LG 60WL30MS-D User manual

IPS Direct LED
Full HD Capable Monito
LGsolutions.com
Specifications
ative Display Resolution 1920 X 1080 (FHD)
High Brightness 400 cd/m2(60WL30MS-D), 350 cd/m2(55WL30MS-D)
Contrast Ratio 1,000:1 (Typ.), 500,000:1 (DCR)
178°/178° Ultra Wide Viewing Angle
Suitable for Portrait or Landscape Installation
RJ-45 LA Control
RGB, DVI and HDMI Connection
RS-232C Control
Convenient External Speaker-Out
Energy Star® 6.0 compliant
Bezel Width 13.4mm(T/L/R), 18mm(B), 68.3mm(D) (60WL30MS-D)
13.4mm(T/L/R), 18mm(B), 82.3mm(D) (55WL30MS-D)
USB Playback
8GB Internal Storage Memory Built-in
Low Power Consumption
3-Year Limited Warranty Parts/Labor/Backlight
Features
TCO Total Cost of Ownership
The the WL30MS series are nergy Star® 6.0 compliant consuming
approximately 40% less energy than non-compliant models. In standby
mode, they use less than one watt of power and meet the environmental
regulations such as PA and rp, while excluding the use of harmful
materials (RoHS) and reducing CO2 emissions.
IPS In Plane Switching
Super IPS accurately display an image’s quality and color at 178° ultra wide
viewing angle. There is no fall-off in color accuracy and no diversion in
contrast ratio at wide angles. From bright sunlight to the most challenging
lighting environments these displays are designed to reproduce and
maintain the ultimate color temperature for lifelike images.
DIGISIGN
60" class (59.5" measu ed diagonally)
55" class (54.6" measu ed diagonally)
60WL30MS-D

55WL30MS-D


Portrait
Landscape
The solution integrated with media player foregoes the need for
additional media players and allows you to cut down expenses.
Media Player Integrated Solution
Superb Picture Quality
O BLACKE I G DEFECT
Display has a built-in temperature control
that adjusts to light and heat eliminating
dark or blackened areas.
IPS Normal
TRUE WIDE VIEWI G
Color changes and distortion are eliminated from
any viewing angle.
PA EL STABILITY
Minimized image distortion when external
pressure is applied.
I PS Normal
IPS Normal
Portrait & Landscape
Flexible usage with landscape or portrait display according to the
display environment.
Embedded player with 8GB
built-in USB memory
Free Software
WL30 Series (SuperSign Elite-w lite)
Narrow Bezel & Slim Depth
With narrower bezel and slimmer depth than those of conventional, you
can save space more efficiently with WL30.
Conventional WL30
Color change average @ 60°
Gamma change average @ 60°
If the outdoor temperature is 86°F
the surface temperature of display is 185°F

49.0”
28.4”
3.2”
400mm
400mm
LIF ’S GOOD...
when it’s green.
LG is committed to improving product
development, manufac- turing and usage to
meet the demand
for products with
environmentally friendlier features. Our
televisions have technologies to reduce
power consumption and in return increase
cost savings per room.
EcoSmart
• Intelligent Sensor - Continually monitors room light conditions to automatically optimize the
picture quality for a more enjoyable viewing experience, which can help save energy.
• Dynamic Power Savings - Using built-in algorithms, TV will automatically reduce the power
consumption based on incoming video, while maximizing picture performance.
• Static Power Savings - Picture brightness level can be set at the preferred power consumption level
to reduce power and increase energy savings.
•RoHS Compliant - Meets directive on restriction of hazardous substances.
•Energy Star 6.0 Qualified - Meets current reduction requirements of energy consumption.
Rear Jack Panel
53.3”
30.8”
2.7”
400mm
400mm
60WL30MS-D
55WL30MS-D

PHYSICAL
SPECIFICATIONS
(CONT.)
Mode 60WL30MS-D 55WL30MS-D
Monitor Dimensions
(W x H x D),
W/O stand.speaker 53.3” x 30.8” x 2.7” 49.0” x 28.4” x 3.2”
Weight (w/Optional
Stand) 55.7 bs. 44.5 bs.
Monitor Dimensions
(W x H x D),(w/Optional
Stand and Speaker) 53.3” x 33.4” x 11.7” 49.0” x 31.4” x 11.7”
Weight (w/Optional
Stand and Speaker) 57.5 bs. 46.3 bs.
Carton Dimensions
(W x H x D) 57.7” x 36.7” x 7.5” 53.0” x 34.3” x 7.5”
Packed Weight 66.1 bs. 54.0 bs.
VESA
TM
Standard
Mount nterface 400mm x 400mm (M6)
SPECIAL FEATURES
Temperature Sensor Yes
Tile Mode @Natural
Mode Yes
Source Selection Component, RGB, DV -D, HDM , USB, DP, Signage ( nternal Memory)
Brightness/Contrast/
Backlight Yes
Position/Size Yes
Auto Config/Phase Yes
SM Method Normal, White Wash, Orbiter, nversion
Advanced Dynamic Contrast, Dynamic Color, Clear White, Skin Color, Noise
Reduction, Digital Noise Reduction, Gamma, Black Level
Time Clock, On/Off Time, Sleep Timer, Power on Delay, Auto Off,
Automatic Standby
nformation Model/Type, Software Version, Serial Number, P Address, MAC
Address, Homepage
nput Label Yes(PC/DTV)
Auto Power/Source
Memory Yes
Key Lock Yes
DPM Select Yes
Energy Saving Yes (Minimum, Medium, Maxium)
Smart Energy Saving Yes
File Play with USB Yes
P P/PBP Yes
nternal Memory 8G
ENVIRONMENT
CONDITIONS
Operation Temp. 0°C ~40°C
Operation Humidity 10% ~80%
POWER
Power Supply 100 -240V~, 50/60Hz
Power Type
Built- n Power
Power C onsumption 180W (Typ.) 140W (Typ.)
150W (Smart Energy Savings) 110W (Smart Energy Savings)
0.7W (DP)
Power off: 0.5W
STANDARD
CERTIFICATION
Safety UL / cUL / CB scheme / TUV
EMC FCC Class "A", VCC , C-tick, CE, KCC
Erp/Energy Star Yes/Yes (Energy Star 6.0)
MEDIA PLAYER
COMPATIBILITY
External Media
Player Attachable Yes (NC1100 / NA1100 / NA1000)
SOFTW ARE
COMPATIBILITY
SuperSign Elite-w lite
/ Elite-c
Yes (Editing, Scheduling, Distribution & Play, Control) / Yes
WARRANTY
3-Year Limited Warranty (Parts/Labor/Backlight)
UPC
7 19192 19187 7 7 19192 19190 7
ACCESSORIES
ncluded
Remote Controller (include battery 2ea), Power Cord, R Receiver,
CD (Owner's Manual, SuperSign Program / Manual), ESG,
RGB Cable
Optional ST-550T (Stand)
SP-2000 (Speaker)
LG lectronics U.S.A., Inc.
H B2B Division
2000 Millbrook Drive
Lincolnshire, IL 60069
Customer Service: 888.865.3026
www.LGsolutions.com/support
Contact your LG Regional Sales Representative:
Channel: 800.897.8871
Hospitality: 800.228.1236
-mail: [email protected]
SP C_WL30_Series_091329_PR
All screen images are simulated. Dimensions and weights are approximate. Design, specifications, and
features subject to change without notice.
© Copyright 2014 LG lectronics USA, Inc. All Rights Reserved. “LG Life’s Good” is a registered trademark
of LG Corp.
N RGY STAR is a registered trademark of the U.S. nvironmental Protection Agency. In Plane Switching is
a trademark of LG Philips LCD Ltd. V SA is a trademark of Video lectronics Standards Association. HDMI,
the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.
All other product and brand names are trademarks or registered trademarks of their respective companies.
Printed in the USA. February 2014
LGsolutions.com
IPS Direct LED
Full HD Capable Monitor
DIGISIGN
60" class (59.5" measu ed diagonally)
55" class (54.6" measu ed diagonally)
60WL30MS-D

55WL30MS-D

PANEL
Mode 60WL30MS-D 55WL30MS-D
Screen Size 60" (59.5" measured diagonally) 55" (54.6" measured diagonally)
Panel Technology PS
Aspect Ratio 16 : 9
Native Resolution 1920 x 1080 (FHD)
Pixels(H x V x 3) 6,220,800
Brightness 400 cd/m2350 cd/m2
Contrast Ratio 1,000:1
Dynamic CR 500,000 : 1
Color gamut 68%
Tni 110°C
Viewing Angle 178°/178°
Color Depth 1.06 Billion→8bit, 16.7 Million
Response Time 9ms (GTG BW) 8ms (GTG BW)
Surface Treatment Hard coating(3H), Anti-reflection treatment of the front polarizer
(Haze 1%)
Orientation Portrait and Landscape
VIDEO (PC)
Max nput Resolution 1920 X 1080@ 60Hz(RGB,HDM /DV -D,DP)
Recommended
Resolution 1920 X 1080@ 60Hz(RGB,HDM /DV -D,DP)
H-Scanning Frequency 30kHz ~ 83kHz (RGB, HDM /DV -D,DP)
V-Scanning Frequency 50Hz ~ 75Hz (RGB), 50Hz~60Hz (HDM /DV -D/DP)
Pixel Frequency 148.5 MHz (RGB, HDM /DV -D,DP)
Sync Compatability Separate / Composite / Digital
Video nput RGB, HDM , DV , DP
Picture mode Vivid, Standard , Cinema, Sports, Game
Color temperature Warm, Medium , Cool
CONNECTIVITY
INPUT (Rear)
Digital HDM (1), DV -D(1), DP(1)
Analog RGB(1)
Audio RGB/DV -D/Component(3.5Φ1)
External Control RS232C(1), RJ45(1), R(1)
USB Yes(1)
HDTV Formats Component : 720p, 1080i , 1080p
HDM : 720p, 1080i, 1080p
OUTPUT
(Rear)
Digital DV -D(1)
External Control RS232C(1)
AUDIO
Balance Yes
Audio Power 20W(10W x 2)
Speaker On/Off Yes
Clear Voice Yes
Sound Mode Standard, Music, Cinema, Sport, Game
PHYSICAL
SPECIFICATIONS
Color Carbon Titan
Bezel Width 13.4mm(T/R/L), 18.0mm(B)
Monitor Dimensions
(W x H x D) (head only) 53.3” x 30.8” x 2.7” 49.0” x 28.4” x 3.2”
Weight (head) 50.8 bs. 39.8 bs.
