LIFE home integration CT2 24 UNI DL Technical specifications

Rev. 01 - 26/2018 LG
CT2 24 UNI DL 24V
F
CONTROL UNIT FOR TWO-LEAF GATES
INSTRUCTIONS AND WARNINGS FOR INSTALLATION, USE AND MAINTENANCE
GB

2
DANGER
Important Safety instructions.
It is important for the safety of persons to follow all instructions.
Save these instructions.
The drive shall be disconnected from its power source during cleaning, maintenance and while replacing parts.
Do not allow children to play with the appliance or its controls, including remotes.
Watch the moving door and keep people away until the door is completely opened or closed.
Take care when operating the manual release since an open door may fall rapidly because of the wind and
may cause harm to people or objects.
Frequently examine the installation, in particular check cables, springs and mounting for signs of wear, damage
or imbalance.
Do not use if repair or adjustment is needed since a fault in the installation or an incorrectly balanced door may
cause injury.
Each month check that security features are working correctly and efficent.
If necessary, adjust and re-check since an incorrect adjustment can present a hazard. If re-adjustment does not
Restore the correct operation, contact your authorized service center for assistance.
The automation must not be installed above 2000mt on sea level.
Insert , conforming to the installation regulations, a device that assures a complete disconnection of the power
source with a distance of opening contacts in the overvoltage III category.
If the power cable is damaged it must be replaced by the manifacturer or by it’s technical service or by a
qualified technician in order to prevent any risk.
WARNING
WARNING:
Automatic door -The door may operate unexpectedly, therefore do not allow
anything to stay in the path of the door.
WARNING:
Important safety instructions.
Follow all of the instructions , a wrongful installation may cause damage.
Apply permanently the warning lables against the the entrapment in a clearly
visible spot or near fixed command devices.
Apply permanently the manual unlock label near it’s control unit.
After the installation , make sure that the mechanism is regulated and that the rotation motor inverts its
movement if the door hits an object.
After the installation make sure that the gate structure doesn’t obstruct public roads or sidewalks.
After the installation make sure that the safety features work correctly.
This device can be used by kids older than 8 years of age , by people with disabilities,without experience
or necessary knowledge , as long as they are being accompanied or they recived instructions and they can
comprehend the dangers of the device .
Kids must not play with the device.
Cleaning and mantainance operations destined to be done by the user must not be done by unattended kids.
efficiently
entrapment in a clearly
its
manufacturer its
maintenance
Important safety instructions.
For personal safety it is important to follow these instructions.
Keep these instructions.
The device must be disconnected from the power supply during cleaning and maintenance operations
and the replacement of components.
Do not allow children to play with the gate control devices. Keep remote controls away from children.
Monitor the moving gate and keep people away as long as the automation is moving.
Be careful when operating the manual release device as the leaves could move with the wind and
cause damage to people or things.
Check the system frequently, in particular the hinges and mechanical stops, check for signs of wear or damage.
Do not use, if repair or adjustment is required, as an installation failure can cause injury.
Check monthly that the safety devices are functioning and efficient.
If necessary, adjust or recheck, incorrect adjustment can present a hazard.
If the intervention does not restore the correct functioning of the automation, contact the authorized
technical assistance center.
The automation must not be installed at an altitude above 2,000 m above sea level.
In accordance with the installation rules, insert a device that ensures complete disconnection from the
power supply with a contact opening distance in overvoltage category III.
If the power cable is damaged, it must be replaced by the manufacturer or its technical assistance
service or in any case by a person with a similar qualification, in order to prevent any risk.
Automation for swing gates
The gate can operate unexpectedly, therefore do not allow anyone or
anything to stop in the gate movement area.
WARNING
Important safety instructions.
Follow all instructions as incorrect installation can cause serious damage.
Permanently fix the warning labels against entrapment in a very visible point
or near any fixed control devices.
Permanently fix the manual release label adjacent to its control unit.
After installation, make sure that the mechanism is properly adjusted and that the movement motor
reverses movement when the door hits an object.
After installation, make sure that the parts of the gate do not clutter public roads or sidewalks.
After installation, make sure that the protection systems work as expected.
This information must also be included in the instructions.
This appliance can be used by children under 8 years of age and by people with reduced physical
abilities, sensory or mental impairments or lack of experience or necessary knowledge, as long as they
are under surveillance or after they have received instructions relating to the safe use of the appliance
and the understanding of the dangers inherent in it.
Children must not play with the device.
Cleaning and maintenance operations intended to be carried out by the user must not be carried out by
children without supervision.

3
mm. 250
mm. 184
min cm 40
5
3
4
1
2
GEBOX ASSEMBLY INSTRUCTIONS

4
1
2
6
6 - 7
6 - 8
6 - 9
6 - 10
6 - 11
12 - 13
14 - 16
15 - 16
16 +
17 -
CONN-1 24Vac:
33 - 34
- / +
35 - 36 - / +
CONN-2
1 LINKS AND CONNECTIONS
1.1 Central Connections
Clamps
Description ( check electical scheme , page 5)
1
ANTENNA:
2Antenna cable imput.
6COMMON COMMANDS:
6 - 7
STOP: Imput N.C. Commands the gate’s halt.
To this can be connected to safety devices such as an emergency arrest button.
When released the command does not do an automatic arrest , it is instead necessary to give a new
movement command. Leave the bridge in place if no devices are installed.
6 - 8 OPEN: Imput N.O. Commands the opening of the gate.
6 - 9
CLOSE : Imput N.O. Commands the gate’s halt.
6 - 10
SETP-BY-STEP: Imput N.O. Command the gate’s actions following this commands :
SEMI-AUTOMATIC MODE : Open ,Stop,Close,Stop
FOUR STEPS MODE : Open,Pause,Close,Pause.
CONDOMINIUM MODE : Open (automatic closing with the active pause time).
6 - 11 PHOTO: Imput N.C for photocells and safety devices . While the gate is opening doesn’t intervene ,
12 - 13 RELE’ CONTACT :
14 - 16 ELECTIC LOCK:
Exit 12Vdc for the connection with the electric lock at 12Vdc 15VA; in order to activate
15 - 16
Exit 24 Vdc 25W max to connect the blinker
16 +
17 -
N.C. = contact normally closed - N.O = contact normally open
The command determines the opening of only one side. Can be given by remote or clamps
When using the terminal block a bridge will be obtained and the clamp n°8 will be OPEN , the clamp n°9 will CLOSE
this bridge will be connected to a switch at clamp n°6 common. The command PEDESTRIAN from terminl block
won’t have the OPEN and CLOSE commands.
EXIT 30 Vdc : To power various devices, max 200mA.
CONN-1 24Vac:
Input transformer power
33 - 34 Engine 2, if closed opens second.
Engine 1, if closed opens first.
PHOTO1: With option 1 Led 4 , the imput becomes N.C. in order to connect the photocell that
acts while in the Closing and Opening phase.
Clean contact Relè Max 3A , default for the connection to an open gate LED
With the activation OPTION 2 Led 2 becomes a command for the courtesy light timed at 3 minutes.
- / +
35 - 36 - / +
- Before proceeding with the links and connections carefully read what is presented in the PRESCRIPTIONS AND
WARNINGS FOR SECURITY and PRESCRIPTIONS AND WARNINGS FOR THE INSTALLATION.
- All of the linking and connecting operations must be performed with the power source disconnected , if the device is not
visible a sign must be applied : “ WARNING UNDER MAINTENANCE ”.
Stocking antenna input , use RG58-50 Ohm cable.
ANTENNA:
For the imputs: STOP - OPEN - CLOSE - STEP BY STEP - PHOTO.
BLINKER:
PEDESTRIAN:
Connections bottom of the control unit
CONN-2 Connection battery charger AGECH-2
while closing it dertermines the inversion of the motion until the complete opening.
Leave the bridge open if no devices are installed.
select the function from the Options meù n°1 Led n°3
Safety devices such as an emergency stop button can be connected to it.
When the command is released, automatic closing is never carried out but a new movement command
must be given. Leave the jumper if no device is provided.
input
Input
Input
Input
PHOTO1: With OPTION 1 Led 4, the input becomes N.C. for the connection of a photocell that intervenes
in Opening and Closing.
Input N.O. Controls the movement of the gate according to the following cycles:
FOUR STEPS MODE: Open, Pause, Close, Pause.
SEMI-AUTOMATIC MODE: Open, Stop, Close, Stop.
CONDOMINIUM MODE: Opens (automatic closure with active pause time).
PHOTO: N.C. input for photocells or safety devices. During the opening of the gate it does not intervene; in
closing it causes the inversion of the movement until the complete opening.
Leave the jumper if no device is provided.
RELAY CONTACT: Dry contact Relay Max 3A, default for the connection of an Open gate light. With the
activation of OPTION 2 Led 2 becomes a command for the courtesy light timed at 3 minutes.
RELAY CONTACT
ELECTRIC LOCK: 12Vdc output for connection of 12Vdc 15VA electric lock; to activate it, select the function
from the Options menu 1 Led 3.
ELECTRIC LOCK
FLASHING: 24 Vdc 25 W max output, for connection of the flashing lamp.FLASHING
PEDESTRIAN: The command causes an opening of only one leaf. It can be given by a remote control or by terminal board.
This terminal is obtained by bridging terminal 8 OPEN with terminal 9 CLOSE, this jumper then connects with a switch to
terminal 6 COMMON. The PEDESTRIAN command from the terminal board excludes the OPEN and CLOSE commands.
PEDESTRIAN
input
inputs
electrical

5
-
-
-
START
16
17
16
16
14
15
F3 3.15A-T
F2 10A-T
12 Vdc 15 VA
Relè 3A
30 Vdc 200mA Max
N.O.
COM.
24 Vac
13 12
POWER
13 12
POWER
L7
L8
L9
L10
L11
AGECH2
F1 3.15A-T
CONN1
CONN2
230Vac
ELECTRICAL CONNECTION
ELECTRIC LOCK
FLASHING
INDICATOR LIGHT
DEFAULT
POWER
POWER
COURTESY LIGHT
OPTIONS N.2
Led 2 On
INDICATOR LIGHT N.6
COURTESY LIGHT N.7
FLASHING
ELECTRIC LOCK
L7
L8
L9
L10
L11
SIGNALS LED
The leds under the terminal block
show the entry state .
L7 and L11 are imputs N.C and must
be turned on , they turn o when
the corresponding imput is activated
L8-L9-L10 are imputs N.O. must be
turned o and they will automatically
turn on when the corresponding
imput is activated
COMMON COMMANDS
Relay
PEDESTRIAN
SIGNALING LED
The LEDs under the terminal block
indicate the state of the entrance.
L7 and L11 are N.C. inputs and they
must be turned on, they turn off when
the corresponding entrance is activated.
L8 - L9 - L10 are N.O. inputs
they must be off, they turn on
when the corresponding entrance
is activated.

6
OFF
230V
OFF
13
ON
ON
230V
2
OFF
230V
OFF
230V
OFF
12
ON
ON
230V
Energy Saving
12
12
In order to optimize electrical consumption
we introduced the ES function.
After 10’ from the central
programmation the Leds of the front
panel will turn o and the keyboardwill
be deactivated.
To re-activate the keyboard turn the
central unit o and on again
2.2 RUN PROGRAMMATION AND SHUTTERS OFFSET
will first turn on and then they will blink.
AssoonasthisprocessisdonethetwogreenLedswillstartblinking ,whilethetworedLedswillstay on
If the result is not satisfying it is possible to execute a manual programmation to define different
offsets.Refer to chapter n°7.
a) Position the shutters at a 45° angle.
b) Press the button for 5” , the 5 Leds
c) Press the gate will execute this sequence :
- Closing Shutter 2,
- Closing Shutte 1,
- Opening Shutter 1, with offset
- Opening Shutter 2,
- Closing Shutter 2, with offset
- Closing Shutter 1.
N.B. In case only one motor is being used connect it with the n°35 and n°36 clamps.
Make sure to fix the mechanical limit switches of opening and closing of the automation
When the programmation is done for 10 minutes the button can be used as a STEP command
N.B.
In order to totally reset the unit , before giving power, press and keep pushed the button, release
after the central unit.
2 CENTRAL UNIT PROGRAMMATION
2.1 TOTAL RESET
ATTENTION
START
START
START
START
To optimize energy consumption,
we have introduced the Energy
Saving function. After 10 minutes
from the control unit setup, the front
panel LEDs turn off and the use of
the keyboard is inhibited. To
reactivate it, it is necessary to switch
the control unit off and on again.
CONTROL UNIT SETUP
Power off the system, hold the start button, power on again and release the start button once the
red leds come on.
PROGRAMMING THE TRAVEL AND THE LEAVES’ SHIFT
N.B. If only one motor is used, connect it to terminals 35 - 36.
Make sure you have fixed the mechanical opening and closing limit switches of the automation.
Place the leaves at 45°
Press and hold down the START button for
5 seconds until all 5 red LED’S blink.
Press START, the automation performs in sequence:
- closure leaf 2;
- closure leaf 1;
- opening leaf 1, with phase shift;
- opening leaf 2;
- closure leaf 2, with phase shift;
- closure leaf 1.
Once programming is complete, the two green LEDs will flash, while the two red LEDs will turn on with
a steady light.
The START key at the end of programming, for 10 minutes can be used as a STEP command
If the result is not satisfactory, it is possible to carry out a manual programming to define the different
phase shifts. See chapter No. 7.
LAG
lag;
lag;
PHASE LAG
PROGRAMMING THE TRAVEL AND PHASE LAG
lags

7
12
12
12
3 REMOTE GESTION
The control unit is equipped with an integrated radio receiver with 750 code memory, on a frequency of
433.92 MHz with LIFE Rolling Code and Auto-Code coding
3.3 Deleting all of the remotes settings
3.1 REMOTE LEARNING
a) Press the button for 5” , the left green
led will turn on and then start blinking.
b) Push for 5” the button and the leds will blink
alternately
As soon as the Leds will stop blinking all
of the remotes settings will be deleted.
a) Press the button for 5” , the left green led
will firstly turn on and then will start blinking.
b) Keep on pressing the remote button until all of the
five Leds will light up the remote
setting will be deleted.
3.2 Removing an already existing remote setting
TOTAL OPENING
a) Press the button the left green Led and the
[A] Led will turn on.
b) Keep the button P1 of the radio control pressed until
all five LEDs light up
a) Press twice the button and the left green led
and the [B] Led will turn on
b) Hold down the P2 button of the radio control until
all five LEDs light up
SHTTER N°1 PEDESTRIAN OPENING
Wait for 20” or press the button again
to anticipate the exit from the programmation mode.
+
+
+
+
++
+
+
REMOTE CONTROL MANAGEMENT
The control unit is fitted with a built-in radio receiver with a 750 code memory and 2 channels with a
433.92 MHz frequency with LIFE Rolling Code and Auto code encoding.
- Press the key fob selection button (top left); the left green LED
under “–“ symbol and the first red dot (A) beside “– “symbol, will
light up.
- Hold down the P1 button on the transmitter that you want to
pair to perform a total opening until all five LEDS light up.
PEDESTRIAN OPENING LEAF N.1
- Press the key fob selection button (top left) twice; the left
green LED under “–“ symbol and the second red dot (B)
beside “– “symbol, will light up.
- Hold down the button on the transmitter that you want to
pair to perform a partial opening until all five LEDS light up.
Wait 20 "or press again the key fob selection button to
quit the setup mode.
REMOVE AN EXISTING REMOTE TRANSMITTER
- Press and hold the key fob selection button for 5 seconds
until the left green light under “–“ symbol comes on and
then starts blinking.
- Hold down the button on the transmitter that you want to
remove until all five LED's light up.
REMOVE ALL EXISTING REMOTE TRANSMITTERS
- Press and hold the key fob selection button for 5 seconds
until the left green light under “–“ symbol comes on and then
starts blinking.
- Press and hold the key fob selection button down again for
5 seconds and the LED’s will blink alternately.
- As soon as the flashing stops, all remotes will be
uccessfully deleted.

8
5 s
10 s
30 s
60 s
120 s
1
2
1
2
+
+
+
+
+
+
5”
+
+
+
+
+
+
4 REGOLATIONS AND OPTIONS
4.1 AUTOMATIC CLOSURE
An automatic closure is activated after a set PAUSE TIME.
4.2 AUTOMATIC CLOSURE
a) Press the button the green right Led turns on
- If none of the leds is turned on the
Wait 20” or press the button again
in order to anticipate the exit from programming mode.
automatic closure is not active , press the
button to activate it .
- If at least one of the leds is on
the automatic closure is activated, in order to
deactivate it press the button untill all of the
Leds are off.
By pressing and you can set the various
values for the PAUSE TIME
Work cycle:
OPEN - PAUSE - CLOSE - PAUSE
MINIMUM
4.3 ADJUSTMENT TIME OF DECELERATION
a) Press the for 5” the Led green and red on the
right will turn on:
ATTENTION:
The deceleration CAN’T be completely eliminated , in this phase the limit switch’s push force will determine
the Stop in the motor’s run.
By pressing and you can adjust the value
of he DECELERATION TIME
MAXIMUM
DEFAULT
LEDS ON
LEDS ON PAUSE TIME
DECELERATION TIME
CHIUSURA NON ATTIVA
+
+
+
+
+
Wait 20” or press the button again
in order to anticipate the exit from programming mode.
OPTIONS SETTING
Automatic reclosure is activated after a preset PAUSE TIME.
AUTOMATIC RE-CLOSURE IS NOT
ENABLED
SLOWDOWN TIME ADJUSTMENT the green and red LEDs on the right
light up:
the SLOWDOWN TIME
The slowdown can NOT be completely eliminated, in this phase the thrust in the limit switch determines the stop of
the motor stroke.

9
+
+
+
+
+
+
5”
2
+
+
+
+
+
+
80%
85%
95%
2
1
1
5 SPEED AND SENSIBILITY
5.1 ADJUSTING SPEED
Wait 20” or press the button again to anticipate the exit from the programming mode.
SENSITIVITY
MINIMUM
5.2 MOTOR SENSITIVITY ADJUSTMENT
a) Press the button for 5” the green and red
Led on the left will turn on.
MAXIMIUM
DEFAULT
LED ON SPEED
MINIMUM 75%
a) Press the button and left red led will turn on:
By pressing or the speed can be adjusted.
MAXIMUM 100%
DEFAULT 90%
LED ON
ATTENTION:
Based on the gate’s structure and on its usage parameters such as sensitivity and speed mus be setted
accordingly to the laws of the country.
+
By pressing or the sensitivity can be
adjusted .
+
Wait 20” or press the button again to anticipate the exit from the programming mode.
SPEED AND SENSITIVITY
SPEED ADJUSTMENT

10
5”
+
+
+
+
+
+
+
+
+
+
+
+.............................................................................
6 OPTIONS MENU
6.1 OPTIONS 1
LED ON OPTIONS 1
Press the button in order to enter insde the OPTIONS MENU 1 , press in sequence the
buttonto advance in the selection , the blinking led will indicate the poeistion , with the button it will be
activated Red fixed Led , with the button it is deactivated.
No active function.
Condominium: Command Step Open only.
Mode: OPEN-STOP-CLOSE-STOP.
Electric lock activation.
The imput CLOSE becomes PHOTO1.
The activation of PHOTO anticipates the closure.
6.2 OPTIONS 2
LED ON OPTIONS 2
Press the button for 5” in order to enter the OPTION MENU 2 , press in sequence the button
to advance in the selection the led blinking shows the position and with the button it is activated , fixed
red Led, with the button it deactivates .
Faster slowing-down speed.
The exit Relè 12-13 becomes a COURTESY LIGHT
Delay of safety interventions during movement.
Funcioning with PRESENT MAN.
.............................................................................
Wait for 20” or press the again to exit programming mode.
+
No active function.
Wait for 20” or press the again to exit programming mode.
+
button to enter the OPTION MENU 1. then press it again in sequence to scroll through the available
options. The flashing LEDS indicate the position and the corresponding option. By pressing button + the function is activated
(red led on), by pressing button – the function is deactivated
s
Condo options: step command only opening
Change operating mode: OPEN-STOPCLOSE-STOP
The CLOSE input becomes PHOTO1.
Activating PHOTO anticipates closure.
then press it again in sequence to scroll
through the available options. The flashing LEDS indicate the position and the corresponding option. By pressing
button + the function is activated (red led on), by pressing button – the function is deactivated
s
Increase the speed during slowdown
The output Relay 12 - 13 becomes COURTESY LIGHT.
Safety intervention delay during movement.
Operation in MAN'S SWITCH
OPEN-STOP-CLOSE-STOP

11
1
2
2
1
12
12
12
12
1
2
2
1
7 MANUAL PROGRAMMING
Press for 5 seconds , the 5 leds will light up and then
start blinking.
Manual programming can be done with a button
connected to terminals 6 - 10 (Step-by-Step) or with
radio control previously memorized, page 7 cap.3.1.
Position the motors at 45 °.
7.1 CLOSING FINISHES LEARNING
During the flashing of the 5 LEDs give a command of
Step by step the leaf [2] must move first in closing,
when he arrives at the stop he has to stop and the Led of the
Right goes on with fixed red light.
Give a second Step-by-Step command the leaf [1] must
move in closing, when it comes in batting it must stop and
the Left LED lights up with a fixed red light.
Give a Step-by-Step command the leaf [1] opens, al
reaching the point where you want to open also
the leaf [2] give a further step-by-step command.
The two wings now proceed in opening until they reach the
respective mechanical stops, the two red LEDs of left and
right they remain in red light.
Give a Step-by-Step command the leaf [2] closes, al
reaching the point where you want to close also
the leaf [1] give a further step-by-step command.
The two doors proceed now in closing until they reach the
respective mechanical stops, the two red LEDs of left and
right they remain in red light.
7.3 LEARNING CLOSING OFFSET
7.2 LEARNING OFFSET AND FINISHES
The automation is now programmed in semi-automatic mode.
If the result obtained is not satisfactory, perform the
reset the control panel and restart from point 7.
START
Manual programming can be done with a button connected
to terminals 6 - 10 (Step-by-Step) or with the previously
memorized radio control, page 7 chap. 3.1.
Place the motors (leaves) at 45 °.
Hold the START button for 5 seconds, the 5 LEDs first light
up and then flash.
CLOSING LIMIT SWITCH LEARNING
While the 5 LEDs are flashing, give a Step-by-Step
command; the leaf [2] must move first performing a closure;
when it reaches the mechanical stop it must stop and the
Right LED lights up with a red steady light.
Give a second step-by-step command; the leaf [1] must
perform a closure, when it reaches the mechanical stop it
must stop and the Left LED lights up with a red steady light.
OPENING AND CLOSING PHASE SHIFT LEARNING
Give a Step-by-Step command; the leaf [1] starts opening; as
soon as it reaches the point where you want to start opening
leaf [2] give a further Step-by-Step command.
The two leaves now proceed to open until they reach their
respective mechanical stops, the two red LEDs on the left
and on the right remain with a steady red light.
OPENING PHASE SHIFT AND LIMIT SWITCHES LEARNING
CLOSING PHASE SHIFT LEARNING
Give a Step-by-Step command; the leaf [2] starts closing; as soon as
it reaches the point where you want to start closing leaf [1] give a
further Step-by-Step command.
The two leaves now proceed to close until they reach their
respective mechanical stops, the two red LEDs on the left and on
the right remain with a steady red light.
Automation is now programmed in semi-automatic mode.
If the result obtained is not satisfactory, carry out the
reset the control unit and start again from point 7.
LEARNING OF THE CLOSURE LIMIT SWITCH
LEARNING OF OPENING PHASE LAG AND LIMIT SWITCH
LEARNING OF CLOSING PHASE LAG

Address: Via Sandro Pertini,3/5 31014 COLLE UMBERTO (TV) Italia
Telephone: + 39 0438 388592
Telefax: + 39 0438 388593
http www.homelife.it
e-mail: [email protected]
