LG Electronics
Bluetooth®Stereo Speaker
MSB-100
User Manual
English
(Image)
All rights reserved.
LG Electronics Inc., 2007
Note: For the best performance and to prevent any damage to, or misuse of
the MSB-100, please read all of the information carefully prior to using the
MSB-100
Any modifications or changes to this manual due to typographical errors or
inaccuracies of stated information shall only be made by LG Electronics Inc.

Page 2
1. Table of Contents
1. TABLE OF CONTENTS ............................................................................................................................................. 2
2. INTRODUCTION ......................................................................................................................................................... 3
3. PART DESCRIPTION................................................................................................................................................. 3
4. HOW TO USE .............................................................................................................................................................. 3
-4.1. CHARGING ........................................................................................................................................................ 3
-4.2. LOW BATTERY................................................................................................................................................... 4
-4.3. POWER ON........................................................................................................................................................ 4
-4.4. POWER OFF ...................................................................................................................................................... 4
-4.5. PAIRING............................................................................................................................................................. 4
-4.6. EASY PAIRING ................................................................................................................................................... 4
-4.7. CONNECTING .................................................................................................................................................... 4
-4.8. VOLUME CONTROL ........................................................................................................................................... 5
-4.9. AUDIO STREAMING............................................................................................................................................ 5
4.9.1. PLAY.......................................................................................................................................... 5
4.9.2. PAUSE ...................................................................................................................................... 5
4.9.3. STOP......................................................................................................................................... 5
4.9.4. FWD........................................................................................................................................... 6
4.9.5. BACK......................................................................................................................................... 6
4.9.6. Fast Forward ............................................................................................................................ 6
4.9.7. Rewind ...................................................................................................................................... 6
-4.10. CALLING ......................................................................................................................................................... 6
4.10.1. Answering a call..................................................................................................................... 6
4.10.2. Making a call .......................................................................................................................... 6
4.10.3. Voice dialing*.......................................................................................................................... 6
4.10.4. Last number redial*............................................................................................................... 6
4.10.5. Ending a call........................................................................................................................... 6
4.10.6. Transferring a call* ................................................................................................................ 7
4.10.7. Call waiting*............................................................................................................................ 7
4.10.8. Call rejecting*......................................................................................................................... 7
4.10.9. SPEAKER Mute..................................................................................................................... 7
4.10.10. MIC Mute .............................................................................................................................. 7
5. SUMMARY OF BUTTON FUNCTIONS................................................................................................................... 7
6. LED INDICATION........................................................................................................................................................ 8
7. TROUBLESHOOTING ............................................................................................................................................... 9

Page 3
8. SPECIFICATION ......................................................................................................................................................... 9
9. PRECAUTIONS......................................................................................................................................................... 10
10. DECLARATION OF CONFIRMATION................................................................................................................. 10
11. ADDITIONAL INFORMATION............................................................................................................................... 10
12. LIMITED WARRANTY ........................................................................................................................................... 12
13. HEARING SAFETY ................................................................................................................................................ 12
2. Introduction
The LG Bluetooth®Stereo Speaker MSB-100 is a wireless Stereo Speaker utilizing Bluetooth®technology.
This product can be used as an audio accessory for devices supporting either the A2DP or Handsfree
Bluetooth®Profiles.
Included in package
(Image)
3. Part description
(Image)
4. How to use
4.1. Charging
- Remove the cover on the charging port and connect the charger.
- While charging, the LED indicator will show a solid red light.
- The speaker can function while charging.
- It takes 3 hours to fully charge the Speaker.
- When charging is complete, the LED indicator will turn off.

Page 4
4.2. Low battery
- The LED indicator will blink red when the battery power is low. (Red LED replaces Blue LED as status
indicator.)
- When the battery is not charged, the LED indicator will blink red and then turn off.
4.3. Power on
- Press and hold the PWR/END button for at least 2 seconds.
9The MSB-100 will be turned on and a booting tone will play.
4.4. Power off
- Press and hold the PWR/END button for at least 5 seconds.
9A shutdown tone will play, the Bluetooth link will be disconnected, and the MSB-100 will be turned off.
4.5. Pairing
- Prior to using the Speaker for the first time, you must pair it with a Bluetooth-enabled handset.
- With the MSB-100 off, press and hold the PWR/END button for 5 seconds.
9You will hear four short beeps and the LED indicator will flicker in blue LED and red LED alternately,
when the device enters Pairing Mode.
Using your Handset, find the Bluetooth Menu and "search for" or "add” new devices.
Select "LG MSB-100" from the list of devices and pair it with your handset.
When asked for the Pass/PIN code during the pairing procedure, please enter “0000”(4Zeros).
9Once pairing has completed successfully, you will hear a beep.
After pairing successfully, be sure to “Connect”to the MSB-100.
9If you want to pair with other devices in the future, the MSB-100 must be in Pairing Mode.
9If the MSB-100 is in “Pairing Mode” for 3 minutes without being paired to a device, the Speaker will
automatically turn off.
4.6. Easy pairing
- With the MSB-100 off, Press and hold the PWR/END button for 2 seconds.
9If the MSB-100 has ever connected with the Handset, It will try to connect to the handset automatically.
9If the MSB-100 doesn’t have ever connected with any devices or it fails to connect to the handset by the
several reasons, it will change the mode to pairing mode. The details about pairing mode are described
above (4.5. Pairing) and the connecting sequences are the same.
4.7. Connecting
There are two ways to connect the “MSB-100” to a Handset.
1. Connecting from a Handset to a MSB-100
From the Bluetooth menu, select the “connect” sub-menu.

Page 5
Select a “LG MSB-100” you want to connect.
2. Connecting from a MSB-100 to a Handset
Press PWR/END button.
If a “MSB-100” has ever paired with a Bluetooth device successfully, such as a mobile phone, it would
initiate a connection with it automatically.
[Auto Reconnect]
When the MSB-100 turns off accidentally or intentionally during connected condition, the speaker and
handset will disconnect.
The Stereo speaker and handset will automatically reconnect without pairing when the MSB-100 turns on.
[out of range]
- When the MSB-100 and your handset are separated by a distance of 33 feet (10meters) or more, the MSB-
100 and handset will disconnect. When the handset and MSB-100 are brought back within the required
distance, the MSB-100 will automatically reconnect with the handset.
- If the MSB-100 and handset do not automatically reconnect when they are back within the required range,
briefly press the PWR/END button to reconnect manually.
4.8. Volume control
- Briefly press the VOLUME UP or VOLUME DOWN button to adjust the speaker volume.
- There are eight levels of speaker volume in handsfree mode.
- There are fifteen levels of speaker volume in audio streaming mode.
4.9. Audio streaming
4.9.1. PLAY
- Briefly press the PLAY button to play the music
4.9.2. PAUSE
- Briefly press the PLAY button to pause the music.
- For some cell phone or MP3 player, pressing PLAY button once may not pause the music, then press Play
button twice quickly to pause the music.
4.9.3. STOP
- Press and hold the PLAY button for 1 second to stop the music

Page 6
4.9.4. FWD
- Briefly press the FWD button for playing the next music.
4.9.5. BACK
- Briefly press the BACK button for playing the previous music.
4.9.6. Fast Forward
- Press and hold the FWD button. On the release, the music will be played again.
4.9.7. Rewind
- Press and hold the BACK button. On the release, the music will be played again.
4.10. Calling
4.10.1. Answering a call
- When there is an incoming call, the MSB-100 will ring.
- Briefly press the PWR/END button to answer an incoming call.
4.10.2. Making a call
- If you make a call from the Handset, the call will (subject to phone settings) transfer automatically to the
MSB-100. If not automatically transferred, you can transfer the call manually by briefly pressing the
PWR/END button on the MSB-100(speaker and handset must be paired).
4.10.3. Voice dialing*
- Briefly press the PWR/END button. You will get the best results if you record the voice dialing tag through
your MSB-100.
NOTE: If the Handset does not support the Voice Dial, the MSB-100 will activate the last number redialing.
4.10.4. Last number redial*
- Press and hold the PWR/END button for 1 second to activate “Last Number Redial”.
The Speaker will beep. and call the last number dialed.
4.10.5. Ending a call
- Briefly press the PWR/END button.

Page 7
4.10.6. Transferring a call*
While on a call on your handset, briefly press the PWR/END button on the MSB-100 to transfer the Audio to
the Speaker, (speaker and handset must be paired)
And to transfer a call from the Speaker to Handset, press and hold PLAY button for 1 second.
4.10.7. Call waiting*
- Answer a second call without hanging up the first call by pressing the PWR/END button for 1 second. Press
the PWR/END button for 1 second to return to the original call.
- Briefly press the PWR/END button to terminate the active call.
4.10.8. Call rejecting*
- Activate call rejecting by pressing the PWR/END button for 1 second when the Handset rings.
4.10.9. SPEAKER Mute
- Briefly press the Mute button for speaker off during the ring. For removal briefly press the Mute button
4.10.10. MIC Mute
- Briefly press the Mute button for mic off during the talking. For removal briefly press the Mute button
*It is possible to use these functions only when your Handset supports them.
For further information about using these features please consult your Handset’s user manual.
5. Summary of Button functions
Function MSB-100
status
Action
Power On Power Off Press the PWR/END button for at least 2 seconds
Power Off Power On Press the PWR/END button for at least 5 seconds
Volume Up Talking Briefly press the VOLUME UP button
Volume Down Talking Briefly press the VOLUME DOWN button

Page 8
Play Play off Briefly press the PLAY button
Pause Play on Briefly press the PLAY button twice quickly
Stop Play on Press the PLAY button for 1 second
Fwd Play on Briefly press FWD button
Back Play on Briefly press RWD button
Fast forward Play on Press and hold the FWD button
Rewind Play on Press and hold the BACK button.
Answering a call Ringing Briefly press the PWR/END button
Ending a call Talking Briefly press the PWR/END button
Call waiting Talking Press the PWR/END button for 1 second
Transferring a call Talking Press the play button for at least 1 second
Last number redialing Idle Press the PWR/END button for 1 second
Voice dialing
(Handset must support)
Idle Briefly press the PWR/END button
Call rejecting Ringing Press the PWR/END button for 1 second
Speaker mute On/Off Ringing Briefly press the Mute button
MIC mute On/Off Talking Briefly press the Mute button
Pairing mode Power Off Press the PWR/END button for 5 seconds
6. LED indication
Functions MSB-100 status LED status
Power On The blue LED light flickers fast 5 times.
Power Off The blue LED light flickers fast 5 times.
Pairing mode The blue and red LED light flicker in turn
continuously
A2DP/AVRCP/Handsfree/Headset
Profile Connected
The blue LED light flickers twice every 5 seconds.
Call Connected The blue LED light flickers twice every 5 seconds.
Unintentional Link Loss
(until the lost link is recovered)
The blue and red LED light flickers once every 5
seconds.
Operating
Hold When pressing a button during the hold status,
the blue LED light flickers fast 5 times.

Page 9
Charging The red LED is lit.
Charging
Charging Complete The red LED is turned off.
7. Troubleshooting
Does not turn on
Check whether the battery of the MSB-
100
is fully discharged.
Charge the battery.
Check whether the Handset supports
the Headset/Handsfree/
A2DP/AVRCP
Bluetooth Profiles.
Determine whether your Handset
supports the
Headset/Handsfree/A2DP/AVRCP
Bluetooth Profiles.
Unable to communicate
with the MSB-100
Check whether the battery of the MSB-
100
is low
Charge the battery.
Check and make sure the Speaker is
on.
Press the PWR/END button for
at least 2 seconds to turn on the
Speaker.
Unable to pair the MSB-
100
with the Bluetooth
device.
Check and make sure the Speaker is
placed in pairing mode.
With the power off, press and hold
the
PWR/END button for at least
5 seconds
to place the Speaker
in pairing mode.
Low sound ( speaker) Check the speaker volume. Increase the volume level.
8. Specification
ITEM Description
Bluetooth Specification V2.0 ( Headset/Handsfree/A2DP/AVRCP )
Battery 3.7V, Li-Polymer
Standby Time ?
Music play time Up to 8Hrs
Talk Time Up to 30Hrs
Charging Time 3Hrs

Page 10
Operating Temperature -20 ~ 60 ℃℃
Dimension/Weight 110.3 x 36.8 x 25.8 / 113.0g
9. Precautions
1. Do not drop the unit from high places.
2. Do not modify, repair & take a part.
3. Do not expose directly to the water, alcohol, benzene, etc. for clearing.
4. Do not expose directly to flammables.
5. Do not place or keep the unit near the flammables.
6. Keep unit away from humidity & dust.
7. Do not place the heavy objects on the unit.
8. Keep away from direct light or heat.
zChanges or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
zRisk of explosion if the battery is replaced by on incorrect type.
zDispose of used batteries according to the instructions.
10. Declaration of Confirmation
FCC NOTICE TO USERS:
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no change to the
antenna or the device is permitted. Any change to the antenna or the device could result in the device
exceeding the RF exposure requirements and void user’s authority to operate the device.
11. Additional Information
1. Radio frequency exposure
This Bluetooth Stereo Speaker, MSB-100, is a radio transmitter and receiver. When in
operation, it communicates with a Bluetooth equipped mobile device by receiving and
