LG V-NET PDRYCB100 User manual

P/NO : MFL67708304
www.lg.com
TYPE : Simple Dry contact
MODEL : PDRYCB100
INSTALLATION MANUAL
• Please read this installation manual completely before installing the product.
• Installation work must be performed in accordance with the national wiring
standards by authorized personnel only.
• Please retain this installation manual for future reference after reading it
thoroughly.
ENGLISH ITALIANO ESPAÑOL FRANÇAIS DEUTSCH
PORTUGUESE
РУССКИЙ ЯЗЫК

2Dry Contact
Dry Contact Unit Installation Manual
TABLE OF CONTENTS
nSafety Precautions.................................................................3
nOverview ................................................................................6
nPart Description......................................................................8
nInstallation Method .................................................................9
Installation................................................................................................9
nInstallation Guide..................................................................11
Step1......................................................................................................11
Step2......................................................................................................12
nAdministrator Guide .............................................................13

Safety Precautions
Installation Manual 3
ENGLISH
nInstallation
Service
Center
Service
Center
To prevent injury to the user or other people and property damage, the following instructions
must be followed.
nIncorrect operation due to ignoring instruction will cause harm or damage. The seriousness is
classified by the following indications.
nMeanings of symbols used in this manual are as shown below.
WARNING
CAUTION
This symbol indicates the possibility of death or serious injury.
This symbol indicates the possibility of injury or damage.
Be sure not to do.
Be sure to follow the instruction.
WARNING
Don’t touch with the hands
while the power is on.
• Cause fire, electric shock, ex-
plosion or injury.
Product installation must
be referred to a service
center or installation shop.
• Cause fire, electric shock, ex-
plosion or injury.
Request installation from
installation shop or service
center when reinstalling
the product.
• Cause fire, electric shock, ex-
plosion or injury.
Safety Precautions

Standardized
product
Safety Precautions
4Dry Contact
Do not install the product
in the place where rain can
get to the product.
• Cause product failure
Do not install the unit in
humid locations.
• Cause product failure
Do not put the product
closer to fire.
• Cause fire
Do not install in a place
that cannot withstand the
weight of the product.
• The product may get dam-
aged or may break.
Do not install the product
to a place that generates
oil, steam, salt, sulfuric
gas, etc.
• Cause the product’s deforma-
tion or failure.
Use standardized Product.
• Cause product failure
Do not change or extend
power lines arbitrarily.
• Cause fire or electric shock.
Do not give a shock to the
product.
• If you give a shock to the prod-
uct, it may cause the product’s
failure.
Do not use a heater near
the power line.
• Cause fire or electric shock.
nOperation

Service
Center
STOP
Safety Precautions
Installation Manual 5
ENGLISH
Do not spill water inside of
the product.
• Cause electric shock or
breakdown.
If the product has been in-
undated, you must refer to a
service center or installation
shop.
• It can cause a fire.
Children and elderly use the
product under the
guardian’s supervision.
• Cause accidents and product
failures.
Do not use for special pur-
pose / place such as con-
serving flora and fauna,
precision instruments, art.
• Otherwise, it can cause property
damage.
Remove the power plug
when cleaning.
• Cause fire or electric shock.
Do not place heavy objects
on the power line.
• Cause fire or electric shock.
Do not disassemble, repair,
or modify the product.
• Cause fire or electric shock.
Do not touch with wet
hands.
• Cause fire or electric shock.

6Dry Contact
Overview
LG Dry Contact is a solution for automatic control of air conditioning system at the owner’s behest.
In simple words, it’s a switch which can be used to turn the unit On/Off after getting the signal from external
sources like key-in lock, door or window switch etc specially used in Hotel rooms.
It’s a small PCB that either can be fit inside the control box of Indoor unit or can be outside the unit in a plastic case
if there is no sufficient space inside the Indoor unit.
Apart from simple installation, it can also be linked to Central Controller via Indoor unit PI485 pcb. For this, all con-
necting wires & an additional small pcb for looping is also provided along with Dry Contact.
Dry Contact can be used in two ways.
1. It can be used to actually turn On/Off the system on receiving the signal from the source.
In this case, user doesn't need to use remote controller anymore to turn On/Off the system.
However all the further settings like temperature, fan speed, mode etc can be done through remote controller
only.
2. Other way is almost similar as above but in this case, after getting the On signal from the external source, user
has to turn On the system from remote controller only. Dry contact just activates the system.
However system can be turned Off directly from the external source. So only On mode is different here.
So in both of above conditions, system can’t be operated without signal from external source which prevents un-
necessary use of system & facilitates its operation only when its required.
These settings can be selected from the remote controller whose details have been explained in the later part of
this manual
So depending upon the requirement, Dry Contact offers a variety of applications to suit the customer’s requirement
in the best possible way.
Overview

Installation Manual 7
ENGLISH
Overview
Indoor PCB
Connector
Power Connector
Dry Contact Controller
Connector

8Dry Contact
Part Description
PDRYCB100 (PCB + Case)
CN-POWER : 24 V~ Connector
CN-CC : Indoor PCB Connector
CN_DRY(L): DRY CONTROLLER Connector
CN_DRY(SIG): DRY CONTROLLER Connector
CN_DRY(ERROR CHECK): ERROR Check Display Connector
CN_DRY(OPER STATE): Operation Display Connector
1
2
3 4 5 6
PCB
Front Case Rear Case
Side Side
ISO View
Cable(1 EA)
(For Connecting with indoor unit)
Installation Manual
Cable 1 EA
(For Central Controller)
Connecting PCB:
6871A30056A
1
2
3
4
5
6
Part Description
* Others :
Screw 4 EA(For installation)
Clamp 4 EA(For installation)

Installation Manual 9
ENGLISH
Installation Method
Installation
1) Loosen and remove two screws that secure the prod-
uct.
2) Position the rear case to the direction towards to the
connector for convenient cable arrangement.
3) Secure the rear case on the installation place using the
supplied fixing screws.
4) Remove knock out shapes on the rear case (4-sided)
according to the connector’s size and direction.
Installation Method

10 Dry Contact
Installation Method
5) Connect the connection wires properly according to the connection method. (Refer to the instruction
and set-up description)
6) Set the switch according to the setting method. (Refer to the instruction and set-up description)
7) Tighten the fixing screws on the top and bottom of the case.
1. Install the product on flat surface and install anchoring screws at more than 2 places. Otherwise
the central controller may not be anchored properly.
2. Do not tighten anchoring screws too tightly. It may cause deformation of the case.
3. Do not deform the case at random. It may cause malfunction of the central controller.

Installation Manual 11
ENGLISH
Installation Guide
Step 1
4
3
2
4
3
2
1 1
2
21
1
DRY CONTACT
PCB
Indoor
PCB
CN-CC CN-CC
24 V~
4
3
2
4
3
2
1 1
2
21
1
DRY CONTACT
PCB
Indoor
PCB
CN-CC CN-CC
24 V~
Connection PCB
(6871A30056A)
PI485 PCB : Special purchase for
Central Control
(Ex : PHNFP14A0 or PSNFP14A0...)
L1 2 3 4
* Single Only
- When you install single product this PCB have to add.
Connect CN-CC with Indoor PCB by the cable(provided)
- Connection of Dry contact only
- Connection of Dry contact & LG Central Controller in case of single constant models.
Installation Guide

12 Dry Contact
Installation Guide
Step 2
Connect CN_DRY with Control Unit .
(Fix SUB PCB into the proper location.)
- To apply power source through PCB
- To apply power source directly to external source
Dry contact
Controller
4
3
2
4
3
2
1 1
2
21
1
L
N
DRY CONTACT
PCB
INPUT
24 V~
RLY2 RLY1
CN_DRY
CN_DRY
Operation Display
Error Check Display
CN-CC
Dry contact
Controller
4
3
2
4
3
2
1 1
2
21
1
L
N
24 V~
RLY2 RLY1
Operation Display
Error Check Display
CN-CC
LG does not
supply this section
LG does not
supply this section
DRY CONTACT
PCB

Installation Manual 13
ENGLISH
Administrator Guide
* Function
It gives selection whether to turn ON the unit directly or not from the external source.
The selection can be made by pressing CANCEL button of the wireless remote controller
3 times within 3 minutes of resetting the unit with facing it towards the unit.
(This function availability depends on indoor unit model)
1. To turn ON the unit directly from the external source
2. Not to turn ON the unit directly from the external source.
Only to activate the system.
If the power gives out, the Air conditioner may be run to before state after
power returns because Air conditioner's function of interruption of electric
power compensation.
ON OFF
CANCEL
AUTO CLEAN
SET
CANCEL Button
Administrator Guide

14 Dry Contact

www.lg.com
TIPO: Dry contact semplice
MODELLO : PDRYCB100
MANUALE D’INSTALLAZIONE
• Leggere questo manuale d’istruzioni prima di installare il condizionatore
d’aria.
• Il lavoro d’installazione deve essere eseguito conformemente alla normativa
vigente sugli impianti elettrici, solo da personale tecnico autorizzato.
• Dopo averlo letto dettagliatamente, conservare questo manuale come
riferimento per il futuro
ITALIANO

2Dry Contact
Manuale di Installazione Unità Dry Contact
INDICE
nPrecauzioni di sicurezza.........................................................3
nPanoramica.............................................................................6
nDescrizione delle parti ............................................................8
nMetodo di installazione ...........................................................9
Installazione..............................................................................................9
nManuale d’installazione ........................................................11
Passaggio 1............................................................................................11
Passaggio 2............................................................................................12
nGuida per l’amministratore ...................................................13

Misure di sicurezza
Manuale d’installazione 3
ITALIANO
nDurante l’installazione
Misure di sicurezza
Per prevenire lesioni all'utente o ad altre persone e danni alla proprietà, seguire le precauzioni
seguenti.
nL'errato utilizzo a causa della mancata lettura delle istruzioni può provocare lesioni o danni.
La gravità è classificata dalle indicazioni seguenti.
nI significati dei simboli utilizzati in questo manuale sono indicati di seguito.
AVVERTENZA
ATTENZIONE
Questo simbolo indica la possibilità di morte o lesioni gravi.
Questo simbolo indica la possibilità di lesioni o danni.
Vietato.
Accertarsi di seguire le istruzioni.
AVVERTENZA
Centro
assistenza
Centro
assistenza
Non toccare con le mani
quando l’alimentazione
elettrica è attiva.
• Questo può produrre incendio,
scossa elettrica, esplosione, o
ferimento alle persone.
L’installazione del prodotto
deve essere eseguita dal
personale del venditore o dal
centro di servizio.
• Questo può produrre incendio,
scossa elettrica, esplosione, o
ferimento alle persone.
Richiedete di far eseguire
l’installazione dal personale
del venditore o dal centro di
servizio quando si reinstalla
il prodotto.
• Questo può produrre incendio,
scossa elettrica, esplosione, o
ferimento alle persone.

Misure di sicurezza
4Dry Contact
Prodotto
standardizzato
Non installare il prodotto in
una posizione in cui la pioggia
possa cadere sul prodotto.
• Si può produrre un guasto del
prodotto.
Non Installare l’unità in locali
umidi.
• Si può produrre un guasto del
prodotto.
Non installare il prodotto in
vicinanza di una sorgente di
fuoco.
• Si può produrre un incendio.
Non installare in una
posizione che non possa
sopportare il peso del
prodotto.
• Il prodotto può essere
danneggiato o rompersi.
Non installare il prodotto in
una posizione che genera
olio, vapore, sale, gas
solforico, ecc..
• Questo può produrre
deformazione o guasto del
prodotto.
Usare il prodotto
standardizzato
• Si può produrre un guasto del
prodotto
Non modificare o prolungare
le linee di alimentazione in
modo arbitrario.
• Questo può produrre incendio o
scossa elettrica.
Non provocare urti sul
prodotto.
• Se si produce un urto sul prodotto,
questo può provocare un guasto.
Non usare un riscaldatore
vicino alla linea di
alimentazione.
• Questo può produrre incendio o
scossa elettrica.
nDurante l’uso

Misure di sicurezza
Manuale d’installazione 5
ITALIANO
Centro
assistenza
Arresto
Non versare l’acqua entro il
prodotto.
• Questo può produrre scossa
elettrica o un guasto al prodotto.
Se il prodotto ha subito un
allagamento, chiamare il
centro di servizio o il
negozio di installazione.
• Questo può produrre incendio o
scossa elettrica.
I bambini e le persone
anziane devono usare il
prodotto con la
supervisione di una persona
addestrata al suo uso.
• Questo può provocare incidenti
e guasti del prodotto.
Non usare per un uso/posizione
speciale come mantenimento di
flora e fauna, strumenti di
precisione, oggetti artistici,
ecc..
• In caso contrario si può produrre
un danno alla proprietà.
Staccare la spina di
alimentazione quando si
esegue la pulizia del
prodotto.
• Questo può produrre incendio o
scossa elettrica.
Non appoggiare oggetti
pesanti sulla linea di
alimentazione.
• Questo può produrre incendio o
scossa elettrica.
Non smontare, riparare o
modificare il prodotto.
• Questo può produrre incendio o
scossa elettrica.
Non toccare il prodotto con
le mani umide.
• Questo può produrre incendio o
scossa elettrica.

6Dry Contact
Panoramica
LG Dry Contact è una soluzione per il controllo automatico del sistema di condizionamento dell'aria su richiesta
dell'utente.
In altri termini, si tratta di un interruttore che può essere usato per accendere/spegnere l'unità dopo avere ottenuto
il segnale da sorgenti esterne come blocco a chiave, interruttore di porte o finestre, ecc. impiegati prevalentemente
nelle camere d'albergo.
Si tratta di un piccolo PCB che può essere installato all’interno della scatola di controllo dell’unità Interna oppure
può trovarsi all’esterno dell’unità in una custodia di plastica se non è presente spazio sufficiente all’interno
dell’unità Interna.
Oltre alla semplice installazione, esso può essere collegato al Controller Centrale attraverso la pcb PI485 dell’unità
Interna. Per questa ragione, tutti i fili di collegamento e una ulteriore piccola pcb per l’iterazione sono forniti insieme
al Contatto Pulito.
Dry Contact può essere utilizzato in due modi.
1. Può essere usato per accendere/spegnere di fatto il sistema o per ricevere il segnale dalla sorgente.
In questo caso non è necessario che l’utente utilizzi un telecomando per accendere/spegnere il sistema.
Tuttavia, tutte le ulteriori impostazioni come temperature, velocità della ventola, modalità di funzionamento ecc.
Devono essere realizzate solo attraverso il telecomando.
2. L’altra modalità è molto simile a quella precedente ma, in questo caso, dopo aver ottenuto il segnale dalla fonte
esterna, l’utente deve solo accendere il sistema dal telecomando. Dry contact semplicemente attiva il sistema.
Tuttavia, il sistema può essere spento direttamente dalla fonte esterna. Quindi qui è differente solo la modalità di
accensione.
Quindi, in entrambe le condizioni di cui sopra, il sistema non può entrare in funzione senza un segnale proveniente
dalla fonte esterna che previene l’utilizzo non necessario del sistema e facilita il suo utilizzo solo quando richiesto.
Queste impostazioni possono essere selezionate dal telecomando i cui dettagli sono stati spiegati nell’ultima parte
del presente manuale
Quindi a seconda della necessità, Dry Contact offre una varietà di applicazioni per adattarsi alle richieste del
cliente nel miglior modo possibile.
Panoramica
Other manuals for V-NET PDRYCB100
1
Table of contents
Languages:
Other LG Switch manuals
Popular Switch manuals by other brands

Motorola
Motorola WS2000 - Wireless Switch - Network Management... Cli reference guide

NEC
NEC N8191-09 user guide

Oracle
Oracle Fabric Interconnect F2-12 installation guide

OEZ
OEZ PS-BHD-1000-Au Instructions for use

Motorola
Motorola EX-3524 Cli reference guide

Siemens
Siemens RUGGEDCOM RS8000 installation guide

ISON
ISON IS-RG528 Series Web Configuration Tool Guide

Southern States
Southern States COLE L Installation instructions manual

Kontron
Kontron MSH8900 user guide

DANLERS
DANLERS TLSW A20 Installation notes

Westermo
Westermo RFIR-127-F4G-T7G-DC user guide

Micas
Micas M2-W6510-32C Hardware installation and reference guide
