LG Code Zero A9 Series User manual

Caution : Please read the safety cautions of this booklet
before checking theproduct.
Buyer Model Name : A9******
Factory Model Name : VS97******
P.No MFL68043138
LG Code Zero
SVC Manual

-2-
Content
■ Product features ..............................................................................................................3
■ Parts and names ......................................................................................................... 4-5
■ Cleaner features ...............................................................................................................6
■ Check these out before use .......................................................................................7
■ Cautions for general usage .............................................................................. 8-12
■ Technical descriptions of parts ............................................................................ 13
■ How to use ............................................................................................................. 14-20
■ Disassembly, assembly and repairing of main parts ........................ 21-27
■ Cautions and what to check for repairing .................................................... 28
■ Circuit diagram ..................................................................................................... 29-32
■ Symptoms of malfunctions and measures ........................................... 33-34
■ Cleaning functions and error modes ................................................................ 35
■ Exploded diagram ............................................................................................... 36-43

-3-
Product features
Item Charger (Adaptor)
Input 100 - 240 V~ 50/60 Hz, 0.8 A
Output DC 29.4 V 1.0 A
Item/Model Battery
Type Rechargeable Lithium Battery
Rated DC 25.55 V , 1900 mAh
Number of
battery cells 7 ea.
Manufactured
by
LG Chem (Battery pack manufactured
by Peopleworks)
LG Chem (Battery pack manufactured
by TWS TECHNOLOGY
(GUANGZHOU) LIMITED)
1) The result is average of suction power with ASTM-F558 standard tested by individual test lab. Individually measured data would be differ-
ent with the test result.
2) Test result according to our test standard, it may be different depending on actual use environment and period of use.
3) Floor, carpet, bedding only (suction port may vary by model)
Item/Model A9*********
Dimensions 260 mm(W) X 270 mm(L) X
1120 mm(H)
Weight 2.7 kg
Power consump-
tion:
400 W (Maximum power: 450 W)/250 W/
80 W (Turbo/Power/Normal)
Suction power 140 W 1)
Battery DC 25.55 V
Battery runtime2)
(When fully
charged, and using
the Power Drive
nozzles3))
Approx. 6 minutes in Turbo
Approx. 9 minutes in Power
Approx. 30 minutes in Normal
Battery run-
time2) (When
fully charged, and
without using
the Power Drive
nozzles3))
Approx. 6 minutes in Turbo
Approx. 9 minutes in Power
Approx. 40 minutes in Normal

-4-
Parts and names
Standing type Wall-mount type
6
1
4
10
5
2
3
8
7
9
6
14
10
2
3
9
1Product body
2Extension pipe
3Multi-surface Power Drive Nozzle®
4Charging station
5Charging station pipe
6Combination tool and crevice tool
holder
7Detachable stand for nozzle and
mop pads
8Charging station support
9Adaptor
10 Battery
Body parts
•
Parts and accessories may vary depending on the model that you have purchased.
Product body Extension pipe Power Drive Floor
Nozzle
Charging station Adaptor
Battery Crevice Tool Combination Tool Wall Anchoring Block Double-sided tape (2)
Screw Anchor (2) Anchoring screw for
wall-mount type (Φ
3.5 mm, length
50 mm)(2)
Anchoring screw for
standing type
(Φ3.5 mm, length
90 mm)
Pre-Filter
(Spare)

-5-
Parts and names
• Please note that these parts come with their corresponding models only.
Hard Dirt Tool Mattress Tool Flexible CreviceTool Multi Angle Tool Flexible Hose Extension
1)
Battery Hard Floor Power Drive
Nozzle®
Bedding Power Punch Mop Nozzle Accessory bag
2) 2)
Detachable stand for
mop pads
Detachable stand for
nozzle
Mop pads (4) Mop pads (6) Water filler jug
Charging station pipe Charging station
support

-6-
Cleaner features
1.Theproductboastsofpowerfulsuctionthatcanbeadjustedperpurposeandsite.
The integrated inverter motor ensures consistent suction and you can adjust the
suction strength depending on where you are cleaning.
2.Antitanglepowernozzle
For cleaning ultrafine particles
3.Duallithiumbatteries
Two long-life dual lithium batteries eliminates the need for chargingin the middle of
cleaning. Each battery lasts about 40 minutes in the Standard mode and thetwo give
you approximately 80 minutes of cleaning.
4.Independentwallmountingchargingstation
Independent wall mounting charging station eliminates the need tosecuring the space
for the charging station.
5.Wirelessconvenience
The product can be used remotely so that the inconvenience fromcables can be
eliminated.

-7-
Check these out before use
Points to be aware of when using the
product
•
Make sure that the dustbin lid is on prior to using the
product. Otherwise, the suction strength will deteriorate
and cleaning will not be satisfactory.
•
Support the bottom of the product when cleaning an
elevated surface.
•
When leaving the product unattended or unused for an
extended period, make sure to place it properly on the
charging station or lie it on the floor. Otherwise, the product
may fall and get damaged or cause an injury.
•
Make sure that the exhaust filter is properly assembled
before using the product.
•
Environmental conditions such as temperature and humidity
may cause static to accumulate on the product. Please
contact the customer service department of LG Electronics
if the problem persists.
•
Any foreign object on the inlet port or extension pipe will
prevent the product from functioning properly. Make sure to
remove any foreign object such as a sock or stocking before
using the product.
•
The battery runtime will be shortened after using the
product repeatedly for an extended period due to its
characteristics.
•
When the battery is about to become fully run down during
use, the last block on the battery indicator will start to flash
and the product will power off after a while. Fully charge
the battery in this case.
•
Please use the product at normal room temperatures as
the battery runtime will deteriorate severely if used at
temperatures lower than 5℃or higher than 38℃for an
extended period of time.
•
Refer to Product specifications for battery run time details.
•
These times are a guide only and may be less depending on
the surface type.
•
It is recommended to swap the battery on the main body
and the battery on the auxiliary charging station regularly
for maintaining the maximum life of the batteries. (For
dual-battery models only)

-8-
Cautions for general usage
The following cautions are intended to protect you from unexpected risk or property loss by ensuring safe and
correct usage of the product.
Cautions are categorized into 'Warning' and 'Caution', which mean:
Pictograms are designed to draw attention to matters and uses that may pose a risk to the
user. Make sure to carefully read any item marked with this symbol and comply with it to
prevent any risk.
WARNING
Failure to comply with this warning may result in serious damage, injury or even death
to the user.
CAUTION
Failure to comply with this warning may result in damage to the product or moderate
injury to the user.
WARNING
1. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concern-
ing use of the appliance by a person responsible for their safety.
2. Children should be supervised to ensure that they do not play with the ap-
pliance.
3. If the supply cord is damaged, it must be replaced by an LG Electronics Ser-
vice Agent in order to avoid a potential hazard.
4. This appliance can be used by children aged 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or instruction concern-
ing use of the appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance must not be performed by children without
supervision.

-9-
Cautions for general usage
Installation and Usage Power requirements
Do not install, charge or store the product where it
may be exposed to water, rainfall or severe moisture.
Do not use the product in any outdoor location, work-
shop or garage environment.
•Such conditions will leave the product vulnerable to re
when charging the battery.
•Please install, charge or store the product in a well-venti-
lated place.
Make sure to avoid places where there is a risk of
leakage of ammable gas, industrial oil or metallic
dust.
•It may cause product malfunction or damage.
If you intend to use the charging station by "stand-
ing" it vertically (standing type), make sure to secure
it to the wall with the appropriate type of screws .
•Otherwise, the charging station or product may slant and
become damaged or cause property damage or injury.
Please place the charging station on an even surface.
•Otherwise, the product may fall and sustain damage or
cause an injury.
If you intend to mount the charging station on a wall
(wall-mounted type), make sure to secure it tightly to
the wall using the appropriate type of screws.
•Failure to do so may damage the product and/or cause an
injury.
Please use the anchoring screws only when the wall is
made of concrete or is solid enough.
•If the Station mounting is performed on an unsuitable
wall it may cause injury and damage the property or prod-
uct.
Never install the charging station on a wall with any
piping (gas, water, air) or power cables behind it.
•There is a risk of injury from electric shock, re or ood-
ing
Do not use or store the product at temperatures
below 5 ° C or above 38 ° C.
•Failure to do so may damage the product.
This product should only be used with AC 230 V.
Make sure to check the power specications of the
place where you intend to use the product.
•The wrong specications will result in electric shock or
damage the product in the event of a short-circuit.
Do not apply excessive force to the power cord to
bend it, or place it under a heavy object as this will
damage it.
•The power cord may get damaged and cause electric
shock or injury.
Please refrain from using multiple power appliances
in one power board or power socket and make sure to
use a power socket with a capacity of 10A.
•Failure to do so may result in re due to abnormal over-
heating of the socket.
•Or it may activate the circuit breaker leading to a loss of
power.
Never touch the power cord and plug with a wet
hand.
•This may result in injury or electric shock.
Please clear any dust or water from the power cord
and plug with a dry cloth.
•Failure to do so may result in electric shock, short circuit
or re.
When unplugging the power cord, never pull the cord
itself and always hold the power plug.
•Failure to do so will damage the cord it and may result in
electric shock or re.
Stop using the product and contact the customer ser-
vice department of LG Electronics if the power cord
or power plug is damaged or the holes of the power
outlet socket are loose.
•Failure to do so may result in electric shock or re.
Make sure to unplug the power cord when cleaning or
maintaining the charging station.
•Failure to do so may result in injury or electric shock.
Make sure to unplug the power cord when the prod-
uct is not to be used for an extended period of time.
•Failure to do so may result in electric shock, short circuit
or re.
Make sure to organize the power cord of the charging
station while using or cleaning the product.
•Otherwise, the cord may get tangled with the product and
result in malfunction, electric shock or injury if its discon-
nected or broken.

-10-
Cautions for general usage
In the event of a gas leakage (propane or urban gas),
make sure to ventilate the area rst without coming
into contact with the product or its power plug.
•Otherwise, there may be sparks which may result in an
explosion, re or injury.
Do not use or store a heating device or ammable
substance(ether, benzene, alcohol, chemicals, com-
bustible spray, insecticide, air freshener or cosmetics)
in close proximity to the product.
•It may result in product malfunction or re.
Do not attempt to clean up a liquid substance (water,
beverage), odorous substances (candy, chocolate,
pet excrement, etc.), metallic objects (such as blade,
pins), ammable substances, surface active agents,
or glass shards with this product.
•It may result in product malfunction or re.
•In the event that any liquid, metallic object, glass shard
or spark gets inside the product, immediately turn off
the product and contact the customer service depart-
ment of LG Electronics.
Do not use the product with the exhaust or inlet port
blocked.
•It will cause the product to overheat and result in mal-
function or re.
In the event that smoke is emitted by the product
while it is charging, immediately unplug the power
cord and contact the customer service department of
LG Electronics.
•Failure to do so may cause electric shock or re.
Do not expose the product, and the battery in partic-
ular, to heat, a heating device or direct sunlight.
•It may result in electric shock, explosion or re.
Do not keep the product or its battery inside a vehicle
which is exposed to direct sunlight.
•It may cause re or explosion.
In the event that some kind of liquid leaks from the
battery, make sure that it does not contact the skin
or eyes.
•It may burn the skin or severely damage the eyes.
•If liquid from the battery comes into contact with part
of the skin, immediately wash it off with plenty of wa-
ter and seek medical advice.
Make sure that no child is allowed to use the product.
•The product is too heavy for a child to handle properly.
Make sure that no hand, foot, hair or clothes gets
stuck in the rotating brush or wheel while using or
cleaning the product.
•Failure to do so may damage the product or result in
injury.
No one other than a qualied technician/service en-
gineer from LG Electronics may disassemble, repair or
modify the product.
•Do not attempt to disassemble or repair the product
yourself as it may result in electric shock, injury or re.
Never use the battery, the charging station and the
adaptor with other appliances other than this prod-
uct.
•It may cause a product malfunction or fire.
Do not use the battery of another appliance in the
product.
•It may cause malfunctioning or re.
Do not arbitrarily disassemble, remove or short-cir-
cuit the battery.
•It may result in electric shock, injury or re.
Do not apply heat or shock to the battery.
•It may cause electric shock, injury or re.
Never insert a sharp metallic object such as a pin, nail
or knife in a hole or gap in the product or the charging
station.
•Otherwise, you may get injured or suffer electric shock.
Do not vacuum liquids with this product. Make sure
that no water, beverage or detergent gets inside the
product or the charging station.
•Failure to do so may result in injury or electric shock.
Do not apply or spray a ammable substance (gaso-
line or thinner) or surface active agent (detergent or
bath soap) on the product.
•It may result in malfunction or re.
Proper usage

-11-
Cautions for general usage
Do not wash the inlet port with water or detergent.
•As the inlet port contains a motor, it may result in elec-
tric shock or re.
Always use the charging station and adaptor provid-
ed with the product to charge the product and its
battery.
•Using any charging device other than the provided
station will damage the battery and result in electric
shock, explosion or re.
Never allow any water, beverage or detergent to get
inside the battery.
•It may cause electric shock, explosion or re.
Do not touch the charging terminals on the product
or the charging station, or insert an electried object
inside the product or the station.
•Otherwise, you may get injured or suffer electric shock.
Always leave the product on the oor standing or
wall-mount charging station when it is not in use. Do
not leave the product on the charging station not
xed to the wall or charging station support.
•Otherwise, the product may fall and get damaged or
cause injury.
In the event that the earth leakage breaker gets
activated while the product is placed on the charging
station, immediately remove the product from the
station and contact the customer service department
of LG Electronics.
•Failure to do so may cause electric shock or re.
Do not wash the dust bin with water.
•The water will get into the motor and cause electric
shock or re.
Do not attempt to vacuum ne dust such as cement
with the product.
•It may cause product malfunction or re.
Make sure that no child can play with the product,
charging station or battery.
•It may damage the product and cause an injury.
•If a child places the product or battery into its mouth,
it will cause electric shock or injury, or damage the
product or battery.
When using the product, remove the wire or string
from the bottom.
•Straps or wires may wrap around the product and
cause a product malfunction or a broken cord.
Discard the packing materials (plastic vinyl, styro-
foam) properly so that no child comes into contact
with them.
•Such materials may cause a child to suffocate.
When disposing of the product, make sure to remove
the battery from the product’s body.
•Failure to do so may result in re or explosion.
Disposal

-12-
Cautions for general usage
Do not apply impact to the product or drop it from a
height.
•It may damage the product and/or result in injury.
Make sure that the product does not fall.
•It may cause injury or damage the product.
Make sure that the filter is installed in the product
prior to each use.
•Failure to install a filter may result in product malfunction.
Make sure to wipe up any liquid such as water or oil
or pet excrement from the floor before using the
product.
•Such substances will cause the unit to malfunction or
cause irreparable damage
Do not clean the product with a volatile or organic
solvent (thinner or acetone).
•It may damage the product.
•Always use a soft cloth to clean the product.
Make sure to avoid running into a person or a pet
while using the product.
•It may cause injury.
Do not kick or apply impact to the product.
•It may cause the product to malfunction.
Do not put any object other than the product,
especially a metallic or magnetic object, on the
charging station.
•It may damage the product or cause electric shock.
Do not clean the same spot repeatedly for an
extended period of time.
•Vibration from the inlet port or rotating brush may
damage the floor or the carpet.
Make sure that your finger does not get stuck when
assembling the product or the charging station.
•It may injure your finger.
Do not let a child or a pet hang onto the charging
station.
•It may cause injury or damage the product.
Do not put double-sided tape directly onto the
wallpaper as it may be torn by external force.
•Anchor the charging station with the wall anchoring
screw(s) to prevent tearing of the wallpaper.
Do not apply force or impact to the filter parts or
dust bin parts.
•The parts may become deformed, compromise the
performance or cause the unit to malfunction.
Do not remove the battery during operation.
•It may cause the product to malfunction.
CAUTION
Proper usage

-13-
Technical descriptions of parts
Item S97*********
Category Integrated motor
Power DC 25.55V
Power consumption 400 W (MAX : 450 W)
R. P. M 115000 R.P.M
Lifecycle More than 205 hours
Model

-14-
How to use
Installing the floor standing
charging station
1Place the charging station support on the floor and
assemble the charging station pipe, the Detachable
stand for nozzle and mop pads and the charging
station in this order.
Click
Detachable
stand for
mop pads
Detachable
stand for nozzle
Charging
station
Charging
station
pipe Charging station
support
CAUTION
•
Avoid getting your fingers stuck in any gap.
2Connect the power adapter to the port on the back of
the charging station and plug the power cord into the
power outlet.
•
The cord can be secured tidily by putting it through
the power cord anchoring ring located on the back
of the charging station pipe.
①
②
3After ensuring there are no pipes or wires inside or
behind the wall, make a hole at the appropriate height
to anchor the charging station and insert the screw
anchor.
•
Recommended diameter of hole: Φ6.5;
Recommended depth: 100 mm.
Screw anchor
4Put the anchoring block on the back of the charging
station and anchor the charging station with the
screw.
•
Make sure to fully tighten the screw.
Anchoring screw
for standing type
Wall anchoring block
Screw
anchor
When using double-sided tape (do not
use if the wall is wallpapered)
1Use double-sided tape to attach the wall anchoring
block to the charging station in step 4.
•
Be sure to remove the center part of the double-sided
tape before mounting it.
Wall anchoring block
2Use the remaining part of the tape to anchor the
station to the wall before inserting the screw.

-15-
How to use
CAUTION
•
Avoid dropping the product and parts when taking them
out of the package. It may damage the product and/or
cause personal injury.
•
Do not use double-sided tape to anchor the charging
station on papered walls. Please use the provided screws
as otherwise the wall paper will get torn by movement of
the charging station during the docking of the unit.
•
We recommend anchoring the station with the anchoring
screw.
•
Use the anchoring screws only when the wall is made of
concrete or is solid enough. An unsuitable wall can cause
the mountings to weaken and cause the Charging station
to fall causing injury and damage the property or product.
•
Do not store the product or battery in the accessory bag
except for the inlet ports and flexible hose extension.
•
Be careful not to throw or drop the accessory bag carrying
accessories such as the inlet ports. It may damage the
product and/or cause personal injury.
•
* The accessory bag is provided only for an applicable
model.
Please note
•
The charging station, its pipe and support cannot be
disassembled separately once they have been assembled,
and the charging station has been attached to the wall.
•
If necessary, the charging station and the nozzle cradle
can be separated from the charging station pipe. Pull the
charging station upward and separate it in sequence while
the charging station support is in a fixed state.
Installing the wall-mount station
1Connect the power adapter to the port on the back of
the charging station and plug the power cord into the
power outlet.
2Ensure that there are no Electrical wires or water pipes
inside the wall where the wall mount bracket will be
attached to. By drilling or screwing, make a hole 1 meter
from the floor to insert the wall plug or screw anchor.
•
Recommended diameter of hole: Φ6.5; Recommended
depth: 60 mm.
3Anchor the station to the wall with the provided
anchoring screws.
1
Wall anchoring
hole
Anchoring
screw for wall-
mount type
Screw
anchor
Please note
•
A service request to change the installation location of the
charging station will incur additional costs if required to do so
by a qualified installer.
•
The Detachable stand for the nozzles and the Detachable
stand for mop pads cannot be separated once they are
assembled.
Uninstalling the station
Keep and charge the product on the charging station after
separating extension pipe and nozzle from the product body.
CAUTION
•
Leaving the extension pipe and nozzle assembled for a long
time may cause damage the product.

-16-
How to use
Storage of the combination tool and
crevice tool
Keep the combination tool and crevice tool on the charging
station for easy access.
1Attach the combination tool and crevice tool to the
dedicated holders.
2Press and hold the inlet removal button and pull
downward to remove the combination tool or crevice
tool.
Nozzles provided additionally can be stored in the accessory
bag.
* The accessory bag is provided only for the applicable
models sold with the Total Care Kit. Do not use the
accessory bag for purposes other than for storage of
nozzles.
Storage of the Mop Nozzle
Storing mop nozzles on the Detachable stand for nozzle
and mop pads helps in finding and using the mop nozzle.
1Mount the mop nozzle to the nozzle cradle.
2Lift the nozzle to separate the mop nozzle.
* The Multi-surface Power Drive Nozzle® can be stored as
well.
Storage of the Mop Pads
Storing mops on the Detachable stand for mop pads helps
in finding and using the mop. Up to 2 mop pads can be
stored.
•
After cleaning with a mop pad, wash and dry the mop
pads before storage. A mop pad which has not been
properly dried may emit an odour when stored.
•
We recommend to hand-wash the mop pad with a pH-
neutral detergent.
•
Do not use bleach or fabric softener when washing the
mop pad.
•
It is not recommended to use a laundry dryer to dry the
mop pad.
•
Do not boil the mop pad. The mop pad may become
deformed.

-17-
How to use
Note about using the product
Points to be aware of when using the
product
•
Make sure that the dustbin lid is on prior to using the
product. Otherwise, the suction strength will deteriorate
and cleaning will not be satisfactory.
•
Support the bottom of the product when cleaning an
elevated surface.
•
When leaving the product unattended or unused for
an extended period, make sure to place it properly on
the charging station or lie it on the floor. Otherwise, the
product may fall and get damaged or cause an injury.
•
Make sure that the exhaust filter is properly assembled
before using the product.
•
Environmental conditions such as temperature and
humidity may cause static to accumulate on the product.
Please contact the customer service department of LG
Electronics if the problem persists.
•
Any foreign object on the inlet port or extension pipe will
prevent the product from functioning properly. Make sure
to remove any foreign object such as a sock or stocking
before using the product.
•
The battery runtime will be shortened after using the
product repeatedly for an extended period due to its
characteristics.
•
When the battery is about to become fully run down
during use, the last block on the battery indicator will
start to flash and the product will power off after a while.
Fully charge the battery in this case.
•
Please use the product at normal room temperatures as
the battery runtime will deteriorate severely if used at
temperatures lower than 5℃or higher than 38℃for an
extended period of time.
•
Refer to Product specifications for battery run time
details.
•
These times are a guide only and may be less depending
on the surface type.
•
It is recommended to swap the battery on the main body
and the battery on the auxiliary charging station regularly
for maintaining the maximum life of the batteries. (For
dual-battery models only)
Using the Product
1Assemble the body, extension pipe, inlet port, and
battery in that order.
Inlet port
Extension pipe Battery
Product
body
2Press the button on the extension pipe to adjust its
length.
•
The pipe has 4 extendable length positions
Pipe length ex-
tension button
3Attach the accessory tool to the body or the
extension pipe.
Extension pipe
CAUTION
•
Prolonged use of the product with the accessory tool
attached may overburden the motor.
•
Using the inlet port to clean a TV, monitor or LCD display
may scratch the screen.
•
Exercise caution to avoid getting your finger stuck in any
gap when assembling the attachments.
•
If any foreign object is sucked into the inlet during
cleaning, operation of the vacuum cleaner might stop
in order to prevent damage to the body or motor.
Immediately stop using the vacuum cleaner and remove
the object before resuming cleaning.

-18-
How to use
2Insert the battery into the auxiliary charging station.
Charging indicator
of the auxiliary
battery
Please note
•
Make sure that the power adapter is connected to both
the charging station and the power outlet
•
If the main battery is charging on the charging station,
the auxiliary battery will only start charging once the main
battery is fully charged.
•
The auxiliary battery indicator flashes when charging
starts.
•
The indicator will stay on when the auxiliary battery is
fully charged.
•
Fully charging a single battery usually takes 3.5 hours,
but it will take twice as long if you charge it along with a
discharged auxiliary battery.
Power / Suction Strength button
You can adjust the suction strength with the suction
strength button located on the handle.
1
2
1Power On/Off button
•
Press the power On/Off button to activate the
Normal mode.
2Mode button
•
Press "+" once to activate the Power mode.
•
Press and hold "+" for more than 3 seconds to
activate the Turbo mode.
•
The unit will take a moment to switch to the Turbo
mode from the Normal mode when the "+" button is
held down.
•
Press "-" to switch from Turbo to Power, or from
Power to Normal.
Charging the Product
1Put the product on the charging station.
•
The battery indicator will start to flash and charging
will proceed in 3 steps.
2The battery indicator starts to flash and charging will
start.
•
All of the indicators will stay on when the battery is
fully charged.
CAUTION
•
Make sure to securely fit the unit on to the charging station.
Otherwise, the product may fall and get damaged.
Please note
•
The battery will not be charged if the ambient
temperature is below 5°C. only charge the battery when
ambient temperatures are between 5° and 38° C.
•
The battery indicator will flash if the product is fully
charged, removed from the station, and charged again
soon. The flashing stops soon, and the indicator stays on.
Charging the auxiliary battery
1Hold the product and pull the battery by pressing both
ends of the battery.

-19-
How to use
Using the nozzles
•
Please note that the following applies to the
corresponding models:
•
The nozzle can be attached to the product body or
extension pipe.
•
Use a different mode if the inlet gets stuck on the floor,
carpet or bed sheets or if you need a more powerful
mode.
CAUTION
•
Do not use the product for any purpose other than
domestic household.
Power Drive Carpet Nozzle
•
It is suitable for cleaning carpets or rugs.
•
It can be used to clean hard floors but will generate some
noise.
CAUTION
•
Do not use this nozzle on a play mat (PVC) for children.
Power Drive Floor Nozzle (some models
only)
•
It is suitable for cleaning hard floor surfaces.
Bedding Power Punch (some models
only)
•
Bedding Power Punch lets you clean bed sheets and
covers more effectively. This attachment can be used
to remove Pet Hair from various surfaces without hair
tangling.
•
Make sure to adjust the suction level to an appropriate
setting when you vacuum-clean a blanket with a thin
outer fabric as the cleaner may attempt to suck the outer
fabric.
Crevice Tool
It is suitable for cleaning dust in a corner or a narrow
space.
Combination Tool
This accessory is helpful for cleaning corners or small gaps.
Basic
For cleaning flat surfaces such as a sofa or mattress.
Brush type
For cleaning delicate surfaces such as a frame or furni-
ture.
Button
CAUTION
•
Prolonged use of the product with an accessory tool
attached may over heat the motor.
•
Using this accessory tool on a TV, monitor or LCD display
may scratch the screen.
•
Avoid getting your finger stuck in any gaps when fitting
the accessory tools.
•
If any foreign object is sucked into the inlet during
cleaning, operation of the unit might stop in order to
prevent damage to the body, motor or inlet. Immediately
stop using the vacuum cleaner and remove the object
before resuming cleaning.
Hard Dirt Tool
It is firm bristles for removing dirt from hard surfaces.
Mattress Tool
It is for mattresses and soft furnishing.

-20-
How to use
Flexible Crevice Tool
Since its length can be adjusted and it can be bent, it is
used for cleaning dust inside the vehicle or narrow spaces in
furniture where bending is necessary.
* The Flexible Crevice Tool is provided only for an applicable
model.
1How to operate the brush
•
You can use the brush by holding and pulling the
brush fixing unit in the arrow direction.
•
You can insert the brush by pressing the button
and inserting the brush fixing unit in the opposite
direction of the arrow.
Brush xing
unit
Button
2How to adjust the length
•
Adjust its length by pressing the length extension
button and pulling or pushing it to the end.
Length extension button
Multi Angle Tool
Since it can be adjusted to various angles and the brush is
soft, it is used to clean the console in the vehicle or on top
of furniture.
* The Multi Angle Tool is provided only for an applicable
model.
Flexible Hose Extension
Since its length can be adjusted, it is connected with the
inlet port and used to clean out of reach places.
* The flexible hose extension is provided only for an
applicable model.
Please note
•
When the flexible hose extension is used, the Power Drive
Floor Nozzle, Power Drive Carpet Nozzle and the Bedding
Power Punch do not work.
•
Attach the Power Drive Floor Nozzle, Power Drive Carpet
Nozzle or the Bedding Power Punch to the body or the
extension pipe when using it.
