LG Flatron L1720B User manual












Model Description
MODEL BRAND
Printing Specification
1. Trim Size (Format) : 215mm x 280 mm
2. Printing Colors
•Cover : LG COLORS
•Inside : Black
3. Stock (Paper)
•Cover : Snow White 150 g/


•Inside : Snow White 100 g/


4. Printing Method :
5. Bindery : Saddle stitch
6. Language : English
7. Number of pages : 29 ( Including blank 3page)
Part No.
1.
2.
Service Guide Specification
Service Guide Specification
Changes
4.
REV.
NO. MM/DD/YY 

 CHANGE NO. CHANGE CONTENTS
1
2
3
4
5
7
6
SUFFIX






L1720BM
ALUSR
LG






(1) Origin Notification
* LGEDI : Printed in Indonesia * LGEWA : Printed in U.K.
* LGESP : Printed in Brazil * LGEMX : Printed in Mexico
* LGENT : Printed in China * LGEIL : Printed in India
8
Special Instructions3.
Product Name FLATRON L1720B 3828TSL084G

Pagination sheet
Pagination sheet 




 
Cover Front cover
Inside
Contents
2
English
3
English
4
English
5
English
….
English
…..
Rear
Cover
English
22
English
23
English
24 (blank)
Rear cover
Inside
(blank)
(blank)

COLOR MONITOR
SERVICE MANUAL
Website:http://biz.LGservice.com
E-mail:http://www.LGEservice.com/techsup.html
CAUTION
BEFORE SERVICING THE UNIT,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
CHASSIS NO. : CL-61
MODEL: L1720B (L1720BM-AL**R)
( ) **Same model for Service
*Same looking with new chassis.
Issue Date; 2004.1

1. LCD CHARACTERISTICS
Type : TFT SXGA LCD
Size : 17 inch
Pixel Pitch : 0.264 (H) x 0.264 (V)
Color Depth : 16.2M colors
Electrical Interface : LVDS
Surface Treatment : Hard-coating(3H), Anti-Glare
Operating Mode : Normally White
, Transmissive mode
Backlight Unit : Top/Bottom edge side 4-CCFL
(Cold Cathode Fluorescent Lamp)
2. OPTICAL CHARACTERISTICS
2-1. Viewing Angle by Contrast Ratio
≥ 10
Left : -60° min., -70°(Typ) Right : +60° min., +70°(Typ)
Top :+45° min., +60°(Typ) Bottom : -45°min., -60°(Typ)
2-2. Luminance : 200(min), 250(Typ)
2-3. Contrast Ratio : 300(min), 450(Typ)
3. SIGNAL (Refer to the Timing Chart)
3-1. Sync Signal
• Type : Separate Sync,
SOG (Sync On Green)
Composite Sync
3-2. Video Input Signal
1) Type : R, G, B Analog
2) Voltage Level : 0~0.71 V
a) Color 0, 0 : 0 Vp-p
b) Color 7, 0 : 0.467 Vp-p
c) Color 15, 0 : 0.714 Vp-p
3) Input Impedance : 75 Ω
3-3. Operating Frequency
Horizontal : 30 ~ 83kHz
Vertical : 56 ~ 75Hz
4
. Max. Resolution
Analog : 1280 x 1024 / 75Hz
5. POWER SUPPLY
5-1. Power
: AC 100-240V~, 50/60Hz , 1.0A
5-2. Power Consumption
6. ENVIRONMENT
6-1. Operating Temperature: 10°C~35°C (50°F~95°F)
(Ambient)
6-2. Relative Humidity : 10%~80%
(Non-condensing)
6-3. MTBF : 50,000 Hours(Min)
7. DIMENSIONS (with TILT/SWIVEL)
FullUp Position
Width : 394 mm (15.51'')
Depth : 232 mm (9.13'')
Height : 379 mm (14.92'')
Folded Position
Width : 394mm (15.51'')
Depth : 127mm (9.13'')
Height : 412mm (14.92'')
8. WEIGHT (with TILT/SWIVEL)
Net. Weight : 4.5 kg (9.92 lbs)
Gross Weight : 7.6 kg (16.76 lbs)
CONTENTS
SPECIFICATIONS
- 2 -
SPECIFICATIONS ................................................... 2
PRECAUTIONS ....................................................... 3
TIMING CHART ....................................................... 4
OPERATING INSTRUCTIONS ................................ 5
WIRING DIAGRAM ................................................. 6
BLOCK DIAGRAM ................................................... 7
DESCRIPTION OF BLOCK DIAGRAM.....................8
ADJUSTMENT ...................................................... 10
TROUBLESHOOTING GUIDE .............................. 12
EXPLODED VIEW...................................................16
REPLACEMENT PARTS LIST ...............................18
PIN CONFIGURAION..............................................20
SCHEMATIC DIAGRAM......................................... 21
MODE
POWER ON (NORMAL)
STAND-BY
SUSPEND
DPMS OFF
H/V SYNC
ON/ON
OFF/ON
ON/OFF
OFF/OFF
POWER CONSUMPTION
less than 43 W
less than 1 W
less than 1 W
less than 1 W
LED COLOR
BLUE
AMBER
AMBER
AMBER
VIDEO
ACTIVE
OFF
OFF
OFF

- 3 -
WARNING FOR THE SAFETY-RELATED COMPONENT.
• There are some special components used in LCD
monitor that are important for safety. These parts are
marked on the schematic diagram and the
replacement parts list. It is essential that these critical
parts should be replaced with the manufacturer’s
specified parts to prevent electric shock, fire or other
hazard.
• Do not modify original design without obtaining written
permission from manufacturer or you will void the
original parts and labor guarantee.
TAKE CARE DURING HANDLING THE LCD MODULE
WITH BACKLIGHT UNIT.
• Must mount the module using mounting holes arranged
in four corners.
• Do not press on the panel, edge of the frame strongly
or electric shock as this will result in damage to the
screen.
• Do not scratch or press on the panel with any sharp
objects, such as pencil or pen as this may result in
damage to the panel.
• Protect the module from the ESD as it may damage the
electronic circuit (C-MOS).
• Make certain that treatment person’s body are
grounded through wrist band.
• Do not leave the module in high temperature and in
areas of high humidity for a long time.
• The module not be exposed to the direct sunlight.
• Avoid contact with water as it may a short circuit within
the module.
• If the surface of panel become dirty, please wipe it off
with a softmaterial. (Cleaning with a dirty or rough cloth
may damage the panel.)
WARNING
BE CAREFUL ELECTRIC SHOCK !
• If you want to replace with the new backlight (CCFL) or
inverter circuit, must disconnect the AC adapter
because high voltage appears at inverter circuit about
650Vrms.
• Handle with care wires or connectors of the inverter
circuit. If the wires are pressed cause short and may
burn or take fire.
PRECAUTION
CAUTION
Please use only a plastic screwdriver to protect yourself
from shock hazard during service operation.

TIMING CHART
- 4 -
VIDEO
SYNC
B
D
CFE
A
<< Dot Clock (MHz), Horizontal Frequency (kHz), Vertical Frequency (Hz), Horizontal etc... (µs), Vertical etc... (ms) >>
H + 31.469 800 640 16 96 48
V–70.8Hz 449 350 37 2 60
H–31.469 840 640 16 96 48
V–59.94 525 480 10 2 33
H–37.5 840 640 16 64 120
V–75 500 480 1 3 16
H–31.468 900 720 18 108 54
V + 70.09 449 400 12 2 35
H + 37.879 1056 800 40 128 88
V + 60.317 628 600 1 4 23
H + 46.875 1056 800 16 80 160
V + 75.0 625 600 1 3 21
H+/–49.725 1152 832 32 64 224
V+/–74.55 667 624 1 3 39
H–48.363 1344 1024 24 136 160
V–60.0 806 768 3 6 29
H–60.123 1312 1024 16 96 176
V–75.029 800 768 1 3 28
H+/–68.681 1456 1152 32 128 144
V+/–75.062 915 870 3 3 39
H+/–61.805 1504 1152 18 134 200
V+/–65.96 937 900 2 4 31
H + 63.981 1688 1280 48 112 248
V + 60.02 1066 1024 1 3 38
H + 79.976 1688 1280 16 144 248
V + 75.035 1066 1024 1 3 38
Mode H/V
Sort
1
2
3
4
5
6
7
8
9
10
11
12
13
25.175
28.321
25.175
31.5
40.0
49.5
57.283
65.0
78.75
100.0
92.978
108.0
135.0
640x350
70Hz
640x480
60Hz
640x480
75Hz
720x400
70Hz
800x600
60Hz
800x600
75Hz
832x624
75Hz
1024x768
60Hz
1024x768
75Hz
1152x870
75Hz
1152x900
65Hz
1280x1024
60Hz
1280x1024
75Hz
Sync
Polarity Frequency
Dot
Clock Total Period
(E)
Video Active Time
(A)
Sync Duration
(D)
Back Porch
(F)
Front Porch
(C)
Resolution

- 5 -
OPERATING INSTRUCTIONS
FRONT VIEW REAR VIEW
Front Control Panel
1. Power Button
Use this button to turn the display on or off.
<Power (DPMS) Indicator>
This Indicator lights up blue when the display
operates normally. If the display is in DPM (Energy
Saving) mode, this indicator color changes to
amber.
2. Button
Use these buttons to choose or adjust items in the
On Screen Display.
3. Menu Button
Use this button to enter or exit the On Screen
Display.
4.
AUTO/SELECT Button
Use this button to enter a selection in the On
Screen Display.
When adjusting your display settings, always
press the AUTO/SELECT button before entering
the On Screen Display(OSD). This will
automatically adjust your display image to the
ideal settings for the current screen resolution
size (display mode).
The best display mode is 1024x768/60Hz.
See front control panel
D-sub Connect
Power Connect
143 2
This feature lets you easily select the best desired image
condition optimized to the environment (ambient
illumination, image types etc.).
•DAY : Bright ambient illumination
•NIGHT : Dark ambient illumination
•TEXT : For text images (Word processing etc.)
•MOVIE : For animation images in videos or movies
•PHOTO : For pictures or drawings
•USER MODE : For use under user setup image
conditions (Brightness, contrast and color tint are
selected by the user in OSD Screen Setup Menu.)
100
100
Bring up Contrast and Brightness adjustment.
:

- 6 -
WIRING DIAGRAM
J707
J702
CN1
CN2
CN4 CN5
CN3
Connector Ass’y :
P/N: 6631T11016C
Connector Ass’y :
P/N: 6631T20024C
Connector Ass’y :
P/N: 6631T20008G
Connector Ass’y :
P/N: 6631T20023A

- 7 -
D-SUB
MST9111B
including
(ADC/LVDS/SCALER )
MTV312
Micom
LCD Module
R,G,B
differential
LL
LLVV
VVDD
DDSS
SS
((
((LL
LLoo
ooww
ww VV
VVoo
oollllttttaa
aagg
ggee
ee
DD
DDiiiiffffffffee
eerr
rree
eenn
nnttttiiiiaa
aallll SS
SSiiiigg
ggnn
nnaa
aalllliiiinn
nngg
gg))
))
LIPS
5V
5V
AC Input
3.3V
Reg. Diode
KDS184
5V 3.3V
12V
R,G,B, H/V Sync
3.3V 2.5V
3.3V 2.5V
BLOCK DIAGRAM

- 8 -
DESCRIPTION OF BLOCK DIAGRAM
1. Video Controller Part.
This part amplifies the level of video signal for the digital conversion and converts from the analog video signal to the
digital video signal using a pixel clock.
The pixel clock for each mode is generated by the PLL.
The range of the pixel clock is from 25MHz to 135MHz.
This part consists of the Scaler, ADC, LVDS transmitter.
The Scaler gets the video signal converted analog to digital, interpolates input to 1280 X 1024 resolution signal and
outputs 8-bit R, G, B signal to transmitter.
2. Power Part.
This part consists of the one 3.3V regulator, and two 2.5V drop diodes to convert power which is provided 12V, 5V in
Power board.
5V is provided for LCD panel and Micom.
Also, 5V is converted 3.3V by regulator and 3.3V is converted 2.5V by drop diode.
Converted power is provided for IC in the main board.
3. MICOM Part.
This part consists of EEPROM IC which stores control data, Reset IC and the Micom.
The Micom distinguishes polarity and frequency of the H/V sync are supplied from signal cable.
The controlled data of each modes is stored in EEPROM.

- 9 -
EMI
COMPONENTS
LINE
100 ~ 240V
INPUT RECTIFIER
AND FILTER ENERGY TRANSFER OUTPUT RECTIFIER AND FILTER
12V
5V
GND
SIGNAL
COLLECTI
ON
PHOTO-
COUPLER
ISOLATION
PWM
CONTROL
CIRCUIT
HVDC 100KHz
PRIMARY SECONDARY
50 ~ 60Hz
Operation description_LIPS
LIPS Board Block Diagram
1. EMI components.
This part contains of EMI components to comply with global marketing EMI standards like FCC, VCCI CISPR, the
circuit included a line-filter, across line capacitor and of course the primary protection fuse.
2. Input rectifier and filter.
This part function is for transfer the input AC voltage to a DC voltage through a bridge rectifier and a bulk capacitor.
3. Energy Transfer.
This part function is transfer the primary energy to secondary through a power transformer.
4. Output rectifier and filter.
This part function is to make a pulse width modulation control and to provide the driver signal to power switch, to
adjust the duty cycle during different AC input and output loading condition to achive the dc output stablize, and also
the over power protection is also monitor by this part.
5. Photo-Coupler isolation.
This part function is to feed back the dc output changing status through a photo transistor to primary controller to
achieve the stabilized dc output voltage.
6. Signal collection.
This part function is to collect the any change from the dc output and feed back to the primary through photo
transistor.

- 10 -
ADJUSTMENT
Windows EDID V1.0 User Manual
Operating System: MS Windows 98, 2000, XP
Port Setup: Windows 98 => Don’t need setup
Windows 2000, XP => Need to Port Setup.
This program is available to LCD Monitor only.
1. Port Setup
a) Copy “UserPort.sys”file to
“c:\WINNT\system32\drivers”folder
b) Run Userport.exe
c) Remove all default number
d) Add 300-3FF
e) Click Start button.
f) Click Exit button.
2. EDID Read & Write
1) Run WinEDID.exe
2) Edit Week of Manufacture, Year of Manufacture,
Serial Number
a) Input User Info Data
b) Click “Update”button
c) Click “Write”button

- 11 -
220
IBM
Compatible PC
PARALLEL PORT
Power inlet (required)
Power LED
ST Switch
Power Select Switch
(110V/220V)
Control Line
Not used
RS232C
PARALLEL
V-SYNC POWER
ST
VGS MONITOR
E
E
V-Sync On/Off Switch
(Switch must be ON.)
F
F
A
A
B
B
C
C
1510
5
569
1
1
1
14
13
25
6
5V
5V
5V
4.7K
4.7K
4.7K
74LS06
74LS06
OFF ON
OFF
ON
11
Video Signal
Generator
Figure 1. Cable Connection
SERVICE OSD
1) Turn off the power switch at the front side of the display.
2) Wait for about 3 seconds and press MENU, POWER switch with 1 second interval.
3) The SVC OSD menu contains additional menus that the User OSD menu as described below.
a) MODULE : To select applied module.
b) NVRAM INIT : EEPROM initialize(24C08)
c) ADC OFFSET : The lowest value of input leves sets to digitally 0(zero).
d) ADC GAIN : The highest value of input levels sets to digitally 255.
e) ADC CAL : W/B balance sets the gain and offset value.
f) ELAPSED CLEAR : To initialize using time.

- 12 -
TROUBLESHOOTING GUIDE
1. NO POWER
NO POWER
(POWER INDICATOR OFF)
CHECK POWER
BOARD, AND FIND
OUT A SHORT POINT
AS OPENING
EACH POWER LINE
CHECK J705
VOLTAGE
PIN5, PIN6 (5V)?
NO
CHECK 5VS LINE
(OPEN CHECK)
CHECK
U501 PIN 8 Voltage
(5V) ?
NO
NO
NO
CHECK U201 PIN 122
PULSE
CHECK U201
CHECK 3.3V LINE
CHECK X-TAL
IS U201
PIN114 (3.3V)
VOLTAGE ?
YES
YES NO PROBLEM
YES
CHECK KEY CONTROL
CONNECTOR ROUTINE
YES

- 13 -
2. NO RASTER (OSD IS NOT DISPLAYED) –LIPS
CHECK MICOM INV
ON/OFF PORT.
J705 PIN9
5V? NO
NO RASTER
(OSD IS NOT DISPLAYED)
CHECK LIPS
J705
PIN5, PIN6
5V?
NO
1. CONFIRM BRIGHTNESS
OSD CONTRL STATE.
2. CHECK MICOM DIM-ADJ
PORT
J705 PIN10
5V? NO
LIPS
CHECK
PULSE AS
CONTACTING SCOPE
PROBE TO CAUTION LABEL.
(CONTACT PROBE TO
CAUTION LABEL.
CAN YOU SEE PULSE
AT YOUR
SCOPE?
NO
REPLACE CCFL LAMP
IN THE LCD MODULE
YES
YES
YES
YES

- 14 -
1. CHECK PIN122, 123
SOLDERING CONDITION
2. CHECK X501
3. TROUBLE IN U201
U201
POWER PIN 8,114
3.3V?
NO CHECK U801
U201
PIN122, 123
OSCILLATE AS
12MHZ?
CHECK CONNECTION LINE
FROM D-SUB TO U501
TROUBLE IN CABLE
OR LCD MODULE
YES
YES
YES
3. NO RASTER (OSD IS NOT DISPLAYED) –MST9111B
NO RASTER
(OSD IS NOT DISPLAYED)
U501
PIN43 IS 64KHz H-SYNC?
PIN44 IS 60Hz V-SYNC?
IS PULSE APPEARED
AT SIGNAL PINS?
AT MODE 12?
NO
NO

- 15 -
4. TROUBLE IN DPM
TROUBLE IN DPM
TROUBLE IN U501
CHECK PC
PC IS NOT GOING
INTO DPM OFF MODE
NO
CHECK H/V SYNC
LINE
NO
YES
YES
CHECK
R773, R775
(SYNC) ?
CHECK
U501 PIN 43.44
SYNC PULSE ?

- 16 -
EXPLODED VIEW
4
1
2
3
12
10
11
13
5
6
8
9
7

- 17 -
EXPLODED VIEW PARTS LIST
Ref. No.
1
2
3
4
5
6
7
8
9
10
11
12
13
Part No.
3091TKL086A
6304FLP086A
6304FLP085A
6304FLP082A
6304FLP076A
6304FLP058A
3809TKL059A
3043TKK134E
6871TST430A
4951TKS111E
6631T11012W
6871TPT271C
3313TL7038A
4951TKK139A
3550TKK398A
3550TKK400A
6850TD9004M
Description
CABINET ASSEMBLY, L1720 BRAND . .
LCD(LIQUID CRYSTAL DISPLAY), LM170E01-A5K6 LG PHILPS TFT COLOR LVDS SXGA OKI GATE D-IC
LCD(LIQUID CRYSTAL DISPLAY), LM170E01-A4K4 LG PHILPS TFT COLOR SXGA LVDS OKI GATE D-IC
LCD(LIQUID CRYSTAL DISPLAY), LM170E01-A5M1 LG PHILPS TFT COLOR SXGA LVDS PEM-NUT
LCD(LIQUID CRYSTAL DISPLAY), LM170E01-A5 LG PHILPS TFT COLOR LVDS SXGA
LCD(LIQUID CRYSTAL DISPLAY), LM170E01-A4 LG PHILPS TFT COLOR 17" TFT LCD
BACK COVER ASSEMBLY, L1720 . SILVER SPRAY
TILT SWIVEL ASSEMBLY, L1720B/PL M/BASE-SPRAY_NEW SCREW/RUBBER
PWB(PCB) ASSEMBLY,SUB, L1720BL CONTROL TOTAL BRAND CL-43
METAL ASSEMBLY, FRAME MAIN L1720BM LPL
CONNECTOR ASSEMBLY, 30P H-H 200MM UL20276 LG708G
PWB(PCB) ASSEMBLY, POWER, 19"+17" M-CHASSIS POWER TOTAL LIEN CHANG "INTEGRATED LIPS" FOR DOCKING TYPE
MAIN TOTAL ASSEMBLY, L1720BM BRAND CL-61
METAL ASSEMBLY, REAR L1720BL
COVER, L1720 BACK CAP
COVER, L1720BL HINGE CAP
CABLE, D-SUB, UL2990-9C(5.8MM) DT 1500MM GRAY 20 MODEL DM

- 18 -
DATE: 2004. 1. 9.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C204 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C205 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C206 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C207 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C208 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C209 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C210 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C211 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C214 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C215 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C216 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C217 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C218 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C219 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C220 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C221 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C222 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C223 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C225 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C226 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C227 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C230 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C231 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C232 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C233 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C240 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C251 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C501 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C502 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C503 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C504 0CH8106F611 10UF 16V M 85STD(CYL) R/TP
C506 0CC030CK01A 3PF 1608 50V 0.25 PF R/TP NP
C507 0CC180CK41A 18PF 1608 50V 5% R/TP NP0
C508 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C701 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C703 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C708 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C709 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C710 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C711 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C717 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C718 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C719 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
C720 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C721 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
C727 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C732 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C733 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C734 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C735 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C760 0CE107EF610 100UF KMG,RD 16V 20% FL BULK
C801 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
DATE: 2003. 1. 9.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C803 0CE107EF610 100UF KMG,RD 16V 20% FL BULK
C804 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C805 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C806 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C807 0CE107EF610 100UF KMG,RD 16V 20% FL BULK
C808 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C809 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C810 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C812 0CE107EF610 100UF KMG,RD 16V 20% FL BULK
C814 0CE107EF610 100UF KMG,RD 16V 20% FL BULK
C815 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C816 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
D701 0DS226009AA KDS226 TP KEC SOT-23 80V 30
D702 0DS226009AA KDS226 TP KEC SOT-23 80V 30
D706 0DS226009AA KDS226 TP KEC SOT-23 80V 30
D804 0DD184009AA KDS184 TP KEC - 85V - - - 30
D805 0DD184009AA KDS184 TP KEC - 85V - - - 30
ZD701 0DZ560009GB BZT52C5V6S DIODES R/TP SOD32
ZD702 0DZ560009GB BZT52C5V6S DIODES R/TP SOD32
ZD703 0DZ560009GB BZT52C5V6S DIODES R/TP SOD32
ZD704 0DZ560009GB BZT52C5V6S DIODES R/TP SOD32
ZD705 0DZ560009GB BZT52C5V6S DIODES R/TP SOD32
ZD711 0DZ560009GB BZT52C5V6S DIODES R/TP SOD32
U201 0IPRPM3008B MST9111B(ANALOG) MSTAR 128P,
U501 0IZZTSZ355A MTV312MV64 MYSON 44P , PLCC
U502 0ISG240860B M24C08W6 SGS-THOMSON 8SOP R/
U801 0IPMGKE011A KIA78D33F KEC DPAK R/TP 3.3V
Q502 0IKE704200H KIA7042AP TO-92 TP 4.2 VOLT
Q503 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q504 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q505 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q703 0TR390609FA KST3906-MTF TP SAMSUNG SOT2
Q704 0TR390609FA KST3906-MTF TP SAMSUNG SOT2
Q706 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q707 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q801 0TR127309AA KTA1273-Y(KTA966A) TP KEC TO
Q802 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
R201 0RJ0682D677 68 OHM 1/10 W 5% 1608 R/TP
R202 0RJ0682D677 68 OHM 1/10 W 5% 1608 R/TP
R203 0RJ0682D677 68 OHM 1/10 W 5% 1608 R/TP
R207 0RJ3900D677 390 OHM 1/10 W 5% 1608 R/TP
R208 0RJ0682D677 68 OHM 1/10 W 5% 1608 R/TP
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
MAIN BOARD
CAPACITORS
DIODEs
ICs
TRANSISTOR
RESISTORs
