OWNER’S MANUAL
Robot Vacuum Cleaner
LRV5900
Before using, please carefully read the Safety Precautions pages to allow for
safe operation of the product. After reading the operation manual, please keep
it in an easily accessible location.
P/No.: 3828FI3868S www.lg.com

FEATURES
Images of the ceiling and floor are obtained from the upper and lower cam-
eras. This establishes the location of the HOM-BOT. to accomplish elaborate
cleaning of the room.
The low height of the HOM-BOT (3.54in) allows it to move freely under beds
and furniture.
Microfiber mop attachment picks up finer dust and dirt from hardwood and
other barefloor surfaces. (Sold separately)
The HOM-BOT also has voice confirmation and instruction that can be easily
understood by the user.
The HOM-BOT has two auto cleaning modes that can be selected by the user.
*Spatial expansion mode, zigzag mode
Noise levels are very low which allows cleaning to be performed at night.
Camera
(upper, lower section)
Please, check
the dust bin

CONTENTS
Safety Precautions
Included with Product
Parts Descriptions
Button Functions
Display Status Information
Before You Start
Overview
2
BEFORE USE
3
HOW TO USE
4
CARE AND MAINTENANCE
28
31
1
How to Install the Home Station
How to Turn the Power Supply On and Off.
How to Start and Stop Cleaning
How to Charge the Battery
Cleaning Modes
Auxiliary Cleaning Modes
Timer Cleaning
Mop Cleaning
(Mop attachment sold separately)
Cleaning the Dust Bin
Cleaning the Dust Bin Filter
Cleaning the Brush
Cleaning the Sensor/Charging Terminal
Cleaning the Side Brush
Cleaning the Ultra Microfiber Mop
(Mop attachment sold separately)
5
ADDITIONAL INFORMATION
1
LG ROBOT VACUUM CLEANER WARRANTY
6
REFERENCE ITEMS
2
5
6
8
10
11
12
13
14
15
16
18
19
20
21
22
23
24
25
26
27
Troubleshooting
Before You Call for Service
LG ROBOT VACUUM CLEANER WARRANTY
Product Specifications
Open Source Software Notice
32
33

1
LG ROBOT VACUUM CLEANER WARRANTY
LG Electronics Inc. will repair or replace your product, at LG’s option, if it proves to be defective in material or workmanship
under personal household use, during the warranty period set forth below, effective from the date of original consumer
purchase of the product. This limited warranty is good only to the original purchaser of the product and effective only when
used in U.S.A. and Canada.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. TO THE EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, IT IS LIMITED IN
DURATION TO THE EXPRESS WARRANTY PERIOD ABOVE. LG WILL NOT BE LIABLE FOR ANY
CONSEQUENTIAL, INDIRECT, OR INCIDENTAL DAMAGES OF ANY KIND, INCLUDING LOST REVENUES
OR PROFITS, IN CONNECTION WITH THE PRODUCT. SOME STATES DO NOT ALLOW LIMITATION ON
HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
This warranty covers only defects in material and workmanship.
LGE will NOT pay for:
1. Expendable items that can wear out, including, but not limited to, filters and belts.
2. A service technician to instruct the user in correct product assembly, operation or maintenance.
3. A service technician to clean or maintain this product.
4. Damage to or failure of this product if it is not assembled, operated or maintained according to all instructions
supplied with this product.
5. Damage to or failure of this product resulting from accident, abuse, misuse or use for other than its intended
purpose.
6. Damage to or failure of this product caused by the use of detergents, cleaners, chemicals or utensils other than
those recommended in all instructions supplied with this product.
7. Damage to or failure of parts or systems resulting from unauthorized modifications made to this product.
This warranty is extended to the original purchaser for products purchased for home use within the U.S.A. In Alaska, the
warranty excludes the cost of shipping or service calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so this exclusion or limitation may
not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from states to
states. To know what your legal rights are, consult your local or state consumer affairs or your state’s Attorney General.
CUSTOMER ASSISTANCE INFORMATION:
WARRANTY PERIOD:
Two Years
From the date of the
original purchase
Any part of the robot vacuum cleaner which fails due to a defect in materials or
workmanship. During this full Two Years warranty, LG will also provide, free of charge, all
labor and shop service to replace the defective part.
(Except-Battery 1 year warranty)
HOW SERVICE IS HANDLED:
To Prove Warranty Coverage
To Obtain Nearest Authorized
Service Center or Sales Dealer, or
to Obtain Product, Customer, or
Service Assistance
Retain your Sales Receipt to prove date of purchase.
A copy of your Sales Receipt must be submitted at the time warranty service is
provided.
Call 1-800-243-0000 (Phone answered 24 hours - 365 days a year) and choose
the appropriate prompt from the menu; or visit our website at: http://us.
lgservice.com. (In Canada- Call 1-888-542-2623, website http://ca.lgservice.com)

2
SAFETY PRECAUTIONS
The purpose of the safety precautions described below is for the user to use the product safely and correctly
to prevent any unexpected risk of injury or damage.
* 1) Place the cords from other appliances out of the area to be cleaned.
2) Do not operate the vacuum in a room where an infant or child is sleeping.
3) Do not operate the vacuum in an area where there are lit candles or fragile objects on the floor to be
cleaned.
4) Do not operate the vacuum in a room that has lit candles on furniture that the vacuum may acciden-
tally hit or bump into.
5) Do not allow children to sit on the vacuum.
6) Do not use the vacuum on a wet surface.
Basic safety precautions
After reading this manual, please keep it in an easily accessible location.
This is the safety alert symbol. This symbol alerts you to potential hazards that can result in
property damage and/or serious bodily harm or death.
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
WARNING
WARNING
CAUTION
For your safety, do not remove the battery
from the HOM-BOT. If you need to replace
the battery take it to the nearest authorized
LG Electronics service center or dealer for
assistance.
Make sure the power cord of the home sta-
tion is not crushed under a heavy object or
damaged by contact with sharp objects.
Never use the HOM-BOT with a bat-
tery and/or home station from any
product other than the HOM-BOT.
Failure to follow this warning can cause elec-
tric shock, fire or product failure. If the power
cord is broken, do not plug it in. Take the
product to the nearest authorized LG Elec-
tronics service center or dealer for assistance.
Do not use the HOM-BOT when
candles or fragile objects are placed
on the floor.
Doing so can cause fire or product failure.
Failure to follow this warning can cause fire
or product failure.
Doing so can cause fire or product failure.
Do not place the home station
and the HOM-BOT near a heating
device.
Always use a dedicated outlet.
Doing so can cause product deformation,
fire, or product failure.
If multiple appliances are connected to an
outlet simultaneously, they can generate
enough heat to cause a fire.
Do not force the power plug to bend.
Do not use the power plug when it
has been damaged or loosened.
When pulling out the power plug, always
pull it out by grabbing the plug, not the
cord. When pulling out the power plug, do
not to touch the prongs with your fingers.
Doing so can cause fire or product failure.
Doing so can cause an electric
shock.

3
SAFETY PRECAUTIONS
Do not touch the power plug with
wet hands.
Do not allow children or pets to play
with or on the HOM-BOT at any time.
Do not use the HOM-BOT while an
object is hanging from it.
Doing so can cause electric shock.
Doing so can cause injury or product dam-
age.
Do not operate the HOM-BOT in a
room where a child is sleeping.
Doing so can cause injury or product dam-
age.
Do not insert any part of the body, such as
a hand or foot, below the brush or wheels
of the HOM-BOT while in use.
Doing so can cause injury or product damage.
Do not spray or place flammable
materials, surfactants, or water in the
vicinity of the HOM-BOT.
Doing so can cause fire or product failure.
* flammable materials: gasoline, thinner, etc.
* Surfactant: detergent, articles for bath, etc.
Turn the power supply off immediately if
any abnormal sound, odor, or smoke is
generated from the HOM-BOT.
Failure to do so can cause fire or product
failure.
Do not operate the HOM-BOT on
narrow and high furniture such as a
wardrobe, refrigerator, desk, table, etc.
Doing so can cause injury , product failure or
damage which is not covered by the warranty.
Do not leave children or pets near
the HOM-BOT unsupervised.
Doing so can cause injury or product dam-
age.
Do not expose the HOM-BOT to
temperatures below 40°F for a long
period of time.
Cleaning will not proceed smoothly
on carpets with tassels or carpets
thicker than 0.315in.
Use the HOM-BOT indoors only.
The HOM-BOT may bump into fur-
niture such as chair legs, table legs,
thin and long furniture, etc. while
operating.
Doing so can cause product failure.
It may be more convenient to
arrange them before using the
product.
Using it outdoors can cause prod-
uct failure and irreparable damage
to the unit.
For a quicker and cleaner performance,
place the chairs on top of the table.
The dust collected in the dust bin
can trigger allergies and may contain
harmful insects.
Frequently empty the dust bin and
keep clean.
Do not drop the HOM-BOT or sub-
ject it to strong impacts.
Doing so can cause injury or product failure
not covered by the warranty.
WARNING
CAUTION

4
SAFETY PRECAUTIONS
In rare cases, the HOM-BOT’s brush
can damage the carpet. If this hap-
pens, immediately stop the cleaning
operation.
When a carpet has long tassels, the
tassels can be damaged.
Do not allow the HOM-BOT to
sweep up liquids, blades, thumb
tacks, kindling, etc.
These items can cause product
failure.
Do not let the main frame and charg-
ing terminal of the home station come
into contact with metallic objects.
Doing so can cause product failure.
Do not put sharp objects into the
opening of the HOM-BOT’s super-
sonic sensor.
Doing so can cause product failure.
Do not use water, detergent, etc. on
the HOM-BOT.
Doing so can cause product failure. Do not
put any water or detergent on the HOM-
BOT. If liquids get inside of the HOM-BOT,
turn off the power supply and contact an
LG Electronics sales agent or customer care
center.
Do not use the HOM-BOT when the
dust bin is completely filled up.
Doing so can cause product failure.
If the floor is wet or has wet spots,
wipe them up before using the HOM-
BOT. Do not use the HOM-BOT on a
wet surface.
Failure to do so can cause product
failure.
Check the following items before use:
• Remove fragile or unnecessary objects from the room to be cleaned. For example, remove
expensive ceramics and valuables from the floor.
• Do not use this product in the room if a child is sleeping on the floor. The child can be hurt.
• Confirm whether the battery has sufficient power, and if it is low, recharge it.
• Empty the dust bin after if fills up.
• Close the doors of any room that you do not want the HOM-BOT to enter.
During cleaning, the HOM-BOT may enter another room and continue cleaning.
• Wipe up any liquids from the floor before cleaning.
• Remove any cables or long strings from the floor.
• Remove cables, strips, towels, socks, etc. from the floor so they will not get caught by the brush.
• Cleaning will not proceed smoothly on carpets with tassels or carpets thicker than
0.315 in. It may be more convenient to remove or rearrange the position of these rugs or
carpets before using the product.
Please note, this product is not intended for use in any workshop, commercial office, garage or outdoor
environment. It is for internal normal indoor residential use only.
Tip
CAUTION
When the robot cleaner is operating,
it may come in contact with chair,
desk or table legs.
For quicker and better cleaning, place the
dining chairs on top of the dining table.

5
INCLUDED WITH PRODUCT
▶Figures can be different from actual objects.
Dust bin filter (spare)
Brush for cleaning filter Mop plate
(Sold separately.)
Ultra microfiber mop
(2 pieces)
Dry cell for
remote controller
(2 AAA size)
Quick guide Operation manual
Remote controller Home station
HOM-BOT
OWNER’S MANUAL
Robot Vacuum Cleaner
LRV5900
Be f o r e u s i n g , pl e a s e c a r e fu l l y r e ad the Sa f e t y P r e c a u t i o n s p a g e s t o al l o w f o r
s a f e o pe r a t i o n o f t h e p ro d u c t . A f t e r r e a d i n g t h e o p e r a t i o n m a n u a l , p l e a s e ke e p
i t i n a n e a s i l y a c c e ssi b l e lo c a t i o n .
www.lg.com

6
PARTS DESCRIPTION - HOM-BOT
▶Figures can be different from actual objects.
Top
Manipulation button
Dust bin cover button
Dust bin cover
Indicator lamp
Upper camera
Home station detector &
Remote control receiver
Ultrasonic sensor
Obstacle detecting sensor window
Ventilation port
Cliff detection sensor
Charging terminal
Brush
Side brush
Wheel
Lower camera
Mop plate attachment hook
Battery
Power switch
Front view
Rear view
Bottom view

7
PART DESCRIPTION – HOME STATION / DUST BIN
▶Figures can be different from actual objects.
Home station
Dust bin
Power lamp
Charging terminal
Reset button
Sponge filter
HEPA filter
Dust bin handle
Dust bin cover
Suction port cover
Dust bin cover release button
Power cord groove

8
BUTTON FUNCTIONS – HOM-BOT
• Use the TIMER button to activate the time delay feature.
• The timer can be set from 1 to 12 hours.
• The timer button only works when the HOM-BOT is attached to the home station.
Always attach HOM-BOT to the home station when setting the timer function
TIMER
HOMING
START/STOP
• Press the START/STOP button to turn the HOM-BOT on/off or start/stop cleaning.
• Press the START/STOP button while the HOM-BOT is on and it will automati-
cally start cleaning.
• If the START/STOP button is pressed during automatic cleaning, the HOM-
BOT will stop cleaning.
• Press and hold the START/STOP button for approximately two seconds to turn
off the HOM-BOT. This puts the HOM-BOT into the Stand By mode
• If the button is pressed while in the timer mode, the timer setting will be canceled.
• Press the HOMING button to move the HOM-BOT to the home station for battery charging.
• When cleaning is complete or the battery is low, the device will automatically
move to the home station to charge the battery even without pressing the
HOMING button.
• If the home station is obstructed, the HOM-BOT may not be able to nd it's
signal and return to it.

9
BUTTON FUNCTIONS – REMOTE CONTROL
Cell by Cell cleaning
The HOM-BOT will clean using
the spatial expansion style.
Zigzag cleaning
Cleaning will be performed
by the HOM-BOT in the
zigzag traveling fashion.
• The HOM-BOT’s power supply cannot be turned on with the remote control.
• To turn on the power supply, turn over the unit and flip the switch to 'On' position.
• In order to do spot cleaning, timer cleaning, zigzag cleaning, and spatial expansion cleaning, you
must first stop the operation of the HOM-BOT.
• If the main power switch on the underside of the HOM-BOT is turned off, the remote will not func-
tion, and the battery cannot be charged.
• If the main switch on the underside of the HOM-BOT is in the off position, the Status display will
flash and sound when the unit is manually placed onto the home station, to indicate that the
main switch is off.
Tip
Start
Directional button
Spot
The HOM-BOT will start cleaning
The HOM-BOT will move as
desired by the user: to front,
rear, left, and right sides for
cleaning.
Cleaning will concentrate within a
space of about 3.28 ft.
HOMING
Stop
Timer
The HOM-BOT will move to the
home station for charging.
It the HOM-BOT is cleaning, all opera-
tions will be stopped. If the HOM-BOT
has been set to timer cleaning mode, the
timer setting will be cancelled.
The timer can be set from 1-12
hours in advance.

10
DISPLAY STATUS INFORMATION
• Use the remote control to change the cleaning mode.
• Once the cleaning mode has been selected, it will be saved and automatically selected when
the unit is turned on again, unit it is changed again.
• To cancel the timer setting, press the STOP button on the remote control or the START/STOP
button on the HOM-BOT.
Battery and timer hour indication
• When in Stand by without any
timer setting, the remaining battery
charge will be shown.
• While waiting for timer cleaning, the
reservation time will be shown.
Timer icon
• This indicates when
timer cleaning has
been set up.
Spot cleaning
• Indicates when the HOM-BOT is in
spot cleaning mode. (page 19)
Spatial expansion cleaning
• Indicates when the HOM-BOT is in
spatial expansion cleaning mode.
(page 18)
Zigzag cleaning
• Indicates when the HOM-BOT is in
zigzag cleaning mode. (page 18)
Battery icon
• Lights when the remaining charge
is displayed on the battery charge
remaining section, and will flash
when charging is required.
Tip

11
BEFORE YOU START
Check these items before cleaning
Loading the remote control battery
1. Open the battery cover by lifting the rear hook of the remote control.
2. Insert two AAA batteries, checking for +, - nodes while loading.
3. Close the battery cover completely so that the batteries will not fall out.
• Do not use this device in a room where a child is left alone. The child could be injured.
• Remove any fragile or valuable items from the floor of the room that is to be cleaned.
• Remove any moisture that might be on the floor.
• Remove cables, strips, towels, socks, etc. from the floor so they will not get caught by the brush.
• Confirm whether battery charge is sufficient, and if it is low, recharge it.
• Empty the dust bin if it is full.
• Close the doors of any room that you do not want the HOM-BOT to enter.
Precautions while using the remote control
• Only press one button at a time.
• Do not drop or subject it to forceful impact.
• Do not store it near devices that give off heat, fire or hot air.
• Certain fluorescent lamps, such as 3 wavelength fluorescent lamps, can interfere with the activation of the
remote control. Therefore, use it as far away as possible from such lamps.
• If the remote control is too far from the HOM-BOT when operated, it may fail to operate properly. Use the
device within 9.84 ft of the HOM-BOT if possible.

12
OVERVIEW
1
2
3
4
5
Use of cleaning methods and auxiliary functions. (page 18~21)
The cleaning method and auxiliary functions can be se-
lected with the remote control.
Install the home station. (page 13)
Insert the power cord plug into an outlet and locate the
station against a wall. If power is not supplied to the
home station, the HOM-BOT will not charge. 3ft
3ft
6ft
Turn on the power supply of the HOM-BOT. (page 14)
Turn on the power switch located on the bottom of the
HOM-BOT to turn on the power supply.
* If the power supply is not turned on, refer to page 14.
Start cleaning. (page 15)
Press the START/STOP button once to turn on. Press
once more to start cleaning.
Automatic charge. (page 16-17)
The HOM-BOT will self-diagnose and automatically return
to the home station to recharge before the complete dis-
charge of the battery. It can take up to three hours to fully
charge the battery.

13
HOW TO INSTALL THE HOME STATION
3ft
3ft
6ft
1. Position the home station against a wall on a hard level surface
to prevent sliding during docking.
Remove objects within 3ft to the right and left side and within
6ft to the front.
2. Plug the power cord into an outlet.
Wrap the power cord around the fixed hanger on the back side
of the home station or along the wall surface so that the travel
path of the HOM-BOT will not be obstructed.
3. Fix the home station against the wall so that it does not move.
How to Install the Home Station
• Always keep the home station plugged in. If the home station is not plugged in, the HOM-
BOT will not return to the station to charge automatically.
• Do not operate the Home Station if it has a damaged cord or plug, if it is not working prop-
erly, or if it has been damaged or dropped. To avoid any electrical hazard, the cord must be
replaced by LG Electronics, or a qualified service person.
Power cord groove
Tip

14
HOW TO TURN THE HOM-BOT POWER SUPPLY ON & OFF
To turn the power supply on, turn the HOM-BOT upside down
on a smooth/soft surface and check whether the main power
supply switch is turned on.
If the main power supply switch is turned off, turn on the
switch.
※ When turning on the power switch, do not press the button
located at the upper section of the HOM-BOT. Operation of
the button can be delayed.
※Turn off the power switch if the HOM-BOT will not be used
for a long period of time, in order to protect the battery.
※The power switch cover is used for protecting the switch
from the dust. Always keep the cover attached.
When the HOM-BOT is not at the Home Station, and is in
the Stand by mode, press the ‘START/STOP’ button for
more than 1 second. The HOM-BOT will be turned on and
a melody will be sounded.
※ If the power is turned on while the HOM-BOT is not at
the Home Station, and nothing is done for ten minutes,
the unit will turn off and enter Standby mode to reduce
battery consumption.
Press the START/STOP button for two seconds while the
HOM-BOT is turned on. A melody will sound when the
power is turned off.
Turning on the main power supply
Turning on from Stand By mode.
Turning off the unit
• The power can be turned off due to the static electricity during
the operation.
- If the power is turned off, turn off the main power switch and
then turn it back on.
• If the power cannot be turned on, do the following.
- Turn on the power switch and wait for more than 3 seconds.
- Press the ‘START/STOP’ button when the power switch is
turned on.
- If the power is not turned on or if there is no display but only
the “Ting” sound, put the HOM-BOT on the home station.
- If there is no change even when HOM-BOT is attached to the
home station, press the reset switch located on the rear side
of the home station while the HOM-BOT is attached on the
home station.
Tip

15
HOW TO START AND STOP CLEANING
After the HOM-BOT is turned on, press the START/STOP button to
begin cleaning. A melody will sound and cleaning will begin.
Press the START/STOP button during the cleaning cycle to stop cleaning.
※ When the 'START/STOP' button is pressed while the power supply is
turned off, the unit will not turn on.
After the HOM-BOT is turned on, press the START button on the re-
mote control. A melody will sound and cleaning will begin.
Press the STOP button during the cleaning cycle to stop cleaning.
※The Hom-Bot cannot be turned on from Standby mode using the
remote control. To turn on the unit, press the 'START/STOP' button
on the body, and then use the remote control to operate.
※When the START button on the main unit or remote control is pressed, HOM-BOT will start cleaning in
‘Spatial expansion’ mode.
※During cleaning, collisions can happen when the sensor cannot detect objects because of their shape.
When this happens, the internal impact detecting sensor will activate and engage a backward motion.
※If the HOM-BOT is set to start cleaning at a location away from the home station, put the device on a flat
floor in order to prevent a malfunction of the obstacle detecting sensor. In addition, start cleaning from a
location where there are no obstacles such as curtains or walls within 11.8in. of the HOM-BOT.
Using the buttons on the HOM-BOT
Using the remote control
For best results:
• Briefly scan the area to be cleaned for big and small objects that may cause difficulty for the
HOM-BOT.
• If cleaning is started when the HOM-BOT is at the home station, the device can rapidly be re-
turned to the home station as the current home position has been accurately read.
Tip

16
HOW TO CHARGE THE BATTERY
If using the HOM-BOT for the first time or to charge the battery by interrupting the cleaning, you can
manually charge the battery.
Method 1. Attach the HOM-BOT to the home station by matching
up the two arrows on the HOM-BOT and the home sta-
tion. A melody will sound and charging will begin.
※ When the HOM-BOT is attached to the home station,
and a “TING” sound is generated repeatedly, please check
and ensure that the power supply on the underside of the
HOM-BOT is in the ON position.
Method 2. When the HOMING button of the remote control or the
HOM-BOT is pressed, charging will start automatically
when the HOM-BOT has returned to the Home Station.
※When the unit is turned on from Standby mode and is within 4in of the home station, the unit will auto-
matically dock itself to the station and charging will begin.
Take the following precautions when using the home station:
• If foreign material is caught in the charging terminal, charging may not proceed smoothly.
Wipe the terminal from time to time with a dry cloth after the power plug is disconnected.
• To prevent electric shock, do not touch the charging terminal with any metallic objects.
• To avoid fire or electric shock, never disassemble or modify the home station.
• Do not to place the home station or power plug near a heating appliance.
Tip
The HOM-BOT returns to the home station at the end of a cleaning cycle
or when its battery is running low.
※In the event that the unit returns to the Home Station due to a low
battery, cleaning will be started, after the charging, from the near-
est place of the area which has not been cleaned before.
※ If the HOM-BOT is unable to dock to the home station on its first at-
tempt, it will try again until it docks successfully.
※When the HOM-BOT has cleaned all areas that it can clean, it will
return to the home station even when the battery level is not low.
Automatic charging
Manual charging

17
Full charging
(Under charging)
In the case of no
existing area to be
cleaned
In the case of
existing area to be
cleaned
The status indication lamp while
robot is charged.
( In spatial expand mode)
High Middle Low Charging is
required
Flickering
※If there is still an area to be cleaned and it returned to the home sta-
tion for recharging, the cleaning mode indicator will be displayed.
- When the battery is fully recharged, it cleans the area that is yet
cleaned.
- If the cleaning mode indicator is lit during charging, pressing the
‘START’ button of the remote controller or ‘START/STOP’ button of
the HOM-BOT will search the un-cleaned area and start the cleaning.
- Pressing the mode selection button on the remote, (ZIGZAG, Cell by
Cell) will start the cleaning from the beginning.
HOW TO CHARGE THE BATTERY
Check 1. If the battery is not charging even when the HOM-BOT is at-
tached to the home station, check the following items.
- Turn the power switch on the bottom of the HOM-BOT off
and then on again.
- Unplug and plug in the power plug on the home station.
- Wipe the terminal on the home station with a dry cloth.
Check 2. If the battery is still not charging after the previous check, try
the following.
- Attach the HOM-BOT to the home station.
- Press the reset button at the rear of the home station for
three seconds.
If the Battery is Not Charging
The remaining battery charge can be confirmed from the charge indication lights, which will indicate charge
as follows:
• During charging, the charge remaining indication lights will flicker.
• When charging is completed at the home station, only the battery icon will illuminate to save power.
• The battery icon will flicker when battery charging is required.
Remaining Battery Charge Indicator
