LifeSource UA-853 Manual

Premium Automatic
Blood Pressure Monitor
Trilingual Instruction Guide - Model UA-853
English
z Français z Español

Please read this important information before using your monitor.

Please remember that only a medical practitioner is qualified to interpret
your blood pressure measurements. Use of this device should not replace
regular medical examinations.

Consult your physician if you have any doubt about your readings.
Should a mechanical problem occur, contact LifeSource® at
1-888-726-9966.

Do not attempt to service, calibrate, or repair this monitor.

Because your UA-853 monitor contains delicate, high-precision parts,
avoid exposing it to extremes in temperature or humidity or to direct
sunlight, shock and dust. LifeSource® guarantees the accuracy of this
monitor only when it is stored and used within the temperature and
humidity ranges noted on page E-21.

Clean the monitor and cuff with a dry, soft cloth or a cloth dampened
with water and a mild detergent. Never use alcohol, benzene, thinner or
other harsh chemicals to clean monitor or cuff.

Remove and replace batteries if monitor is not used for more than six
months. Alkaline batteries recommended.
PRECAUTIONS
The UA-853 is designed to be used at home, by those who are eighteen (18)
years and older, to monitor blood pressure (systolic and diastolic) and pulse
rate.
IMPORTANT INFORMATION

Fast. Easy. Accurate.
Congratulations on purchasing a state-of-the-art LifeSource®
blood pressure monitor—one of the most technologically
advanced monitors available today. Designed for ease of use
and accuracy, this monitor will facilitate your daily blood
pressure regimen.
Physicians agree that daily self-monitoring of blood pressure
is an important step individuals can take to maintain
cardiovascular health and prevent the serious consequences
associated with undetected and untreated hypertension.
A&D Medical has been manufacturing high quality
healthcare products for ove 20 years. We are committed to
providing you and your family with monitoring devices that
provide the utmost in accuracy and convenience.
LifeSource - Designed for Life.

In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991 E-1
TABLE OF CONTENTS
?WHAT DISPLAY SYMBOLS MEAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-2
MONITOR COMPONENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-3
HOW UA-853 WORKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-4
BEFORE YOU START . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-4
SELECTING THE CORRECT CUFF SIZE . . . . . . . . . . . . . . . . . . . . . . . . . .E-5
TAKING YOUR BLOOD PRESSURE. . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-6
WHAT IS AN IRREGULAR HEARTBEAT . . . . . . . . . . . . . . . . . . . . . . . . . E-11
ABOUT CUFF INFLATION METER . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-11
ABOUT AVERAGE READING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-12
ABOUT PRESSURE RATING INDICATOR™ . . . . . . . . . . . . . . . . . . . . . . . E-12
ABOUT MEMORY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-13
USING THE MONITOR WITH AC ADAPTER . . . . . . . . . . . . . . . . . . . . . . E-14
ABOUT BLOOD PRESSURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-15
TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-20
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-21
CONTACT INFORMATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-22
FRENCH INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F-1
SPANISH INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .S-1

E-2 LifeSource Health Line (Toll-Free): 1-888-726-9966
WHAT DISPLAY SYMBOLS MEAN
?
?
Display/
Symbol
Measurement is in progress,
remain as still as possible.
Take measurement again and
consult with your physician.
Replace all batteries with new
ones when the symbol blinks.
Alkaline batteries recommended.
Try the measurement again.
Remain very still during the
measurement.
Fasten the cuff correctly, and try
the measurement again.
Check for air leaks along the
tube and around the air socket.
Refasten the cuff and retake mea-
surement.
Make sure tube is properly con-
nected to cuff and monitor.
Try the measurement again.
Remain very still during the
measurement.
Measurement is in progress,
remain as still as possible.
Refer to the section “About
Pressure Rating Indicator” for
further explanation.
Press AM button once to turn
alarm off.
The symbol shown while measure-
ment is in progress. It blinks while
detecting the pulse.
An irregular heartbeat or body
movement may have occurred.
Refer to page E-11 for more infor-
mation on irregular heartbeats.
Previous measurement stored in
MEMORY.
The battery power indicator during
measurement.
The batteries are low when it
blinks.
Unstable blood pressure due to
excessive body movement.
The systolic and diastolic values are
within 10 mmHg of each other.
The pressure value did not increase
during inflation.
The cuff is not fastened correctly.
There is an air leak in the cuff or
monitor.
The pulse is not detected correctly.
Cuff Inflation Meter
Pressure Rating Indicator™
The alarm is turned on.
Battery Full
Battery Low
PULSE DISPLAY ERROR
Condition/Cause Recommended
Action

In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991 E-3
MONITOR COMPONENTS
Display MEMORY Button
START Button
(Orange illumination during the AM)
(Blue illumination during the PM)
Air Socket
AM Button
PM Button
Air Connector Plug
Air Hose
Arm Cuff
AC Adapter Jack AC Adapter
Battery Compartment Battery Cover
FRONT
BACK

E-4 LifeSource Health Line (Toll-Free): 1-888-726-9966
You must install 4 type AA (1.5 volt) batteries (alkaline batteries
recommended), or use the AC Adapter (see page E-14 for using the Monitor
with AC Adapter) and attach the cuff to the monitor before using it. To install
batteries (or replace them if the “Low Battery” symbol appears on display),
proceed as follows:
1. Remove battery compartment cover by gently
pushing down on arrow and sliding cover forward.
2. Put in bottom row of batteries first. Place the
batteries in compartment with positive (+) and
negative (–) terminals matching those indicated in
the compartment. Be sure batteries make contact
with compartment terminals.
3. Replace cover by sliding it into the compartment and gently pressing into
place.
NOTE: Rechargeable batteries will not work with this monitor.
LifeSource® blood pressure monitors are easy to use, accurate and digitally
display full measurement readouts. Our technology is based on the
“oscillometric method” – a noninvasive blood pressure determination. The
term “oscillation” refers to any measure of vibrations caused by the arterial
pulse. Our monitor examines the pulsatile pressure generated by the arterial
wall as it expands and contracts against the cuff with each heartbeat.
The cuff is inflated until the artery is fully blocked. The inflation speed is
maximized and the pressure level is optimized by the device. The monitor
takes measurements while the cuff is both inflating and deflating. This results
in a faster measurement providing greater comfort to the user.
AM/PM TimeWise™ Technology
This monitor automatically stores each measurement as an AM or PM reading
in memory (note: clock must be properly programmed before initial use).
Healthcare providers agree that understanding your AM and PM readings can
assist in the proper diagnosis and management of your heart health through
lifestyle and/or medication modifications.
HOW UA-853 WORKS
?
BEFORE YOU START
?!
Step 1
Step 2
Step 3

In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991 E-5
Using the correct cuff size is important for an accurate reading. A cuff that is
too large will produce a reading that is lower than the correct blood pressure;
a cuff that is too small will produce a reading that is higher than the correct
blood pressure. With your arm hanging at the side of your body, measure the
circumference of your upper arm at the midpoint between the shoulder and
elbow.
!
SELECTING THE CORRECT CUFF SIZE
ARM SIZE RECOMMENDED CUFF
SIZE REPLACEMENT CUFF MODEL #
9.4" - 14.2" (24 - 36cm) Medium Cuff UA-280
14.2" - 17.7" (36-45cm) Large Cuff UA-281
NOTE: The LifeSource small cuff is not compatible with the UA-853 monitor.
USE SMALL CUFF USE LARGE CUFFPROPER FIT RANGE
INDEX
Cuff Size Indicator On The Cuff
Our cuff has an indicator which tells you whether you are using the correct
cuff size or not. Place the cuff on your arm (see Page E-6 to learn how to put
the cuff on correctly) and if the Index Mark points within the Proper
Fit Range, you are using the correct cuff size. If the Index points outside of the
Proper Fit Range, contact A&D Medical at 1-888-726-9966 (in Canada, call
Auto Control Medical at 1-800-461-0991) for more information on where to
obtain a cuff replacement.
NOTE: If the cuff size indicator falls on a borderline between two size categories,
pick either one and make sure to use the same cuff size for each measurement.

E-6 LifeSource Health Line (Toll-Free): 1-888-726-9966
Adjusting the Built-in Clock
The UA-853 Automatic Blood Pressure Monitor has a built-in clock that gives
you the time and date and can tell you when a blood pressure reading stored
in memory was taken. We recommend that you adjust the clock prior to use.
To adjust the clock, follow these simple steps:
1. Press and hold the AM button until the digits start blinking.
2. Select the year using the PM button.
Press the AM button to set the current year and move to month/day
selection. The date can be set anywhere between the years 2006 and 2056.
3. Select the month using the PM button.
Press the AM button to set the current month and move to day selection.
4. Select the day using the PM button.
Press the AM button to set the current day and move to hour/minute
selection.
5. Select the hour using the PM button.
Press the AM button to set the current hour and move to minute selection.
6. Select the minute using the PM button.
Press the AM button to set the current minute and activate the clock.
7. The Clock is now set.
TAKING YOUR BLOOD PRESSURE

In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991 E-7
Setting the Alarm
This monitor has 3 reminder alarms. You can set 3 different reminder alarms
within a 24-hour period.
1. Press and hold the AM button until the digits
start blinking. Then press the MEMORY
button. “P-1” is shown at the middle line of
the display.
2. Select the hour using the PM button and press
the AM button to set the hour and move to
minute selection. Press the MEMORY button
to complete the reminder setting after selecting
minute.
3. Then the display shows “P-2” and the
symbol for the second reminder. Repeat the above process if you need a
second or third reminder programmed.
4. If you do not want a second or third reminder set, simply press the
MEMORY button until the clock is displayed on the screen.
NOTE: To disable the alarm, simply press the AM button. The symbol will
disappear from the screen.
TAKING YOUR BLOOD PRESSURE
Press and hold
UA-853DIGITALBLOOD PRESSURE MONITOR

E-8 LifeSource Health Line (Toll-Free): 1-888-726-9966
3. Secure cuff around arm. The cuff should be
snug but not too tight. You should be able to
insert two fingers between the cuff and your
arm.
Tips for Blood Pressure Monitoring:

Relax for about 5 minutes before measurement.

Do not smoke or ingest caffeine at least 30 minutes prior to
measurement.

Remove constricting clothing and place cuff on bare arm.

Unless your physician recommends otherwise, use left arm
to measure pressure.

Do not talk during measurement.

Do not cross legs and keep your feet flat on floor during measurement.
TAKING YOUR BLOOD PRESSURE
Now you are ready. Follow these simple steps:
1. Sit comfortably with your left arm resting on a
flat surface so that the center of your upper arm
is at the same height as your heart.
2. Lay left arm on the table, palm up and thread cuff
end through metal loop, smooth size against arm.
Then position the tube off-center toward the inner
side of arm in line with the little finger.
4. Confirm that the Index Mark points within the proper fit range.

In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991 E-9
TAKING YOUR BLOOD PRESSURE
5. Press the START button. As the cuff pressurizes, measurement will begin
and the Cuff Inflation Meter will show on the display screen. It is normal
for the cuff to feel very tight.
Note: If an appropriate pressure is not obtained, the device automatically starts
to inflate again.
Note: If you wish to stop inflation at any time, press the START button again.
6. When the measurement is complete, the systolic and diastolic pressure
readings and pulse rate are displayed. The cuff deflates and the monitor
automatically shuts off after 60 seconds, or you can turn it off by pressing
the START button. Your measurement is automatically stored in memory
(the monitor can store up to 90 readings in memory).
NOTE: If you press the MEMORY button before the auto shut-off, the current
measurement will not be stored into memory.
7. Remove cuff and make note of your blood pressure and pulse rate in the
Blood Pressure Logbook, indicating the date and time of measurement.
IMPORTANT: Measure blood pressure at the same time each day.
SYSTOLIC
DIASTOLIC
PULSE

E-10 LifeSource Health Line (Toll-Free): 1-888-726-9966
Measurement with the desired systolic pressure:
If your systolic pressure is expected to exceed 230 mmHg follow these steps:
1. Place the cuff on the left arm, unless your physician tells you otherwise.
2. Press and hold the START button until a number 30 to 40 mmHg higher
than your expected systolic pressure appears.
3. Release the START button when the desired number is reached. 280
mmHg is the highest pressure level the monitor can reach. Measurement
will then begin. Continue to measure your blood pressure as described on
Page E-8.
TAKING YOUR BLOOD PRESSURE

In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991 E-11
WHAT IS AN IRREGULAR HEARTBEAT
ABOUT CUFF INFLATION METER
The UA-853 Blood Pressure Monitor provides a blood pressure and pulse
rate measurement even when an irregular heartbeat occurs. The Irregular
Heartbeat symbol will appear in the display window in the event an
Irregular Heartbeat has occured during measurement. An irregular heartbeat
is defined as a heartbeat that varies by 25% from the average of all heartbeat
intervals during the blood pressure measurement. It is important that you
relax, remain still and refrain from talking during measurements.
NOTE: We recommend contacting your physician if you see this
symbol frequently.
The Cuff Inflation Meter is located on the left side of the display screen to
tell you when the blood pressure monitor is inflating and deflating the cuff.
The Cuff Inflation Meter moves up during inflation and moves down during
deflation.
Inflation in Progress Inflation Complete Deflation/Measurement in
Progress

E-12 LifeSource Health Line (Toll-Free): 1-888-726-9966
ABOUT AVERAGE READING
The UA-853 provides an average blood pressure reading based
on the total measurements stored in memory. The average
blood pressure reading appears briefly when you recall the
measurements stored in memory. You can also access your
AM/PM Average Readings by pressing the MEMORY button,
then the AM or PM button.
The Pressure Rating Indicator™ is a feature which
provides a snapshot of your blood pressure classification
based on your measurements. This will let you quickly
know what your blood pressure readings mean. Each
segment of the bar indicator corresponds to the
Seventh Report of the Joint National Committee
(JNC7) on Prevention, Evaluation and Treatment of
High Blood Pressure from the National Heart, Lung
and Blood Institute - May 2003. For a more detailed
look at this blood pressure classification, please refer to
“Assessing High Blood Pressure” on page E-16.
:The indicator displays a segment, based on the current measurement,
corresponding to the JNC7 Classification.
NOTE: Due to other risk factors (e.g. diabetes, obesity, smoking, etc.) in
addition to your blood pressure measurement, the Pressure Rating Indicator
is approximate. Please consult with your physician for interpretation and
diagnosis of your blood pressure measurements.
JNC7 Classification Indicator
Stage 2 Hypertension
Stage 1 Hypertension
Prehypertension
Normal
Example
Hypertension
Stage 2
ABOUT PRESSURE RATING INDICATOR™
NUMBER OF MEASUREMENTS STORED IN
MEMORY
AVERAGE

In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991 E-13
NOTE: This device stores the last 90 measurements in memory. The data is
retained as long as the batteries are in the device. When you remove the
batteries or the batteries are drained, the data will be erased.
1. Press the MEMORY button.
2. The average data of all the measurements
and the number of measurements stored
are displayed.
Then, each time the MEMORY button
is pressed, the memory data is displayed
starting from the most recent. After
the last reading is displayed, the display
returns to the clock display.
3. To recall AM/PM readings, press:
MEMORY + AM button
Average of total AM measurements stored is displayed. Each time the AM
button is pressed, the memory data taken during the AM is displayed
starting from the most recent. After the last measurement is displayed, the
display returns to the clock display.
MEMORY + PM button
Average of total PM measurements stored is displayed. Each time the PM
button is pressed, the memory data taken during the PM is displayed
starting from the most recent. After the last measurement is displayed, the
display returns to the clock display.
If the MEMORY button is pressed again, the display returns to the average
data of all the measurements.
Clearing the memory data
4. Press and hold the MEMORY button until the “ ” (memory) mark
blinks to clear the stored data.
ABOUT MEMORY
Press the
MEMORY button
Averaged Systolic
Averaged Diastolic
Number of Readings
Average of all readings

E-14 LifeSource Health Line (Toll-Free): 1-888-726-9966
USING THE MONITOR WITH AC ADAPTER
The UA-853 has an AC adapter jack to allow you to supply power from an
outlet in your home. We recommend you use only the supplied AC adapter to
avoid potential damage to the monitor.
Connecting the AC adapter to the monitor:
1. Gently insert the AC adapter plug into a 120V AC outlet.
2. Connect the AC adapter plug into the jack on the back of the monitor.
Disconnecting the AC adapter from the monitor:
1. Turn the unit off by pressing the START button.
2. Disconnect the plug from the jack of the monitor quickly.
3. Gently remove the AC adapter from the outlet.
NOTE: If monitor has batteries and an AC adapter connected, the measurements
stored in memory will be lost if AC adapter is unplugged from the wall first.To
ensure that measurements remain in memory, make sure the unit is off and
that the jack plugged into the monitor is removed quickly before unplugging
adapter from the wall.
AC Adapter
Plug
Jack

In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991 E-15
What Is Blood Pressure?
Blood pressure is the force exerted by blood against the walls of the arteries.
Systolic pressure occurs when the heart contracts; diastolic pressure occurs
when the heart expands. Blood pressure is measured in millimeters of mercury
(mmHg).
What Affects Blood Pressure?
Blood pressure is affected by many factors: age, weight, time of day, activity
level, climate, altitude and season. Certain activities can significantly alter one’s
blood pressure. Walking can raise systolic pressure by 12 mmHg and diastolic
pressure by 5.5 mmHg. Sleeping can decrease systolic blood pressure by as
much as 10 mmHg. Taking your blood pressure repeatedly without waiting an
interval of 5 minutes between readings, or without raising your arm to allow
blood to flow back to the heart, can also affect it.
In addition to these factors, beverages containing caffeine or alcohol, certain
medications, emotional stress and even tight-fitting clothes can make a
difference in the readings.
What Causes Variations In Blood Pressure?
An individual’s blood pressure varies greatly from day to day and season
to season. For hypersensitive individuals, these variations are even more
pronounced. Normally, blood pressure rises during work or play and falls to its
lowest levels during sleep.
ABOUT BLOOD PRESSURE

E-16 LifeSource Health Line (Toll-Free): 1-888-726-9966
Assessing High Blood Pressure for Adults
The following standards for assessing high blood pressure (without regard to age
or gender) have been established as a guideline. Please note that other risk factors
(e.g. diabetes, obesity, smoking, etc.) need to be taken into consideration and
may affect these figures. Consult with your physician for an accurate assessment.
JNC7 Classification Table – for adults within the U.S.
ABOUT BLOOD PRESSURE
BP Classification Systolic (mmHg) Diastolic (mmHg)
Normal < 120 and < 80
Prehypertension 120-139 or 80-89
Stage 1 Hypertension 140-159 or 90-99
Stage 2 Hypertension
≥ 160 or ≥ 100
SOURCE: The Seventh Report of the Joint National Committee on Prevention,
Evaluation and Treatment of High Blood Pressure for Adults. National Heart,
Lung and Blood Institute - May 2003.
WHO Classification Table - for adults outside of the U.S. (e.g. Canada, Mexico)
BP Classification Systolic (mmHg) Diastolic (mmHg)
Optimal < 120 and < 80
Normal < 130 or < 85
High-Normal 130-139 or 85-89
Stage 1 Hypertension 140-159 or 90-99
Stage 2 Hypertension 160-179 or 100-109
Stage 3 Hypertension
≥ 180 or ≥ 110
SOURCE: Standards to assess high blood pressure, without regard to age or
gender, have been established by the World Health Organization (WHO).

In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991 E-17
What Is Hypertension?
Hypertension (high blood pressure) is the diagnosis given when readings
consistently rise above normal. It is well known that hypertension can lead
to stroke, heart attack or other illness if left untreated. Referred to as a “silent
killer” because it does not always produce symptoms that alert you to the
problem, hypertension is treatable when diagnosed early.
Can Hypertension Be Controlled?
In many individuals, hypertension can be controlled by altering lifestyle and
minimizing stress, and by appropriate medication prescribed and monitored
by your doctor. The American Heart Association recommends the following
lifestyle suggestions to prevent or control hypertension:
Don’t smoke. Have regular physical checkups
Reduce salt and fat intake. Maintain proper weight.
Monitor your blood Exercise routinely.
pressure at periodic intervals.
Why Measure Blood Pressure at Home?
It is now well known that, for many individuals, blood pressure readings
taken in a doctor’s office or hospital setting might be elevated as a result of
apprehension and anxiety. This response is commonly called “white coat
hypertension.” In any case, self-measurement at home supplements your
doctor’s readings and provides a more accurate, complete blood pressure
history. In addition, clinical studies have shown that the detection and
treatment of hypertension is improved when patients both consult their
physicians and monitor their own blood pressure at home.
ABOUT BLOOD PRESSURE
