LG TWIN171411B User manual

www.lg.com
Copyright © 2017-2019 LG Electronics Inc. All Rights Reserved.
OWNER’S MANUAL
WASHING
MACHINE
Before beginning installation, read these instructions carefully.
This will simplify installation and ensure that the product is installed
correctly and safely. Leave these instructions near the product after
installation for future reference.
WD1411SBW
ENGLISH
MFL69962014
Rev.05_101719

TABLE OF CONTENTS
This manual is produced for a group of products
and may contain images or content different from
the model you purchased.
This manual is subject to revision by the
manufacturer.
SAFETY INSTRUCTIONS ......................................03
Important Safety Instructions...............................................................04
INSTALLATION.......................................................07
Parts ....................................................................................................07
Accessories .........................................................................................07
Specifications ......................................................................................08
Installation Place Requirements..........................................................09
Unpacking and Removing Transit Bolts...............................................10
Using Anti-Slip Sheets (Optional) ........................................................ 11
Wooden Floors (Suspended Floors).................................................... 11
Leveling the Appliance.........................................................................12
Connecting Supply Hose.....................................................................12
Installing the Drain Hose .....................................................................15
Electrical Connections (In the UK Only) ..............................................15
OPERATION ...........................................................16
Using the Washing Machine................................................................16
Sorting Laundry ...................................................................................17
Adding Cleaning Products...................................................................18
Control Panel.......................................................................................20
Programme Table ................................................................................21
Option Programme ..............................................................................25
Using Smart ThinQ Application............................................................29
SMART FUNCTIONS..............................................29
Using Smart Diagnosis™ ....................................................................31
MAINTENANCE......................................................32
Cleaning Your Washing Machine.........................................................32
Cleaning the Water Inlet Filter .............................................................32
Cleaning the Drain Pump Filter ...........................................................33
Cleaning the Dispenser Drawer...........................................................34
Tub Clean (Optional) ...........................................................................34
Caution on Freezing During Winter .....................................................35
TROUBLESHOOTING............................................37
Diagnosing Problems ..........................................................................37
Error Messages ...................................................................................40

03
ENGLISH
SAFETY INSTRUCTIONS
The following safety guidelines are intended to prevent unforeseen risks or
damage from unsafe or incorrect operation of the product.
The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described
below.
This symbol is displayed to indicate matters and operations that can
cause risk. Read the part with this symbol carefully and follow the
instructions in order to avoid risk.
WARNING - This indicates that the failure to follow the instructions
can cause serious injury or death.
CAUTION - This indicates that the failure to follow the instructions
can cause the minor injury or damage the product.
To reduce the risk of re, electric shock, or injury to persons when using
your product, basic safety precautions should be followed, including the
following:
Technical Safety
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• If the power cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualied persons in order to avoid a hazard.
• Ventilation openings must not be obstructed by a carpet.
• This appliance is intended to be used in household only and not in applications
such as:
- Staff kitchen areas in shops, ofces and other working environments;
- Farm houses;
- By clients in hotels, motels and other residential type environments;
- Bed and breakfast type environments;
- Areas for communal use in blocks of ats or in launderettes
• Use a new hose or hose-set supplied with the appliance. Reusing old hoses can
cause a water leak and subsequent property damage.
• The water pressure must be between 100 and 800 kPa.
• The maximum capacity in some cycles for dry clothes to be washed is 11 kg.
WARNING

04
Important Safety Instructions
To reduce the risk of re, electric shock, or injury to persons when using
your product, basic safety precautions should be followed, including the
following:
Installation
•Never attempt to operate this appliance if it is damaged, malfunctioning, partially
disassembled, or has missing or broken parts, including a damaged cord or plug.
•This appliance should only be transported by two or more people holding the
appliance securely.
•Do not install the appliance in a damp and dusty place. Do not install or store the
appliance in any outdoor area, or any area that is subject to weathering conditions
such as direct sunlight, wind, rain, or temperatures below freezing.
•Tighten the drain hose to avoid separation.
•This appliance must not be installed behind a lockable door, a sliding door or a
door with a hinge on the opposite side to that of the appliance, in such a way that
a full opening of the appliance door is restricted.
•Do not use a multi outlet power board, extension cable or double adapter with this
appliance.
•This appliance must be earthed / grounded via the mains supply lead. In the event
of malfunction or breakdown, earthing / earthing / grounding will reduce the risk of
electric shock by providing a path of least resistance for electric current.
•This appliance is equipped with a power cord having an equipment-earthing
/ earthing / grounding conductor and a earthing / grounding power plug. The
power plug must be plugged into an appropriate outlet socket that is installed and
grounded in accordance with all local codes and ordinances.
•Improper connection of the equipment-earthing / grounding conductor can result in
risk of electric shock. Check with a qualied electrician or service personnel if you
are in doubt as to whether the appliance is properly grounded.
•Do not modify the power cord provided with the appliance.If it does not t the
outlet, have a proper outlet installed by a qualied electrician.
WARNING

05
ENGLISH
Operation
•Do not attempt to separate any panels or disassemble the appliance. Do not apply
any sharp objects to the control panel in order to operate the appliance.
•Do not repair or replace any part of the appliance. All repairs and servicing must
be performed by qualied service personnel unless specically recommended in
this Owner’s Manual. Use only authorized factory parts.
•Keep the area underneath and around your appliances free of combustible
materials such as lint, paper, rags, chemicals, etc.
•Do not put animals, such as pets into the appliance or allow children to play with
the appliance.
•Do not leave this appliance door open. Children may hang on the door or crawl
inside the appliance, causing damage or injury.
•Use new hoses or hose-set supplied with the appliance. Reusing old hoses can
cause a water leak and subsequent property damage.
•Never reach into this appliance while it is operating. Wait until the drum has
completely stopped.
•Do not put in, wash or dry articles that have been cleaned in, washed in, soaked
in, or spotted with combustible or explosive substances (such as wax, oil, paint,
gasoline, degreasers, drycleaning solvents, kerosene, vegetable oil, cooking oil,
etc.). Improper use can cause re or an explosion.
•In case of ood, disconnect the power plug and contact the LG Electronics
customer information centre.
•Do not lean or push down on the door excessively, when the appliance door is
open.
•Do not touch the door during steam or drying programmes.
•Do not use ammable gas and combustible substances (benzene, gasoline,
thinner, petroleum, alcohol, etc.) near the appliance.
•If the drain hose or supply hose is frozen during winter, use it only after thawing.
•Keep all washing detergents, softener and bleach away from children.
•Do not touch the power plug or the appliance controls with wet hands.
•When pulling out the power plug from an outlet, hold the power plug, not the cable.
•Do not bend the power cable excessively or place a heavy object on it.
•Do not wash rugs, mats, shoes or pet blankets, or any other items other than
clothes or sheets, in this machine.
•This appliance must only be used for domestic household purposes and should
not be used in mobile applications such as caravans or boating.
•If there is a gas leakage (isobutane, propane, natural gas, etc.), do not touch the
appliance or power plug and ventilate the area immediately.
