FLATRON L1751S-BN
FLATRON L1751S-BN
◗ Brilliant Active Matrix TFT Display
◗Ultra Fast 12ms Response Time
◗ Simple One Touch-Auto-Setup Function
◗LightView Function (Brightness Control)
◗160/160 Degree Wide Viewing Angle
◗Universal 90-264 VAC Power
◗ EPA Energy Star and VESA DPMS Compliant
17" (17.0" VIS) ACTIVE MATRIX LCD MONITOR
TM
◗TCO'03 Low-Emission Compliant
VESA DDC2B, DDC1, Plug and Play Compatible
◗

FLATRON L1751S-BN
FLATRON L1751S-BN
FLATRON L1751S-BN
563LE
BACK
LIVE: 1/2”From Trim
TRIM: 8 1/2”x 11”
BLEED: 1/8”All Around
(All Black)
17" (17.0" VIS) ACTIVE MATRIX LCD MONITOR
www.LGusa.com
The FLATRON LCD 1751S-BN will make your work space look larger and your
work look better. its brilliant active matrix TFT display with ultra-fast 12ms
response time creates crystal clear images without ghosting effect. And
features like simple one button auto setup and LightView brightness control
give you ease and convenience you want.
©2005 LG Electronics U.S.A., Inc. All trademarks are property of their respective owners. Design and specifications subject to change without notice. 3/05
LG ELECTRONICS U.S.A., INC.
HEADQUARTERS
1000 Sylvan Avenue, Englewood Cliffs, NJ 07632 ◗Tel: [phone], Fax: [phone] ◗ www.LGusa.com
Saved: 02/21/2002 01:04 PM
Printed: 02/21/2002 01:05 PM
Document Name: 563LE spec sheet
Fonts: HelveticaNeue LightCond, Eurostile BoldCondensed, Zapf Dingbats, BLI Frutiger BlackItalic, HelveticaNeue Condensed, Eurostile BoldExtendedTwo, HelveticaNeue BoldCond, BL Frutiger Black, R
Frutiger Roman, L Frutiger Light,BI Frutiger BoldItalic, UB Frutiger UltraBlack,Helvetica
Graphics: GRAY ISO 9001/EPS, Digitally,logo with icon#1/eps, LG Group/2000 CIP,3year quickswap logo.eps, tco B&W logo/eps,ES.clr B&W, red_bar.eps, LG Electronics, 563LE.eps, gold_bar.eps,
blue_bar.eps,Glowing Line (Sell Sheet)/EPS, BW_bar.eps, BW_bar.eps, Glowing Line (B&W)/EPS, 563LE greyscale.eps
Colors: Black, Red, Cyan, Magenta, Yellow
DISPLAY TYPE 17.0" (17.0" VIS) Active Matrix TFT Color LCD Screen
DISPLAY AREA (H x V) 13.3" x 10.6" (338mm x 270mm)
DISPLAY COLORS 16.2Million
PIXEL PITCH 0.264mm x 0.264mm Pixel
PIXEL CONFIGURATION RGB Stripe Arrangement
SURFACE TREATMENT Hard Coating 3H,Anti-Glare
ELECTRONIC INTERFACE LVDS
BACKLIGHTING 4CCFL
MAXIMUM RESOLUTION 1280 x 1024
BRIGHTNESS 250cd/m2(Typical)
CONTRAST RATIO 550:1 (Typical)
RESPONSE TIME 12ms
VIEWING ANGLE H: 160°,V:160°
HORIZONTAL SCANNING
FREQUENCIES 30-83KHz,Auto-Synchronous
VERTICAL SCANNING FREQUENCIES 56-75Hz,Auto-Synchronous
AUTO-SYNC SUPPORT640 x 350 up to 70Hz, 640 x 480 up to 70Hz, 720 x 400 up to 70Hz, 800 x 600 up to 75Hz,
832 x 624 up to 75Hz, 1024 x 768 up to 75Hz, 1152 x 870 up to 75Hz, 1280 x 1024 up to 75Hz
CONTROL TYPE On-Screen Display of Adjustments
INPUT SIGNAL RGB Analog
INPUT TERMINALS Standard VGA D-Sub 15-pin Connector
SYNC SIGNALING Separate H/V
MEMORY MODES 13 Factory Preset, 10 User-Settable
VESA PLUG AND PLAY LEVEL DDC2B, DDC1
DIGITAL ON-SCREEN CONTROLS Brightness, Contrast, Gamma, Horizontal/Vertical Position, Clock, Phase (+/-), Language Select,
Auto-Adjust, OSD Position, Color Temp (9300K, 6500K, User), ADC Calibration, LightView
FRONT PANEL CONTROLS Menu, Adjust/LightView (+/-), Auto-Set/Select, Power
POWER REQUIREMENTS 90-264 VAC, 50-60Hz
DPMS POWER CONSUMPTION On: 40 Watts, Standby: 1 Watts, DPMS Off: 1 Watts
TILT/SWIVEL Tilt: Down 5°/Up 20°Swivel: 350
VESA MOUNTING COMPLIANCE Standard VESA Mounting, 100mm x 100mm Screw Spacing
DIMENSIONS WITH BASE (WxDxH) 14.5" x 9.1" x 15.3" (368mm x 230mm x 389mm)
SHIPPING DIMENSIONS (WxDxH) 17.8" x 12.7" x 20.5"
WEIGHT 10.8 lbs Net; 14.3 lbs Shipping
SAFETY/REGULATORYTCO‘03, UL1950, FCC-B, EPA Energy Star,IEC950, CSA, CE,
TUV-GS, SEMKO, GOST,ISO 9241-3,7,8, C-TICK,VCCI-2
ACCESSORIES Power Cord, Signal Cable, Manual, Install Disk
LGEUS WARRANTY 3Year QuickSwap Replacement Program
UPC# 719192179264
