Lifetime SyncroLight DC08B User manual

Page | 1
DC08B
Low-Voltage DC Light Controller
User Manual
Version 4.1
August 2012
Copyright © 2012 Lifetime Software Ltd

SyncroLight DC08B User Manual
Page | 2
1. Choosing a Power Supply
The controller operates at voltages between 7 and 30 volts DC. All 8 outputs from the
card will produce the same voltage as that used to power the controller. When choosing
a power supply ensure it is of the correct voltage and has sufficient ampere to power all
equipment connected to 8 outputs (when all 8 outputs are on simultaneously).
For Example, if controlling 8 sets of LED lights and each set requires 24v and 600ma. You
will need a 24v power supply of at least 4800ma (600*6 = 4800) or 4.8 amps.
The maximum recommended output is 2 Amps per channel, or 5 Amps per card. Whilst
the components used on the card are rated at 30 Amps, the card has only been designed
and tested for use with low power lighting equipment such as individual sets of LED
lighting. For animated lighting displays using LED lighting, you seldom require high
ampere outputs since it is usual to have lots of individually controllable lights, for
animation purposes, rather than lots of sets wired together on one channel.
2. Building a Network
In order for the computer to be able to control the lights, the controllers and computer need to
be on a RS-485 based network. This is a serial network, capable of reliable transmitting of
data over a distance.
The network starts at the computer, but since computers do not usually have an RS-485
port a converter is required. These can take the form of either:
RS-242 to RS-485 converter (for older computers with serial COM ports).
USB to RS-485 converter.
The recommended USB-RS485 converter, shown below, has been tested with the
SyncroLight controllers and software. The converter is available for sale, with full
installation instructions, on the SyncroLight website.

SyncroLight DC08B User Manual
Page | 3
The network is a 2-wire network, which connects to each controller in a liner multi-drop
arrangement, connecting to each controller in turn. The network should not contain any
spurs or loops.
To ensure reliable data transmission it is often recommended that RS-485 networks are
terminated with a resistor between the two wires. This is optional as in most cases the
network will work fine without any terminating resistor. If you find messages on the
network are being lost (i.e. lights not coming on/ going off as expected), then it may be
worth adding a resistor. The SyncroLight controllers keep a count of the number of
corrupt messages to aid in identification of poor network performance.
We strongly recommend the use of shielded network cable (available on the SyncroLight
website) to minimise interference from electrical cables and equipment. When running
network and power cables around your light display to controllers and lights, try and run
the network cable away from power cables to minimise any risk of electrical interference.
Don’t worry if you have to run the network cables alongside power cables, you’ll
probably be Ok. Just remember where you have done so and revisit this area should you
have any communication problems on the network.
The shielding of each cable should be joined at each controller and connected to the
ground connection provided on the USB-RS485 converter.
Each controller on the network is given a unique numeric address, often called either,
controller address, controller id or device id. This controller address, which has a value
between 1 and 255, is used by the software to identify and address each output on the
network (i.e. Controller Id 3 Channel 1).
New controllers come with a default id of 1, which can easily be changed using the
SyncroLight Device Manager Software.

SyncroLight DC08B User Manual
Page | 4
3. Wiring the Controller

SyncroLight DC08B User Manual
Page | 5
Power
Using a power supply that provides a DC voltage of between 7 and 30 volts, connect the
positive and negative supply to the terminal block as shown in the diagram.
Outputs
The controller has 8 outputs (channels) each of which are individually controllable.
Equipment, such as light strings, should be connected to the controller as follows:
The negative (-) supply to the equipment is connected to one of the 8 outputs of
the card.
The positive (+) wire to the equipment is connected directly to the positive (+)
power supply of the controller. (Separate Terminals are not provided on the card
for the positive (+) supply to the equipment).
Network Connections
We recommend the use of 2-core shielded cable for the network connections. Terminal
connection on the controllers are labelled A and B, outputs of the USB-RS485 converter
are as shown below.
Where the wire colours are red and black, we suggest using the red wire to connect to
the ‘A’ terminals and black wire to connect to the ‘B’ terminals. Adopt your own colour
code if you have different colour wire.

SyncroLight DC08B User Manual
Page | 6
4. Testing and Configuring the Controller
1. Without any network or lights connected, turn on the power to the controller. The
status indicator LED should flash to indicate the controller is running but has no
network connected.
2. Turn off the power to the controller.
3. Connect the controller to the computer via the USB-RS485 converter (or similar RS-
485 interface). If you have multiple controllers, just connect one to the network for
testing.
4. Start the SyncroLight Device Manager Software. The screen should look like the one
below.
5. Select the appropriate Serial Port from the drop down list for your RS-485 network.
6. Ensure the Baud rate is set to 57600 and controller id set to 0.
7. If you have the USB-RS485 converter you can verify that RS-485 network is active
by a little flashing red LED on the USB-RS485 converter.
8. Turn on the power to the controller. The status indicator LED on the controller
should now stay lit to indicate an active network. (The little red LED on the
converter will continue to flash).

SyncroLight DC08B User Manual
Page | 7
9. If you press the ‘Refresh’button on the controller, the controller’s details should
appear on the right of the window as shown below.
Note: Controllers can have an Id between 1 and 255 inclusive. Address 0 is a special
‘broadcast’ id that can be used in the Device Manager, ALL controllers will respond
to this id. This is useful for testing a controller if you have forgotten its id! (Just
ensure only one controller is connected though as all controllers will respond).
10. You can now change the default baud rate and id of the controller using the
controller settings on the right. If you make any changes press ‘Save’ and turn the
controller off and on as directed (Screen below shows the controller id being
changed to 70).

SyncroLight DC08B User Manual
Page | 8
11. You can now connect the lights to your controller and test each channel in turn
using the Device Manager software. Check one of the Channel check boxes on the
left hand side and press the ON button or move the brightness slider up. The lights
connected to channel 1 of your controller should come on. Repeat this to test all 8
channels.
.
