LG ON2DN User manual

OWNER’S MANUAL
DVD Mini
Hi-Fi Audio
MODEL
ON2DN
2005_Rev01
www.lg.com
Copyright © 2020 LG Electronics Inc. All Rights Reserved.
Please read this manual carefully before operating your set and retain it for future
reference.
MFL71726911

1 Getting Started
Getting Started2
Getting Started
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead
symbol within an equilateral
triangle is intended to alert the
user to the presence of uninsulated
dangerous voltage within the
product’s enclosure that may be of
sufcient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature
accompanying the product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
CAUTION: The apparatus should not be exposed to
water (dripping or splashing) and no objects lled
with liquids, such as vases, should be placed on the
apparatus.
WARNING: Do not install this equipment in a
conned space such as a book case or similar unit.
CAUTION: Do not use high voltage products around
this product. (ex. Electrical swatter) This product may
malfunction due to electrical shock.
CAUTION: This product employs a Laser System.
To ensure proper use of this product, please read
this owner’s manual carefully and retain it for future
reference. Shall the unit require maintenance, contact
an authorized service center.
Use of controls, adjustments or the performance of
procedures other than those specied herein may
result in hazardous radiation exposure. To prevent
direct exposure to laser beam, do not try to open the
enclosure.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided
for ventilation and to ensure reliable operation of
the product and to protect it from over heating.
The openings should never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product should not be placed in a built-
in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
NOTICE: For safety marking information including
product identication and supply ratings, please refer
to the main label on the bottom or the other surface
of the product.

Getting Started 3
Getting Started
1
CAUTION concerning the Power Cord
The Power Plug is the disconnecting device. In case
of an emergency, the Power Plug must remain readily
accessible.
Check the specication page of this owner’s manual
to be certain of the current requirements.
Do not overload wall outlets. Overloaded wall outlets,
loose or damaged wall outlets, extension cords, frayed
power cords, or damaged or cracked wire insulation
are dangerous. Any of these conditions could result
in electric shock or re. Periodically examine the
cord of your device, and if its appearance indicates
damage or deterioration, unplug it, discontinue use of
the device, and have the cord replaced with an exact
replacement part by an authorized service center.
Protect the power cord from physical or mechanical
abuse, such as being twisted, kinked, pinched, closed
in a door, or walked upon. Pay particular attention to
plugs, wall outlets, and the point where the cord exits
the device.
CAUTION: Be careful to make sure children do not
put their hands or any objects into the *speaker duct.
* speaker duct: A hole for plentiful bass sound on
speaker cabinet (enclosure)
CAUTION: No naked ame sources, such as lighted
candles, should be placed on the apparatus.
Symbols
~Refers to alternating current (AC).
0Refers to direct current (DC).
Refers to class II equipment.
1Refers to stand-by.
!Refers to “ON” (power).
Refers to dangerous voltage.

Table of Contents4
1 Getting Started
2 Safety Information
6 Unique Features
7 Introduction
7 – Playable Discs
7 – About the “7” Symbol Display
7 – Symbols Used in this Manual
7 – Regional Codes
8 Playable file Requirement
8 – Music file requirement
8 – Photo file requirement
9 – Video file requirement
9 – Compatible USB Devices
9 – USB device requirement
10 Remote control
12 Top panel
13 Front panel / Rear panel
2 Connecting
14 Connections to Your TV
14 – HDMI Out connection
15 – Resolution Setting
16 Optional Equipment Connection
16 – AUX IN Connection
17 – USB Connection
Table of Contents
3 System Setting
18 Adjust the setup settings
18 – OSD Initial language settings - Optional
18 – To display and exit the Setup menu
19 – Language
19 – Display
20 – Audio
21 – Lock (Parental Control)

Table of Contents 5
1
2
3
4
5
6
4 Operating
22 Using the Home Menu
23 Basic Operations on Disc
24 Advanced Operations on Disc
24 – Displaying Disc Information
on-screen
24 – To display the DVD Menu
24 – To display the DVD title
24 – 1.5 times speed playback
24 – Screen Saver
25 – Starting play from selected time
25 – Resume playback
25 – Changing subtitle code page
26 – Marked Playback
27 – Viewing a PHOTO file
28 USB Operations
30 Using BLUETOOTH® wireless technology
30 – Listening to music stored on the Bluetooth
devices
32 Sound adjustment
32 – Setting the sound mode
32 – Adjusting BASS level
32 Other Operations
32 – Turn off the sound temporarily
32 – Resume stop
33 – Last Scene Memory
33 – Power Resume - Optional
33 – System Select - Optional
33 – Using Microphone
33 – Adjusting MIC ECHO level
34 – Sleep Timer Setting
34 – Dimmer
5 Troubleshooting
35 Troubleshooting
35 – General
6 Appendix
37 Area Code List
38 Language code List
39 Trademarks and Licenses
40 Maintenance
40 – Notes on Discs
40 – Handling the Unit
41 Specifications

Getting Started6
Getting Started
1
Unique Features
BLUETOOTH®
Listens to music stored on your Bluetooth device.
Full HD up-scaling
Views Full HD picture quality with simple setup.

Getting Started 7
Getting Started
1
Introduction
Playable Discs
This unit plays DVD±R/RW and CD-R/RW that
contains audio titles, MP3, WMA and/or JPEG les.
Some DVD±RW/DVD±R or CD-RW/CD-R cannot be
played on this unit due to the recording quality or
physical condition of the disc, or the characteristics of
the recording device and authoring software.
DVD-VIDEO (8 cm/12 cm disc)
Discs such as movies that can be
purchased or rented.
DVD±R (8 cm/12 cm disc)
Video mode and nalized only.
DVD-RW (8 cm/12 cm disc)
Video mode and nalized only.
DVD+R: Video mode only
Supports the double layer disc also.
DVD+RW (8 cm/12 cm disc)
Video mode and nalized only.
Audio CD: Music CDs or CD-R/CD-
RW in music CD format that can be
purchased.
About the “7” Symbol Display
“7” may appear on your TV display during operation
and indicates that the function explained in this
owner’s manual is not available on that specic
media.
Symbols Used in this Manual
rDVD-Video, DVD±R/RW in Video
mode or VR mode and nalized
tAudio CDs
yVideo les contained in the Disc
uAudio les contained in the Disc
iPhoto les contained in the Disc
, Note
Indicates special notes and operating features.
> Caution
Indicates cautions for preventing possible damages
from abuse.
Regional Codes
This unit has a regional code printed on the rear of
the unit. This unit can play only DVD discs labeled
same as the rear of the unit or “ALL”.
yMost DVD discs have a globe with one or more
numbers in it clearly visible on the cover. This
number must match your unit’s regional code or
the disc cannot play.
yIf you try to play a DVD with a different regional
code from your unit, the message “Check Regional
Code” appears on the TV screen.

Getting Started8
Getting Started
1
Playable file
Requirement
Music file requirement
Disc (DVD/CD)
MP3/WMA le compatibility with this unit is limited
as follows.
ySampling frequency: within 32 to 48 kHz (MP3),
within 32 to 48 kHz (WMA)
yBit rate: within 32 to 320 kbps (MP3),
40 to 192 kbps (WMA)
ySupport Version: v2, v7, v8, v9
yMaximum les: 999
yMaximum folders: 99
yFile extensions: “.mp3”/ “.wma”
yCertain MP3/WMA les may not be played
depending on the type or format of the le.
yCD-ROM le format: ISO 9660/ JOLIET
yWe recommend that you use Easy-CD Creator,
which creates an ISO 9660 le system.
yA protected le by DRM (Digital rights
management) cannot be played on the unit.
yThe DTS disc is not supported.
You have to set the disc format option to [Mastered]
in order to make the discs compatible with the LG
players when formatting rewritable discs. When
setting the option to Live File System, you cannot use
it on LG players.
(Mastered/Live File System: Disc format system for
Windows Vista)
USB
MP3 le compatibility with this unit is limited as
follows.
ySampling frequency: within 32 to 48 kHz
yBit rate: within 32 to 320 kbps
yMaximum les: 999
yMaximum folders: 99
yFile extensions: “.mp3”
yCertain MP3 les may not be played depending on
the type or format of the le.
Photo file requirement
Photo le compatibility with this unit is limited as
follows:
yMax pixel in width: 2760 x 2048 pixel
yMaximum les: Under 999
ySome discs may not operate due to a different
recording format or the condition of disc.
yFile extensions: “.jpg”
yCD-ROM le format: ISO9660/ JOLIET

Getting Started 9
Getting Started
1
Video file requirement
Video le compatibility with this unit is limited as
follows:
yAvailable resolution: within 720 x 576 (W x H)
pixels.
yThe le name of the Video subtitle should be
entered within 45 characters.
yIf there is impossible code to express in the Video
le, it may be displayed as “ _ ” mark on the display.
yFrame rate: less than 30 fps.
yIf the video and audio structure of recorded les is
not interleaved, either video or audio is outputted.
yPlayable Video le: “.avi”, “.mpg”, “.mpeg”
yPlayable Subtitle format: SubRip (*.srt/ *.txt), SAMI
(*.smi), SubStation Alpha (*.ssa/ *.txt), MicroDVD
(*.sub/ *.txt), SubViewer 2.0 (*.sub/ *.txt), Vobsub
(*.sub)
yPlayable Codec format:
“Xvid”, “MPEG-1”, “MPEG-2”
yPlayable Audio format: “AC3”, “PCM”, “MP3”,
“WMA”,
ySampling frequency: within 32 to 48 kHz (MP3),
within 32 to 48 kHz (WMA)
yBit rate: within 32 to 320 kbps (MP3),
40 to 192 kbps (WMA)
yFor Discs formatted in Live le system, you can not
it on this unit.
yIf the name of movie le is different from that of
the subtitle le, during playback of a Video le,
subtitle may not be display.
yIf you play a Xvid le differ from Xvid spec, it may
not operate normally.
yIf you play GMC video le which is more than
1-warp point, video playback screen will not
smooth.
Compatible USB Devices
yMP3 Player: Flash type MP3 player.
yUSB Flash Drive:
Devices that support USB2.0 or USB1.1.
yThe USB function of this unit does not support all
USB devices.
USB device requirement
yDevices which require additional program
installation when you have connected it to a
computer, are not supported.
yDo not extract the USB device while in operation.
yFor a large capacity USB, it may take longer than a
few minute to be searched.
yTo prevent data loss, back up all data.
yIf you use a USB extension cable or USB hub, the
USB device is not recognized.
yUsing NTFS le system is not supported. (Only
FAT(16/ 32) le system is supported.)
yThis unit recognizes up to 999 les.
yExternal HDD, Card readers, Locked devices, or
hard type USB devices are not supported.
yUSB port of the unit cannot be connected to PC.
The unit cannot be used as a storage device.
ySome USB may not work with this unit.

Getting Started10
Getting Started
1
Remote control
Replacement of battery
Remove the battery cover on the rear of the remote
control, and insert the battery with 4and 5
matched correctly.
Risk of re or explosion if the battery is replaced by
an incorrect type.
• • • • • • • • • • • • • • a • • • • • • • • • • • • •
1 (Standby):Turns the power on or off.
B (Open/Close): Opens and closes the disc tray.
F (Function): Selects the function and input source.
Input source / Function Display
Disc DVD.CD
USB USB
AUX input AUX
Bluetooth BT
!(Home): Displays the [Home Menu] on a DVD.CD
function.
DISC MENU: Accesses the menu on a DVD disc.
TITLE: If the current DVD title has a menu, the title
menu appears on the screen. Otherwise, the disc
menu may not appear.
• • • • • • • • • • • • • • b • • • • • • • • • • • • •
mINFO/DISPLAY: Accesses On-Screen Display.
MARKER: Marks play list. (Page 26)
W/S/A/D (up/ down/ left/ right): Used to
navigate on-screen displays.
m(Select): Acknowledges menu selection.
](Close): Moves backwards in the menu or exits
the setup menu.
h REPEAT: Listens to your les/tracks/chapters
repeatedly or randomly.

Getting Started 11
Getting Started
1
• • • • • • • • • • • • • • c • • • • • • • • • • • • •
Z(Stop): Stops playback.
X(Play): Starts playback.
M(Pause): Pauses playback.
C/V(Skip): Skips backward or forward.
c/v(Scan): Scans for a section within a track/file/
chapter.
EQ: Chooses sound impressions.
VOL (Volume) +/-:Adjusts speaker volume.
BASS +/-: Adjusts bass level.
[ (Mute): Mutes the sound.
• • • • • • • • • • • • • • d • • • • • • • • • • • • •
0-9 numerical buttons: Selects numbered options in
a menu.
SLEEP:Sets the system to turn off automatically at
a specified time. (Dimmer: The display window will be
darkened by half.)
CLEAR
- Removes a number when setting the password.
- Deletes all the saved stations.
• • • • • • • • • • • • • • e • • • • • • • • • • • • •
MIC VOL (Microphone Volume) -/+: Adjusts
microphone volume.
MIC (Microphone) ECHO -/+: Adjusts microphone
echo level.
TV Control buttons:Controls the TV. (LG TV only)
- You can control the sound level, input source,
and power switching of LG TVs as well.
Hold 1 (TV) and press VOL (+/-) button
repeatedly until the TV turns on or off.

Getting Started12
Getting Started
1
Top panel
f
a
bcd
e
a 1(Standby)
Turns the power on or off.
bUSB Port
You can play MP3 les by connecting the USB
device.
cDisplay window
dF (Function)
Selects the function and input source.
Input source / Function Display
Disc DVD.CD
USB USB
AUX input AUX
Bluetooth BT
eB(Open/Close)
Opens and closes the disc tray.
C/V(Skip/Scan)
- Skips backward or forward.
- Scans for a section within a track/file/chapter.
Z(Stop)
Stops playback.
VOL (Volume) -/+
Adjusts speaker volume.
N(Play/Pause)
Starts or pauses playback.
fMIC VOL (Microphone volume) -/+
Adjust microphone volume.
MIC (Microphone) ECHO -/+
Adjusts microphone echo level.
BASS -/+
Adjusts bass level.
EQ
Chooses sound impressions.

Getting Started 13
Getting Started
1
Front panel / Rear panel
aRemote sensor
bDisc tray
cPower cord
dSERVICE ONLY: S/W download connector.
eHDMI OUT TO TV: Connect to TV.
fAUX IN (L/R): Connect an auxiliary device.
gMIC (Microphone) 1/2: Connect a microphone.
a
bc d e f g

2 Connecting
Connecting14
Connecting
2
Connections to Your TV
HDMI Out connection
If you have a HDMI TV or monitor, you can connect it
to this unit using a HDMI cable (Type A, High Speed
HDMI™ Cable).
Connect the HDMI OUT jack on the unit to the HDMI
IN jack on a HDMI compatible TV or monitor.
Set the TV’s source to HDMI (refer to TV’s Owner’s
manual).
Unit
TV
yYou can fully enjoy digital audio and video
signals together with this HDMI connection.
yWhen you use HDMI connection, you can
change the resolution for the HDMI output.
(Page 15)
, Note
yChanging the resolution when the connection
has already been established may result in
malfunctions. To solve the problem, turn off
the unit and then turn it on again.
yWhen the HDMI connection with HDCP is
not veried, TV screen is changed to black or
green screen or the snow noise may occur
on the screen. In this case, check the HDMI
connection, or disconnect the HDMI cable.
yMake sure the unit is connected directly to
the TV. Tune the TV to the correct video input
channel.
> Caution

Connecting 15
Connecting
2
yIf a connected HDMI device does not accept
the audio output of the unit, the HDMI
device’s audio sound may be distorted or may
not output.
yWhen you connect a HDMI or DVI compatible
device make sure of the following:
- Try switching off the HDMI/DVI device and
this unit. Next, switch on the HDMI/DVI
device and leave it for around 30 seconds,
then switch on this unit.
- The connected device’s video input is set
correctly for this unit.
- The connected device is compatible with
720 x 480i (or 576i), 720 x 480p (or
576p), 1280 x 720p, 1920 x 1080i or
1920 x 1080p video input.
yNot all HDCP-compatible HDMI or DVI devices
will work with this unit.
- The picture will not be displayed properly
with non-HDCP device.
- This unit does not playback and TV screen
is changed to black or green screen or the
snow noise may occur on the screen.
yIf there is noise or lines on the screen, please
check the HDMI cable and use a higher
version cable than High Speed HDMI™ Cable.
yThe HDMI sounds output only DVD.CD
function.
, Note Resolution Setting
The unit provides several output resolutions for
HDMI.
You can change the resolution using [Setup] menu.
1. Press ! on the remote control.
2. Use W/S/A/D on the remote control to
select the [Setup] and press m on the remote
control.
The [Setup] menu appears.
3. Use W/S on the remote control to select
[Display] option then press Don the remote
control to move to the second level.
4. Use W/S on the remote control to select the
[Resolution] option then press D on the remote
control to move to the third level.
5. Use W/S on the remote control to select the
desired resolution then press m on the remote
control to confirm your selection.
yIf your TV does not accept the resolution you
have set on the unit, you can set resolution to
480p (or 576p) as follows: Press Z on the
remote control for more than 5 seconds
y[Home Menu] appears only on DVD.CD
function.
, Note

Connecting16
Connecting
2
Optional Equipment
Connection
AUX IN Connection
Connect an output of auxiliary device (Camcorder, TV,
Player, etc) to the AUX IN (L/R) connector.
If your device has only one output for audio (mono),
connect it to the left audio jack on the unit.
Unit
Red
White
Listening to music from your external
device
The unit can be used to play the music from many
types of external device.
1. Connect the external device to the AUX IN (L/R)
connector of the unit.
2. Turn the power on by pressing 1.
3. Press F to select AUX.
4. Turn on the external device and start it playing.
Audio cable
DVD, Blu-ray player etc.

Connecting 17
Connecting
2
USB Connection
Connect a USB device (or MP3 player, etc.) to the
USB ports on the unit.
USB device
Removing the USB device from the unit:
1. Choose a different function/mode or press
I once.
2. Remove the USB device from the unit.
, Note

3 System Setting
System Setting18
System Setting
3
Adjust the setup
settings
By using the Setup menu, you can make various
adjustments to items such as picture and sound.
You can also set a language for the subtitles and the
Setup menu, among other things. For details on each
Setup menu item, see pages 18 to 21.
OSD Initial language settings -
Optional
During the rst use of this unit, the initial language
setup menu appears on your TV screen. You must
complete initial language selection before using the
unit. English will be selected as the initial language.
1. Press 1 to turn the unit on. The language setup
menu will appear on the screen.
2. Use W/S/A/D on the remote control to
select a language then press m on the remote
control.
The confirm menu will appear.
3. Use A/D on the remote control to select the
[Enter] then m on the remote control to finish
the language setup.
To display and exit the Setup
menu
1. Press !on the remote control.
Displays the [Home Menu].
2. Select an [Setup] by using A/Don the remote
control.
3. Press mon the remote control.
Displays the [Setup].
4. Press !on the remote control or ]on the
remote control to exit in the [Setup] Menu.
About help menu for Setup
Menu Buttons Operation
W/S
Move W/S Moving to another
menu.
A
Move AMoving to previous level.
D
Move DMoving to next level
or selecting menu.
]
Close ]To exit the [Setup]
menu.
m
Select mTo conrm menu.
[Home Menu] appears only on DVD.CD function.
, Note

System Setting 19
System Setting
3
Language
Menu Language
Select a language for the Setup menu and on screen
display.
Disc Audio / Disc Subtitle / Disc Menu
Select the language you prefer for the audio track
(disc audio), subtitles, and the disc menu.
[Original]
Refers to the original language in which the disc
was recorded.
[Other]
To select another language, press numeric
buttons and then m on the remote control
to enter the corresponding 4-digit number
according to the language code list on the page
38.
If you enter the wrong language code, press
CLEAR on the remote control.
[Off (for Disc Subtitle)]
Turns off Subtitle.
Display
TV Aspect
Select the screen aspect to use based on the shape
of your TV screen.
[4:3]
Select when a standard 4:3 TV is connected.
[16:9]
Select when a 16:9 wide TV is connected.
Display Mode
The Display Mode setting works only when the TV
Aspect mode is set to 4:3.
[Letterbox]
Displays a wide picture with bands on the upper
and lower portions of the screen.
[Panscan]
Automatically displays the wide picture on the
entire screen and cuts off the portions that do
not t. (If the disc/le is not compatible with Pan
Scan, the picture is displayed at Letterbox ratio.)
Resolution
Sets the output resolution of HDMI video signal.
Refer to “Resolution Setting” for details about the
resolution (page 15).
[Auto]
If the HDMI jack is connected to TVs providing
display information (EDID), automatically selects
the resolution best suited to the connected TV.
[1080p]
Outputs 1080 lines of progressive video.
[1080i]
Outputs 1080 lines of interlaced video.
[720p]
Outputs 720 lines of progressive video.
[480p (or 576p)]
Outputs 480 (or 576) lines of progressive video.
[480i (or 576i)]
Outputs 480 (or 576) lines of interlaced video.

System Setting20
System Setting
3
Audio
DRC (Dynamic Range Control)
Make the sound clear when the volume is turned
down and prevent a sudden sound increase (Dolby
Digital only). Set to [On] for this effect.
HD AV Sync
Sometimes Digital TV encounters a delay between
picture and sound. If this happens you can
compensate by setting a delay on the sound so that
it effectively ‘waits’ for the picture to arrive: this is
called HD AV Sync. Use W/S on the remote control
to scroll up and down through the delay amount,
which you can set at anything between 0 and
300ms.
