LG 24MB35PU User manual

www.lg.com
ENGLISH
OWNER’S MANUAL
IPS LED MONITOR
(LED LCD MONITOR)
22MB35PU
24MB35PU
Please read this manual carefully before operating
your set and retain it for future reference.
IPS LED(LED LCD) MONITOR MODEL

2
ENG
ENGLISH
TABLE OF CONTENTS
CONTENTS
3 ASSEMBLINGANDPREPAR-
ING
3 Unpacking
4 Partsandbuttons
5 SettinguptheMonitorset
5 - AttachingtheStandBase
5 - Detachingthestandbase
6 - Detachingthestandbody
7 - Mountingonatable
7 - Adjustingtheangle
8 - Adjustingthestandheight
8 - UsingtheKensingtonlockingdevice
9 - Swivelstand
9 - UsingthePivotfunction
10 - Mountingonawall
11 USINGTHEMONITORSET
11 ConnectingtoaPC
11 - D-SUBconnection
11 - DVI-Dconnection
13 - Peripheraldeviceconnection
14 CUSTOMIZINGSETTINGS
15 CustomizingSettings
15 - MenuSettings
16 -Picture
17 -Color
18 -Display
19 -Others
20 READERSetting
21 -SUPERENERGYSAVING
22 TROUBLESHOOTING
24 SPECIFICATIONS 
24 22MB35PU
25 24MB35PU
26 PresetModes(Resolution)
26 Indicator
27 PROPERPOSTURE
27 ProperpostureforusingtheMonitorset.

3
ENG
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLINGANDPREPARING
Unpacking
Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal
dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct
andaccessories.
 Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.
 Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.
 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.
 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade
ofproductfunctions.
CAUTION
NOTE
StandBase
CD(Owner'sManual)/
Card
D-SUBCable
(Thiscableisnotincludedinall
countries.)
PowerCord
DVI-DCable
(Thiscableisnotincludedinall
countries.)
(Dependingonthecountry) (Dependingonthecountry)
USBCable
AudioCable

4
ENG
ENGLISH
ASSEMBLING AND PREPARING
Partsandbuttons
(PowerButton)
PowerIndicator
 LEDOn:Powerison
 LEDOff:Powerisoff
FrontSideButtons
InputConnectors(Seep.11to13)Seep.11to13)to13)13))

5
ENG
ENGLISH
ASSEMBLING AND PREPARING
SettinguptheMonitorset
AttachingtheStandBase
1 PlacetheMonitorsetwiththescreenside
downonaflatandcushionedsurface.
StandBase
StandBody
 Toprotectthescreenfromscratches,cover
thesurfacewithasoftcloth.
2 Checktheposition(atthefrontandrear)of
thestandbody,thenmountthestandbaseon
thestandbodyasshowninthefigure.
CAUTION
 Thecomponentsappearingintheillustra-
tionsmaylookdifferentfromtheactualprod-
uct.
 Donotcarrythemonitorupside-downasthis
maycauseittofalloffitsstand,resultingin
damageorinjury.
 Toavoiddamagingthescreenwhenlifting
ormovingthemonitor,onlyholdthestandor
theplasticcover.Thisavoidsputtingunnec-
essarypressureonthescreen.
 Onlyremovethetapeandthelockingpin
whenthemonitorismountedonthestand
baseandisinanuprightposition.Otherwise,
thestandbodymayprotrude,whichmay
leadtoinjury.
Detachingthestandbase
1 Placethemonitor'sscreenfacedown.
Toprotectthescreenfromscratches,coverthe
surfacewithasoftcloth.
2 Detachthestandbasefromthestandbody.
CAUTION

6
ENG
ENGLISH
ASSEMBLING AND PREPARING
Detachingthestandbody
1 Placethemonitor'sscreenfacedown.To
protectthescreenfromscratches,coverthe
surfacewithasoftcloth.
2 Usingascrewdriver,removethefourscrews
anddetachthestandfromthemonitor.

7
ENG
ENGLISH
ASSEMBLING AND PREPARING
Adjustingtheangle
1 Placethemonitormountedonthestandbase
inanuprightposition.
2 Adjusttheangleofthescreen.Theangleof
thescreencanbeadjustedupto5°forwards
and20°backwardsforacomfortableviewing
experience.
 Toavoidinjurytothefingerswhenadjusting
thescreen,donotholdthelowerpartofthe
monitor'sframeasillustratedbelow.
 Becarefulnottotouchorpressthescreen
areawhenadjustingtheangleofthemonitor.
WARNING
Mountingonatable
1 Liftthemonitorandplaceitonthetableinan
uprightposition.
Installatleast10cmawayfromthewallto
ensuresufficientventilation.
2
3 Pressthe (Power)buttononthefrontofthe
monitortoturnonthemonitor.
10 cm
10 cm
10 cm
10 cm
 Unplugthepowercordpriortomovingor
installingthemonitor.Thereisriskofelectric
shock.
CAUTION
FrontSideRearSide
ConnectthePowercordtothemonitor,then
plugthepowercordintothewalloutlet.

8
ENG
ENGLISH
ASSEMBLING AND PREPARING
Using the Kensington locking
device
TheconnectorfortheKensingtonlockislocated
ontherearofthemonitor.
Formoreinformationoninstallationandusage,
refertotheKensingtonlockusermanualorvisit
thewebsiteathttp://www.kensington.com.
ConnectthemonitortothetablewiththeKensing-
tonlockcable.
 UsingtheKensingtonlockisoptional.The
accessoriescanbepurchasedatyourlocal
electronicsstore.
NOTE
 Oncethepinisremoved,itisnotnecessary
tore-insertittoadjusttheheight.
Adjustingthestandheight
1 Placethemonitormountedonthestandbase
inanuprightposition.
2 Removethetapeattachedatthebottomrear
ofthestandbody,thenpulloutthelocking
pin.
3 Theheightcanbeadjustedupto110mm.
 Donotputyourfingerbe-
tweenthescreenandthe
base(chassis)whenadjust-
ingthescreen'sheight.
Tape
LockingPin
StandBody

CAUTION
WARNING
110.0mm

9
ENG
ENGLISH
ASSEMBLING AND PREPARING
Swivelstand
 ImageshownmaydifferfromyourMonitor
set.
1 Swivel355degreesandadjusttheangleofthe
Monitorsettosuityourview.
1 Liftthemonitortoitshighestheighttoutilize
thePivotfunction.
UsingthePivotfunction
Thepivotfunctionallowsyoutorotatethescreen
90degreesclockwise.
2 Landscape&Portrait:Youcanrotatethepanel
90°clockwise.Pleasebecautiousandavoid
contactbetweenthemonitorheadandthe
StandBasewhenrotatingthescreentoaccess
thePivotfunction.Ifthemonitorheadtouches
theStandBase,thentheStandBasecould
crack.
Head
section
Stand
section
3 Becarefulwiththecableswhenrotatingthe
screen.

10
ENG
ENGLISH
ASSEMBLING AND PREPARING
Mountingonawall
Forproperventilation,allowaclearanceof10cm
oneachsideandfromthewall.Detailed
instructionsareavailablefromyourdealer,seethe
optionalTiltWallMountingBracketInstallationand
SetupGuide.
IfyouintendtomounttheMonitorsettoawall,
attachWallmountinginterface(optionalparts)to
thebackoftheset.
WhenyouinstalltheMonitorsetusingawall
mountinginterface(optionalparts),attachit
carefullysoitwillnotdrop.
1Please,Usethescrewandwallmountinterface
inaccordancewithVESAStandards.
2Ifyouusescrewlongerthanstandard,the
monitormightbedamagedinternally.
3Ifyouuseimproperscrew,theproductmightbe
damagedanddropfrommountedposition.In
thiscase,LGElectronicsisnotresponsiblefor
it.
4VESAcompatible.
5PleaseuseVESAstandardasbelow.
 784.8mm(30.9inch)andunder
*WallMountPadThickness:2.6mm
*Screw:Φ4.0mmxPitch0.7mmx
Length10mm
 787.4mm(31.0inch)andabove
*PleaseuseVESAstandardwallmountpad
andscrews.
10 cm
10 cm
10 cm
10 cm
 Disconnectthepowercordfirst,andthen
moveorinstalltheMonitorset.Otherwise
electricshockmayoccur.
 IfyouinstalltheMonitorsetonaceilingor
slantedwall,itmayfallandresultinsevere
injury.
 UseonlyanauthorizedLGwallmount
andcontactthelocaldealerorqualified
personnel.
 Donotovertightenthescrewsasthismay
causedamagetotheMonitorsetandvoid
yourwarranty.
 Useonlyscrewsandwallmountsthat
meettheVESAstandard.Anydamages
orinjuriesbymisuseorusinganimproper
accessoryarenotcoveredbythewarranty.
 UsethescrewsthatarelistedontheVESA
standardscrewspecifications.
 Thewallmountkitwillincludeaninstallation
manualandnecessaryparts.
 Thewallmountbracketisoptional.Youcan
obtainadditionalaccessoriesfromyourlocal
dealer.
 Thelengthofscrewsmaydifferdepending
onthewallmount.Besuretousetheproper
length.
 Formoreinformation,refertothe
instructionssuppliedwiththewallmount.
CAUTION
NOTE
Model 22MB35PU
VESA(AxB) 100x100
Standardscrew M4
Numberofscrews 4
24MB35PU

11
ENG
ENGLISH
USING THE MONITOR SET
USINGTHEMONITORSET
ConnectingtoaPC
 YourMonitorsetsupportsPlug&Play*.
*Plug&Play:APCrecognizesaconnected
devicethatusersconnecttoaPCandturn
on,withoutdeviceconfigurationoruser
intervention.
D-SUBconnection
TransmitsanalogvideofromyourPCtothe
Monitorset.ConnectthePCandtheMonitorset
withthesuppliedD-sub15pinsignalcableas
showninthefollowingillustrations.
 Macadapter
ForAppleMacintoshuse,aseparateplug
adapterisneededtochangethe15pin
highdensity(3row)D-SUBVGAconnector
onthesuppliedcabletoa15pin2row
connector.
 WhenusingaD-Subsignalinputcable
connectorforMacintosh
NOTE
DVI-Dconnection
TransmitsadigitalvideosignalfromyourPCto
theMonitorset.ConnectthePCandtheMonitor
setwithaDVIcableasshowninthefollowing
illustrations.

12
ENG
ENGLISH
USING THE MONITOR SET
 "SelfImageSetting"Function.
Thisfunctionprovidestheuserwithoptimal
displaysettings.Whentheuserconnects
themonitorforthefirsttime,thisfunction
automaticallyadjuststhedisplaytooptimal
settingsforindividualinputsignals.(Only
supportedinAnalogMode)
 ‘AUTO’Function.
Whenyouencounterproblemssuchas
blurryscreen,blurredletters,screenflicker
ortiltedscreenwhileusingthedeviceor
afterchangingscreenresolution,pressthe
AUTOfunctionbuttontoimproveresolution.
(OnlysupportedinAnalogMode)
NOTE
SelfImageSettingFunction
Pressthepowerbuttononthebottompanelto
turnthepoweron.Whenmonitorpoweristurned
on,the"SelfImageSetting"Functionisexecuted
automatically.(OnlysupportedinAnalogMode)
 WhenyouwanttousetwoPCinourMonitor,
pleaseconnectthesignalcable(D-SUB/
DVI-D)respectivelyinMonitorset.
 IfyouturntheMonitorsetonwhileitiscold,
thescreenmayflicker.Thisisnormal.
 Somered,green,orbluespotsmayappear
onthescreen.Thisisnormal.
NOTE
 Connectthesignal
inputcableandtighten
itbyturningthescrews
clockwise.
 Donotpressthescreen
withyourfingerforalongtimeasthismay
resultintemporarydistortiononthescreen.
 Avoiddisplayingafixedimageonthe
screenforalongperiodoftimetoprevent
imageburn.Useascreensaverifpossible.
CAUTION

13
ENG
ENGLISH
USING THE MONITOR SET
 Peripheraldevicesaresoldseparately.
 TheUSBportsontheleftandbottomofthe
monitorcanbeusedtoconnectthekey-
board,mouse,andotherUSBdevices.
 Cableswithangledplugsmayhaveclear-
anceissues,usestraightplugswhenpos-
sible.
AngleType StraightType
Peripheraldeviceconnection
Connectperipheraldevicestothemonitor.
NOTE
NOTE
 Speakersmaynotworknormally,depending
ontheserverPCsettings.
 Virtualsolutionsmayaffectthefunctionsor
speedofthespecificUSBstoragedevice.
NOTE
 Themonitor'sUSBterminalsupportsUSB
2.0andhighspeedcables.  

TwoUSBDownstreamports
Connecttheseportstoamouse,
USBkeyboard,memorystickwith
currentspecunder100mA.
OneUSBUpstreamport
Connectthisporttothedown-
streamportofacomputer,laptop
orUSBmonitor(Yourcomputeror
USBmonitormustsupportUSB
andhaveUSBports).

14
ENG
ENGLISH
CUSTOMIZING SETTINGS
CUSTOMIZINGSETTINGS
1 PressthedesiredbuttononthebottomoftheMonitorset.
2 ChangethevalueofthemenuitembypressingthebuttonsonthebottomoftheMonitorset.
Toreturntotheuppermenuorsetothermenuitems,usetheuparrow( )button.
3 SelectEXITtoleavetheOSDmenu.
MonitorsetButtons
Button Description
Accessesthemainmenus.(Seep.15)
OSDLocked/OSD
Unlocked
Thisfunctionallowyoutolockthecurrentcontrolsettings,so
thattheycannotbeinadvertentlychanged.
PressandholdtheMENUbuttonforseveralseconds.Then
OSDof“OSDLock”willappear.Afterthat,usercanselect
lockorunlockbypressingleft/rightbutton.
Ifuserselectsthe“Lock”iconbypressingthe“OK”button,
themessage“OSDLocked”willappear.Otherwise,“OSD
Unlocked”willappear.Afterselectingthe“Lock”,Ifyouwant
tochangetoUnlock,youcanpushthe“MENU”buttonfor
severalseconds.Themessage“OSDUnlocked”willappear.
UsethisbuttontoenterReaderModemenu.Itsfunctionworkstodisplayscreenas
paper-likepictureforEyecomfort.Ifyouwanttomoreinformation.(Seep.20)
UsethisbuttontoenterSUPERENERGYSAVINGmenu.(Seep.21)
Whenadjustingyourdisplaysettings,alwayspresstheAUTObuttonontheMONITOR
SETUPOSD.(OnlysupportedinAnalogMode)
Thebestdisplaymode 1920x1080
Youcanchoosetheinputsignal.
• Whentwoinputsignalsareconnected,youcanselecttheinputsignal(D-SUB/DVI)
youwant.
• Whenonlyonesignalisconnected,itisautomaticallydetected.Thedefaultsettingis
D-SUB.
EXIT
ExittheOSD(OnScreenDisplay).
(PowerButton) Turnsthepoweronoroff.
PowerIndicator Thepowerindicatorstayswhiteifthedisplayisrunning
properly(OnMode).IfthedisplayisinSleepMode,thepower
indicatorblinkswhite.

15
ENG
ENGLISH
CUSTOMIZING SETTINGS
CustomizingSettings
MenuSettings
1 PressMENUbuttononthebottomoftheMonitorset
todisplaytheMenuOSD.
2 Settheoptionsbypressingthe◄or►or▼
buttons.
3 Selectthe"NextMenu"buttontoenterthemore
optionsettings.
4 SelectEXITtoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,
usetheuparrow( )button.
Eachoptionisexplainedbelow.
Menu>NextMenu Analog Digital Description
Picture Contrast ● ● Toadjustthecontrastofthescreen
Sharpness ● ● Toadjusttheclearnessofthescreen
Color Gamma
● ● Tocustomizethecolorofthescreen
ColorTemp
SixColor(onlyusefor
24MB35PU)
ColorReset(onlyuse
for24MB35PU)
Display Horizontal ●Toadjustthepositionofthescreen
Vertical
Clock ●Toimprovetheclarityandstabilityofthescreen
Phase
Others Language ● ● Tocustomizethescreenstatusforauser'soperating
environment
PowerIndicator
OffTimeSetting ● ●
 Analog:D-SUB(Analogsignal)input.
 Digital:DVI-D(Digitalsignal)input.
Menu Analog Digital Description
Volume ● ● Toadjustthevolume
Brightness ● ● Toadjustthebrightnessofthescreen
Response
Time
(onlyusefor
24MB35PU)
● ●
Youcansetaresponsetimefordisplayedpicturesbasedonthespeedofthescreen.
Foranormalenvironment,itisrecommendedthatyouuse'Off'.Forafast-moving
picture,itisrecommendedthatyouuse'High'.
Wide/
Original
● ●
Wide
Switchtofullscreenmodeaccordingtoinputimagesignal.
Original
Changetheinputimagesignalratiotooriginal.
*ThisfunctionworksonlyifinputresolutionislowerthanMonitorsetratio(16:9).
Reset ● ● Restoreallfactorydefaultsettings.Pressthe◄,►buttonstoresetimmediately.

16
ENG
ENGLISH
CUSTOMIZING SETTINGS
1 PressMENUbuttononthebottomoftheMonitorset
todisplaytheMenuOSD.
2 Selectthe"NextMenu"buttontoenterthemore
optionsettings.
3 EntertoPicturebypressingthe▼button.
4 Settheoptionsbypressingthe◄or►or▼
buttons.
5 SelectEXITtoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,
usetheuparrow( )button.
Eachoptionisexplainedbelow.
Menu>NextMenu>Picture Description
Contrast Toadjustthecontrastofthescreen.
Sharpness Toadjusttheclearnessofthescreen.

17
ENG
ENGLISH
CUSTOMIZING SETTINGS
Color
1 PressMENUbuttononthebottomoftheMonitorset
todisplaytheMenuOSD.
2 Selectthe"NextMenu"buttontoenterthemore
optionsettings.
3 SelectColorbypressingthe►button.
4 EntertoColorbypressingthe▼button.
5 Settheoptionsbypressingthe◄or►or▼
buttons.
6 SelectEXITtoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,
usetheuparrow( )button.
Eachoptionisexplainedbelow.
Menu>NextMenu>Color Description
Gamma Setyourowngammavalue.:Gamma0,Gamma1,Gamma2onthemonitor,
highgammavaluesdisplaywhitishimagesandlowgammavaluesdisplay
blackishimages.
ColorTemp Custom
•Red:Setyourownredcolorlevels.
•Green:Setyourowngreencolorlevels.
•Blue:Setyourownbluecolorlevels.
Selectthescreencolor.
Warm:Setthescreentowarmcolortemperature(morered).
Medium:Setthescreentomediumcolortemperature.
Cool:Setthescreentocoolcolortemperature(moreblue).
SixColor
(onlyusefor24MB35PU)
Setsandstoresthehueandsaturationforsixcolors(Red/Green/Blue/Cyan/
Magenta/Yellow)tosatisfythecolorrequirementsofauser.
Hue Adjuststhescreenhue.
Saturation Adjuststhecolorsharpnessonthescreen.Lowervaluesmake
thecolorsharpnessweakerandcolorslighterwhilehigher
valuesmakethecolorsharpnessstrongerandcolorsdark.
ColorReset
(onlyusefor24MB35PU)
Resetsthecolorsettingstothefactorydefaultsettingsforthecurrentinput
device.

18
ENG
ENGLISH
CUSTOMIZING SETTINGS
Display
1 PressMENUbuttononthebottomoftheMonitorset
todisplaytheMenuOSD.
2 Selectthe"NextMenu"buttontoenterthemore
optionsettings.
3 SelectDisplaybypressingthe►button.
4 EntertoDisplaybypressingthe▼button.
5 Settheoptionsbypressingthe◄or►or▼
buttons.
6 SelectEXITtoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,
usetheuparrow( )button.
Eachoptionisexplainedbelow.
Menu>NextMenu>Display Description
Horizontal Tomoveimageleftandright.
Vertical Tomoveimageupanddown.
Clock Tominimizeanyverticalbarsorstripesvisibleonthescreenbackground.The
horizontalscreensizewillalsochange.
Phase Toadjustthefocusofthedisplay.Thisitemallowsyoutoremoveanyhorizontal
noiseandclearorsharpentheimageofcharacters.

19
ENG
ENGLISH
CUSTOMIZING SETTINGS
Others
1 PressMENUbuttononthebottomoftheMonitorset
todisplaytheMenuOSD.
2Selectthe"NextMenu"buttontoenterthemore
optionsettings.
3 SelectOthersbypressingthe►button.
4 EntertoOthersbypressingthe▼button.
5 Settheoptionsbypressingthe◄or►or▼
buttons.
6 SelectEXITtoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,
usetheuparrow( )button.
Eachoptionisexplainedbelow.
Menu>NextMenu>Others Description
Language Tochoosethelanguageinwhichthecontrolnamesaredisplayed.
PowerIndicator Usethisfunctiontosetthepowerindicatoronthebottomsideofthemonitorto
OnorOff.IfyousetOff,itwillgooff.
IfyousetOnatanytime,thepowerindicatorwillautomaticallybeturnedon.
OffTimeSetting Themonitorsetwillswitchtopoweroffmodeafterthetimetobechosenbyuser
(1~24hours)

20
ENG
ENGLISH
CUSTOMIZING SETTINGS
READERSetting
1 PressREADERbuttononthebottomoftheMonitor
settodisplaytheReaderModeOSD.
2 Settheoptionsbypressingthe◄buttons.
ReaderMode Description
Reader1 Itisamodethatthescreenisadjustedtothebestforthenewspaper.Ifyou
wantscreenmorebright,youcancontrolbrightnessinMenuOSD.
Reader2 Itisamodethatthescreenisadjustedtothebestforthecartoon.Ifyouwant
screenmorebright,youcancontrolbrightnessinMenuOSD.
ReaderOff Itisamodethatreadermodeisoff.
Eachoptionisexplainedbelow.
NOTE
IfoptionofReaderModeisReader1orReader2,PictureModewillautomaticallybeCustomand
SuperEnergySavingwillautomaticallybeOff.
