LG CL88 Specification sheet

Additional Information
Specifications
Power Requirements Refer to the main label on
the unit.
Power Consumption Refer to the main label on
the unit.
Dimensions (W x H x D) Approx. 450.0 mm x
167.0 mm x 332.0 mm
Bus Power Supply (USB) 5 V 0500 mA
Amplier
(Total RMS output power) 2,900 W RMS
Design and specications are subject to change without
notice.
Replacement of battery
(R03)
(R03)
About Ferrite Core (Optional)
Wind power cord cable around the ferrite core twice.
Caution
yWhen you use the multiple socket, it is advisable to use
15 A socket. 10 A socket may cause power off due to
lack of power supply.
yDo not place objects on the speakers. It may cause the
objects to fall and make property damage.
yInstall the speakers on a rm surface not to slide. The
vibration caused by the strong output can shake and
move the speakers.
yAvoid turning up max volume in a small enclosed space.
The powerful and intense output of the speakers can
shake the ceiling and get the objects in the room falling.
yTo protect from hearing damage, keep the sufcient
distance from the speaker. The overwhelming sound
from the speaker may cause a person’s hearing damage.
yAllow more than 20 cm of free space between the
main set and the speakers when you install the main
set on the ground. High sound pressure from the
speakers can make the set vibrate which can disturb
the CD playback.
yConnect the power cord to wall outlet directly if
possible. Or when you use an extension cable, it is
highly recommended to use an extension cable of
110 V / 15 A or 230 V / 15 A, otherwise the unit may
not operate properly because of the lack of power
supply.
yDo not overload the extension cord with excessive
electrical load.
Note
yDo not look directly at the light emitting part when the
LIGHTING is turned on.
yIf the illumination brightness is glaring, switch on the
room lights or turn off the LIGHTING of the unit.
POWER: This unit operates on a mains supply of
200 - 240 V ~ 50 / 60 Hz.
Wiring: This unit is supplied with a BS 1363 approved
main plug. When replacing the fuse, always use a fuse of
the same rating and approved to BS 1362. Never use this
plug with the fuse cover omitted. To obtain a replacement
fuse cover contact your dealer. If the type of plug supplied
is not suitable for the mains sockets in your home, then
the plug should be removed and a suitable type tted.
Please refer to the wiring instructions below:
Warning: A mains plug removed from the mains lead of
this unit must be destroyed. A mains plug with bared wires
is hazardous if inserted in a mains socket. Do not connect
either wire to the earth pin, marked with the letter E or
with the earth symbol 6or coloured green or green and
yellow. If any other plug is tted, use same rating of fuse in
the plug.
Important: The wires in this mains lead are coloured in
accordance with the following codes:
- BLUE: NEUTRAL, BROWN: LIVE - As the colours of the
wires in the mains lead of this unit may not correspond
with the coloured marking identifying the terminals in your
plug, proceed as follows: The wire which is coloured blue
must be connected to the terminal which is marked with
the letter N or coloured black. The wire which is coloured
brown must be connected to the terminal which is marked
with the letter L or coloured red.
www.lg.com
Copyright © 2019 LG Electronics Inc. All Rights Reserved.
SIMPLE MANUAL
Mini Hi-Fi
System
Please read this manual carefully before operating your set and retain it for
future reference.
To view the instructions of advanced features, visit
http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODEL
CL88
1910_Rev01
MFL71447108
ENGLISH
CL88-FB.DKENHLK_SIM (Sheet)_MFL71447108.indd 2 2019-10-23  12:08:53

Front Panel
aUSB 1 Port
You can play sound files by connecting the USB device.
b1(Standby)
Turns the power on or off.
cDisplay window
d
F (Function)
Selects the function and input source.
eUSB 2 Port
You can play sound files by connecting the USB device.
f
MASTER VOLUME
- Adjusts speaker volume.
- Selects the lighting effects.
- Selects vocal effects.
LIGHTING
Selects the lighting mode.
MIC VOL (Microphone volume) -/+
Adjusts microphone volume.
MIC (Microphone) ECHO
Selects ECHO mode.
g (Remote sensor)
MIC (Microphone) 1/2 jack
AUX IN 1 jack
h
KEY CHANGER (L/l)
Changes the key to suit your vocal range.
VOICE CANCELLER
You can reduce the vocal tones during music playback
from various input sources.
VOCAL EFFECTS
Selects various vocal effects mode.
i 3TWIN
Connects two speakers for TWIN mode in WIRELESS
PARTY LINK.
DJ LOOP
Selects DJ LOOP mode.
(DJ LOOP mode can use during CD/USB playback.)
N(Play/Pause)
- Starts or pauses playback.
- Selects stereo/mono.
V(Skip/Search)
- Skips forward.
- Searches for a section within a track/file.
- Selects the radio stations.
PARTY ACCELERATOR MODE
Selects PARTY ACCELERATOR MODE.
j
Disc tray
kPARTY ACCELERATOR lever
Slide the lever to create a party atmosphere.
a b dc e
fn
ghijklm
l
USB REC / DEMO
- Records to USB.
- Stops Recording.
- In power off status, if you press USB REC / DEMO,
show DEMO mode.
SPECIAL EQ / BASS BLAST (or BASS BLAST+)
- Chooses special equalizer.
- Press and hold to select BASS (or BASS+) effect
directly.
Z(Stop)
Stops playback or cancels DELETE function.
C(Skip/Search)
- Skips backward.
- Searches for a section within a track/le.
- Selects the radio stations.
B(Open/Close)
Opens and closes the disc tray.
mCLUB, DRUM, USER (DJ PAD)
Selects CLUB, DRUM or USER sound effect to mix.
(If you want to use USER, you have to register a source
with “LG XBOOM” app.)
1, 2, 3, 4 (DJ PAD)
Press a desired sound pad.
n
DJ SCRATCHER / LEVEL CONTROL & SEARCH
- Turns clockwise or counterclockwise to make scratch
sound.
- Turns clockwise or counterclockwise to control the
USER EQ level.
- Searches a folder or a le.
- Adjust DJ EFFECT level.
DJ EFFECT
Selects a desired DJ EFFECT.
SEARCH
Moves to folder or file in selection mode.
OK
Selects a folder when searching a file.
USER EQ
Selects the equalizer created by your own
Rear Panel
aPower cord
bANTENNA (FM)
cAUX IN 2 (L/R)
dSPEAKER LIGHTING SYSTEM
Connect the speaker lighting cables.
eSPEAKERS connector
Speaker Connection
Download the LG XBOOM App to your device.
(Android only)
For more information, download the online owner’s
manual. http://www.lg.com
LG Sound Sync (Wireless)
Controller App
100 100
100
MIDL
MIDR
100 100
100
MID LMID R
b c d e
a
100 100
100
MIDL
MIDR
