Lifetime 125 Quick start guide

®
04/21/2008
VISIT THE LIFETIME WEB SITE:
WWW.LIFETIME.COM
30” Shed Extension Kit 11’ Sheds
MODEL #0125
ASSEMBLY
INSTRUCTIONS AND
OWNER’S MANUAL
Save this instruction in the event you must contact the manufacturer for replacement parts.
For Assistance, including missing or broken parts,
Call Customer Service at:
1 [phone]
** Do Not Contact the Store **
INSTRUCTION #1036820
Copy

BEFORE BEGINNING ASSEMBLY
Identify and inventory all parts using the checklist boxes on the Parts List. Keep the
hardware bags and their contents separate. If any parts are missing, call our Customer
Service Department.
**A MINIMUM OF TWO ADULTS ARE REQUIRED FOR ASSEMBLY**
SAFETY INSTRUCTIONS
Failure to follow these safety instructions may result in serious injury or property damage. Proper and complete
assembly, use and supervision is essential for proper operation and to reduce the risk of accident or injury. A high probability
of serious injury exists if this display is not installed, maintained, or operated properly. • If using a ladder during assembly,
use extreme caution. Follow all warnings and cautions on the ladder carefully. • 2 people are required for assembly. •
Misuse could result in system failure. • If technical assistance is required, contact the manufacturer.
Most injuries are caused by misuse and/or failure to follow instructions.
PARTS LIST
AA 1028035 Center Roof Cap (1021070)* 1
AB 1019503 Gutter Channel 2
AC 1007977 Wall Support Channel 2
AD 1007988 Truss Channel 1
AE 1007996 Inner Roof Panel (1000496)* 2
AF 1007997 Wall Panel (1000272)* 2
AJ 1008000 Inner Floor Panel (1000463)* 2
AK 1008001 Roof Support Strip 4
AM 1020423 Truss Support Strip 2
Shed Parts Box [1019238]
GA 1010271 1/2” Foam Cube 4
Skylight Hardware Bag [1011616] 1
LA BW01200 #10-1” Fender Washer 7
LB 1010132 #10 x 5/8” Pan Head Screw 7
Truss Extension Hardware Bag [1016014] 1
FA 1009117 Floor Bracket 2
FB 300072 1/4” x 1 1/2” Hex Bolt 11
FC BN00300 1/4” Cap Nut 11
FD 1012933 Center Gutter Connector 1
Shed Screw Hardware Bag [1011615] 1
SS BS07500 1/4” x 5/8” Screw 60
SS
LB
LA
FB
FC
1. 7/16” Wrenches (2)
2. 3/8” Wrenches (2)
3. #2 Phillips screwdriver or
Electric drill with phillips head
Tools and Materials Required for
Assembly
(Not Included)
FA
FD
GA
* The number in Parentheses
indicates the number molded into the
plastic part.

3
AA AE AF
AC
AB
AD
HARDWARE IS NOT ACTUAL SIZE
(unless otherwise indicated)
AJ AK AM
a. This extension kit adds another 30” to the length of your shed. Before beginning expansion of your shed be
sure that your site can accommodate the new size.
Site Selection
If you are Extending an Existing Shed
1. See “Option 2” instructions on page 11. If you have not yet assembled your shed, use the
“Option 1” instructions on the next page.

4
1. Check contents of boxes and compare to parts listed on the Parts List.
2. Follow instructions that came with your shed, but when you come to the following sections of
your Owner’s Manual assemble the additional floor, wall, window and truss parts that are included
in this kit.
Opt. 1.1: Add 30” to the length of your site’s wooden platform (shown) or cement platform; the width will remain
the same. This may require the use of additional lumber or other materials.
Site Selection
16” 14”
Note: Floor studs are all 16” on center with one at 14” on center. Refer to Site Selection & Platform Instructions
in Owner’s Manual.
Option 1: Add Extension Kit During Shed Assembly

5
Assemble Floor
Opt. 1.2: Fit together the two Inner Floor Panel extensions (AJ).
Opt. 1.3: Connect the Inner Floor Panel extensions (AJ) to the other Inner Floor Panels and finish off by
connecting the last two Outer Floor Panels that came with your shed.
AJ
AJ
Note: Refer to the corresponding section in your Owner’s Manual for more specific instructions.

6
Opt. 1.4: Add the two Wall Panel (AF) extensions as you attach the other Wall Panels around the shed.
Assemble Wall (Right or Left)
Assemble Truss Frames
Finger Tighten Hardware
Opt. 1.5: Fit two Truss Support Strips (AM) together. Bolt Truss Support Strips, Center Gutter Connector
(FD) and two Gutter Channels (AB). Refer to the Owner’s Manual that came with your shed when assembling
other truss frames.
AM AM
WARNING
Do not overtighten the Cap Nut. If the end of
the Bolt breaks through the plastic cap, call our
Customer Service Department.
FD
FB
FC
AB
AB
AM
Note: Refer to the corresponding section in your Owner’s Manual for more specific instructions.
Note: Refer to the corresponding section in your Owner’s Manual for more specific instructions.

7
Opt. 1.6: Attach a Gutter Channel (AB) (Truss Support Strips fit inside Gutter Channel). Attach Truss
Channel (AD) to Gutter Channel at each end.
AB
AD
AD
AM (x2)
FB
FC
FB
FC
Tighten All Hardware
Opt. 1.7: Attach Truss Assembly to two Wall Support Channels (AC). Do not completely tighten the Cap Nut
(FC) until after truss is secured to the wall.
AC
FB
FC Use Second
Holes from
the end.
AB
AC
Opt. 1.8: Continue attaching other Truss Assemblies to Wall Support Channels (AC) according to your original
Shed Instructions.
WARNING
Do not overtighten the Cap Nut. If the end of
the Bolt breaks through the plastic cap, call our
Customer Service Department.

8
Opt. 1.10: Attach one Floor Bracket (FA) to each Wall Support Channel (AC) and fasten the Floor Bracket
to the floor. You only need to do this step if you plan to anchor your shed. See the “Anchoring the Shed” step
at the end of your Owner’s Manual.
FC AC
FA
Tighten all Hardware.
WARNING
Do not overtighten the Cap Nut. If the end of
the Bolt breaks through the plastic cap, call our
Customer Service Department.
Install Truss Assemblies
Opt. 1.9: Follow Owner’s Manual instructions to assemble the connect Truss Frames included in this kit to your
shed, along with those that came with your shed.
FB

9
Install Roof Sections
Opt. 1.11: Attach Inner Roof Panels (AE) using Screws (SS) Always start inserting screws at the top of the
Inner Roof Panel. Refer to the Owner’s Manual that came with your original shed.

10
Repeat Step 23 for all four
center roof sections.
Opt. 1.12: Install a Center Roof Cap (AA) with 1/4” x 5/8” Screws (SS) to the Roof Panels.
Attach Roof Cap (AA) to Truss on
both sides with 1/4” x 5/8” Screws
(SS).
Only use a hand
screwdriver for the
Skylights
Note: This is an interior upward
view.
Note: This is an
exterior view.
Only use a hand
screwdriver on this step
Opt. 1.13: Fold End Roof Cap along its hinge. Install it at the front of the shed.
