LG FWV1117BTSA User manual

OWNER'S MANUAL
WASHER AND DRYER
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
FWV1117WTSA FWV1117BTSA
MFL71818826
Rev.02_101622
www.lg.com
Copyright © 2021-2022 LG Electronics Inc. All Rights Reserved.
global_main.book.book Page 1 Sunday, October 16, 2022 2:53 PM

TABLE OF CONTENTS
This manual may contain images or
content that may be different from the
model you purchased.
This manual is subject to revision by the
manufacturer.
SAFETY INSTRUCTIONS
CARING FOR THE ENVIRONMENT ............................................................. 5
Environmental and Economical Tips..................................................................5
Disposal of the Packaging Material ...................................................................6
Disposal of Your Old Appliance ..........................................................................7
READ ALL INSTRUCTIONS BEFORE USE .................................................... 8
Safety Messages...................................................................................................8
WARNING .................................................................................................... 8
Technical Safety....................................................................................................8
Maximum Capacity ..............................................................................................9
Technical Safety for Using the Dryer .................................................................9
Installation ..........................................................................................................10
Operation ............................................................................................................10
Maintenance .......................................................................................................12
Disposal ...............................................................................................................12
INSTALLATION
Parts and Specifications .......................................................................... 13
Front View ...........................................................................................................13
Rear View.............................................................................................................14
Specifications......................................................................................................15
Accessories..........................................................................................................16
Installation Place Requirements............................................................ 17
Installation Location ..........................................................................................17
Wooden Floors (Suspended Floors) .................................................................17
Ventilation ...........................................................................................................18
Ambient Temperature .......................................................................................18
Electrical Connection .........................................................................................18
Unpacking the Appliance ........................................................................ 19
Lifting the Appliance Off the Foam Base.........................................................19
Removing the Transit Bolt Assemblies............................................................19
Levelling the Appliance ........................................................................... 21
Checking the Level .............................................................................................21
global_main.book.book Page 2 Sunday, October 16, 2022 2:53 PM

Adjusting levelling feets ....................................................................................21
Using Anti-Slip Sheets........................................................................................22
Connecting the Water Supply Hose ....................................................... 23
Note for Connection ..........................................................................................23
Checking the Rubber Seal .................................................................................23
Connecting the Hose to the Water Tap...........................................................23
Connecting the Hose to the Appliance............................................................24
Installing the Drain Hose ........................................................................ 25
Installing the Drain Hose with the Elbow Bracket .........................................25
OPERATION
Operation Overview................................................................................. 26
Washing the Clothes..........................................................................................26
Control Panel ............................................................................................ 28
Control Panel Features ......................................................................................28
Preparing the Wash Load ........................................................................ 31
Sorting the Clothes ............................................................................................31
Checking the Clothes Care Label......................................................................31
Checking the Clothes before Loading .............................................................31
Adding Detergents and Softeners.......................................................... 33
Detergent Dosage..............................................................................................33
Using the ezDispense drawer...........................................................................33
Adding Detergent Tablets.................................................................................36
Adding Water Softener......................................................................................36
Programme Table..................................................................................... 37
Washing Programme.........................................................................................37
Extra Options ......................................................................................................39
Selectable Maximum Spin Speed .....................................................................40
Consumption Data .............................................................................................41
Drying Programme................................................................................... 43
General Tips for Drying .....................................................................................43
Using a Dry Programme....................................................................................44
Extra Options and Functions .................................................................. 46
Customizing a Washing Programme...............................................................46
Using Special Options........................................................................................47
Using Basic Options ...........................................................................................47
Using the ezDispense ........................................................................................48
Settings................................................................................................................51
global_main.book.book Page 3 Sunday, October 16, 2022 2:53 PM

SMART FUNCTIONS
LG ThinQ Application ............................................................................... 53
LG ThinQ Application Features.........................................................................53
Installing LG ThinQ App and Connecting an LG Appliance...........................54
Activating Network Connection........................................................................55
Using the Appliance Remotely .........................................................................55
Deactivating Network Connection...................................................................55
Standby Power Consumption...........................................................................55
Open Source Software Notice Information ....................................................56
Smart Diagnosis ....................................................................................... 57
Using LG ThinQ to Diagnose Issues.................................................................57
Using Audible Diagnosis to Diagnose Issues .................................................57
MAINTENANCE
Cleaning After Every Wash...................................................................... 58
What to Clean .....................................................................................................58
Cleaning the Exterior .........................................................................................58
Cleaning the Appliance Periodically ...................................................... 59
Tub Clean ............................................................................................................59
Cleaning the Water Inlet Filter .........................................................................59
Cleaning the Drain Pump Filter and Performing an Emergency Water
Evacuation...........................................................................................................60
Cleaning the ezDispense Drawer.....................................................................60
TROUBLESHOOTING
Before Calling for Service ........................................................................ 63
Error Messages...................................................................................................63
ezDispense Error Messages..............................................................................65
Noises You Might Hear......................................................................................66
Operation ............................................................................................................67
Performance .......................................................................................................69
Odour...................................................................................................................70
ezDispense..........................................................................................................71
Drying ..................................................................................................................72
Wi-Fi .....................................................................................................................72
Customer Care and Service...............................................................................73
global_main.book.book Page 4 Sunday, October 16, 2022 2:53 PM

5
SAFETY INSTRUCTIONS
ENGLISH
SAFETY INSTRUCTIONS
CARING FOR THE ENVIRONMENT
Environmental and Economical Tips
Energy and water consumption
• Water consumption and energy usage can be affected by the weight
of the load. To make the best use of your appliance, load the
maximum amount of dry clothes for the particular programme.
• The most efficient programmes in terms of energy consumption are
generally those that perform at lower temperatures and longer
duration.
• Noise and remaining moisture content are influenced by the spinning
speed: the higher the spinning speed in the spinning phase, the
higher the noise and the lower the remaining moisture content.
• Evenly loading laundry up to the capacity indicated by the
manufacturer for the respective programmes will contribute to
energy and water savings.
• For washing smaller amounts of clothes, the automatic load
recognition system will help reduce the amount of water and energy
usage.
• Use the Speed programme for small, lightly soiled loads.
• Cold water laundry detergents can be as effective at lower
temperatures (about 20 ℃). Using 20 ℃settings will use less energy
than 30 ℃or higher temperatures.
Detergent
• Detergent should be chosen according to type, colour, soiling of the
fabric and the washing temperature. And it should be used according
to the instruction of the detergent manufacturer. Use only
detergents that are suitable for front loading washing machines.
• Use less detergent on smaller loads.
- Partial load: 1/2 of the normal amount.
- Minimum load: 1/3 of full load.
global_main.book.book Page 5 Sunday, October 16, 2022 2:53 PM

6
SAFETY INSTRUCTIONS
Selecting Extra Options and Functions
• Select the water temperature suitable for the type of load you are
washing. Follow the garment fabric care labels for best results.
• The Pre Wash option is recommended for washing a heavily soiled
load.
When Using a Dry Programme
• To save energy, choose the highest possible spin speed for the wash
programme when drying in a tumble dryer.
• For most drying, make sure all clothes are similar in material and
thickness.
• When you select drying only, spinning runs automatically for energy
efficiency.
Disposal of the Packaging Material
• The packaging materials are designed to protect the appliance from
unexpected damage during transportation.
• After installing the appliance, dispose of the packaging waste
according to recycling symbols of material types. Put the packaging
waste in relevant containers to recycle it.
global_main.book.book Page 6 Sunday, October 16, 2022 2:53 PM

7
SAFETY INSTRUCTIONS
ENGLISH
Disposal of Your Old Appliance
• This crossed-out wheeled bin symbol indicates that waste
electrical and electronic products (WEEE) should be
disposed of separately from the municipal waste stream.
• Old electrical products can contain hazardous substances
so correct disposal of your old appliance will help prevent
potential negative consequences for the environment and
human health. Your old appliance may contain reusable
parts that could be used to repair other products, and
other valuable materials that can be recycled to conserve
limited resources.
• You can take your appliance either to the shop where you
purchased the product, or contact your local government
waste office for details of your nearest authorised WEEE
collection point. For the most up to date information for
your country, please see www.lg.com/global/recycling.
global_main.book.book Page 7 Sunday, October 16, 2022 2:53 PM

8
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
The following safety guidelines are intended to prevent unforeseen
risks or damage from unsafe or incorrect operation of the appliance.
The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as
described below.
Safety Messages
WARNING
WARNING
To reduce the risk of explosion, fire, death, electric shock, injury or
scalding to persons when using this product, follow basic precautions,
including the following:
Technical Safety
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• Children of less than 3 years should be kept away unless continuously
supervised.
This symbol is displayed to indicate matters and operations
that can cause risk. Read the part with this symbol carefully
and follow the instructions in order to avoid risk.
WARNING
This indicates that the failure to follow the instructions can
cause serious injury or death.
CAUTION
This indicates that the failure to follow the instructions can
cause the minor injury or damage to the product.
global_main.book.book Page 8 Sunday, October 16, 2022 2:53 PM

9
SAFETY INSTRUCTIONS
ENGLISH
• If the power cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order
to avoid a hazard.
• Ventilation openings must not be obstructed by a carpet.
• This appliance is intended to be used in household only.
• Use a new hose or hose-set supplied with the appliance. Reusing old
hoses can cause a water leak and subsequent property damage.
• The water pressure must be between 50 kPa and 800 kPa.
Maximum Capacity
The maximum capacity in some cycles for dry clothes to be used is
Wash (10.5 kg)/Dry (7 kg) .
The recommended maximum capacity for each washing programme
may differ. To get good wash results, please refer to Programme
Table in OPERATION chapter for further details.
Technical Safety for Using the Dryer
• Do not dry unwashed items in the appliance.
• Items that have been soiled with substances such as cooking oil,
vegetable oil, acetone, alcohol, petroleum, kerosene, spot removers,
turpentine, waxes and wax removers should be washed in hot water
with an extra amount of detergent before being dried in the
appliance.
• Never stop the appliance before the end of the drying cycle unless all
items are quickly removed and spread out so that the heat is
dissipated.
• Items such as foam rubber (latex foam), shower caps, waterproof
textiles, rubber backed articles and clothes or pillows fitted with foam
rubber pads should not be dried in the appliance.
• Fabric softeners, or similar products, should be used as specified by
the fabric softener instructions.
• Remove all objects from pockets such as lighters and matches.
• The appliance is not to be used if industrial chemicals have been used
for cleaning.
global_main.book.book Page 9 Sunday, October 16, 2022 2:53 PM

10
SAFETY INSTRUCTIONS
Installation
• This appliance should only be transported by two or more people
holding the appliance securely.
• Do not install the appliance in a damp and dusty place. Do not install
or store the appliance in any outdoor area, or any area that is subject
to weathering conditions such as direct sunlight, wind, rain, or
temperatures below freezing.
• Make sure the power plug is completely pushed into the power
outlet.
• Do not plug the appliance into multiple outlet sockets, power boards,
or an extension power cable.
• Do not modify the power plug provided with the appliance. If it does
not fit the power outlet, have a proper outlet installed by a qualified
electrician.
• This appliance is equipped with a power cord having an equipment-
earthing / grounding conductor (earthing pin) and a grounding
power plug. The power plug must be plugged into an appropriate
outlet socket that is installed and earthed / grounded in accordance
with all local codes and ordinances.
• Improper connection of the equipment-grounding conductor can
result in risk of electric shock. Check with a qualified electrician or
service personnel if you are in doubt as to whether the appliance is
properly grounded.
Operation
• Never attempt to operate the appliance if it is damaged,
malfunctioning, partially disassembled, or has missing or broken
parts, including a damaged cord or plug.
• Do not apply any sharp objects to the control panel in order to
operate the appliance.
• Do not attempt to separate any panels or disassemble the appliance.
• Do not repair or replace any part of the appliance. All repairs and
servicing must be performed by qualified service personnel unless
specifically recommended in this Owner's Manual. Use only
authorized factory parts.
global_main.book.book Page 10 Sunday, October 16, 2022 2:53 PM
