LG 24MT35S-PZ.AEK User manual

SMART TV
Quick Setup Guide
Please read this manual carefully before operating
your set and retain it for future reference.
www.lg.com
P/NO: MFL67883501 (1402-REV03)
Printed in Korea
*MFL67883501*

ENG
ENGLISH
2
Wireless Network Connection
Wired Network Connection
* Image shown may differ from your TV.
* Image shown on a PC or mobile phone may vary depending on the OS(Operating System).
Internet connection
Wired router
wireless router

ENGENGLISH
3
Network Setting
Premium Apps are pre-installed on the TV. These may vary by country.
1 Press the SMART button to access the
Smart Home menu. Select Settings and press
Wheel(OK).
Ö
Settings
More
More
Settings
2 Select the NETWORKĺNetwork Connection
menu.
Network Connection
Network Status
Soft AP
Wi-Fi Direct
NETWORK
MiracastTM / Intel's WiDi
My TV Name : **
3 Select the Start Connection.
Connect to your wired or wireless network.
Network Connection
To connect to a wired network:
Connect a LAN cable to the back of TV.
To connect to a wireless network:
Requires a wireless router or access point.
Start Connection
or
Enjoy various Smart TV features through network.
4 The device automatically tries to connect to the
network available(wired network first).
Cancel
Connecting to the network.
Network Connection
If you select Cancel or it fails to connect to the
network, the network list available is displayed.
Choose the network you want.
Choose the network you want.
Wired Network
Wireless : AAA
Wireless : BBB
Wireless : CCC
Wireless : 11111
Wireless : 22222
Manual Setup
Refresh List
Network Connection
If you want to connect your TV to a wireless router,
select the network you want and enter the password.
Network Connection
Wireless : AAA
Forgot your password? Contact your AP manufacturer.
Enter security key of network.
5 The connected network is displayed.
Select Complete to confirm the network connection.
If you select the Other Network List, the network
list available is displayed.
Network is connected.
Wireless:AAA
Select [Other Network List] to connect to another network.
Complete Other Network List
Network Connection

ENG
ENGLISH
4
1 Press the SMART button to access the Smart
Home menu. Select Settings and press
Wheel(OK).
Ö
Settings
More
More
Settings
2 Select the NETWORK ĺNetwork Status menu.
Network Connection
Network Status
Soft AP
Wi-Fi Direct
NETWORK
MiracastTM / Intel's WiDi
My TV Name : **
Follow the instructions below that correlate to your
network status.
Check the TV or the router.
Network Status
TV Gateway DNS Internet
When an ܯappears TV.
1Check the connection status of TV, AP and cable
modem.
2Power off and power on TV, AP and cable modem.
3If you are using a static IP, enter IP directly.
4Contact internet companies or AP companies.
yAdditional points to check when using a
wireless connection
1Check the password for the wireless
connection in the router settings window.
2Change the router SSID (network name) or
the wireless channel.
Check the router or consult your Internet
service provider.
Network Status
TV Gateway DNS Internet
When an ܯappears TV and Gateway.
1Unplug the power cord of the AP, cable modem
and try to connect after 5 seconds.
2Initialize(Reset) the AP or cable modem.
3Contact internet companies or AP companies.
Network Status
TV Gateway DNS Internet
When an ܯappears TV, Gateway and DNS.
1Unplug the power cord of the AP, cable modem
and try to connect after 5 seconds.
2Initialize(Reset) the AP or cable modem.
3Check that the MAC address of the TV/router is
registered with your Internet service provider. (The
MAC address displayed on the right pane of the
network status window should be registered with
your Internet service provider.)
4Check the router manufacturer’s website to make
sure your router has the latest firmware version
installed.
Troubleshooting Network Problems

ENGENGLISH
5
Install the programme on your PC.
1 Go to www.lg.com Then, select your region.
2 Select SUPPORT. Then, Search for your model.
3 Select Drivers & Software or SOFTWARE UPDATE. Then, select .
4 You can run the programme when installation is complete.
NOTE
yDLNA service is only available if TV and other devices are connected via a single router.
SmartShare PC SW Installing & Setting
DLNA Connection to Smartphone
1 Check that Wi-Fi is enabled on your smartphone.
2 Install/run the app for sharing content on your smartphone (It's called SmartShare on LG phones).
3 Enable your smartphone to share content files with other devices.
4 Select the file type you want to play (movie, audio or photo).
5 Select a movie, music or photo file to play on the TV.
6 Add the selected file to the playlist.
7 Select a TV model name on which to play the files. (The TV model name is labelled on the rear side of the
panel.)
8 Play the media file to view and enjoy it on your TV.

ENG
ENGLISH
6
SMART ĺ 6HWWLQJVĺSUPPORT ĺSoftware Update
Uses Software Update to check and obtain the latest version. If not updated, certain functions may not work
properly. It is also possible to check manually for available updates.
Software Update Set it to On.
If an update is available, a prompt will appear to perform the update.
Automatic update mode If an update is available, the update automatically starts without prompting.
Check Update Version Checks the latest update version installed. When a new update is available, the
download process can be performed manually.
NOTE
yWhen the update starts, a pop-up window is displayed to show the update status and then disappears within
five seconds.
yThe latest version can be obtained via the digital broadcast signal or an internet connection.
yChanging the programme while downloading the software via a digital broadcast signal interrupts the
download process. Returning to the initial programme allows downloading to resume.
yIf software is not updated, certain functions may not work properly.
y[For Finland/Sweden/Denmark/Norway models.]
If the software update is performed via the broadcasting signal, you will be prompted to continue the update
regardless of whether the Automatic update mode is enabled or not.
SMART ĺSettings ĺNETWORK ĺ Wi-Fi Direct
The Wi-Fi Direct function supports wireless connection technology. With
SmartShareTM , you can share files or
screens of devices connected to Wi-Fi Direct.
Ö
[TAAAA]
Do you want to request a connection?
Automatically connect without asking
Yes No
Connection
Wi-Fi Direct
Device Name Connection
TAAAA
BBBB
Wi-Fi Direct
a
On
1 If Wi-Fi Direct is set to On, a list of available devices
appears.
»To use
Wi-Fi Direct, go to Settings ĺNETWORK and
set
Wi-Fi Direct (a) to On .
2
When you are prompted to request connection, select Yes.
Wi-Fi Direct is now connected to your TV.
* If you are not using Wi-Fi Direct to minimize the interference between Wi-Fi devices, it is recommended to set
Wi-Fi Direct
(a) to Off. You can only use devices that support Wi-Fi Direct.
Updating the TV Firmware
Wi-Fi Direct Setting

ENGENGLISH
7
Miracast
TM
allows a portable device to securely send video and sound to TV wirelessly.
Connection
Miracast
TM
/ Intel's WiDi
Device Name Connection
TAAAA
The device which is applied Miracast
TM
and intel's WiDi
technology can be shown on the TV.
MiracastTM / Intel's WiDi
a
On
1 Miracast
TM
is set to On on your TV or portable device.
Go to the Network settings to set the Miracast
TM
.
2 When your portable device is detected, select the device.
3 For more information about how to connect the portable device, refer to the portable
device manual.
MiracastTM Setting
WiDi (Wireless Display) Setting
WiDi represents Wireless Display. Intel’s WiDi (Wireless Display) technology enables easy and fast connection
without wires or internet network for mirrored and dual monitor display on your TV. You can sit back and experience
your favorite movies, videos, photos, online shows and more in full HD on your TV with great image clarity and
sound.
1 Intel's WiDi is set to On. Connect your laptop to AP. (Without AP, it is possible to this function; it is
recommended to connect to AP.) Your laptap runs the Intel WiDi(
P,
P,
P,
P,
P,
P,
P,
P,
P,
P,
P,
P,
P,
P,
P,
P,
P,
) programme.
2 It detects LG Smart TVs available, which supports WiDi. In the list, select the TV you want and click Connect.
Enter the PIN number( a) shown on the screen into the input field( b) on your laptop and then click Continue.
NOTE
yWhen you connect the TV and laptop, you should set up TV mode for “Live TV” and “external input”. If not,
your computer cannot detect LG Smart TV.
Öa
[Intel's WiDi] Request connection
Enter the following Security keys.
* When WiDi is connected, devices connected
with Wi-Fi Direct are disconnected.
MY PIN : ****
Cancel
Remain: 92 second(s)
b
TV Screen Notebook Screen
3 The wireless environment may affect the screen display. If the connection is poor, the Intel WiDi connection may
be lost.
* LG TV is not need to register.
* For more information on Intel WiDi, visit http://intel.com/go/widi.
* A list of Intel's WiDi devices does not appear on the TV screen. Please check the list on your laptop.

ENG
ENGLISH
8
»a: Change Device tab
»b: Device control buttons
»c: Expand the ScreenRemote
»d: Exits the Screen Remote
»e: Moves the position of the
ScreenRemote to left or right
External Device Menu External Device Menu
a
b
d
e
c
Universal Control
To use the Universal Control function (for Magic Remote Control only)
With the Magic Remote Control, you can easily control your set-top box, Blu-ray player, home theater system, and
Sound Bar.
1 Check if the device is connected to the TV.
2 After pressing the ' ' button on the Magic Remote Control, select the device you want to control in the
Change Device tab. The Screen Remote that can control the device appears.
3
You can control external devices using the Screen Remote on the screen.
(This may not work with the ' ' button for some models.)
4 Control external devices using the navigation keys, wheel (OK), or BACK button on the Magic Remote Control.

Please call LG Customer Service if you experience any problems.
