LG V-CD46 H Series User manual

Model
Language
Page
Material Size(W*H)
Designer
Designer Confirm
Color(cover/body)
Part No. Description
Date
No. Date
Chage Record
Change content ECO No.
Weight 100g
1
2
3
4
5
6
7
8
9
V-CD483HTC.CLSLSL
English
71/1
150 X 220(mm)
2007.01.23 GAOYAN
MFL32709213 Owner's Manual

V-CD47*H**
V-CD48*H**
V-CD49*H**
V-CD46*H**

- 2-

6
7
8
10
9
21
MAX
MIN
FLOOR
CARPET
SOFA
CURTAIN
OFF
20
18
14
13
16
17
18
- 3 -

24
23
25
27
26
22
- 4-

E
Please read all the following information,
which contains important instructions for
the safety, the use and the maintenance
of the appliance.
This appliance complies with the following
EC Directives: -73/23/EEC, 93/68/EEC-
Low Voltage Directive-89/336EEC -EMC
Directive.
 Never allow children to use the appliance
unsupervised.
 Do not use the appliance If the main lead
is damaged or faulty.
 If the main lead is damaged, it must be
replaced by an approved LG Electronics
Service Agent to avoid a hazard.
 Always switch the vacuum cleaner off
before :
•changing the dust bag
•changing or cleaning the filters.
 If no dustbag is inserted, the cover
cannot be closed. Please do not use
force!
Do not vacuum flammable or explosive
substances(liquids or gases).
Do not vacuum hot ash, embers etc. nor
sharp objects.
Do not vacuum water or other liquids.
When you vacuum with an attachment
appliance that has a rotating brush roller,
do not reach into the running brush roller.
Connecting the flexible hose
Push the end of the head (1) on the flexible
hose (2) into the attachment point on the
vacuum cleaner.
To remove the flexible hose from the
vacuum cleaner, press on the button (3)
situated on the head, then pull upwards.
Assembling the tubes
• Telescopic tube (4)
(depending on model)
- Hold spring latch (5)
- Pull out the tube to required length.
- Release spring latch to lock.
Using the cleaning head and Accessory
Fit the large cleaning head onto the end of the
tube.
• The 2 position head (6) is equipped with a
pedal (7) which allows you to alter its
position according to the type of floor to be
cleaned.
Hard floor position(tiles, parquet floors...).
Press on the pedal to lower the brush.
Carpet or rug position.Press on the pedal
to lift the brush up.
Storage (11)
When you have switched off and unplugged
the appliance, press on the button (14) to
automatically rewind the cord.
You can move or store your appliance in a
vertical position by sliding the hook on the
large cleaning head into the clip on the
underside of the appliance.
Electronic power control (12)
How to plug in and use
Information for your safety
How to Use
Suction capacity increases steplessly up
to MAX.
Pull out the mains lead to the desired
length and plug into the socket.
Nozzles (depending on model)
• Crevice Tool (8)
For vacuuming in those normally inaccess-
ible places i.e. reaching cobwebs, or down
the side of a sofa!
• Upholstery Nozzle (9)
For vacuuming upholstery, mattresses, etc. The
thread collectors help to pick up the threads and fluff.
• Dusting brush (10)
For vacuuming picture frames furniture
outlines, books and other uneven objects.
• Accessory Holder can be attached on the
Extention wands using clamping hook.
Accessories can be stored in the holder (21).
OFF: Power off CURTAIN: Low
FLOOR: Full power.
- 5 -

• Push the latch (18) forwards in the
direction of the arrow and remove the
full dust bag throw it away.
• Insert the new dust bag into the cleaner(19).
- 6 -
