LG Flatron L1942P User manual

Model W2600V-PF W2442PA-BF L206WU-PF (USB Monitor)
LCD Size / viewable 26" Class (25.5" Diagonal) 24" Class (24.0" Diagonal) 20" Class (20.1" Diagonal)
Pixel Pitch 0.2865mm
0.277mm 0.258mm
Screen Aspect Ratio 16:10
16:9 16:10
Native Resolution 1920 x 1200
1920 x 1080 1680 x 1050
Auto H/V Frequency 30~83kHz / 56~75Hz
30
~
83kHz, 56
~
75Hz 30~83kHz / 56~75Hz
Brightness 300 cd/m² 300 cd/m² 300 cd/m²
Contrast Ratio (typical) DFC 5,000:1
DFC 10,000:1 DFC 5,000:1
Viewing Angle (H/V) 170° / 160°
170˚/160˚ 170° / 170°
Response ime ( ypical) 5ms
5ms (2ms G to G) 2ms GTG
Video Inputs DSUB / DVI / HDMI™D-Sub / DV -D (HDCP) / HDM ™ D-Sub / DV -D (HDCP) / HDM ™ D-Sub / DV -D (HDCP)
USB 2.0 Hub 1 up / 4 down -- 1 up / 2 down (Video only)
PC Audio In -- Yes --
Headphone Out Yes Yes --
Power Consumption - On/Standby 50W / 1W 42W / under 1W 45W / 2W
VESA™Mounting (Screw Spacing) 100mm x 100mm 100mm x 100mm 100mm x 100mm
Stand Tilt, Swivel, Height Adjust, Base Detachable Tilt, Swivel, Height Adjust., Pivot, Base Detachable Tilt, Swivel, Height Adjust., Pivot, Base Detachable
Features ntelligent Auto (Auto Resolution), f-ENG NE™, P P, Forte Manager, ez
Zooming ntelligent Auto (Auto Resolution), f-ENG NE™, 4:3 in Wide, Forte Pivot, Windows Vista™Certified
ntelligent Auto (Auto Resolution), f-ENG NE™,
MultiLink:Connect up to six USB Monitors,
4:3 in Wide, Windows Vista™Certified
Set w/ Stand (WxDxH) 23.7" x 10.6" x 18.2" (min H) 22.2” (max H)
23.0" x 10.6" x 17.2" 18.5" x 10.7" x 16.5" (min H) 22.0” (max H)
Set w/o Stand (WxDxH) 23.7" x 3.2" x 16.3"
23.0" x 2.4" x 14.0" 18.5" x 2.4" x 12.4"
Shipping Dimension 27.1" x 10.9" x 21.1"
25.4" x 8.7" x 16.1" 21.9" x 14.9" x 9.6"
Weight (lbs.) w/stand | w/o stand | Shipping 23.1 lbs | 17.0 lbs | 29.1 lbs 13.67 lbs | 10.36 lbs | 17.86 lbs 13.2 lbs | 9.7 lbs | 16.1 lbs
Hazardous Substances Standard --
RoHS
--
Emission Standard -- -- --
Power Saving Standard EPA ENERGY STAR®EPA ENERGY STAR®--
Limited Warranty 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight) -3 Years (Parts, Labor, Backlight)
UPC 7 19192 18508 1
7 19192 18527 2
7 19192 18469 5
Model W2242P-BS W2042 Q-BF W1942 Q-BF W1934S-BN
LCD Size / viewable 22" Class (22.0" Diagonal) 20" Class (20.1" Diagonal) 19" Class (18.9" Diagonal) 19" Class (18.9" Diagonal)
Pixel Pitch 0.282mm 0.258mm 0.285mm 0.285mm
Screen Aspect Ratio 16:10 16:10 16:10 16:10
Native Resolution 1680 x 1050 1680 x 1050 1440 x 900 1440 x 900
Auto H/V Frequency 30~83kHz / 56~75Hz 30~83kHz / 56~75Hz 30~83kHz / 56~75Hz 30~83Hz / 56~75Hz
Brightness 300 cd/m² 300 cd/m² 300 cd/m² 300 cd/m²
Contrast Ratio (typical) DFC 8,000:1 DFC 8,000:1 DFC 8,000:1 1,000:1
Viewing Angle (H/V) 176° / 170° 170° / 170° 170° / 170° 170° / 170°
Response ime (typical) 5ms 5ms 5ms 5ms
Video Inputs DSUB / DVI / HDMI™D-Sub / DV -D (HDCP) D-Sub / DV -D (HDCP) D-Sub / DV -D (HDCP) D-Sub
USB 2.0 Hub -- -- -- --
PC Audio In -- -- -- --
Power Consumption - On/Standby 40W / 1W 40W / 1W 36W / 1W 36W / 1W
VESA™Mounting (Screw Spacing) 75mm x 75mm 75mm x 75mm 75mm x 75mm 75mm x 75mm
Stand Tilt, Height Adjust., Pivot,
Base Detachable Tilt, Base Detachable Tilt, Base Detachable Tilt, Base Detachable
Features ntelligent Auto (Auto Resolution),
f-ENG NE™, 4:3 in Wide, Forte Pivot ntelligent Auto (Auto Resolution), f-ENG NE™,
4:3 in Wide, Windows Vista™Certified ntelligent Auto (Auto Resolution), f-ENG NE™,
4:3 in Wide, Windows Vista™Certified ntelligent Auto (Auto Resolution), 4:3 in Wide
Set w/ Stand (WxDxH) 20.3" x 8.2" x 16.7" (min H) 21.0” (max H) 18.7" x 7.8" x 15.4" 17.7" x 7.8" x 15.1" 17.7" x 7.2" x 14.8"
Set w/o Stand (WxDxH) 20.3" x 2.3" x 13.6" 18.7" x 2.5" x 12.6" 17.7" x 2.5" x 11.8" 17.7" x 2.4" x 11.8"
Shipping Dimension 22.4" x 16.0" x 8.7" 21.1" x 14.8" x 4.9" 21.7" x 14.1" x 4.7" 20.1" x 5.5" x 14.8"
Weight (lbs.) w/stand | w/o stand | Shipping 11.8 lbs | 9.3 lbs | 15.4 lbs 9.9 lbs | 9.5 lbs | 11.6 lbs 9.0 lbs | 8.6 lbs | 10.7 lbs 7.1 lbs | 6.6 lbs | 10.6 lbs
Hazardous Substances Standard -- RoHS RoHS RoHS
Emission Standard TCO'03 TCO'03 TCO'03 TCO’03
Power Saving Standard EPA ENERGY STAR®EPA ENERGY STAR®EPA ENERGY STAR®EPA ENERGY STAR®
Limited Warranty 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight)
UPC 7 19192 18518 0 7 19192 18455 8 7 19192 18457 2 7 19192 18419 0
lcd
monitors
LCD Widescreen Desk Top Monitors
www.LGcommercial.com

LCD Desk Top Monitors
MODEL L2000CP-BF L1942P-BS L1942 -BF L1942S-BF
LCD Size / viewable 20" Class (20.0" Diagonal) 19" Class (18.9" Diagonal) 19" Class (18.9" Diagonal) 19" Class (18.9" Diagonal)
Pixel Pitch 0.255mm 0.294mm 0.294mm 0.294mm
Screen Aspect Ratio 4:3 5:4 5:4 5:4
Native Resolution 1600 x 1200 1280 x 1024 1280 x 1024 1280 x 1024
Auto H/V Frequency 30~83kHz / 56~85Hz 30~83kHz / 56~75Hz 30~83kHz / 56~75Hz 30~83kHz / 56~75Hz
Brightness 300 cd/m² 300 cd/m² 300 cd/m² 300 cd/m²
Contrast Ratio (typical) 800:1 DFC 8,000:1 DFC 8,000:1 DFC 8,000:1
Viewing Angle (H/V) 178° / 178° 176° / 170° 170° / 170° 170° / 170°
Response ime (typical) 8ms GTG 5ms 5ms 5ms
Video Inputs DSUB / DVI / HDMI™D-Sub / DV -D D-Sub / DV -D (HDCP) D-Sub / DV -D (HDCP) D-Sub
Power Consumption - On/Standby 58W / 1W 33W / 1W 33W / 1W 33W / 1W
VESA™Mounting (Screw Spacing) 100mm x 100mm 75mm x 75mm 75mm x 75mm 75mm x 75mm
Stand Tilt, Swivel, Height Adjust., Pivot,
Base Detachable Tilt, Swivel, Height Adjust., Pivot, Base Detachable Tilt, Base Detachable Tilt, Base Detachable
Features ntelligent Auto (Auto Resolution), f-ENG NE™, Ez Zooming ntelligent Auto (Auto Resolution), f-ENG NE™, Forte Pivot ntelligent Auto (Auto Resolution), f-ENG NE™ntelligent Auto (Auto Resolution), f-ENG NE™
Set w/ Stand (WxDxH) 17.6" x 9.6" x 17.6" (min H) 20.8" (max H) 16.0" x 9.5" x 16.6" (min H) 20.9” (max H) 16.0" x 7.3" x 16.5" 16.0" x 7.3" x 16.5"
Set w/o Stand (WxDxH) 17.6" x 2.8" x 13.6" 16.0" x 2.3" x 13.7" 16.0" x 2.5" x 13.6" 16.0" x 2.5" x 13.6"
Shipping Dimension 21.9" x 10.3" x 20.7" 19.7" x 15.6" x 8.8" 18.4" x 4.6" x 15.5" 18.4" x 4.6" x 15.5"
Weight (lbs.) w/stand | w/o stand | Shipping 16.8 lbs | 12.8 lbs | 20.9 lbs 9.5 lbs | 7.1 lbs | 13.7 lbs 7.5 lbs | 7.1 lbs | 10.4 lbs 7.5 lbs | 7.1 lbs | 10.4 lbs
Hazardous Substances Standard RoHS RoHS RoHS RoHS
Emission Standard TCO’03 TCO’03 TCO’03 TCO’03
Power Saving Standard EPA ENERGY STAR®EPA ENERGY STAR®EPA ENERGY STAR®EPA ENERGY STAR®
Limited Warranty 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight) 3 Years (Parts, Labor, Backlight)
UPC 7 19192 18427 5 7 19192 18516 6 7 19192 18491 6 7 19192 18472 5
LG Electronics U.S.A., nc.
Commercial Products Division
2000 Millbrook Drive
Lincolnshire, L 60069
LC_LCDSmScrn_020904_PR
Channel: 1.800.897.8871
Enterprise: 1.800.897.8788
Hospitality: 1.800.228.1236
Healthcare: 1.877.793.6484
Customer Service: 1.888.865.3026
E-mail: LGcommer[email protected] www.LGcommercial.com
Dimensions and weights are approximate. Design, specifications, and features subject to change without notice.
© Copyright 2009 LG Electronics USA, nc. All Rights Reserved. "LG Life's Good" is a registered trademark of LG Corp. f-Engine is a registered trademark of LG Electronics
USA, nc. Windows and Windows Vista are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. VESA is a
trademark of Video Electronics Standards Association. HDM , the HDM Logo and High-Definition Multimedia nterface are trademarks or registered trademarks of HDM
Licensing LLC. ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. All other product and brand names are trademarks or registered
trademarks of their respective companies.
Printed in the USA. February 2009
lcd
monitors
MODEL L1734S-BN
LCD Size / viewable 17" Class (17.0" Diagonal)
Pixel Pitch 0.264mm
Screen Aspect Ratio 5:4
Native Resolution 1280 x 1024
Auto H/V Frequency 30~83Hz / 56~75Hz
Brightness 300 cd/m²
Contrast Ratio (typical) 700:1
Viewing Angle (H/V) 160° / 160°
Response ime ( ypical) 5ms
Video Inputs DSUB / DVI / HDMI™D-Sub
Power Consumption - On/Standby 31W / 1W
VESA™Mounting (Screw Spacing) 75mm x 75mm
Stand Tilt, Base Detachable
Features ntelligent Auto (Auto Resolution), f-ENG NE™
Set w/ Stand (WxDxH) 14.7" x 7.2" x 15.4"
Set w/o Stand (WxDxH) 14.7" x 2.4" x 12.3"
Shipping Dimension 16.5" x 5.2" x 14.9"
Weight (lbs.) w/stand / Shipping 7.7 lbs / 10.0 lbs
Hazardous Substances Standard --
Emission Standard TCO’03
Power Saving Standard EPA ENERGY STAR®
Limited Warranty 3 Years (Parts, Labor, Backlight)
UPC 7 19192 18417 6
With an ultra fast 2ms response time, content stays
crisper and clearer while ghosting effect is reduced.
Experience images optimized for various levels of
brightness resulting in a more accurate color
reproduction and deeper blacks.
An integrated digital high-quality picture system that
separates the relationship between brightness and
color so that each can be adjusted independently.
Connect up to six MultiLink USB monitors via USB
connectivity.
Automatically sets your computer’s resolution to the
monitor’s recommended resolution.
Brightness, contrast, and color optimization
customized to your application (photo, text and
movie modes, day or night).
Switch resolution modes with a touch of a button.
(screen resolution reduces by one level).
TCO’03: Certified monitors meet strict requirements
for visual ergonomics including pixel array,
luminance, contrast, front frame reflection and color
characteristics. Work load ergonomics (tilt and
height adjustments), electrical and magnetic
emissions, electrical safety and environmental
considerations are also taken into account.
Energy Star: Many LG LCD Desktop Monitors meet
Energy Star requirements in On, Sleep, and Off
Modes.
RoHS: The RoHS is an EU directive which restricts the
amount of six hazardous substances allowed in
certain electronic equipment.
MultiLink
echnology
Intelligent Auto
(Auto Resolution)
LightView
eZ Zooming
LG LCD Monitor Technologies and Features*:
*Technologies and features not found in all models.
