IT’S A BIG DEAL
Our LG EasyClean™ double oven is equipped with an
enormous 6.7 cubic feet of room plus an upper oven
that’s 6” high- which gives you easy access to your
oven with room to cook more. Now you can bake
and broil tall items in the small oven without having
to pre-heat your entire oven. Or you can use both
ovens and cook two dishes at once. Either way, your
cooking will taste larger than life.
The next generation of oven cleaning,
EasyClean™, provides a quick and easy way
to clean your oven while still being able to
use the conventional self-clean method.
Just spray water, and after 20 quick
minutes, simply wipe away the mess.
Cook two meals at once – Allows you
to cook different dishes at different
temperatures all at the same time. Gives
you room for everything you’d need for a
holiday dinner.
Easy to use and easy to clean, the
IntuiTouch™ Control System makes
operating your range a snap. The left side
of the panel mirrors the cooktop elements,
while the right side controls the oven
functions.
Freestanding Electric Double Oven
LDE3035
COOKING PERFORMANCE
•6.7 cu. ft. Total Oven Capacity
(2.3 cu. ft. / 4.4 cu. ft.)
•EasyClean™ Technology
•Tall Upper Oven (6”)
•4 Radiant Elements
STYLE AND DESIGN
•Available in Stainless Steel,
Smooth White, Smooth Black Finishes
•WideView™ Window
•Brilliant Blue Interior
CONVENIENCE
•IntuiTouch™ Keypad
•GoCook™ Oven Light
•12 Hr. Automatic Shut-Off
•Self-Cleaning (Upper and Lower Ovens)
•Recessed Broiler Safe for your hands
EasyClean™ Technology Large Capacity IntuiTouch™ Control System

Freestanding Electric Oven
LDE3035
CapaCity
Upper Oven 2.32 cu. ft.
Lower Oven 4.38 cu. ft.
Total 6.7 cu. ft.
OVEN FEatURES
EasyClean™ Technology •
Configuration Freestanding Electric Double Oven
Bake Element (Upper) 2100W / 4 Pass (Exposed Bake)
Broil Element (Upper) Sheathed Heater, 3200W
Bake Element (Lower) 2500W / 4 Pass (Exposed Bake)
Broil Element (Lower) 3800W / 6 Pass
Oven Cooking Modes Bake, Broil, Proof (lower only), Warm
Oven Cleaning Features Delay Bake, Delay Clean, Automatic Shut-Off
Cleaning EasyClean™, Self Clean
Oven Light •
Oven Rack 2 Standard Racks & 1 Offset
Oven Rack Positions 7
Sabbath Mode Star-K Certified
COOKtOp
Element Configuration
Left Front 9" / 2500W
Left Rear 6" / 1200W
Center (Warm Zone) 7" / 100W
Right Front 9" / 6" 3200W / 1400W
Right Rear 6" / 1200W
Cooktop Burner Type Radiant
Cooktop Finish Grey Patterned on Black Ceramic Glass
CONtROl
Control Location Backsplash
Control Type IntuiTouch™ Keypad
Control Display VFD (Scrolling Display)
appEaRaNCE
Available Colors Stainless Steel, Smooth White, Smooth Black
Handle Matching Stainless
Oven Door Feature Large WideView™ Window, Full SS Wrap
DiMENSiONS/ClEaRaNCES/WEiGHt
Shipping Weight (lbs) 263
Product Weight (lbs) 213
Cabinet Width (in) 30"
Overall Depth (in) 28 3/16"
Overall Height (in) 47 7/16"
Overall Width (in) 28 3/16"
Shipping Dimensions (WxHxD) 33" x 49 5/8" x 29 15/16"
Oven Interior Dimensions (Upper) (in) (W x H x D) 24 1/2" x 9 9/16" x 18 15/16"
Oven Interior Dimensions (Lower) (in) (W x H x D) 24 1/2" x 16 5/16" x 18 15/16"
Height to Cooking Surface (in) 36"
pOWER/RatiNGS
Amp Rating at 208V 10.3 KW
Amp Rating at 240V 13.8 W / 57.4 A
KW Rating at 208V 120/208 VAC
KW Rating at 240V 120 / 240 VAC
WaRRaNty
Warranty 1 year parts and labor (in home service)
5 years limited on cooktop and radiant surface units (in home service)
UpC CODES
LDE3035ST Stainless Steel 048231 318259
LDE3035SW Smooth White 048231 318266
LDE3035SB Smooth Black 048231 318273
