LG GR-C502HLCU User manual

Please read this manual carefully before operating
your set and retain it for future reference
OWNER’S MANUAL
REFRIGERATOR
P/NO : MFL67477515
Copyright © 2019-2021 LG Electronics. All rights reserved
Rev.04_170821
FRENCH ARABIC
ENGLISH

2
Starting
Before Setting The Temperature
Door Alarm
Self Test
Controls For Freezer Compartment
Controls For Refrigerator Compartment
Express Freeze (Optional)
Child Lock (Optional)
Wi-Fi (Optional)
Door Cooling+
Vegetable Drawer
Defrosting
Deodorizer
Ice Making
Hygiene Fresh (Optional)
Water Dispenser (Optional)
Lamp Replacement
Inverter-On Feature (Optional)
Vacation Time
G*-*4**/ G*-*5**
CONTENTS
IMPORTANT SAFETY INFORMATION......................3
INSTALLATION ........................................................12
INNER PARTS..........................................................13
OPERATIONS ..........................................................15
SUGGESTIONS ON FOOD STORAGE...................25
CLEANING ...............................................................26
GENERAL INFORMATION ......................................28
IMPORTANT WARNINGS........................................29
BEFORE CALLING FOR SERVICE.........................30
SMART FUNCTIONS (Only for applied models)......22

3
IMPORTANT SAFETY INFORMATION
To reduce the risk of fire, electric shock, or injury to persons when using your product, basic safety
precautions should be followed, including the following. Read all instructions before using this
appliance.
WARNING
BASIC SAFETY PRECAUTIONS
This guide contains many important safety messages. Always read and obey all safety messages.
This is a safety alert symbol. It alerts you to safety messages that inform you of hazards that can
hurt or seriously injured or cause damage to the product. All safety messages will be preceded
by the safety alert symbol and the hazard signal word DANGER, WARNING, or CAUTION.
These words mean:
WARNING
DANGER
CAUTION
You will be hurt or seriously injured if you
don’t follow instructions.
To reduce the risk of fire, electric shock,
or injury to persons when using your
product, basic safety precautions should
be followed, including the following.
Read all instructions before using this
appliance.
Indicates an imminently hazardous
situation which, if not avoided, may
result in minor or moderate injury, or
product damage only.
All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you
what can happen if the instructions are not followed.

WARNING
Keep ventilation openings, in the appliance
enclosure or in the built-in-structure, clear of
obstruction.
Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food
s to r ag e c o mp a rt m en t , u n l e s s t h e y a r e
recommended by the manufacturer.
The refrigerant and insulation blowing gas used in
the appliance requires special disposal procedures.
When disposal, please consult with services agent or
a similarly qualified person.
4
IMPORTANT SAFETY INFORMATION

5
This symbol alerts you to flammable materials
that can ignite and cause a fire if you do not take
care.
This appliance contains a small amount of isobutane
refrigerant (R600a), but it is also combustible. When
transporting and installing the appliance, care should be
taken to ensure that no parts of the refrigerating circuit
are damaged.
If a leak is detected, avoid any naked flames or potential
sources of ignition and air the room in which the
appliance is standing for several minutes. In order to
avoid the creation of a flammable gas air mixture if a
leak in the refrigerating circuit occurs, the size of the
room in which the appliance is used should correspond
to the amount of refrigerant used. The room must be 1
2
m in size for every 8 g of R600a refrigerant inside the
appliance.
When positioning the appliance, ensure the supply cord
is not trapped or damaged.
Do not locate multiple portable socket-outlets or
portable power supplies at the rear of the appliance.
Risk of Fire and Flammable Materials
IMPORTANT SAFETY INFORMATION

IMPORTANT SAFETY INFORMATION
1. When connecting the power
Dedicated outlet should be used.
Using several devices at
one outlet may cause fire.
Do not allow the power plug to face
upward or to be
squeezed at the back
of the refrigerator.
Plug may get damaged,
which causes fire or
electric shock.
Do not allow the power cord to bend or
pressed by heavy object. Do not extend or modify the length of the power plug.
It may damage the power
cord and cause fire or
electric shock.
It damages the power cord
and cause electric shock
or fire.
Unplug the power plug while cleaning,
handling or replacing the interior LED
lamp of the refrigerator.
It may cause electric
shock or injury.
Remove water or dust from the power
plug and insert it with the ends of the
pins securely connected.
Make sure of grounding.
Dust, water or unstable
connection may cause
fire or electric shock.
Incorrect grounding
may cause
breakdown -and
electric shoc
When the power cord or the power plug is
damaged or the holes of
the outlet are loosed,
do not use them.
It may cause electric shock
or short circuit.
The tempered glass on
door can be broken
by impact, do not touch the
broken parts you may
injured.
Do not pull out the cord or touch the power
plug with wet hands.
It may cause electric
shock or injury.
6

7
IMPORTANT SAFETY INFORMATION
2. When using the refrigerator
Do not place heavy object or the
dangerous object
(container with liquid)
on the refrigerator.
Do not cling to the door or the shelves
of the door or home bar of the
freezer or the cool chamber.
It may fall and cause injury,
fire or electric shock when
opening or closing the door.
It may make the refrigerator
fall over or damage the
hands. Especially, do not
allow the children to do
the above.
Do not install the refrigerator in wet
place or place where
water or rain splashes.
Deterioration of insulation
of electric parts may cause
electric leakage.
Do not use or store
inflammable materials like
ether, benzene, alcohol,
medicine, LP gas, spray or
cosmetics
near or in the
refrigerator.
It may cause
explosion or fire.
Do not use drier to dry the inside,
nor light a candle to
remove odor
Do not store medicine or academic
materials in the refrigerator.
It may cause
explosion or fire.
When the material with
strict temperature
control is stored, it may be
deteriorated or it may
make an unexpected
reaction to cause
any risk.
Do not use the combustible spray near the
refrigerator. Install in places away from the fire such as the place where flammable
gas is leaked.
It may cause fire. It may cause fire.

8
If there is a gas leakage (isobutane, propane,
natural gas, etc.), do not touch the appliance
or power plug and ventilate the area
immediately. This appliance uses a refrigerant
gas (isobutane,R600a). Although it uses a
small amount of the gas,
it is still combustible
gas. Gas leakage
during appliance
transport, installation
or operation can
cause fire,
explosion or injury if sparks are caused
IMPORTANT SAFETY INFORMATION
Do not place flower vase, cup, cosmetics,
medicine or any container
with water on the
refrigerator.
Use the submerged refrigerator only after
checking it.
It may cause fire, electric shock
or injury by dropping down.
It may cause electric
shock or fire.
When gas is leaked, do not touch the
refrigerator or the outlet and ventilate the
room immediately.
Do not spray water at the outside or the inside
of the refrigerator or do not clean it with
benzene or thinner.
Deterioration of insulation
of electric parts may
cause electric shock
or fire.
When any strange smell or smoke is detected
from the refrigerator, disconnect the power
plug immediately and contact to the
service center.
It may cause fire.
2. When using the refrigerator
Do not allow any person except the
qualified engineer to disassemble, repair
or alter the refrigerator.
It may cause injury,
electric shock or fire.
When disposing the refrigerator, remove
the packing materials like gasket
from the door
It may cause to lock
out the child.
Do not use the refrigerator for non-domestic
purpose (storing medicine or testing
material, using at the ship, etc.).
It may cause an unexpected
risk such as fire, electric
shock, deterioration
of stored material or
chemical reaction.
Install the refrigerator on a solid and level
floor.
Installing it on an unstable
place may cause injury by
falling down the refrigerator
when opening or
closing the door.

9
Do not insert hand or metal stick into the
exit of cool air, cover, bottom of the
refrigerator, heat proof grill (exhaust hole)
at backside.
What to do with your old refrigerator,
It may cause electric
shock or injury.
Your refrigerator contains liquid
(refrigerant, lubricant) made of
recyclable materials, All these
materials must be sent to a
recycling waste disposal site
as they can be reused after a
specific recycling process.
In case of thunder and lightning, or if not
in use for a long period
of time, detach
the power plug.
Place all the components
in the right
places before
connecting the
power.
There is a danger of
electric shock or fire.
Do not remove the
back cover. Never leave lit candles on the fridge, high risk of causing
fire or product
damage.
IMPORTANT SAFETY INFORMATION
2. When using the refrigerator

10
Do not place glass
containers, bottles or cans
(especially those containing
carbonated drinks) in the
freezer compartment,
shelves or ice bin that will
be exposed to
temperatures below
freezing.
CAUTION
Wait for 5 minutes or longer when
reconnecting the plug.
It may cause the operation
of the freezer to fail.
Do not touch food or containers at the
freezer with wet
hands.
Do not put bottle in the freezer.
It may cause frostbite.
Violating these directions may cause injury or damage to health, house or furniture. Always be careful,
please.
Carry the refrigerator with the handle bar
provided at the bottom-front and
top-rear of the
refrigerator.
Otherwise, your hands
may be slipped to
cause injury.
Pull out the power plug not by grasping the
cord. But by the plug of its
end.
It may cause electric shock
or short circuit to fire.
Do not insert hand into the bottom of
the refrigerator.
The iron plate of the bottom
may cause injury.
Completely empty inside before taking
out the container from the door.
Opening or closing the door of the
refrigerator may cause injury to the
person around it, please be careful.
Opening or closing the
door may cause feet
or v hands to be
caught in the chink
in door or child hand
get hurt by the corner.
IMPORTANT SAFETY INFORMATION

11
Please do not use a dishwasher to clean the lower
drawers; the high temperature may cause damage to
the baskets which make them unusable.
If the appliance is equipped with a lock (some countries
only), keep the key out of reach of children.
This appliance is intended to be used in household and similar applications such as
- staff kitchen areas in shops, offices and other working environments;
- farm houses and by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
Do not use carbonated water. Gas pressure
may cause leakage.
Clean the water tank according to the
instructions.
Do not lean on the doors, Hinges may
deregulate themselves,
causing air leak and
performance
deterioration
Use only water. If any other liquid is used,
the operation of the system may be
deteriorated. If a problem occurs by using
any liquid other than water,
the manufacturer
will not be
responsible.
Movable parts like shelf, basket, etc
should be handled with care.
May get damaged or break if dropped.
Do not put any living animal in the
refrigerator.
WARNING
THIS REFRIGERATOR IS MANUFACTURED WITH GREAT CARE, AND UTILIZES THE
LATEST IN TECHNOLOGY.
WE ARE CONFIDENT THAT YOU WILL BE FULLY SATISFIED WITH IT'S PERFORMANCE AND
RELIABILITY.
BEFORE YOU START YOUR REFRIGERATOR, PLEASE READ THIS BOOKLET CAREFULLY.
IT PROVIDES EXACT INSTRUCTIONS FOR INSTALLATION, OPERATION AND
MAINTENANCE, AND ALSO SUPPLIES SOME USEFUL HINTS.
IMPORTANT SAFETY INFORMATION

12
Inverter-On feature (Optional)
Minimum requirement: UPS/ Inverter should be in ON condition having minimum 600VA capacity
along with minimum 120Ah capacity battery connected with the refrigerator’s power supply socket.
1. Clean your refrigerator thoroughly and wipe off
all dust accumulated during shipping.
2. Install accessories such as ice cube box, etc.,
in their proper places. They are packed
together to prevent possible damage during
shipment.
3. Connect the power supply cord (or plug) to the
outlet. Don't double up with other appliances
on the same outlet.
4. Prior to storing food, leave your refrigerator on
for 2 or 3 hours.
Check the flow of cold air in the freezer
compartment to ensure proper cooling. Your
refrigerator is now ready for use.
5. After installing the appliance, connect the
power plug into a socket outlet. Before moving
and discarding the appliance, disconnect the
plug from the socket outlet.
Dimensions and Clearances
Too small of a distance from adjacent items may
result in degradation of freezing capability and
increased electricity costs. Allow over 50mm
clearance from each adjacent wall when
installing the appliance.
Ambient Temperature
The appliance is designed to operate within a
limited range of ambient temperatures,
depending on the climate zone. do not use the
appliance at a temperature exceeding the limit.
The internal temperatures could be affected by
the location of the appliance, the ambient
temperature, the frequency of door opening and
so on.
The climate class can be found on the rating
label.
Climate Class
0
Ambient Temperture Range C
SN (Extended Temperate)
+10 - +32
N (Temperate)
+16 - +32
ST (Subtropical)
+16 - +38
T (Tropical)
+16 - +43/+10 - +43*
*Australia, India, Kenya
NOTE
The appliances rated from SN to T are intended
to be used at an ambient temperature between
0 0
10 C and 43 C
Image for representation purpose only
INSTALLATION
1. Select a good location.
Place your refrigerator where it is easy to use.
2. Avoid placing the unit near heat sources,
direct sunlight or moisture.
3. To avoid vibrations, the unit must be level.
If required, adjust the leveling screws to
compensate for unevenness of the floor.
The front should be slightly higher than the
rear to aid in door closing.
Leveling screws can be turned easily by
tipping the cabinet slightly.
Turn the leveling screws clockwise ( ) to
raise the unit, counterclockwise ( ) to lower
it.
4. Don't install this appliance below 5 °. It may
cause the debasement of the refrigerator.
NEXT
-
G*-*5**
G*-*4**
A
700
700
B
1780
1680
C
730
730
D
25
25
E
660
660
F
705
705
G
1331
1331
H
1232
1232

13
SUGGESTION FOR ENERGY SAVING
- Please do not keep the door open for a long time, close door in the shortest time.
- Too much food are not advised to be put I enough space should be kept for cool air circulating
freely.
- Do not set the temperature of refrigerator lower than needed. Do not put the food near the
temperature sensor.
- Allow hot food to cool prior to storing. Placing hot food in the fridge-freezer could spoil other food,
and lead to higher electric bills.
- Do not block air vents with food. Smooth circulation of cold air keeps fridge-freezer temperature
even.
- Do not open the door frequently. Opening the door lets warm air enter the fridge-freezer, and
cause temperature to rise.
- The automatic defrosting system in the appliance ensures that the compartment remains free of
ice build up under normal operating conditions
- This guide covers several different models. The refrigerator you have purchased may
have some or all of the features shown above.
- To keep a position of inner parts like as baskets, drawers and shelves supplied by
manufacturer is the most efficient usage for energy saving.
- Due to continuously development, model specification subjected to change.
Smart Diagnosis
Freezer Door Rack
Water Tank
Refrigerator Door
Rack
Egg Tray
Levelling Screw
Vegetable Drawer
Hygiene Fresh
(Optional)
Shelves
Deodorizer
Fresh Room Drawer
/Pull Out Tray (Optional)
Lamp
REFRIGERATOR
COMPARTMENT
FREEZER
COMPARTMENT
Lamp
Shelf
Twisting Ice Serve
Type Ice Making
Water Dispenser Model
Freezer Temperature
Control Dial
INNER PARTS
NOTE

14
Vegetable Drawer
Hygiene Fresh
(Optional)
Shelves
Deodorizer
Fresh Room Drawer
/Pull Out Tray (Optional)
Lamp
REFRIGERATOR
COMPARTMENT
FREEZER
COMPARTMENT
Lamp
Shelf
Twisting Ice Serve
Type Ice Making
Non Water Dispenser Model
Smart Diagnosis
Freezer Door Rack
Refrigerator Door
Rack
Egg Tray
Levelling Screw
Freezer Temperature
Control Dial
Refrigerator Door
Rack
(Optional)
INNER PARTS
SUGGESTION FOR ENERGY SAVING
- Please do not keep the door open for a long time, close door in the shortest time.
- Too much food are not advised to be put I enough space should be kept for cool air circulating
freely.
- Do not set the temperature of refrigerator lower than needed. Do not put the food near the
temperature sensor.
- Allow hot food to cool prior to storing. Placing hot food in the fridge-freezer could spoil other food,
and lead to higher electric bills.
- Do not block air vents with food. Smooth circulation of cold air keeps fridge-freezer temperature
even.
- Do not open the door frequently. Opening the door lets warm air enter the fridge-freezer, and
cause temperature to rise.
- The automatic defrosting system in the appliance ensures that the compartment remains free of
ice build up under normal operating conditions
- This guide covers several different models. The refrigerator you have purchased may
have some or all of the features shown above.
- To keep a position of inner parts like as baskets, drawers and shelves supplied by
manufacturer is the most efficient usage for energy saving.
- Due to continuously development, model specification subjected to change.
NOTE

15
The higher number the control setting is, the lower the temperature of the freezer compartment
becomes
Since the temperature of the refrigerator and freezer compartments is controlled with a fixed amount
of. cooled air, the refrigerator compartment will be warmer if the freezer compartment becomes
colder.
When the freezer compartment is not cold enough in winter, adjust the control for the freezer to High
(6~8).
STARTING
BEFORE SETTING THE TEMPERATURE
DOOR ALARM
SELF TEST
CONTROLS FOR FREEZER COMPARTMENT
OPERATIONS
Your refrigerator contains a built in diagnostic capability. If it develops a malfunction in certain areas, it
will display an error code to assist the repair technician. While an error code is displayed, other
control and display functions will not operate.
If an error code is displayed, contact a service center. Do not disconnect the power cord from the
outlet.
When the door of the refrigerator or the freezer is open for 1 minute, an alarm will sound three times. It
the door remains open, the alarm will repeat every 30 seconds.
The temperature of the refrigerator is kept constant regardless of changes in room temperature. It is
recommended that, once set, the temperature settings(the controls for the refrigerator and freezer
compartments) not be changed unless necessary.
This refrigerator has one temperature control button for the refrigerator compartment and one
temperature control dial for the freezer compartment.
The default setting of the temperature control button for the refrigerator compartment is '3' or '4'.
The default setting of the temperature control dial for the freezer compartment is '5'.
This refrigerator has a temperature sensor in the refrigerator compartment. It will start and stop the
compressor automatically as needed.
When your refrigerator is first installed, allow it (7-8 hours) to stabilize at normal operating
temperatures prior to filling it with fresh or frozen foods.
If operation is interrupted, wait 5 minutes before restarting.

CONTROLS FOR REFRIGERATOR COMPARTMENT
16
COLD COLDEST
Ref. Temp Control Button
REF. TEMP CONTROL The default setting of the temperature control button
for the refrigerator compartment is NORMAL.
To control the refrigerator temperature, press the REF.
TEMP CONTROL button.
Whenever pressing the button, LED emitting the light.
The temperature is set in 7 steps, from COLD to
COLDEST cooling. (COLD = warmest, COLDEST =
coldest temperature)
FOR INTERNAL CONTROLLER MODEL
FOR EXTERNAL CONTROLLER MODEL
Display graphic can be different, depend on the type of your refrigerator.
Press ‘Hygiene Fresh’ button to operate hygiene fresh motor (optional).
The number showing up on the LED luminesce indicate the temperature of refrigerator compartment.
0
Press ‘FRIDGE’ button to control refrigerator temperature.
EXPRESS FREEZE (OPTIONAL)*
When the refrigerator is first turned ON the EXPRESS FREEZE feature can be turn ON. The
compressor and circulating fan operate at maximum cooling capacity to quickly lower the refrigerator
temperature. It shuts off automatically.
For non-dual display
For dual display
• If warm food is placed into the refrigerator, FAST FREEZING can be started with the button on the control
panel. FAST FREEZING will shut off when the temperature reaches the proper level or it can be shut off
manually by pressing the FAST FREEZING button.
For non-dual display
For dual display
O
- Press a button, Fridge temperature will be down each 1 C
Whenever pressing the button, the LED emits light.
- Press b button, Hygiene Fresh motor will be on, power mode, off.
OPERATIONS

17
CHILD LOCK (OPTIONAL)*
• CHILD LOCK
Press and hold the child lock button for 3 seconds to lock the child lock. When it is locked, the Lock LED
will be on and the other button will not operate. To unlock, press and hold the CHILD LOCK button for 3
seconds again.
For non-dual display
For dual display
This sets the refrigerator to connect to your home's Wi-Fi network.
Wi-Fi (OPTIONAL)*
For non-dual display
For dual display
DOOR COOLING+
If water of foreign substances enter the cool air vent while cleaning,
efficiency will be lowered.
VEGETABLE DRAWER
How to use
Vegetable drawer can be used through the control of knob.
Check the position of knob prior to store the food.
Do not locate the knob on the middle point.
* This feature will be OFF by itself, if the refrigerator is switched OFF.
OPERATIONS
Wireless function S/W version : V 1.0
For the consideration of the user, this device should be installed and operated with a minimum distance of
20 cm between the device and the body.
Wireless LAN module Specifications
Model
LCW-008
Frequency Range
2412 to 2472 MHz
Output Power (Max)
IEEE 802.11b: 17.93 dBm
IEEE 802.11g: 17.92 dBm
IEEE 802.11n (HT20): 17.79 dBm
IEEE 802.11n (HT40): 16.93 dBm

18
ICE MAKING
Twisting Ice Serve Type
To make ice cubes, fill the ice tray with water and insert
in its position.
To remove ice cubes, hold the lever of the tray and pull
turn gently. Then, ice cubes drop in to the ice cube box.
WARNING
WARNING
Fill with potable water only.
NOTE
You can disassemble the Ice Maker to
secure space in the freezer.
Ice Trays
Ice Cube Box
<Twisting Ice Serve Type>
1
2
Twisting Ice Serve Type: Remove 1 and 2
1. Ice Tray
2. Ice Cube Box
Do not use anything other than water.
Fill the water up to the marked line.
DEFROSTING
DEODORIZER
OPERATIONS
Defrosting takes place automatically.
The defrosted water flows down to the evaporating tray which is located in the lower back side of the
refrigerator and is evaporated automatically.
Unpleasant odor of food in fresh food
compartment is deodorized with no harm to
the user and the food.
As Deodorizer is located in cooling air inlet for circulating air in fresh food compartment, there is no
need for any handling.
Do not prick the cooling air inlet with a sharp tip because Deodorizer may get damaged.
When storing food with strong odor, wrap it or store it in a container with a lid because odor may be
passed on to other foods.
Re-Using of Deodorizer
Deodorizer can be revived and re-used.
Separate the Deodorizer from the refrigerator
Use hair drier to remove moisture or malodor
and oxidize under sunl
How to use

19
HYGIENE FRESH (OPTIONAL)
CAUTION
Before installing or using the product, make sure to read
the owner's manual carefully to use the product
accurately as intended. This HYGIENE FRESH filter
has the antibacterial function of removing the virus or
bacteria inside the refrigerator and the deodorizer
function to remove the scent.
To use the HYGIENE FRESH filter, touch the button on the display panel on the front side
of the door and switch over to the AUTO or POWER mode.
(Whenever you touch the button, the HYGIENE FRESH filter will be switched to
POWER OFF AUTO.)
• •
AUTO
Switch over to use mode
Switch over to use mode.
When the user switches to AUTO or POWER mode, the
LED around the filter is also turned on. Do not put in
your finger or alien particles inside the fan. It can be
caused of an injury or malfunction.
CAUTION
CAUTION
Do not wash the HYGIENE FRESH filter by using
water because it can be caused of malfunction.
This filter may not be effective for all types of bacteria
and virus.
This is effective to remove the bacteria which is not on
the food in the refrigerator.
You can purchase the HYGIENE FRESH filter at the nearest distributor or the service center.
POWER OFF AUTOAUTO
OPERATIONS

WATER DISPENSER (OPTIONAL)
20
Pour water after the water tank is in position.
Necessarily separate the water tank to clean it our when not in use.
When the water tank is not in position after filling it with water, water can leak out by the valve.
Pouring water in the water tank
1. Open the cover cap and pour water into the
water tank.
2. Close the cover cap.
3. The water tank is optional removable part
which can be applied to enlarge the storage
capacity. You can use the upper basket after
removing the water tank and closing up the
hole with a plug.
The plug is enclosed with the egg tray.
CAUTION
Do not use anything other
then water, even hot
water needs to be cooled
before being poured into
the water tank.
Do not fill more than the
indicated level.
Drinking Water
1. Press the dispenser pad with cup.
2. The water is released when the dispenser pad is pressed. The pad returns to its original position
when the cup is removed and the water stops its flow.
Cover Cap
OPERATIONS
NOTE
