QUICK GUIDE
50M USB2.0 EXTENDER SET
Local & Remote Units Sold Separately
04152021
INT-USB2-50C
INT-USB2-50CWP INT-USB2-50HWP
INT-USB2-50H

2QUICK GUIDE / INT-USB2-**
Liberty’s 2.0 USB Extender set from the Intelix series oers you the exibility of choosing between a
wall plate and a traditional unit for either the Local or Remote side. Once paired, these will expand the
computer’s USB port to a two-port powered USB hub. These devices provide the ability to extend up to
two USB 2.0 peripherals 50 meters away from the computer, way beyond the typical 5-meter limitation
of only using one CAT6 cable. This means each peripheral connected to the Remote unit can receive a
full 480 mA of power and can even power the peripherals without the host connection. Oering sleek
commercial-grade housing, these high-grade USB extenders provide a simple and exible solution for
any application, including education, commercial, and medical.
Connecting and extending various USB peripherals to your laptop or personal computer (such as web
cameras, microphones, cable cards and disk drives) couldn’t be any easier. Truly plug-and-play; no
driver is required when using software platforms such as Zoom, Teams, YouTube, Facetime, and other
messaging applications.
PACKAGE CONTENTS
(x1) USB 2.0
Type-B to Type-A
adapter cable
REMOTE PRODUCT BREAKDOWN
PRODUCT OVERVIEW
(x1) Quick
Start Guide
(x1) Power
Supply
(x1)
Extender
Wall Plate*
(x1) Power
Supply
(x2) Mounting ears
with screws
(x1) Quick
Start Guide
(x1) 2-pin
phoenix jack
(x1)
Extender Box*
(x1) USB 2.0
Type-B to Type-A
adapter cable
*Includes one option
*Includes one option

3
QUICK GUIDE / INT-USB2-**
PACKAGE CONTENTS
REMOTE PRODUCT BREAKDOWN
1. DC Power
2. USB 2.0 Type A for Periphials
3. LED Indicator for Power Status
4. Female RJ45 for Link Connecon
5. Phoenix Connector - only power the device on the front or back
41
3
3
2
1
4
5
INT-USB2-50C
22 3
FRONTREAR
FRONT
REAR
INT-USB2-50CWP

4QUICK GUIDE / INT-USB2-**
LOCAL PRODUCT BREAKDOWN APPLICATION DIAGRAM
32
INT-USB2-50H
51
FRONTREAR
1. DC Power
2. USB 2.0 Type B for Computer
3. LED Indicator for Power Status
4. Female RJ45 for Link Connecon
5. Phoenix Connector - for oponal power connecon.
Note: Only power the device on the front or back.
4
5
2
1
INT-USB2-50HWP
FRONTREAR

5
QUICK GUIDE / INT-USB2-**
LOCAL PRODUCT BREAKDOWN APPLICATION DIAGRAM
Select either a wall plate or box for either the Local or Remote side. The host/local and remote/client
are interchangable and are purchased separately.
Below is an example showing all four products.

6QUICK GUIDE / INT-USB2-**
TECHNICAL SPECIFICATIONS
Model INT-USB2-50C INT-USB2-50CWP INT-USB2-50H INT-USB2-50HWP
Physical Parameter
Case Material Industrial grade Metal Chassis with metal brackets or wall plate
Dimensions 82mm(W)x49m-
m(D)x20mm(H)
45mm
(W)×103mm
(D)×21mm (H)
82mm(W)x49m-
m(D)x20mm(H)
45mm
(W)×103mm
(D)×21mm (H)
Weight 100g 102g 100g 102g
Power Protecon Over current, over voltage, short circuit protecon
Power Output DC 12V 1A
Power Input AC 100-240V 50/69Hz
Power Consumpon 2.28W
Operang Temperature 32 F-104 F
USB Specicaons
Supported Transfer Rates Transfer rate up to 480 Mbps
Power Protecon Over current, over voltage, short circuit protecon
USB Specicaons Fully compable with USB 2.0/1.0 specicaons
LED Indicator 1 x LED: Power Status
Ports 2 x Female USB 2.0 A 1 x Female USB 2.0 B
Extension Distance Up to 50m using the appropriate catergory cable *CAT6 recommended
Features
Operang System Windows®7 (1080p and under only), Windows 8.1, Windows 10 or higher
macOS™ 10.10 or higher Google™ Chromebook™ Version 29.0.1547.70 or
higher Linux
USB Charging Protocol Supports charging connected USB devices without host connecon if exter-
nal power supply is used
USB Communicaon
Protocol
Will pass UVC 1.1 signals and communicaon

7
