Life Fitness Signature Series FZPEC User manual

SIGNATURE SERIES
FZPEC PECTORAL FLY
Customer Support Services
PARTS MANUAL
Page 1

FZPEC PECTORAL FLY
Page 2
CONTENTS
________________________________________
PAGE
COMPONENT ASSEMBLY 3
COMPONENT ASSEMBLY II 4
COMPONENT ASSEMBLY LEGEND 5
SEAT CARRIAGE ASSEMBLY 6
SEAT CARRIAGE ASSEMBLY LEGEND 7
ADJUSTER HANDLE ASSEMBLY 8
PEC-14 TOWER ASSEMBLY 9
PEC-14 TOWER ASSEMBLY LEGEND 10
5 LB. INCREMENT WEIGHT ASSEMBLY 11
10 LB. INCREMENT WEIGHT ASSEMBLY 12
15 LB. INCREMENT WEIGHT ASSEMBLY 13
HEAD PLATE ASSEMBLY 14
HEAD PLATE ASSEMBLY LEGEND 15
IMAGE 16

________________________________________
COMPONENT ASSEMBLY
SEE PAGE 5 FOR LEGEND
Page 3
17"Length
12
66
65
4
35
34
33
1
5
7
23
19
2
60
32
11
26
24
25
48
18
18
18
18
15
49
47
20
16
16
62
30
10
17
19
3
36
37
27
31
61
14
13
13
64
22
21
63
70
68
69
41
41
41
59
58
67
39
39
39
39
39
39
39
39
39
39
39
29
40
40
40
42
38
38
46
46
44
43
43
45
6
9
8
FZPEC PECTORAL FLY

Page 4
________________________________________
COMPONENT ASSEMBLY II
SEE PAGE 5 FOR LEGEND
FZPEC PECTORAL FLY
52
57
56
54
50
51
55
53

Page 5
________________________________________
COMPONENT ASSEMBLY LEGEND
FZPEC PECTORAL FLY
ITEM NO. QTY. PART NO. DESCRIPTION ITEM NO. QTY. PART NO. DESCRIPTION
1 1 8164501 WLDMT, FZPEC, MAIN FRAME 36 2 7326201 CAP, D-TUBE - TOP
2 2 8165001 WLDMT, FZPEC, PIVOT HSNG 37 4 3238601 M10X1.5 THREADED INSERT (HEX)
3 1 7625095 WLDMT, FZ WT STK PULLEY BRKT 38 5 3236201 SCREW, M10 X1.5 20MM
4 2 8165201 BRKT, FZPEC, CAM ADJ. 39 54 3236601 WASHER, 3/8 SAE SS
5 1 8164801 WLDMT, FZPEC, PRESS ARM -RT 40 15 3236206 SCREW, M10 X1.5 45MM
6 1 8164601 WLDMT, FZPEC, PRESS ARM - LH 41 16 3236801 NUT, M10 HEX NYLOCK SS
7 1 7486001 WLDMT, FZFLY HANDLE - RT 42 1 3236902 NUT, M16 X 2 HEX JAM SS
8 1 7486101 WLDMT, FZFLY HANDLE - LT 43 6 3236202 SCREW, M10 X1.5 25MM
9 1 7330501 WLDMT, FZ SEAT SUPPORT 44 1 3236208 SCREW, M10 X1.5 55MM
10 1 7911101 ASSY, SEAT CARRIAGE 45 5 3251204 SCREW, M10 X1.5 X 35MM HEX ST ZN
11 1 8165301 ASSY, FZPEC TOWER - 14 46 6 3251202 SCREW, M10 X1.5 X 25MM HEX ST ZN
12 2 8165501 CAM, FZPEC 47 2 7351501 SPRING; PULL PIN LARGE
13 7 3237801 PULLEY, 4.5" OD 48 2 7424801 KNOB, POP PIN
14 1 7333901 CAP, LARGE FLOV- END 49 2 7425102 PIN, PULL X 6.75
15 4 8094101 COVER, PULLEY-BOLTED PARTIAL 50 1 7603001 LABEL, FZAB PLACARD
16 4 7330001 SPACER, INTERNAL X .403 51 1 8173200 LABEL, FZPEC, PLACARD
17 2 7330002 SPACER, INTERNAL X .653 52 1 7571301 LABEL, SERIAL NUMBER
18 8 3235601 BEARING, 6205 BALL 53 1 7422004 LABEL, 2" ASTM WARN
19 4 7330006 SPACER, INTERNAL X 1.765 54 1 7422003 LABEL, MOVING PARTS
20 2 7316509 SHAFT, 25MM X 13.740 55 1 7524501 LABEL, 1-9 STRAIGHT
21 2 7435301 COLLAR, SHAFT 1.020 ID 56 1 8171401 LABEL, FZPEC, 1-5 CURVED LH
22 4 3104903 1.00" ID 1.25" OD BRONZ BUSHING 57 1 8171301 LABEL, FZPEC 1-5 CURVED RT
23 2 3238501 CAP, 1/2 X 5/8 58 2 3239101 SCREW, M5X10 PHL PAN TT ST
24 2 3235802 GRIP, 1.00 ID X .25 X 17.50 59 1 7385203 SPACER, .406 X .750 X .500
25 2 7662902 CAP, GRIP 1.50 OD 60 2 7690101 BUMPER, SLEEVE - 1 INCH DIA
26 2 7662802 RING, GRIP 1.50 OD 61 1 7419601 COVER, FOOT-20 DEG.
27 2 7333801 CAP, SMALL FLOV- END 62 1 7776501 SHAFT, .625 X .406 X 1.200
28 1 3239201 SPRING, EXT, .375 X .049 X 2.00 63 5 3237403 PLUG, 1" HOLE
29 1 7425295 BRKT, SEAT INDICATOR 64 2 6757701 CLIP, CABLE 2-7/8 X 1 X 1
30 1 7407502 PIN, LINK 65 1 7423809 CABLE, FZPEC 224-1/2
31 2 3232401 RING, RETAINING, EXTERNAL 66 2 7342201 PLATE, CABLE END
32 1 7778001 ASSY, FZ ADJUSTER HANDLE 67 2 3254703 NUT, M10 X 1.5 HEX ZINC
33 1 74743XX PAD, HEAD REST 68 2 7630101 RETAINER, CM/MJ, PULLEY
34 1 74741XX PAD, LARGE BACK 69 2 7335401 NUT, M10 X 1.5 SOCKET HEAD
35 1 72971XX PAD, SEAT SADDLE 70 2 3236207 SCREW, M10 X1.5 50MM

________________________________________
SEAT CARRIAGE ASSEMBLY - 7911101
Page 6
5
3
2
1
4
6
7
10 11
12
9
8
10
11
7
SEE PAGE 7 FOR LEGEND
FZPEC PECTORAL FLY

________________________________________
SEAT CARRIAGE ASSEMBLY LEGEND
Page 7
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7911295 WLDMT, SEAT CARRIAGE SHDW GRAY
2 7 7889701 ROLLER, SEAT CARRIAGE
3 4 7911901 SPACER, .625 DIA X 16 GA.
4 3 7912001 SPRING, SEAT CARRIAGE
5 7 3232408 RING, BRE .443, 5100-46, ST,PP,B
6 1 3235700 SPRING, GAS 80N
7 2 7414301 STUD, M10 BALL END M10 X 1.5
8 1 7339401 BRACKET, GAS SPRING
9 1 7334001 FOOT, 2.50 X 4.49 FLOV
10 2 3236601 WASHER, 3/8 SAE SS
11 2 3236801 NUT, M10 HEX NYLOCK SS
12 2 3241201 M4 PHL PAN F ST ZN
FZPEC PECTORAL FLY

Page 8
________________________________________
ADJUSTER HANDLE ASSEMBLY - 7778001
7
6
5
4
1
3
2
4
5
5
5
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7777595 WLDMT, FZ SEAT ADJ HANDLE SHADOW GRAY
2 1 7331801 LINK, ADJUSTER
3 1 7331601 PIN, INDEX
4 2 7407501 PIN, LINK
5 4 3232401 RING, RETAINING, EXTERNAL
6 1 7287901 HANDLE, ADJUSTER
7 1 3110010 ROLL PIN, 1/8 X 7/8
FZPEC PECTORAL FLY

Page 9
________________________________________
PEC-14 TOWER ASSEMBLY - 8165301
FZPEC PECTORAL FLY
16
15
1
2
8
7
6
9
10
11
12
13
19
11
17
14
18
21
22
22
22
20
23
23
5
4
3
24
SEE PAGE 10 FOR LEGEND
WEIGHT STACK LABELS
7927201 LABEL, 390 LB STACK
7927301 LABEL, 195 KG STACK

Page 10
________________________________________
PEC-14 TOWER ASSEMBLY LEGEND
FZPEC PECTORAL FLY
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7350701 ASSY, HEAD PLATE (14)
2 14 7328401 WEIGHT PLATE, 20 LB
3 1 7327601 ASSY, INCREMENT WT - 5 LB
4 1 7327701 ASSY, INCREMENT WT - 10 LB
5 1 7327801 ASSY, INCREMENT WT - 15 LB
6 2 7328701 SPACER, INC WT STACK - 14 PLT
7 2 7351001 SPACER, INC WT STACK
8 1 7621101 RETAINER, GUIDE ROD - TOP
9 4 7328619 GUIDE ROD, .75 OD SOLID 47.00
10 4 7337901 BUSHING, GUIDE ROD
11 4 7352101 CUSHION, WEIGHT STACK
12 4 3103301 SHAFT COLLAR, 3/4 I.D. ZINC
13 1 8170301 COVER, FZPEC, TOWER- BOTTOM FRONT
14 1 7318901 COVER, TOWER- BOTTOM REAR
15 1 7318601 COVER, TOWER- TOP FRONT
16 1 7318701 COVER, TOWER- TOP REAR
17 1 7765701 SHROUD, TOWER- REAR SHORT
18 2 7765601 SHROUD, TOWER- FRT SHORT RH
19 2 7326301 CAP, D-TUBE - BOTTOM
20 6 7583501 RETAINER, FZ SHROUD
21 2 3236202 SCREW, M10 X1.5 25MM
22 13 3239101 SCREW, M5X10 PHL PAN TT ST
23 9 3236501 M4 X 0.7 PHL PAN MS ST ZN
24 2 3239102 SCREW, M5X12 PHL PAN TT ST BZ

5 LB. INCREMENT WEIGHT ASSEMBLY - 7327601
________________________________________
Page 11
3
2
1
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7968501 ASSY, FZ INC WEIGHT 5LB
2 1 7328001 BRKT, INCREMENT WT - 5 LB
3 2 3236202 SCREW, M10 X1.5 25MM
FZPEC PECTORAL FLY

10 LB. INCREMENT WEIGHT ASSEMBLY - 7327701
________________________________________
Page 12
1
2
3
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7968501 ASSY, FZ INC WEIGHT 5LB
2 1 7328101 BRKT, INCREMENT WT - 10 LB
3 2 3236202 SCREW, M10 X1.5 25MM
FZPEC PECTORAL FLY

________________________________________
Page 13
15 LB. INCREMENT WEIGHT ASSEMBLY - 7327801
3
1
2
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7968501 ASSY, FZ INC WEIGHT 5LB
2 1 7328201 BRKT, INCREMENT WT - 15 LB
3 2 3236202 SCREW, M10 X1.5 25MM
FZPEC PECTORAL FLY

HEAD PLATE ASSEMBLY - 7350701
________________________________________
Page 14
SEE PAGE 15 FOR LEGEND
16
8
6
14
12
15
2
1
10
13 11
5
4
7
3
9
WEIGHT STACK LABELS
7927201 LABEL, 390 LB STACK
7927301 LABEL, 195 KG STACK
FZPEC PECTORAL FLY

________________________________________
Page 15
HEAD PLATE ASSEMBLY LEGEND
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7326701 HEAD PLATE
2 1 7347801 STEM, 9 PLATE
3 1 3236001 BUSHING, SPRING PIN
4 1 7327201 WLDMT, INCREMENT WT PIN
5 1 8024501 SPRING, 1/2 OD X 1-1/2
6 1 7326101 KNOB, INC WT SELECTOR
7 1 3110008 ROLL PIN, 1/8 X 1-1/4
8 1 7326401 HOUSING, SELECTOR - FRONT
9 1 7326501 HOUSING, SELECTOR - REAR
10 1 7362101 STABILIZER, HEAD PLATE
11 4 7459601 BUSHING, HEAD PLT STABILIZER
12 1 7356501 PLUG, LANYARD ATTACHMENT
13 4 3236202 SCREW, M10 X1.5 25MM
14 1 7338101 ASSY, WT STACK SELECTOR PIN
15 1 7523601 CRIMP, CABLE
17398601 CAP, SELECTOR KNOB, LBS
16 OR
17398701 CAP, SELECTOR KNOB, KG
FZPEC PECTORAL FLY

Page 16
