LG EM530S User manual

Operating Instructions
Built in Oven
Please read this instruction manual carefully before using the oven.
This will ensure that you know the important safety information and the
correct operation of the oven.
Please keep this manual in a easily accessible place and refer to it
anytime. Please transfer this manual to new owner if you sell the oven.
EM5 0S
www.lg.com
MFL30298507

2
Contents
Safety ............................................................................. 4~14
Appliance description .................................................. 15
Control panel ................................................................. 16~17
Accessories ................................................................... 18~19
Side runners .................................................................. 20
Telescopic runners
Feature not available all countries) ... 21~22
Catalytic Liners
Feature not available all countries) ......... 23
Setting the clock ........................................................... 24
Before using for the first time ...................................... 25
Using the oven ............................................................... 26
Oven functions .............................................................. 27~28
Operation ....................................................................... 29~41
Switching the oven on .................................................. 29
Changing the oven temperature ................................... 30
Switching off the oven ................................................... 31
Safety cut-out ................................................................ 31
Energy efficiency........................................................... 31
Clock functions an symbols ........................................ 32
Setting the timers .......................................................... 33
Programming the overall cooking time.......................... 34~35
Programming the en of cooking time .......................... 36~37
Combining overall cooking time an
en of cooking time ...................................................... 38~39
Setting the time of ay ................................................. 40
Useful functions ............................................................ 41
Baking ............................................................................ 42~43
Baking table .................................................................. 44~48
Roasting ......................................................................... 49~50
Roasting table ................................................................ 51
Grilling ............................................................................ 52~53
Grilling table................................................................... 53
Defrosting....................................................................... 54
Special functions .......................................................... 55
Cleaning and care ......................................................... 56~58
Oven light ...................................................................... 59
Oven door....................................................................... 60~64

3
Troubleshooting ............................................................ 65~66
Error codes..................................................................... 67
Technical specifications................................................ 68
Installation instructions ............................................... 69
Customer service & spare parts................................... 70

4
Important safety instructions
Rea an follow all instructions before using your oven to prevent
the risk of fire, electric shock, personal injury, or amage when
using the appliance. This gui e not cover all possible con itions
that may occur. Always contact your service agent or manufacturer
about problems that you o not un erstan .
• This oven must only be installe by a license electrician.
• The installer is responsible for the correct electrical connection of
the appliances an the observance of the relative safety co es
an recommen ations.
• Rating plate is locate on the left si e of the oor or on the back
cover.
This is the safety alert symbol. This symbol alerts you to
potential hazar s that can cause eath or serious injury. All
safety messages will follow the safety alert symbol an either
the wor “WARNING” or “CAUTION”. These wor s mean:
This symbol will alert you to hazar s or unsafe
practices which coul cause serious bo ily
harm or eath.
WARNING
This symbol will alert you to hazar s or unsafe
practices which coul cause bo ily injury or
property amage.
CAUTION

5
Electrical Safety
• This appliance must be connecte to the mains power supply by a
specially licensed electrician only.
• Electrical lea s an cables shoul not be allowe to touch the
oven.
• The oven should be connected to the electricity supply by
means of a proper circuit breaker or fuse. Never use
multiple plug adapters or extension leads.
• This connection may be achieved by having the plug
accessible or by incorporation a switch in the fixed wiring
in accordance with the wiring rules.
- Failure to o so can result in a fire.
WARNING

6
Safety
Damage
• If the oven has been damaged in transport, do not connect
it.
• In the event of a fault or damage to the appliance, do not
attempt to operate it.
• Repairs of the appliance should be carried out by a
licensed technician only. Wrong repairs may result in
considerable danger. If you need repairs, contact an LG
Service Center or your dealer.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
• Never remove the outer casing from the oven. If the oven
is faulty and needs servicing or you are in doubt about its
condition, unplug it from the wall socket and contact the
nearest after-sales service centre
- Failure to o so can result in malfunctioning an eath or
electrical shock when using.
WARNING

7
Maintenance
• The power supply of the appliance should be turned off
when it is being repaired or cleaned.
• Be careful in connecting electrical appliances to sockets
near to this appliance.
• Do not use high-pressure water cleaners or steam jet
cleaners for electrical safety reasons.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of the
glass.
• The appliance should be powered down before replacing
the lamp to avoid the possibility of electric shock.
- Failure to o so can result in malfunctioning an eath or
electrical shock when using.
WARNING

8
Safety
Safety during Operation
• Do not touch interior parts until it has cooled down
sufficiently.
- When the oven operates, the interior parts will be very hot
an burns may occur.
WARNING
• Accessible parts may become hot during use. Young
children should be kept away.
• Accessible parts may become hot when the grill is in use,
children should be kept away.
• The appliance is not intended for use by young children or
infirm persons without supervision.
• Young children should be supervised to ensure that they
do not play with the appliance.
• Children should be kept at a safe distance when the oven
operates.
• Children should be kept at a safe distance until the oven
has cooled down after cooking.
• This appliance is not intended for use by persons
including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
WARNING

9
• Never block the air vents
- The oven may overheat an automatically switch itself off. It
will remain inoperable until it has coole sufficiently.
• Do not cover or obstruct the ventilation with cloths or
paper.
- The cloths or paper may catch fire as hot air is emmite from
the oven.
• Do not spill or pour water in the vents.
WARNING

10
Safety
Safety during Operation
• When in use, the oven interior surfaces become very hot!
Care should be taken to avoid touching heating elements
inside the oven.
- These walls may be hot enough to burn skin even after
cooking is finishe , though they o not appear to be so, avoi
placing han s an arms insi e the oven.
• The oven surfaces will become hot when the appliance is
operated at a high temperature for a long period of time.
• The oven door must be closed when cooking is
performing.
• When cooking, take care when opening the oven door as
hot air and steam will escape rapidly.
- The hot air or steam release may cause scal ing.
• When cooking dishes that contain alcohol, the alcohol can
evaporate due to the high temperatures. The vapor can
catch fire if it comes into contact with a hot oven part.
• Never store flammable or easily deformable materials in
the oven to reduce the risk of fire in the oven cavity.
• Should an oven fire occur, leave the oven door closed and
turn the oven off. If the fire continues, throw baking soda
on the fire or use a fire extinguisher. Do not put water or
flour on the fire.
- Flour may be explosive an water can cause a grease fire to
sprea an cause personal injury.
• Use oven gloves when removing a dish from the oven.
- The trays an racks are hot.
WARNING

11
• The oven must be secured by screwing a minimum of 2 thin
general purpose self tapping screws into the 2 upper
mounting holes located on the outer side facias, into the
cabinetry. Check if the oven is installed properly
• Do not store or operate this equipment outdoors. Do not use
this product near water for example,near a kitchen sink, in a
wet basement, or near a swimming pool, and the like)
• Be sure all packing materials are removed from the
appliance before operating it.
• Do not use this oven for commercial purposes.
- This oven has been esigne only for the cooking of househol
foo s an for Domestic use.
• Do not use the oven door as a rest table for hot or cookware.
• Never use your appliance for warming or heating the room
• Do not step, lean, or sit on the door of the oven.
- These can cause the oven to tip resulting in burns or
serious injuries
WARNING
• Do not touch an electric cord with a wet hand.
- It is very angerous. You can get an electric shock.
• Be careful not to damage the power cable.
• Do not operate this appliance if it has a damaged power
cable or plug.
• Do not immerse power cable or plug in water and keep
power cable away from heated surfaces.
• Do not let cord hang over edge of table or counter.
WARNING

12
Safety
Safety during Operation
• Don’t spread aluminium foil on the bottom of the oven and
do not place any baking trays or tins on it.
- The aluminium foil blocks the heat, which may result in
amage to the enamel surfaces an cause poor cooking
results an this will result in poor baking by lack of heat
circulation.
WARNING
• Please ensure cooking times are correctly set
- Over cooking may result in the foo catching fire an
subsequent amage to your oven.
WARNING
• Don’t pour water into the oven bottom when it is hot.
- This coul cause amage to the enamel surface an eform
the base.
• When cooking very moist cakes, use the deep pan.
- Dripping fruit juices from the baking tray will leave stains,
which become in elible.
• Frozen foods such as pizzas should be cooked on the wire
grill.
- If the Baking tray is use , it may become eforme ue to the
great ifference in temperature.
• Do not heat unopened food containers.
- Buil -up of pressure may cause the container to burst an
result in injury.
WARNING

13
Disposal
• Your new oven has been correctly packaged for
transportation. Remove all of the packaging material
before putting the appliance into use.
• The packaging material can be completely recycle . You can
obtain a resses for environmentally-frien ly isposal operations
from your local authority.
• If you wish to store your oven away temporarily, choose a ry,
ust-free place. Dust an amp may a versely affect the working
parts in the oven.
CAUTION

14
Safety
For the protection of the environment,used appliances must be
Disposed of property.
• The appliance must not be ispose of along with normal
omestic waste.
• Your local authority will inform you of times for uplifting special
waste or i entify public isposal facilities for you.
Used appliances
Used appliances must be rendered unusable prior to
disposal so that they no longer present a risk. To achieve
this, disconnect from the mains supply and remove the
power supply cable.
WARNING

15
Overview
Appliance description
Top-heating
an grill heating
element
Si e runners
Control panel
Door
han le
Air outlet
Oven light
Door seal
Rear wall heating
element
Oven cavity
Fat Filter
Full glass oor
Level 6
Level 5
Level 4
Level 3
Level 2
Level 1
Oven levels are numbere from the bottom up.
The 5 an 6 levels are mainly use for grill functions. Always grill
with the oor close .
The cooking tables throughout this operating instructions give you
suggeste oven level, however you can change these to suit
yourself.
Note : Rating plate can be locate at left-han inner e ge of the
oor or front-si e of the oven.
Rating plate

16
Control panel
23
1
1. Display for Temperature/Time
2. Time button
3. Function selector

17
5
4
4. Temperature/Time selector
5. “OK” (Enter or Yes) button

18
Fat filter
For protecting the fan against fat buil ing up.
The filter may be in place when the fan is use
for roasting.
Note:
To install the fat filter, insert the two hooks
Into the holes on the fan cover as
illustrate .
The fat filter must cover the fan venting
holes completely. Do not use the fat filter
In baking mo e, as it restricts the air flow.
Wire grill
For ishes, baking tins, grilling an
roasting tins.
For grilling meat, place the wire grill on
the upper level above the eep pan.
Baking tray
For cakes, sponges an biscuits.
Deep pan
For moist cakes, for roasting an for
catching roasting juices or fat.
Grill tray
For grilling meat, to be place on top of
the eep pan. Dripping fat is caught in the
eep pan.
Accessories

19
Tips on using the trays and wire grills
Ensure that the trays
an wire grills are
properly fitte onto the
two si e oven levels.
Take particular care
when removing finishe
ishes an meals from
the oven!
Use a suitable cloth pot
hol er or oven gloves.
If you are using the wire grill in combination with the eep pan or
some other tray to catch ripping liqui s or fat, then o not put the
trays own on the bottom of the oven, sli e them into the lower
levels.
If you place trays on the oven floor, the resulting buil -up of heat
can amage the surface of the oven. For this reason, there must
always be a minimum gap of 2 cm between the accessories an the
oven floor.
Fitting the wire grill, baking tray and deep pan
Sli e the tray or wire grill in at
the esire level.
The oven levels are numbere
from the bottom up to the top.
6
5
3
2
1
4
6
5
3
2
1
4
Deep pan
Baking tray
gap 2cm

20
Side runners
Attaching the side runners
Note !
If you purchase the catalytic liners, refer to the proce ures of
attaching catalytic liners at page 23 for si e runners.
When using the oven for the first time, attach the side runners
as following procedures.
You can find the side runners in the accessory box.
1. Place the U-form of the si e
runner between the two screw
holes as illustrate .
2. Insert an fasten the two
screws clockwise.
3. Attach the other in the same way.
