LG FLATRON L2013P User manual

Make sure to read the Important Precautions before using the product.
Keep the User's Guide(CD) in an accessible place for furture reference.
See the label attached on the back cover and quote this information to your
dealer when you require service.
L2013P
User’s Guide

A1
This unit has been engineered and manufactured to ensure your personal
safety, however improper use may result in potential e shock or fire hazards.
In order to allow the proper operation of all safeguards incorporated in this
display, observe the following basic rules for its installation, use, and
servicing.
On Safety
Use only the power cord supplied with the unit. In case you use another power
cord, make sure that it is certified by the applicable national standards if not being
provided by the supplier. If the power cable is faulty in any way, please contact the
manufacturer or the nearest authorized repair service provider for a replacement.
The power supply cord is used as the main disconnection device. Ensure that the
socket-outlet is easily accessible after installation.
Operate the display only from a power source indicated in the specifications of
this manual or listed on the display. If you are not sure what type of power supply
you have in your home, consult with your dealer.
Overloaded AC outlets and extension cords are dangerous. So are frayed power
cords and broken plugs. They may result in a shock or fire hazard. Call your service
technician for replacement.
Do not Open the Display.
There are no user serviceable components inside.
There are Dangerous High Voltages inside, even when the power is OFF.
Contact your dealer if the display is not operating properly.
To Avoid Personal Injury :
Do not place the display on a sloping shelf unless properly secured.
Use only a stand recommended by the manufacturer.
To Prevent Fire or Hazards:
Always turn the display OFF if you leave the room for more than a short period
of time. Never leave the display ON when leaving the house.
Keep children from dropping or pushing objects into the display's cabinet
openings. Some internal parts carry hazardous voltages.
Do not add accessories that have not been designed for this display.
During a lightning storm or when the display is to be left unattended for an
extended period of time, unplug it from the wall outlet.
Important Precautions

A2
Important Precautions
On Installation
Do not allow anything to rest upon or roll over the power cord, and do not place
the display where the power cord is subject to damage.
Do not use this display near water such as near a bathtub, washbowl, kitchen
sink, laundry tub, in a wet basement, or near a swimming pool.
Displays are provided with ventilation openings in the cabinet to allow the release
of heat generated during operation. If these openings are blocked, built-up heat
can cause failures which may result in a fire hazard. Therefore, NEVER:
Block the bottom ventilation slots by placing the display on a bed, sofa, rug, etc.
Place the display in a built-in enclosure unless proper ventilation is provided.
Cover the openings with cloth or other material.
Place the display near or over a radiator or heat source.
Do not rub or strike the Active Matrix LCD with anything hard as this may scratch,
mar, or damage the Active Matrix LCD permanently.
Do not press the LCD screen with your finger for a long time as this may cause
some afterimages.
Some dot defects may appear as Red, Green or Blue spots on the screen.
However, this will have no impact or effect on the display performance.
If possible, use the recommended resolution to obtain the best image quality for
your LCD display. If used under any mode except the recommended resolution,
some scaled or processed images may appear on the screen. However, this is
characteristic of the fixed-resolution LCD panel.
On Cleaning
Unplug the display before cleaning the face of the display screen.
Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display
screen because over-spraying may cause electrical shock.
On Repacking
Do not throw away the carton and packing materials. They make an ideal
container in which to transport the unit. When shipping the unit to another
location, repack it in its original material.
On Disposal
The fluorescent lamp used in this product contains a small amount of mercury.
Do not dispose of this product with general household waste.
Disposal of this product must be carried out in accordance to the regulations of
your local authority.

A3
Connecting the Display
100
Before setting up the monitor, ensure that the power to the monitor, the
computer system, and other attached devices is turned off.
Connecting the stand base or Removing the stand base
1. Place the monitor with its front facing downward on a cushion or soft cloth.
2. Align the hooks on the stand base with the matching slots in the base of
the monitor.
3. Insert the hooks into slots.
Important
This illustration depicts the general model of connection. Your monitor may differ from
the items shown in the picture.
Once you connect the stand base, try not to disconnect it.
Do not carry the product upside down holding only the stand base. The product may
fall and get damaged or injure your foot.
Hook
Screw
100
4. Use a coin on the back of the stand base and turn the screw clockwise to
tighten.
5. When you desire to disintegrate the monitor from the stand base, use a
coin to turn the screw counterclockwise.
Slot
The tape and locking pin may only be removed from those
monitors equipped with a standing base when the base is pulled up.
Otherwise, you may be injured by the protruding sections of the stand.
Warning:

A4
Connecting the Display
Before setting up the monitor, ensure that the power to the monitor, the
computer system, and other attached devices is turned off.
Positioning your display
Adjust the position of the panel in various ways for maximum comfort.
Tilt Range : -5˚~20˚ Swivel : 350˚
Ergonomic
It is recommended that in order to maintain an ergonomic and comfortable viewing
position, the forward tilt angle of the monitor should not exceed 5 degrees.
Height Range : maximun 3.15 inch (80.0mm)
Landscape & Portrait : You can rotate the panel 90o clockwise.
(* For detailed information, please refer to the Pivot Sofeware CD provided.)
* Make sure not to touch the
floor when the head rotates
to use the Pivot function.
80.0mm
First, remove
the locking pin.

A5
Connecting the Display
Using the Computer
1. Place the monitor in a convenient, well-ventilated location near your computer.
To adjust height of your monitor, unlock the stand lock on top of the stand.
2. Connect the signal cable. When attached, tighten the thumbscrews to secure
the connection.
3. Connect the power cord into a proper power outlet
that is easily accessible and close to the display.
Wall-outlet type*
PC-outlet type*
MAC
PC
Power Cord Signal Cable
Analog signal
D-sub*
Digital signal
- DVI*
* Varies according to model.
1
2
Mac adapter
For Apple Macintosh use, a separate plug
adapter is needed to change the
15 pin high density (3 row) D-sub VGA
connector on thesupplied cable to a
15 pin 2 row connector.
NOTE
This is a simplified representation of the rear view.
This rear view represents a general model; your display may differ from the view as shown.
When connecting DVI signal cable
When connecting D-Sub signal cable

A6
Control Panel Functions
Front Panel Controls
Buttons
Use these buttons to choose or adjust items in
the On Screen Display.
MENU Button
Use this button to enter or exit the On Screen
Display.
Use this button to turn the display on or off.
This Indicator lights up green when the display operates
normally(On Mode). If the display is in sleep(Energy
Saving) mode, this indicator color changes to amber.
Power Button
Power
Indicator
Use this button to enter a selection in the On Screen
Display.
SELECT Button
Control Function

A7
Control Panel Functions
Control Direct Access Function
Bring up Contrast and Brightness adjustment.
100
100
LIGHT VIEW
DAY TEXT
MOVIE
NIGHT
USER MODE
TEXT
MOVIE
AUTO IN PROGRESS
INPUT SELECT
DVI DIGITAL
DVI ANALOG
DSUB ANALOG
CONTROLS LOCKED
CONTROLS UNLOCKED
This function allows you to secure the current control
settings, so that they cannot be inadvertently changed.
Press and hold the MENU button and button for 3
seconds: the message “CONTROLS LOCKED” appears.
You can unlock the OSD controls at any time by pushing
the MENU button and button for 3 seconds:
the message “CONTROLS UNLOCKED” will appear.
Use this button to make DVI DIGITAL, DVI ANALOG or DSUB
ANALOG connector active. This feature is used when two computers
are connected to the display. The default setting is Dsub.
• DVI DIGITAL
• DVI ANALOG
• DSUB ANALOG
SOURCE Selection:
SOURCE ▼▲ SELECT
LIGHT VIEW:
When adjusting your display settings, always press the AUTO
button before entering the On Screen Display(OSD). This will
automatically adjust your display image to the ideal settings
for the current screen resolution size (display mode).
The best display mode is 1600 X 1200@60Hz.
AUTO adjustment function
CONTROLS LOCKED/UNLOCKED:
MENU and
This feature lets you easily select the best desired image condition
optimized to the environment (ambient illumination, image types etc.).
• DAY : Bright ambient illumination
• NIGHT : Dark ambient illumination
• TEXT : For text images (Word processing etc.)
• MOVIE : For animation images in videos or movies
• PHOTO : For pictures or drawings
• USER MODE : For use under user setup image conditions
(Brightness, contrast and color tint are selected by the user in
OSD Screen Setup Menu.)

A8
On Screen Display (OSD) Control Adjustment
Screen Adjustment
Making adjustments to the image size, position and operating parameters of
the display is quick and easy with the On Screen Display Control system. A
short example is given below to familiarize you with the use of the controls.
The following section is an outline of the available adjustments and selections
you can make using the OSD.
To make adjustments in the On Screen Display, follow these steps:
Press the MENU Button, then the main menu of the OSD appears.
To access a control, use the or Buttons. When the icon you want
becomes highlighted, press the SELECT Button.
Use the Buttons to adjust the item to the desired level.
Accept the changes by pressing the SELECT Button.
Exit the OSD by Pressing the MENU Button.
NOTE
Allow the display to stabilize for at least 30 minutes before making image adjustments.

A9
On Screen Display(OSD) Selection and Adjustment
To adjust the brightness and
contrast of the screen
CONTRAST/
BRIGHTNESS
COLOR
ADJUSTMENT
POSITION
TRACKING
SETUP
OSD
POSITION
Main menu Sub menu A D Reference
The following table indicates all the On Screen Display control, adjustment,
and setting menus.
USER(R/G/B)
9300K
6500K
To adjust the position of the
screen
To customize the color of the
screen
To customize the screen status
for a user's operating environment
To adjust position of the OSD
window on the screen
To improve the clarity and
stability of the screen
: Adjustable
A : Analog Input
D : Digital Input
CONTRAST
BRIGHTNESS
H POSITION
V POSITION
AUTO
CLOCK
PHASE
LANGUAGE
IMAGE SIZE
TRANSPARENCY
ZOOM
HORIZONTAL
VERTICAL
NOTE
The order of icons may differ depending on the model (A9~A12).

A10
On Screen Display(OSD) Selection and Adjustment
NOTE
OSD (On Screen Display) menu languages on the monitor may differ from the manual.
You were introduced to the procedure of selecting and adjusting an item
using the OSD system. Listed below are the icons, icon names, and icon
descriptions of the all items shown on the Menu.
OSD Adjust Description
BRIGHTNESS
To adjust the brightness of the screen.
CONTRAST
To adjust the contrast of the screen.
Vertical Position
To move image up and down.
Horizontal Position
To move image left and right.
To adjust the brightness and contrast of the screen
To adjust the position of the screen
OSD Adjust Description
CONTRAST/BRIGHTNESS
CONTRAST 100
BRIGHTNESS 99
RGB
OSD
To customize the color of the screen
OSD Adjust Description
USER
9300K
6500K
RED/GREEN/BLUE
Set your own color levels.
Select the screen color.
• 9300K: Slightly bluish white.
• 6500K: Slightly reddish white.
COLOR ADJUSTMENT
USER 9300K 6500K
RGB
RED 50
50
50
GREEN
BLUE
OSD
IMAGE POSITION
RGB
HORIZONTAL 50
VERTICAL 50
OSD

A11
On Screen Display(OSD) Selection and Adjustment
To improve the clarity and stability of the screen
OSD Adjust Description
This function is suitable for analog signal input
only. This button is for the automatic
adjustment of the screen position, clock and
phase.
To minimize any vertical bars or stripes visible
on the screen background.The horizontal
screen size will also change.
To adjust the focus of the display. This item
allows you to remove any horizontal noise and
clear or sharpen the image of characters.
Phase adjustment should be done after
adjusting the Clock.
AUTO
CLOCK
PHASE
SETUP
LANGUAGE
1600x1200 75kHz / 60Hz
ELAPSED TIME 00004H
ENGLISH
RGB
IMAGE SIZE FULL
TRANSPARENCY 50
ZOOM
OSD
To customize the screen status for a user's operating environment
OSD Adjust Description
To choose the language in which the
control names are displayed.
This function displays the image in its
original size or enlarged size so as to fit in
the full screen of the LCD panel.
To adjust the transparency of the OSD
menu screen.
To adjust horizontal and vertical image size
simultaneously.
If you want to move the zooming point, use
the H/V POSITION function in the sub-
menu. However, if the monitor turns off
when zooming in and out the screen, the
monitor will be returned to original screen.
LANGUAGE
IMAGE SIZE
TRANSPARENCY
ZOOM
TRACKING
AUTO
CLOCK
PHASE
ON
RGB
50
86
OSD

A12
To adjust position of the OSD window on the screen
OSD Adjust Description
Horizontal Position
To adjust horizontal position of the OSD window on the
screen.
Vertical Position
To adjust vertical position of the OSD window on the
screen.
OSD POSITION
RGB
HORIZONTAL 50
VERTICAL 50
OSD
On Screen Display(OSD) Selection and Adjustment

A13
Troubleshooting
No image appears
Check the following before calling for service.
No image appears
Is the power cord of the
display connected?
Is the power indicator
light on?
Is the power on and the
power indicator green?
Is the power indicator
amber?
Do you see an "OUT OF
RANGE" message on
the screen?
Do you see a "CHECK
SIGNAL CABLE"
message on the screen?
Do you see a "CONTROLS LOCKED" message on the screen.
Do you see “CONTROLS
LOCKED”when you
push MENU button?
You can secure the current control settings, so
that they cannot be inadvertently changed. You
can unlock the OSD controls at any time by
pushing the MENU button and button for 3
seconds: the message “CONTROLS
UNLOCKED”will appear.
Check and see if the power cord is connected
properly to the power outlet.
Press the Power button.
Adjust the brightness and the contrast.
If the display is in power saving mode, try moving
the mouse or pressing any key on the keyboard
to bring up the screen.
Make sure if the power is on.
Try to turn on the PC.
This message appears when the signal from the
PC (video card) is out of horizontal or vertical
frequency range of the display. See the
'Specifications' section of this manual and
configure your display again.
This message appears when the signal cable
between your PC and your display is not
connected. Check the signal cable and try again.

A14
Troubleshooting
Display image is incorrect
Display Position is
incorrect.
On the screen
background, vertical
bars or stripes are
visible.
Any horizontal noise
appearing in any
image or characters
are not clearly
portrayed.
The screen color is
mono or abnormal.
The screen blinks.
Press the AUTO button to automatically adjust
your display image to the ideal setting.
If the results are unsatisfactory, adjust the
image position using the H position and V
position icon in the on screen display.
Check Control Panel --> Display -->
Settings and see if the frequency or the
resolution were changed. If yes, readjust the
video card to the recommend resolution.
Press the AUTO button to automatically adjust
your display image to the ideal setting.
If the results are unsatisfactory, decrease the
vertical bars or stripes using the CLOCK icon
in the on screen display.
Press the AUTO button to automatically adjust
your display image to the ideal setting.
If the results are unsatisfactory, decrease the
horizontal bars using the PHASE icon in the
on screen display.
Check Control Panel --> Display -->
Settings and adjust the display to the
recommended resolution or adjust the display
image to the ideal setting. Set the color setting
higher than 24 bits (true color).
Check if the signal cable is properly connected
and use a screwdriver to fasten if necessary.
Make sure the video card is properly inserted
in the slot.
Set the color setting higher than 24 bits (true
color) at Control Panel - Settings.
Check if the screen is set to interlace mode
and if yes, change it to the recommend
resolution.
Make sure the power voltage is high enough, It
has to be hgher than AC100-240V 50/60Hz.

A15
Troubleshooting
Have you installed the display driver?
Have you installed the
display driver?
Do you see an
"Unrecognized monitor,
Plug&Play (VESA DDC)
monitor found"
message?
Be sure to install the display driver from the
display driver CD (or diskette) that comes with
your display. Or, you can also download the
driver from our web site: http://www.lge.com.
Make sure to check if the video card supports
Plug&Play function.
“IMAGE SIZE” function on OSD menu does not work.
Check if the resolution is set as 1600x1200.
The optimal resolution is 1600x1200 and the
image is fully displayed on the monitor and is not
converted as 1:1 image size.
“IMAGE SIZE” function
on OSD menu does not
work?

A16
Specifications
20.1 inches (51.0cm) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
20.1 inches viewable
0.255mm pixel pitch
Horizontal Freq. Analog : 28 - 92kHz (Automatic)
Digital : 28 - 80kHz (Automatic)
Vertical Freq. 56 - 85Hz (Automatic)
Input Form Separate TTL, Positive/Negative
Composite TTL Positive/Negative
SOG (Sync On Green)
Digital
Signal Input 15 pin D-Sub Connector
DVI - I connector (Digital/Analog)
Input Form RGB Analog (0.7Vp-p/75ohm), Digital
Max D-Sub : Analog - VESA 1600 x 1200@60Hz
DVI : Analog - VESA 1600 x 1200@60Hz
Digital - VESA 1600 x 1200@60Hz
Recommend VESA 1600 x 1200@60Hz
DDC 2B
On Mode : 60W
Sleep Mode ≤3W
Off Mode Analog : ≤2W
Digital : ≤3W
Width 44.60 cm / 17.56 inches
Height 44.83 cm / 17.64 inches(Min)
52.83 cm / 20.79 inches(Max)
Depth 24.26 cm / 9.55 inches
Net 8.88 kg
Tilt range -5˚~20˚
Swivel range 350˚
Height range 80mm / 3.15 inches
Rotate 90˚clockwise(Landscape -> Portrait)
AC 100-240V ~ 50/60Hz 1.2A
Operating Conditions
Temperature 10˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20˚C to 60 ˚C
Humidity 5 % to 95 % non-Condensing
Display
Sync Input
Video Input
Resolution
Plug&Play
Power
Consumption
Dimensions
&Weight
(with tilt/ swivel
stand)
Tilt/Swivel Range
Power Input
Environmental
Conditions

A17
Specifications
Attached( ), Detached ( O )
Attached( O ), Detached ( )
Wall-outlet type or PC-outlet type
Tilt/Swivel Stand
Signal cable
Power cord
NOTE
Information in this document is subject to change without notice.

A18
Specifications
Preset Modes (Resolution)
Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
640 x 350
640 x 480
640 x 480
640 x 480
720 x 400
800 x 600
800 x 600
800 x 600
832 x 624
1024 x 768
1024 x 768
1024 x 768
1152 x 870
1152 x 900
1280 x 1024
1280 x 1024
1600 x 1024
1600 x 1200
31.47
31.47
37.50
43.27
31.47
37.88
46.88
53.67
49.72
48.36
60.02
68.68
68.68
61.80
63.98
79.98
62.11
75.00
70
60
75
85
70
60
75
85
75
60
75
85
75
65.96
60.02
75.02
60
60
Indicator
On Mode
Sleep Mode
Off Mode
green
amber
off
LED Color
MODE

A19
VESA wall mounting
Connected to another object (stand type and wall-
mounted type. This monitor accepts a VESA-
compliant mounting interface pad.- optional)
For further information, refer to the VESA Wall
Mounting Instruction Guide.
Kensington Security Slot- optional
Connected to a locking
cable that can be purchased
separately at most
computer stores
How to Install the VESA Standard wall mounting
This monitor meets VESA-compliant mounting interface pad
specifications.
Specifications
