FLATRON L1715S
FLATRON L1715S
◗ Brilliant Active Matrix TFT Display
◗Auto-Synchronous Support from 640 x 350 up to 1280 x 1024 @ 75Hz
◗ Simple One Touch-Auto-Setup Function
◗LightView Function (Brightness Control)
◗VESA DDC2B, DDC1, Plug and Play Compatible
◗Universal 90-264 VAC Power
◗ EPA Energy Star and VESA DPMS Compliant
17" (17.0" VIS) ACTIVE MATRIX LCD COLOR MONITOR
TM
◗TCO'99 Low-Emission Compliant

FLATRON L1715S
FLATRON L1715S
FLATRON L1715S
563LE
BACK
LIVE: 1/2”From Trim
TRIM: 8 1/2”x 11”
BLEED: 1/8”All Around
(All Black)
17" (17.0" VIS) ACTIVE MATRIX LCD COLOR MONITOR
www.LGusa.com
The LG Flatron L1715S is the perfect general use space saving monitor with
the quality and reliability you expect from LG.With auto-synchronous support
from 640 x 350 up to 1280 x 1024 @ 75Hz and a brilliant active matrix TFT
display,viewing is a pleasure. Plus it is PC and MAC compatible, has
features like simple one button auto setup and is VESA DDC2B, DDC1,Plug
and Play compatible - all in a slim design.The FLATRON L1715S Active Matrix
LCD Color Monitor from LG.Simply Brilliant.
©2003 LG Electronics U.S.A., Inc. All trademarks are property of their respective owners. Design and specifications subject to change without notice. 9/03
LG ELECTRONICS U.S.A., INC.
HEADQUARTERS
1000 Sylvan Avenue, Englewood Cliffs, NJ 07632 ◗Tel: [phone], Fax: [phone] ◗ www.LGusa.com
Saved: 02/21/2002 01:04 PM
Printed: 02/21/2002 01:05 PM
Document Name: 563LE spec sheet
Fonts: HelveticaNeue LightCond, Eurostile BoldCondensed, Zapf Dingbats, BLI Frutiger BlackItalic, HelveticaNeue Condensed, Eurostile BoldExtendedTwo, HelveticaNeue BoldCond, BL Frutiger Black, R
Frutiger Roman, L Frutiger Light,BI Frutiger BoldItalic, UB Frutiger UltraBlack,Helvetica
Graphics: GRAY ISO 9001/EPS, Digitally,logo with icon#1/eps, LG Group/2000 CIP,3year quickswap logo.eps, tco B&W logo/eps,ES.clr B&W, red_bar.eps, LG Electronics, 563LE.eps, gold_bar.eps,
blue_bar.eps,Glowing Line (Sell Sheet)/EPS, BW_bar.eps, BW_bar.eps, Glowing Line (B&W)/EPS, 563LE greyscale.eps
Colors: Black, Red, Cyan, Magenta, Yellow
DISPLAY TYPE 17.0" (17.0" VIS) Active Matrix TFT Color LCD Screen
DISPLAY AREA 13.3" x 10.6" (338mm x 270mm)
DISPLAY COLORS More than 16.1 Million (6 Bit + FRC)
PIXEL PITCH 0.26mm x 0.26mm Pixel
PIXEL CONFIGURATION RGB Stripe Arrangement
SURFACE TREATMENT Hard Coating 3H,Anti-Glare
ELECTRONIC INTERFACE LVDS
BACKLIGHTING 4CCFL
MAXIMUM RESOLUTION 1280 x 1024
BRIGHTNESS 250cd/m2(Typical)
CONTRAST RATIO 450:1 (Typical)
RESPONSE TIME 16ms (Typical)
VIEWING ANGLE H: 160°,V:140°
HORIZONTAL SCANNING
FREQUENCIES 30-83kHz,Auto-Synchronous
VERTICAL SCANNING FREQUENCIES 56-75Hz,Auto-Synchronous
AUTO-SYNC SUPPORT640 x 350 up to 70Hz, 640 x 480 up to 70Hz, 720 x 400 up to 70Hz,
800 x 600 up to 75Hz, 832 x 624 up to 75Hz, 1024 x 768 up to 75Hz, 1280x1024 up to 75Hz
CONTROL TYPE On-Screen Display of Adjustments
INPUT SIGNAL RGB Analog
INPUT TERMINALS Standard VGA D-Sub 15-pin Connector
SYNC SIGNALING Separate H/V
MEMORY MODES 13 Factory Preset, 10 User-Settable
VESA PLUG AND PLAY LEVEL DDC2B, DDC1
DIGITAL ON-SCREEN CONTROLS Brightness, Contrast, Horizontal/Vertical Position, Clock, Phase (+/-), 5 Language Select, Image Size
Auto-Adjust, OSD Position, Color Temp (9300K, 6500K, User), Information, LightView
FRONT PANEL CONTROLS Power,Menu, Adjust (Up/Down/Left/Right), Auto-Set, LightView
POWER REQUIREMENTS 90-264 VAC, 50-60Hz
DPMS POWER CONSUMPTION On: 40 Watts, Standby: 3 Watts, DPMS Off: 3 Watts
TILT/SWIVEL Tilt: Down 0°/Up 25°
VESA MOUNTING COMPLIANCE Standard VESA Mounting, 100mm x 100mm Screw Spacing
DIMENSIONS WITH BASE (WxDxH) 15.2" x 6.0" x 14.7" (386mm x 152mm x 372mm)
WEIGHT 9.5 lbs (4.3 kg) Net; 12.6 lbs (5.7 kg) Shipping
SAFETY/REGULATORYTCO‘99, UL1950, FCC-B, EPA Energy Star,IEC950, CSA, CE,
TUV-GS, SEMKO, GOST,ISO 9241-3,7,8, C-TICK,VCCI-2
ACCESSORIES Power Cord, Signal Cable, Manual, Install Disk
LGEUS WARRANTY 3Year QuickSwap Replacement Program
UPC# 719192165892
EPA POLLUTION PREVENTER
T
H
R
E
E
Y
E
A
R
Q
U
I
C
K
S
W
A
P
R
E
P
L
A
C
E
M
E
N
T
P
R
O
G
R
A
M
SHIPPING DIMENSIONS (WxDxH) 17.1" x 6.6" x 18.7" (438mm x 167mm x 476mm)
