LG RK7 Specification sheet

MODEL
RK7
SIMPLE MANUAL
HIGH POWER
SPEAKER
SYSTEM
www.lg.com
Copyright © 2018 LG Electronics Inc. All Rights Reserved.
Please read this manual carefully before operating your set and retain it for future reference.
To view the instructions of advanced features, visit http://www.lg.com and then download
Owner’s Manual. Some of the content in this manual may differ from your unit.
MFL70720501
SLOVENŠČINA SHQIP
BOSANSKI
SVENSKA
DANSK NORSK SUOMI
SRPSKIHRVATSKILATVIEŠUROMÂNĂPOLSKI
SLOVENČINA
ČESKY
ENGLISH
PORTUGUÊS
ΕΛΛΗΝΙΚΑ
ESPAÑOLITALIANO
NEDERLANDS
FRANÇAISDEUTSCH
БЪЛГАРСКИ
MAGYAR
МАКЕДОНСКИ
RK7-DK.DEUSLLK_SIM_ENG_MFL70720501.indd 1 2018-07-04  10:07:16

Top panel
Download the Music Flow Bluetooth App to your
device. (Android only)
For more information, download the online owner’s
manual. http://www.lg.com
LG Sound Sync
Controller App
aDisplay window
b1(Standby)
Turns the power on or off.
3DUAL
Connects two speakers for DUAL mode in WIRELESS PARTY
LINK.
3MULTI
Connects multiple speakers for MULTI mode in WIRELESS
PARTY LINK.
The unit might not synchronize between audio and
video in DUAL/MULTI mode.
cF (Function)
- Selects the function and input source.
- Press and hold to select the PARTY LINK with AUX.
N(Play/Pause)
- Starts or pauses playback.
- Selects stereo/mono (Horizon mode only).
C/V(Skip/Search)
- Skips backward or forward.
- Searches for a section within a file.
- Selects the radio stations.
d AUTO DJ / RDS
- Selects the AUTO DJ mode.
- RDS (Radio Data System)
USER EQ / DEMO
- Selects the sound effect created by your own.
- In power off status, if you press USER EQ / DEMO, show
DEMO mode.
SOUND EFFECT / BASS BLAST (or BASS BLAST+)
- Chooses sound impressions.
- Press and hold to select BASS (or BASS+) effect directly.
LIGHTING
Selects lighting mode.
e+/- (Volume)
Adjusts speaker volume.
c
a
e
d
b
RK7-DK.DEUSLLK_SIM_ENG_MFL70720501.indd 2 2018-07-04  10:07:17

Front panel / Rear panel
aRemote sensor bFM ANTENNA
cMIC (Microphone) jack
dAUX IN / OUT (L/R)
eOPTICAL IN
fUSB port
gAC IN socket
Vertical Horizon
How to place the unit
abcde f g
RK7-DK.DEUSLLK_SIM_ENG_MFL70720501.indd 3 2018-07-04  10:07:18

Additional Information
Specifications
Power Requirements Refer to the main label on
the unit.
Power Consumption
Refer to the main label on
the unit.
Networked standby : 0.5 W
(If all network ports are
activated.)
Dimensions (W x H x D) Approx. 345 mm X
650 mm X 345 mm
Bus Power Supply (USB) 5 V 0500 mA
Amplifier
(Total RMS output power) 550 W RMS
Design and specifications are subject to change without
notice.
Note
yDo not look directly at the light emitting part when the
LIGHTING is turned on.
yIf the illumination brightness is glaring, switch on the
room lights or turn off the LIGHTING of the unit.
How to disconnect the wireless network
connection or the wireless device
Turn off the unit by pressing the power button for more
than 5 seconds.
Replacement of battery
(R03)
(R03)
Declaration of Conformity
Hereby, LG Electronics declares that the radio equipment type
HIGH POWER SPEAKER SYSTEM is in compliance with Directive
2014/53/EU. The full text of the EU declaration of conformity is
available at the following internet address:
http://www.lg.com/global/support/cedoc/cedoc#
For consideration of the user, this device should be installed and
operated with a minimum distance of 20 cm between the device
and the body.
Frequency range Output power (Max.)
2402 to 2480 MHz 10 dBm
RK7-DK.DEUSLLK_SIM_ENG_MFL70720501.indd 4 2018-07-04  10:07:19
