEAT®Certification GOLD --
Environment Ro S -- Ro S --
EMC FCC-B, CE FCC-B, CE FCC-B, CE FCC-B, CE
Power aving tandard ENERGY STAR®5.0 -- -- --
Limited Warranty 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight)
UPC
7 19192 18861 7 7 19192 90026 4 7 19192 18527 2 7 19192 18427 5

Energy Star: Many LG LCD Desktop Monitors meet
Energy Star requirements in On, Sleep, and Off
Modes
Ro S: The Ro S is an EU directive which restricts the
amount of six hazardous substances allowed in
certain electronic equipment.
*Technologies and features vary per model.
EPEAT is an environmental procurement tool that
evaluates the environmental impact of electronic
products in categories such as reduction and
elimination of environmentally sensitive materials,
energy efficiency, design for recycling, product
longevity and end-of-life management. LG is proud
to have many monitors rated EPEAT Gold; the highest
EPEAT certification.
Experience images optimized for various levels of
brightness resulting in a more accurate color
reproduction and deeper blacks.
An integrated digital high-quality picture system that
separates the relationship between brightness and
color so that each can be adjusted independently.
MODEL N1742LP-BF (Network Monitor, PCI Card type) N1941WP-PF (Network Monitor, PCI Card type) N194WA-BF (Network Monitor, Ethernet type)
LCD ize / viewable 17" Class (17.0" Measured Diagonally) 19" Class (18.9" Measured Diagonally) 19" Class (18.5" Measured Diagonally)
Pixel Pitch 0.264mm 0.283mm 0.283mm
creen Aspect Ratio 5:4 16:9 16:10
Native Resolution 1280 x 1024 1366 x 768 1440 x 900
Brightness 250 cd/m² 250 cd/m² 250 cd/m2
Contrast Ratio DFC 8000:1 DFC 8000:1 DFC 20,000:1
Viewing Angle ( /V) 170° / 160° 170° / 160° 170° / 160°
Response Time 5ms 5ms 5ms
Video Inputs D-Sub D-Sub D-Sub
PC Audio Out -- -- --
Power Consumption - On/ tandby 23W / Under 1W 36W / Under 1W 23W / Under 1W
VE A™Mounting (Screw Spacing) 75mm x 75mm 75mm x 75mm 75mm x 75mm
tand Tilt, Base Detachable Tilt, Base Detachable Tilt, Base Detachable
Features f-ENGINE, sRGB, DDC/CI f-ENGINE, Built-In Speakers, 4:3 in wide f-ENGINE, Built-In Speakers, 4:3 in wide
Unit Dimensions et w/ tand (WxDx ) 14.5" x 7.3" x 15.4" 17.6" x 7.8" x 14.1" 17.6" x 7.8" x 15.1"
Unit Dimensions et w/o tand (WxDx ) 17.6" x 2.2" x 15.4" 17.6" x 2.3" x 10.9" 17.6" x 2.5" x 11.8"
Carton Dimensions (WxDx ) 20.1" x 14.4" x 4.7" 24.8" x 14.1" x 4.7" 20.1" x 14.1" x 4.7"
Weight (lbs.) w/stand | w/o stand | hipping 6.8 lbs | 6.2 lbs | 10.8 lbs 7.7 lbs | 7.1 lbs | 11.0 lbs 8.6 lbs | 8.2 lbs | 10.3 lbs
afety UL(cUL), TUV-GS, SEMKO UL(cUL), TUV-GS UL(cUL), TUV-GS
EPEAT®Certification SILVER -- --
Environment -- -- --
EMC FCC-B, CE FCC-B, CE FCC-B, CE
Power aving tandard ENERGY STAR®5.0 -- --
Limited Warranty 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight)
UPC 7 19192 90040 0 7 19192 90039 4 7 19192 18759 7
LG LCD Monitor Technologies and Features*:
MODEL L1942 E-BF/L1942TE-BF/L1942PE-B T1710B-BN / T1910B-BN (Touch creen) W1942TQ-BF W1943 -PF
LCD ize / viewable 19" Class (18.9" Measured Diagonally) 17" Class (17.0" Measured Diagonally)
19" Class (19.0" Measured Diagonally) 19" Class (18.9" Measured Diagonally) 19" Class (18.9" Measured Diagonally)
Pixel Pitch 0.294mm 0.264mm (17")
0.294mm (19") 0.285mm 0.285mm
creen Aspect Ratio 5:4 5:4 16:10 16:10
Native Resolution 1280 x 1024 1280 x 1024 1440 x 900 1440 x 900
Brightness 250 cd/m² 200 cd/m2 300 cd/m² 300 cd/m²
Contrast Ratio DFC 8000:1 DFC 20,000:1 DFC 8000:1 1000:1
Viewing Angle ( /V) 170° / 170° 170° / 160° 170° / 170° 170° / 170°
Response Time 5ms 5ms 5ms 5ms
Video Inputs D-Sub / DVI-D D-Sub D-Sub, DVI-D ( DCP) D-Sub
PC Audio Out -- -- -- --
Power Consumption - On/ tandby 22W / Under 1W 23W / Under 1W 36W / Under 1W 36W / Under 1W
VE A™Mounting (Screw Spacing) 75mm x 75mm 75mm x 75mm 75mm x 75mm 75mm x 75mm
tand Tilt, Base Detachable (L1942SE&L1942TE) /
Tilt, Base Detachable, Swivel, Pivot, eight-Adjustable(L1942PE) Tilt Tilt, Base Detachable Tilt, Base Detachable
Features f-ENGINE Touch Screen, f-ENGINE, USB f-ENGINE, 4:3 in wide 4:3 in wide
Unit Dimensions et w/ tand (WxDx ) 16.0" x 7.3" x 16.5" (SE, TE)
16.0" x 9.5" x 16.6" (PE)
14.5" x 12.4" x 3.7" (17")
16.0" x 13.6" x 3.7" (19") 17.7" x 7.8" x 15.1" 17.7" x 7.2" x 14.8"
Unit Dimensions et w/o tand (WxDx ) 16.0" x 2.5" x 4.5" (SE, TE)
16.0" x 2.3" x 13.6" (PE)
14.5" x 12.4" x 2.4" (17")
16.0" x 13.6" x 2.4" (19") 17.7" x 2.5" x 11.8" 17.7" x 2.4" x 11.8"
Carton Dimensions (WxDx ) 18.2" x 15.5" x 4.5" (SE, TE)
19.7" x 15.6" x 8.8" (PE)
16.9" x 14.8" x 6.3" (17")
18.6" x 16.4" x 6.3" (19") 21.7" x 14.1" x 4.7" 20.1" x 5.5" x 14.8"
Weight (lbs.) w/stand | w/o stand | hipping 10.6 lbs | 8.2 lbs | 14.3 lbs (PE)
10.6 lbs | - | 14.3 lbs (SE)
8.6 lbs | - | 11.5 lbs (TE)
8.59 lbs. (17"), 10.36 lbs. (19") I 7.93 lbs. (17"), 9.70 lbs. (19") I
11.24 lbs. (17"), 12.34 lbs. (19") 9.0 lbs | 8.6 lbs | 11.0 lbs 7.1 lbs | 6.6 lbs | 11.0 lbs
afety UL(cUL), TUV-GS, SEMKO UL(cUL), TUV-GS, SEMKO UL(cUL), TUV-GS, SEMKO UL(cUL), TUV-GS, SEMKO (NEMKO)
EPEAT®Certification SILVER -- -- --
Environment -- Ro S Ro S Ro S
EMC FCC-B, CE FCC-B, CE FCC-B, CE FCC-B, CE
Power aving tandard ENERGY STAR®5.0 -- -- ENERGY STAR®5.0
Limited Warranty 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight)
UPC 7 19192 18638 5 (SE) 7 19192 90017 2 (TE)
7 19192 90016 5 (PE)
7 19192 18833 4 (T1710B)
7 19192 18834 1 (T1910B) 7 19192 18457 2 7 19192 18419 0
LCD Desktop Monitors & Network Monitors
LG Electronics U.S.A., Inc.
Commercial Displays
2000 Millbrook Drive
Lincolnshire, IL 60069
LC_LCDSmScrn_031130_PR
Contact your LG Regional ales Representative:
Vertical Markets: 800.897.8788
Channel: 800.897.8871
Hospitality: 800.228.1236
E-mail: [email protected]om
Customer ervice: 888.865.3026
www.LGsolutions.com/support www.LGsolutions.com
Dimensions and weights are approximate. Design, specifications, and features subject to change without notice.
© Copyright 2011 LG Electronics USA, Inc. All Rights Reserved. "LG Life's Good" is a registered trademark of LG Corp. f-Engine is a registered trademark of LG Electronics
USA, Inc. Windows and Windows Vista are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. VESA is a
trademark of Video Electronics Standards Association. DMI, the DMI Logo and igh-Definition Multimedia Interface are trademarks or registered trademarks of DMI
Licensing LLC. ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. All other product and brand names are trademarks or registered
trademarks of their respective companies.
Printed in the USA. April 2011
