LG RL4 Specification sheet

Pagination & Folding
Printing Specifications
Cover Woodfree 80 g/㎡
Inner Woodfree 80 g/㎡
Cover Uncoated
Inner Uncoated
Cover 1 color (Black) Prepared
Inner 1 color (Black) 2019-03-18
148 x 210 mm (A5 size_Folded size) Checked
Only folding
Center folding once Appoved
4
Binding Method
Book Binding
Completed total pages
Note
Material
Coating
Color
LEE KYONG WON
Description Manual
P/No. MFL71281412
Ver. 1.0
Size

www.lg.com
Copyright © 2019 LG Electronics Inc. All Rights Reserved.1901_Rev01
SIMPLE MANUAL
HIGH POWER
SPEAKER SYSTEM
Please read this manual carefully before operating your set and retain it for
future reference.
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner’s Manual. Some of the
content in this manual may differ from your unit.
MODEL
RL4
MFL71281412
Additional Information
Specifications
Power Requirements Refer to the main label on
the unit.
Power Consumption Refer to the main label on
the unit.
Dimensions (W x H x D) Approx. 275 mm X
530 mm X 275 mm
Bus Power Supply (USB) 5 V 0500 mA
Amplier
(Total RMS output power) 150 W RMS
Design and specications are subject to change without
notice.
Note
yDo not look directly at the light emitting part when the
LIGHTING is turned on.
yIf the illumination brightness is glaring, switch on the
room lights or turn off the LIGHTING of the unit.
ENGLISH
RL4-NK.DPHLLLK_SIM_ENG_MFL71281412.indd 2 2019-03-13  2:33:08

Top panel
Download the LG XBOOM App to your device.
(Android only)
For more information, download the online owner’s
manual. http://www.lg.com
LG Sound Sync (Wireless)
Controller App
c
a
e
d
b
aDisplay window
b1(Standby)
Turns the power on or off.
LIGHTING
Selects the lighting mode.
3TWIN
Connects two speakers for TWIN mode in WIRELESS PARTY
LINK.
SOUND EFFECT / BASS BLAST (or BASS BLAST+)
- Chooses sound impressions.
- Press and hold to select BASS (or BASS+) effect directly.
cAUTO DJ
Selects the AUTO DJ mode.
N(Play/Pause)
Starts or pauses playback.
C/V(Skip/Search)
- Skips backward or forward.
- Searches for a section within a file.
dMIC ECHO / DEMO
- Selects ECHO mode.
- In power off status, if you press MIC ECHO / DEMO, show
DEMO mode.
VOCAL EFFECTS
Selects various vocal effects mode.
KEY CHANGER
Changes the key to suit your vocal range with C/V
(Skip/Search) button.
VOICE CANCELLER
You can reduce the vocal tones during music playback from
various input sources.
eF (Function)
- Selects the function and input source.
- Press and hold to adjust delay time when using PARTY LINK
with AUX.
MIC (Microphone) VOL (Volume)
Adjusts microphone volume.
+/- (Volume)
Adjusts speaker and microphone volume.
Rear panel
aMIC (Microphone) jack
bAUX IN / OUT (L/R)
cUSB port
dAC IN socket
Vertical Horizon
How to place the unit
abcd
RL4-NK.DPHLLLK_SIM_ENG_MFL71281412.indd 3-4 2019-03-13  2:33:11
