LG MBM64101611 User manual

Please call LG Customer Service if you experience any problems.
SMART TV Quick Setup GuideSMART TV Quick Setup Guide
* Image shown may differ from your TV.
* Image shown on a PC or mobile phone may vary depending on the OS(Operating System).
Wireless Network Connection
Wireless router
or
Wireless router
NOTE
LG wireless dongle is required to use Wi-Fi network.
Do not remove the wireless dongle while the wireless network is working.
Wired Network Connection
Internet connection
Wired router
Network Setting
Premium Apps are pre-installed on the TV. These may vary by country.
1Press the SMART
REC
button to access the Smart
Home menu. Select SETTINGS and
press Wheel(OK).
4The device automatically tries to connect to the
network available(wired network first).
SETTINGS

SETTINGS
SETTINGS
Cancel
Connecting to the network.
Network Connection
If you select Cancel or it fails to connect to the
network, the network list available is displayed.
Choose the network you want.
2Select the NETWORK → Network Connection
menu. Network Connection
Choose the network you want.
Wired Network
Wireless : AAA
Wireless : BBB
Wireless : CCC
Wireless : 11111
Wireless : 22222
Manual Setup
Refresh List
Network Connection
Network Status
Soft AP
Wi-Fi Direct
Miracast™ / Intel’s WiDi
My TV Name : NETCAST4
NETWORK
If you want to connect your TV to a wireless
router, select the network you want and enter the
password.
Network Connection
Wireless : AAA
Enter security key of network.
Forgot your password? Contact your APmanufacturer.
3Select the Start Connection.
Connect to your wired or wireless network.
Enjoy various Smart TV features through network.
To connect to a wired network:
Connect a LAN cable to the back of TV.
To connect to a wireless network:
Requires a wireless router or access point.
Start Connection
or
Network Connection
5The connected network is displayed.
Select Complete to confirm the network
connection.
If you select the Other Network List, the network
list available is displayed.
Network is connected.
Select [Other Network List] to connect to another network.
Network Connection
Wireless : AAA
Complete Other Network List
1 Press the SMART
REC
button to access the Smart
Home menu. Select SETTINGS and
press Wheel(OK).
SETTINGS

SETTINGS
SETTINGS
2 Select the NETWORK → Network Status menu.
Network Connection
Network Status
Soft AP
Wi-Fi Direct
Miracast™ / Intel’s WiDi
My TV Name : NETCAST4
NETWORK
Follow the instructions below that correlate to your
network status.
Check the TV or the router.
Network Status
TV Gateway DNS Internet
When an ✔appears TV.
1 Check the connection status of TV, AP and
cable modem.
2 Power off and power on TV, AP and cable
modem.
3 If you are using a static IP, enter IP directly.
4Contact internet companies or AP companies.
Additional points to check when using a
wireless connection
1 Check the password for the wireless
connection in the router settings window.
2 Change the router SSID (network name) or
the wireless channel.
Check the router or consult your Internet
service provider.
Network Status
TV Gateway DNS Internet
When an ✔appears TV and Gateway.
1 Unplug the power cord of the AP, cable modem
and try to connect after 5 seconds.
2 Initialize(Reset) the AP or cable modem.
3 Contact internet companies or AP
companies.
Network Status
TV Gateway DNS Internet
When an ✔appears TV, Gateway and DNS.
1 Unplug the power cord of the AP, cable modem
and try to connect after 5 seconds.
2 Initialize(Reset) the AP or cable modem.
3 Check that the MAC address of the TV/router
is registered with your Internet service provider.
(The MAC address displayed on the right
pane of the network status window should be
registered with your Internet service provider.)
4 Check the router manufacturer’s website to
make sure your router has the latest firmware
version installed.
Troubleshooting Network Problems
LG wireless
dongle
P/NO : MBM64101611 (1401 -REV00)
Printed in Korea *MBM64101611*

Please call LG Customer Service if you experience any problems.
SMART TV Quick Setup Guide
Installing & Setting
Install the SmartShare PC SW(DLNA) and programme on your PC.
1 Go to . Then, select your region.
2 Select SUPPORT. Then, Search for your model.
3 Select Drivers & Software or SOFTWARE UPDATE. Then, select SmartShare PC SW(DLNA).
4You can run the programme when installation is complete.
NOTE
DLNA service is only available if TV and other devices are connected via a single router.
DLNA Connection to Smartphone
1 Check that Wi-Fi is enabled on your smartphone.
2 Install/run the app for sharing content on your smartphone (It's called SmartShare on LG phones).
3 Enable your smartphone to share content files with other devices.
4 Select the file type you want to play (movie, audio or photo).
5 Select a movie, music or photo file to play on the TV.
6 Add the selected file to the playlist.
7 Select a TV model name on which to play the files. (The TV model name is labelled on the rear side of the
panel.)
8 Play the media file to view and enjoy it on your TV.
WiDi (Wireless Display) Setting
MiracastTM Setting
Wi-Fi Direct Setting
Updating the TV Firmware
WiDi represents Wireless Display. Intel’s WiDi (Wireless Display) technology enables easy and fast connection
without wires or internet network for mirrored and dual monitor display on your TV. You can sit back and experience
your favorite movies, videos, photos, online shows and more in full HD on your TV with great image clarity and
sound.
1 Intel's WiDi is set to On. Connect your laptop to AP. (Without AP, it is possible to this function; it is
recommended to connect to AP.) Your laptap runs the Intel WiDi( ) programme.
2It detects LG Smart TVs available, which supports WiDi. In the list, select the TV you want and click Connect.
Enter the PIN number( a) shown on the screen into the input field( b) on your laptop and then click Continue.
NOTE
When you connect the TV and laptop, you should set up TV mode for “Live TV” and “external input”. If not,
your computer cannot detect LG Smart TV.
a
b
TV Screen Notebook Screen
3The wireless environment may affect the screen display. If the connection is poor, the Intel WiDi connection may
be lost.
* LG TV is not need to register.
* For more information on Intel WiDi, visit http://intel.com/go/widi.
* A list of Intel's WiDi devices does not appear on the TV screen. Please check the list on your laptop.
REC
SMART → SETTINGS SETTINGS →NETWORK → Wi-Fi Direct
The Wi-Fi Direct function supports wireless connection technology. With SmartShare
TM
, you can share files or
screens of devices connected to Wi-Fi Direct.
Wi-Fi Direct


[TAAAA]
Do you want to request a connection?
Yes No
Wi-Fi Direct
Device Name Connection
TAAAA
BBBB
a
On
Automatically connect without asking
1 If Wi-Fi Direct is set to On, a list of available devices
appears.
»To use
Wi-Fi Direct, go to SETTINGS SETTINGS →NETWORK
and set
Wi-Fi Direct (a) to On .
2
When you are prompted to request connection, select Yes.
Wi-Fi Direct is now connected to your TV.
* If you are not using Wi-Fi Direct to minimize the interference between Wi-Fi devices, it is recommended to set
Wi-Fi Direct
(a) to Off. You can only use devices that support Wi-Fi Direct.
REC
SMART →SETTINGS SETTINGS →SUPPORT → Software Update
Uses Software Update to check and obtain the latest version.
It is also possible to check manually for available updates.
Software Update Set it to On.
If an update is available, a prompt will appear to perform the update.
Automatic update mode If an update is available, the update automatically starts without prompting.
Check Update Version Checks the version installed and when an update is available, the download process
can be performed manually.
NOTE
When the update starts, the update progress window appears for a short time and disappears.
The latest version can be obtained via digital broadcast signals or internet connections.
Changing the programme while downloading the software via digital broadcast signal interrupts the download
process. Returning to the initial programme allows downloading to resume.
If software is not updated, certain functions may not work properly.
Miracast
TM
allows a portable device to securely send video and sound to TV wirelessly.
Connection
Miracast
TM
/ Intel's WiDi
Device Name Connection
TAAAA
The device which is applied MiracastTMand intel's WiDi
technology can be shown on theTV.
MiracastTM / Intel's WiDi
a
On 1. Miracast
TM
is set to On(
a
)on your TV and portable device.
Go to the Network settings to set the Miracast
TM
.
2. When your portable device is detected, select the device.
