LG Flatron L1720PQ User manual

L1720PQ
17” Active-Matrix LCD Monitor
Sleek Modern Design
L1720PQ
PRODUCT INFORMATION
Digital input, wide viewing angle technology and an incredibly sharp picture make
the L1720PQ LCD monitor a solid choice. Its design is based on the award-winning
L2320A LCD monitor, offering a sleek footprint and finished back, that’s sure to be
a perfect fit for any sized home or office.
KEY FEATURES
• Sleek, Stylish, Space-Saving Design
• Digital (DVI-D) and Analog Inputs
• Glossy Silver / Tiltable Base
• Built-in USB Hub (1 Up / 2 Down)
• Ultra Fast 8ms Response Time
• 700 : 1 Contrast Ratio
• 170 / 170 Degree Viewing Angle
BUILT IN
TV
TUNER
BUILT-IN
SPEAKERS
S-VIDEO
INPUT

L1720PQ
17” Active-Matrix TFT-LCD Monitor
RETAIL PACKAGING INCLUDES:
(1) Power Cord
(1) Signal Cable (15-Pin D-SUB)
(1) Stereo Cable (Audio)
(1) Main Remote Control
(2) AAA battery
(1) Install Disk
(1) Manual Book
(1) Manual Paper
(1) Warranty Card
FRONT REAR
PLUG AND PLAY!
•Watch your favorite DVD Movies!
•Watch your favorite TV Shows!
•Connect to your Digital Camcorder or Digital Camera!
•Connect to your favorite Game Consoles!
SIDE
• For More Information, please visit www.LGUSA.com
• Phone: [phone]
Type: 32.0” (32.0” VIS) WXGA Active Matrix TFT Screen
Size: 27.47” (698mm) horizontal x 15.44” (393mm) vertical
Colors: 16.7 Million (8-bit)
Pixel Pitch: 0.170mm x 0.511mm
Maximum Resolution: 1366 x 768
Brightness: 500 cd/m
2
Contrast Ratio: 1000 : 1 (AI) 500 : 1 (Typical)
Response Time: 8ms (GTG)
Horizontal Viewing Angle: 178 degrees
Vertical Viewing Angle: 178 degrees
Interface: LVDS
Surface Treatment: Anti-glare, Hard coating (3H)
PC Input: (1) 15 Pin D-SUB, (1) DVI-D, (1) PC Audio In
TV Tuner: (1) Built-In
Video Input: (1) Composite, (1) S-Video, (2) Component Video
Audio Input: (1) Standard A/V (Left & Right)
Audio Output: (1) Headphone Output
RS-232C Control: (1) 9-Pin D-SUB
Monitor Communications: DDC 2B
Power Voltage: AC 90~264 V (47~63Hz, auto-switch)
Type: Built in Power
Switch Type: Touch Sense Type
Normal Usage: 160W
Stand-by Usage: Under 5W
31.3W) X 19.4(H) X 3.9(D) in / Set(w/o stand) (803x493x100mm)
31.3(W) X 21.3(H) X 4.1(D) in / Set(w/stand) (803x540x104mm)
38.0(W) X 21.3(H) X 4.1(D) in / Set(w/stand, speakers)
(964x540x104mm)
36.1(W) X 27.7(H) X 13.1(D) in / Box (917x704x332mm)
42.5 lb (19.3kg) (Set, w/o speakers)
57.3 lb (26.0kg) (Shipping Weight)
Cableless, Detachable Side Speakers (1 Pair)
10W x 2 (Output)
Power, Source, Menu, Adjust (Left/Right/Up/Down),
Auto/Select
Advanced PIP, Image Zoom Function, RS-232C Control Jack,
SRS WOW Audio Enhancement Technology, Discrete IR
Codes, Matching Speakers, Anti-Theft Lock Port
UL, FCC(ClassB), EPA Energy Star, CE, SEMKO, CSA, VCCI-2,
CCC, GOST, TUV-GS
(1) Remote Control, (1) Power Cord, (1) A/V Cable, (1) 15-Pin
D-SUB Cable, (1) PC Audio Cable, (1) DVI-D Cable, (1) 19-Pin
Cable, (1) S-VHS Cable, (2) AAA Batteries, User’s Manual
Standard VESA Mounting, 200mm x 200mm Screw Spacing
719192178854
719192179714
DISPLAY
USER INTERFACE
POWER
MECHANICAL
(WxHxD)
Weight
SPEAKER
SPECIAL FUNCTIONS
SAFETY/ REGULATORY
ACCESSORIES
VESA MOUNTING
UPC#
L C D
M o n i t o r s
O p t i c a l
D r i v e s
M e m o r y
P r o d u c t s
L G I T P r o d u c t s w w w . L G u s a . c o m
DISPLAY
SYNC & VIDEO
USER INTERFACE
POWER
Type: 17.0” (17.0” VIS) Active Matrix TFT Screen
Size: 13.3” (338mm) horizontal x 10.6” (270mm) vertical
Colors: 16.8 Million (8-bit)
Pixel Pitch: 0.264mm x 0.264mm
Maximum Resolution: 1280 x 1024
Brightness: 300 cd/m
2
Contrast Ratio: 700 : 1
Response Time: 8ms
Horizontal Viewing Angle: 170 degrees
Vertical Viewing Angle: 170 degrees
MTBF: 50,000
Interface: LVDS
Surface Treatment: Anti-glare, Hard coating (3H)
Horizontal : 30 ~ 83 kHz
Vertical : 56 ~ 75 kHz
Sync Compatibility : Separate, Composite, SOG, Digital
PC Input: (1) 15 Pin D-SUB, (1) DVI-D
USB: (1) Upstream, (2) Downstream
Monitor Communications: DDC 2B
Power Voltage: AC 90~264 V (47~63Hz, auto-switch)
Type: LIPS (LCD Integrated Power Supply, Adapter +
Inverter)
Switch Type: Tact Type
Normal Usage: 40W
Stand-by Usage: Under 1W
MECHANICAL (WxHxD)
WEIGHT
STAND
CERTIFICATIONS Safety
EMC
Low radiation
Ergonomics
Power saving
ACCESSORIES
UPC#
15.5(W) X 14.9(H) X 5.0(D) in / Set (394x379x232mm)
17.9(W) X 18.7(H) X 7.5(D) in / Box (456x475x191mm)
VESA Compliant Wall-Mount
10.8 lb (4.9kg) / 14.3 lb (6.5kg) (Set/Box)
Built In
Tilt 25 Degree (Up)
UL, TUV-GS, SEMCO
FCC-B, CE
TCO-99
ISO 13406-2
EPA Energy Star
(1)Power Cord, (1)Signal Cable (D-Sub), (1)DVI-D Cable,
(1)Manual Book, (1)Manual paper, (1)warranty card,
(1)Install disk
719192181397
SPECIFICATIONS
CONTACT US
www.LGusa.com
VIEWS
VIEWS
FRONT BACK SIDE POWER BUTTON
• The L1720PQ LCD Monitor Comes with LG’s 3 Year QuickSwap Warranty
• 3 Years Parts, Labor and Backlight
• LG Pays Shipping Both Ways
• 48 Hour Swap Program
• Call Toll-Free 1-800-243-000 (24 Hours 7 Days a Week)
WARRANTY
