LIFTINGITALIA InDomo HP Quick guide

LIFTINGITALIA S.r.l.



1(26)
IM.TEC.027.EN_rev.6.3 - February 2022
MAINTENANCE INSTRUCTIONS
example
InDomo HP
Plaorm li
INSTRUCTIONS D’ENTRETIEN

2(26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
6.3 Update p. 7 22.02.2022
6.2 Inseron Lumiere maintenance, update spare parts list 14.06.2018
6.1 Inseron p. 9 - Maintenance in case of counter-ceiling 16.05.2018
6General update and new layout 30.01.2013
5Nomenclature update 26.05.2010
4Detail revision 02.05.2010
Rev. Descripon Date

3(26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
TABLE OF CONTENTS
1. GENERAL REQUIREMENTS AND INSTALLATION SITE MANAGEMENT ............................6
1.1. GENERAL REQUIREMENTS .....................................................................6
2. PRELIMINARY CONTROLS................................................................. 7
2.1. PRELIMINARY SAFETY CHECKS..................................................................7
2.2. PRELIMINARY CHECKS OF THE INSTALLATION SITE.................................................7
2.3. OBLIGATIONS OF THE INSTALLER................................................................7
3. TEST PROCEDURE ....................................................................... 8
3.1. GENERAL INFORMATION ......................................................................8
4. MANINTENANCE TOOLS.................................................................. 9
4.1. OUT OF SERVICE MODE ......................................................................10
4.2. MAINTENANCE OPERATIONS..................................................................10
4.3. IN FRONT OF THE CONTROL BOARD............................................................10
4.4. IN THE PIT ..................................................................................11
4.5. INSIDE THE CAR .............................................................................12
5. USE OF EMERGENCY KEY ................................................................16
6. USE OF THE LANDING DOORS EMERGENCY KEY.............................................23
7. UNBLOCKING AFTER SAFETY DEVICE INTERVENTION ........................................23
7.1. BLOCK VALVE ...............................................................................23
7.2. SAFETY BRAKE ..............................................................................23
8. USE OF EMERGENCY KEY ................................................................24
9. SPARE PARTS LIST ......................................................................24
10. LUMIERE FLOOR DOOR MAINTENANCE - Manual door closer .................................25

4(26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
SCOPO DEL MANUALE
SICUREZZA PERSONALE E RICONOSCIMENTO DEL RISCHIO
RISK SYMBOLOGY AND PHRASES
NOTICE
READ THIS MANUAL CAREFULLY before installing and using the product. This product must
be installed and put into opera on according to the provisions and regula ons in force. Improper
installa on or improper use of the product can cause damage to people and property, as well as
cause the warranty to lapse.
FOLLOW THE SUGGESTIONS AND RECOMMENDATIONS TO OPERATE IN SAFETY.
Any unauthorised modi ca on can compromise the safety of the system, as well as the correct
opera on and the life of the machine. If you have any doubts regarding the correct understanding
of the informa on and contents contained in this manual, contact LIFTING ITALIA S.r.l. immediately.
QUALIFIED PERSONNEL: The product covered by this documenta on can only be installed
by quali ed personnel, in compliance with the a ached technical documenta on, above all in
compliance with the safety warnings and the precau ons contained therein.
Keep the technical and safety documenta on near the li system.
RISK CLASSIFICATION AND RELATIVE GRAVITY OF DAMAGE
DANGER The symbol indicates that the failure to comply with appropriate safety measures
causes death or serious physical injury.
WARNING The symbol indicates that the failure to observe the corresponding safety
measures can cause death or serious personal injury.
CAUTION The symbol indicates that failure to observe the relevant safety measures can
cause minor or moderate personal injury or damage to the device.
NOTICE It is not a symbol of security. It indicates that the failure to comply with relevant
safety measures can result in property damage.
INFORMATION It is not a symbol of security. It indicates important informa on.
This manual contains safety rules that must be observed to safeguard personal safety and to prevent damage to the property.
The indica ons to be followed to guarantee personal safety are highlighted by a triangle symbol while those to avoid material
damage are not preceded by the triangle. The hazard warnings are shown as follows and indicate the diff erent levels of risk in
descending order.
The purpose of this manual is to provide correct informa on on the installa on and correct use of the product, in order to
contribute to personal safety and to the proper func oning of the system. Keep the manual for the en re life of the product. In
the event of a change of ownership, the manual must be provided to the new user as an integral part of the product.
If there are mul ple levels of risk, the danger warning always indicates the highest one. If a warning is drawn with a triangle to
warn to the risk of injury to persons, the risk of possible property damage may also be caused at the same  me.
PURPOSE OF THE MANUAL
PERSONAL SECURITY AND RISK RECOGNITION
NOTE: During installa on / maintenance of the pla orm, the safety func ons are temporarily suspended. Therefore, all
necessary precau ons must be taken to avoid personal injury and / or damage to the product.
RISK LEVEL

5(26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
GUIDA ALLA LETTURA DEL MANUALE
RESPONSABILITÀ E CONDIZIONI DI GARANZIA:
GENERAL DANGER ELECTRICITY DANGER DANGER FLAMMABLE MATERIAL
DANGER OF FALL BY A LEVEL DANGER SUSPENDED LOADS DANGER OF CRUSHING
OBLIGATIORY TO WEAR THE
PROTECTION HELMET
OBLIGATORY TO WEAR SAFETY
SHOES
OBLIGATORY WEAR THE PROTECTIVE
GLOVES
OBLIGATORY TO WEAR EYE
PROTECTION
OBLIGATION TO WEAR THE AUDIO
PROTECTION OBLIGATORY TO WEAR THE MASK
OBLIGATORY TO WEAR PROTECTIVE
CLOTHES OBLIGATORY TO KEEP CLOSED OBLIGATORY TO CHECK THE PROTECTIONS
GENERIC PROHIBITION FORBIDDEN TO STEP ON PROHIBITED TO WALK ON OR STOP
IN THIS AREA
WARNING SIGN
MANDATORY SIGN
PROHIBITION SIGN
EMERGENCY AND FIRST AID SIGNS INDICATION SYMBOLS
RESPONSIBILITY OF THE INSTALLER
The elevator / pla orm is produced and intended to be installed as described in the a ached project drawing
and in this manual; any divergence from the prescribed procedure may aff ect the opera on and safety of the
system and cause the immediate cancella on of the warranty.
Any modi ca on or varia on made to the project and the to the assembly Instruc ons must be documented
in detail and referred to LIFTING ITALIA S.r.l., in order to allow the company an adequate assessment. Under no
circumstances can a modi ed system be ac vated without the express authoriza on of LIFTING ITALIA S.r.l.
Installers are responsible for ensuring compliance with safety procedures at work and any health and safety
regula ons in force in the country and on the site where the assembly is carried out.
The elevator / pla orm must only be used in the way envisaged by the system and illustrated in the rela ve
manuals (transporta on of people and / or things, maximum loads, cycles of use, etc.). LIFTING ITALIA S.r.l.
assumes no responsibility for damage to persons and property caused by improper use of the system.
MANUAL READING GUIDE
LIABILITY AND WARRANTY CONDITIONS:
NOTE WELL KEEP DRY OBLIGATORY TO CHECK
THE PROTECTIONS
FIRST AID
NOTE: Pictures and images on this manual are for illustra on purposes only.

6(26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
2 x
MAX 50 kg
> 50 kg
IMPORTANT!
For more informa on on safety, liability and warranty condi ons, receipt and storage of material
on site, packaging, waste disposal, cleaning and storage of the product; refer to the "SAFETY IN-
STRUCTIONS AND SITE MANAGEMENT" manual.
NOTICE
PRELIMINARY CHECKS: Once the packaging has been opened, check that the product is intact and has not been
damaged during transport. Should any anomalies or damage be found, please dispatch them in wri ng on the transport
document to the transport company, giving wri en no ce to LIFTINGITALIA S.r.l.
CAUTION
SAFETY AND SITE MANAGEMENT - OVERALL DISPOSITIONS:
1. Always secure tools and any objects against falling;
2. Pay the utmost a en on to all the steps described in this;
3. While assembling the parts making up the system or a er installa on, be careful of any sharp burrs (machining
residues);
• Before proceeding with the installa on, it is necessary to remove any rubble and material deposited during the
construc on of the sha .
• Only nuts and bolts included in the supply must be used.
• The bags containing the screws must be opened in correspondence with the respec ve opera ng phases indicated in
this manual.
• The instruc ons described in this manual refer to a reinforced sha , to a fastening with mechanical expansion plugs
of the stud type. For the use of plugs in masonry other than the reinforced concrete see the a achment to this
manual. For the sha s with metal framework, we proceed by replacing the plugs with normal screws.
• In these instruc ons and on the wiring diagram, the stops are indicated with 0, 1, (2, 3 etc.), meaning "0" the lowest stop:
the numbers on the push-bu on panels may be diff erent according to the user's needs (for example - 1, 0, etc.).
The assembly must be
performed by a MINIMUM 2
people;
If the load is greater than 50kg, use the hoist
for handling.
NOTE: In this manual, we will talk about "SHAFT" meaning for it the base slab, the slab of landing and the ver cal wall
that connects its slabs.
1. GENERAL REQUIREMENTS AND INSTALLATION SITE MANAGEMENT
1.1. GENERAL REQUIREMENTS

7(26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
PRELIMINARY SAFETY CHECKS
WARNING
BEFORE STARTING THE INSTALLATION/MAINTENANCE, YOU NEED TO:
• Check that the main electrical system is up to standard and provided with adequate
grounding; 
• Check the presence of an effi cient ligh ng system at the place of installa on;
• Check the cleanliness of the sha area/pit that there are no liquids (water, oil, ...) on the
bo om;
• Check that the entrances to the work areas are properly closed.
• Check that all the holes and the housings for the electric cables are free, inspectable, well
 nished and dry;
• Check that there is adequate ven la on for the smoke exhaust;
BEFORE STARTING THE INSTALLATION, YOU NEED TO:
• Arrange a material deposit area near the work area, easily accessible and protected from
the bad weather.
• Prepare any li ing equipment to be used.
• Check the presence of all materials, using the list.
• Check the state of all materials at the  me of receipt on site and in case of damage or
missing contact the supplier immediately.
• Periodically check the materials des ned for long storage before installa on to avoid
possible deteriora on caused by incorrect storage.
• Check the completeness of the a ached documenta on.
NOTICE
BEFORE STARTING THE INSTALLATION, CHECK THE FOLLOWING MEASURES AND COMPARE THEM WITH
THOSE ON THE PROJECT DRAWING:
• Width (distance between the side walls)
• Depth (distance between front and back wall)
• Base/Pit depth
• Travel
• Headroom height
• Plumbing of the sha and any plumb parts already installed
• Dimensions of any necessary arrangements (breaking down the landing doors, distance between the guides,
• Determine the  nished  oor level of each  oor;
 
measurements taken by the building contractor.
2. PRELIMINARY CONTROLS
2.1. PRELIMINARY SAFETY CHECKS
2.2. PRELIMINARY CHECKS OF THE INSTALLATION SITE
2.3. OBLIGATIONS OF THE INSTALLER

8(26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
3. TEST PROCEDURE
The plaorm li has been designed to reduce the necessity of periodical maintenance.
The safety components have been cered in accordance with the current regulaons. The plaorm li has been cered in accor-
dance with Machine Direcve 2006/42/CE, to guarantee the maximum realibility of the products and the complete user’s safety.
The actual maintenance requirements comprise a periodical check by an authorized Body, to be eected every two years. We
recommend that maintenance operaons be eected to ensure the correct funconing of the li.
The owner of the li is invited to plan and strictly follow the maintenance operaon schedule. Should any irregularity or trouble
occur, the maintenance personnel must be noed immediately.
INFORMATION
As far as the following items are concerned : general instrucons, safety instrucons,
responsibility and warranty, material receiving and storage on site, packing, waste
disposal, cleaning and maintenance, please consult the manual “SAFETY AND MATE-
RIAL HANDLING ON SITE”.
3.1. GENERAL INFORMATION
The stops are indicated as 0, 1, 2, 3, “0” meaning the lowest oor: the COP numbering may be dierent according to the customer’s
needs (example –1, 0, etc.);
The other reference documents are as follows:
• Project drawings referred to the li;
• Electrical schemes an instrucons;
• Hydraulic scheme.
For threaded xings coupling, please respect the below table.
All the screws used for the li assembly, have been ghtened using the parameters stated in the below table.
SCREW COUPLE MAX (Nm) COUPLE MIN (Nm)
M3 1.2 1.0
M4 2.6 2.1
M5 5.1 4.1
M6 9.0 7.0
M8 21.0 17.0
M10 42.0 34.0
M12 71.0 57.0
M16 175.0 145.0
In case of necessity, consult the table.

9(26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
Plaorm or foldable
safety ladder, 5 steps
Phillips
screwdriver
Flat-blade
screwdriver
Socket wrench
5 to 27 mm
Spanner
5 ÷ 27 mm
2 each size
Ratcheng ring spanner
13 to 19 mm
Hammer
Tape measure
Drill
Allen key
with ball end
2,5 to 8 mm
Scissors for
electricians
for Brickwork 6 to 22 mm
Metal 2 to 13 mm
Rubber
hammer
Adjustable
pliers
Portable
lamp
Insulaon tape
Chronometer
Digital Mul-
meter
4. MANINTENANCE TOOLS
NOTICE
The li maintenance operaons must be carried out by qualied personnel, authorized in accordance with the current
legislaon.

10 (26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
4.1. OUT OF SERVICE MODE
The following instrucons describe the out of service procedure.
1. Make sure the car is empty;
2. Bring the car to the lowest oor;
3. Wait for the busy signal to be o;
4. Open all the circuits of the power supply board;
5. Check if all the other landing doors are closed correctly;
6. Arrange the “out of service” boards to be placed on all landings.
On compleon of the above listed operaons, the li can be considered out of service, and cannot be used.
4.2. MAINTENANCE OPERATIONS
The frequency and the descripon of the operaons are stated in the table, paragraph 1.5. The recommended frequency is referred
to the normal use of the li, which means 1200 runs per month; a more frequent use requires a more frequent maintenance. The
commissioning operaons fare listed in the Installaon Manual; these are to be repeated, should there be a me gap of more than
six months between the installaon and the commissioning dates, or should the service be suspended for more than six months.
Should any element need to be replaced, we recommend using original components from the supplier LIFTINGITALIA S.r.l.
The operaons described below are to be eected by qualied personnel only.
The following maintenance areas have been idened:
1. IN FRONT OF THE CONTROL BOARD;
2. IN THE PIT;
3. ON THE PLATFORM (“CAR”).
The following table shows the maintenance areas in connecon with paragraph 1.5.
maintenance area N. of operaon
In front of the control board 2, 6, 7, 10, 11, 12, 13, 14, 15, 16, 17, 19, 20, 27, 28, 30, 31
In the pit 7, 8, 9, 15, 18, 23, 24, 25, 26, 31
Inside the car 1, 2, 3, 4, 5, 7, 8, 9, 16, 21, 22, 23, 24, 25, 26, 29
Make sure that all the safety measures are taken, before starng to work in the maintenance areas.
4.3. IN FRONT OF THE CONTROL BOARD
Several operaons are to be eected in front of the control board under power.
• disable power by means opening the main switch;
• close the main switch only if required, paying aenon to the safety rules to be followed in presence of components under
power.

A
A
11 (26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
* SAFE-PIT = PIT SAFETY
DEVICE
 
CAUTION
DANGER OF CRUSHING - BEFORE ACCESSING THE PIT IT IS MANDATORY:
• Acvate the “pit safety device” (Safe-Pit) as indicated in the following instrucons.
• Open the main switch located in the power supply panel (ref. IM.TEC.026 § 5.6).
• Perform the an-entrapment procedures described in the following instrucons (point 4).
I0021.52.1002_rev.6
RISK OF DAMAGE
TO THE SYSTEM
CUT OFF THE POWER SUPPLY ONLY
WHEN THE PLATFORM HAS REACHED
THE FURTHER DOWN FLOOR
PLATFORM MAIN SWITCH
ENTRANCE FORBIDDEN
WITHOUT AUTHORIZATION
ACTIVATE THE SAFETY DEVICE
FROM OUTSIDE THE SHAFT
BEFORE ENTERING INTO THE PIT
WARNING! CRUSHING
PLATFORM MACHINERY
WARNING! CRUSHING
PLATFORM MACHINERY
BEFORE ENTERING INTO THE PIT
• MAKE SURE THE PLATFORM IS OFF-FLOOR
• OPEN THE ACCESS DOOR WITH THE UNLOCK KEY
• IN CASE OF ELECTRIC LOCK, UNLOCK THE LOCK BOLT USING
THE TIP OF A SCREWDRIVER ON THE WHITE BUTTON AND
CHECK THAT WHEN THE DOOR IS CLOSED, IT DOES NOT LOCK
• PL ACE THE MECHANICAL DEVICE FOR THE SHAFT PIT
SAFETYAND ENABLE IT FROM OUTSIDE
• GO INTO THE PIT ONLY WHEN THE ACOUSTIC SIGNAL IS OFF
WARNING! CRUSHING
1. Bring the car to one of the upper oors, possibly at the minimum height of 2500mm from
the pit boom and in any case OUT OF THE LANDING FLOOR (red led on the door of the
control panel OFF). In this way, the Safe Pit device can be easily enabled;
2. open the landing door using the unblocking key;
3. as soon as the landing door has been unblocked, a light and sound emergency signal will be
enabled, to remind the maintenance operator of the “Safe Pit” device to be acvated;
ulized a special lever;
4. In the event of an electric lock, release the lock bolt pushing the white buon A by using
the p of a screwdriver and CHECK THAT BY CLOSING THE DOOR IT DOES NOT LOCK;
5. USE DEVICES TO KEEP THE LANDING DOOR OPEN;
6. Acvate the “pit boom safety device” by operang it from the outside;
7. should you have trouble when posioning the Safe Pit device, and should the light and
sound signal sll be on, it means that the car is too close to the pit boom. So, close the
landing door, reset the control board and send the car to the upper oor. Get back to
the previous sequence of steps;
8. as soon as the light and sound signal is deacvated, pit access and maintenance
operaons inside are possible;
9. upon the work completed, leave the pit and close the Safe Pit. The light and sound signal
will be acve again unle the device has returned to the resng posion. Close the
landing door and check it is locked o correctly.
10. Make sure all the landing doors are closed and locked o.
11. Reset the control board in order to put the li into operaon.
4.4. IN THE PIT
•

12 (26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
4.5. INSIDE THE CAR
WORKING ON THE BACK SIDE OF THE CONTROL BOARD
The Plaorm li has been designed to guarantee an easy access to the safety brake directly from the car.
Follow the below instrucons:
• with the car staonary at one of the stops, open the Mains Supply Switch, press the STOP buon in car and make sure that the
li cannot be commanded from the control board;
• remove the service panel unscrewing the safety screws;
Hull height COP Half height COP
• put the service panel aside;
Make sure the wires are not pulled during the panel removal.
• eect the necessary operaons on the safety brakes;
• re-posion the service panel and x it with the safety screws;
• unblock the STOP buon in the car, close the Mains Supply Switch and check the correct funconing of the li.

13 (26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
• Remove the xing screws on one side of
the counter-ceiling
• Unhook the safety karabiner
• Completely reverse the counter-ceiling to access
the plaorm roof.
MAINTENANCE IN CASE OF COUNTER-CEILING
ACCESSING THE UPPER PART OF THE LIFT
The Plaorm Li has been designed in order to avoid maintenance operaons on the car roof that is normally not bearing: all
the sensors are xed above the frame, so that the operator can access easy them, by leaning over the car ceiling while wor-
king inside the car. The same thing concerns magnets and overrun switch posioning in the sha. Should the maintenance
require accesing components located on the roof, follow the below instrucons:
• press the STOP buon in the car and make sure that the li cannot be commanded from the control board; the STOP
must be enabled every me the safety mode is to be acvated;
• disable the STOP buon and bring the car to the height of 300mm under the upper landing level. In case of doorless car,
it is an easy operaon, while in presence of car doors, dierent aempts must be made, using COP buons and remai-
ning inside the car;
• in the required posion, press the STOP buon in the car and make sure that the li does not move. Remove the roof lid
unscrewing the two safety screws, and then pushing the away from the COP side. Now, a sound signal will warn that the
headroom spacer must be enabled;

14 (26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
CABIN ROOF ACCESS
1-piece ceiling 3-piece ceiling

15 (26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
The car roof is not bearing. Do not step on the roof, or on the rims.
• put the headroom spacer in vercall posion. The acousc signal will
be disabled, which means that the maintenance in the headroom is
possible;
• lean over the roof, using a safety ladder or plaorm, and eect the necessary maintenance operaons;
Do not step on the roof. It is not bearing.
• to move the car during the maintenance operaons, return inside the car completely, bring the headroom spacer to the resng
posion, close the safety lid completely and unblock the STOP buon in the car;
• Do not force any operaon with the operator leaning over the car roof, descent included.
• Do not force any operaon with the safety lid up – risk of collision (with sha elements) exists.
• on maintenance completed, return inside the car completely, bring
the headroom spacer to the resng posion, close the safety lid com-
pletely and unblock the STOP buon in the car; then check the correct
funconing of the li.
HEADROOM SPACER CLOSED
HEADROOM SPACER OPEN

16 (26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
CAR MOVEMENT AND FLOOR LEVELLING
Check the correct car movement and stops using the related commands.
from the car: try to send the li to each of the stops (both during ascent and descent), che-
cking the correct automac stop, with the maximum dierence in height of 10 mm above
or under the landing level;
in absence of car doors: the li must stop immediately when the car buon is released;
inside the levelling zone the li will stop at the landing level;
from all the landings: try to call the li, checking the correct automac stop and the “busy”
and “present” lights funconing;
make sure that the li cannot be commanded from the COP without the enabling key.
• •
EMERGENCY POWER SUPPLY
Check the eciency of the emergency power supply unit, as far as alarm, car emergency
lighng and forced descent to the lowest oor are concerned.
bring the car to the upper oor;
switch the power o by opening the power supply switch (not the Driving Force one) loca-
ted on the power supply board;
car emergency light will be enabled;
push the alarm buon: the siren will be acvated;
press and hold any call buon: the car will descend and stop at the lowest stop level, then
the door can be opened (sliding doors open automacally).
For baery replacement (baeries inside the control board) follow the below instrucons.
open the Driving Force Switch and enable the control board lighng;
disconnect the baey connectors, trying to avoit shorts;
replace baeries and re-connect the connectors;
close the Driving Force Switch, disable the control board lighng and repeat test operaons
from A. to E.;
dispose of the exhausted baeries bringing them to the authorized points (as special and
dangerous waste).
• •
OPERATION
RECOMMENDED FREQUENCY
1st run every
6 months
every 1/2
year(s)
every
5/10 years
5. USE OF EMERGENCY KEY

1:1
17 (26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved

Check the eciency of all the photocells or light barriers.
WITHOUT car doors:
remain in car and command the ascent;
outside the oor levelling zone, intercept the photocell area; the li will stop unl the
obstacle has been removed and the ascent has been newly commanded;
repeat with each photocell;
repeat inside the oor levelling zone.
WITH car doors:
Intercept the barrier area during the automac closure; the door will re-open.
• •
LOCKS
Check the locks of all the landing doors.
Check the correct opening-closing movement, with and without the emergency key;
Check if the removable bridge on the xed contact, as well as the lock chain in the doorleaf
hole have been assembled properly;
Check the independence between the chain contact and the preliminary half-closing con-
tact.
• •
PISTON SYNCHRONISM
Check if the two stems arrive to the end-of-run simultaneously (car in lower overrun).
• •
MAUAL PUMP - EMERGENCY DESCENT BUTTON
Check the eciency of emergency ascent and descent devices.
open the Driving Force main switch located on the power supply board;
with the car staonary at the lowest stop, acvate the manual pump for some ten cycles;
open the door with the emergency key and check the car liing; close the door
press and hold the red “Emergency descent” buon; check if the descent has taken place.
• •
PISTON SEALS TEST
Check the oil quanty in the recovery bole (500 ml): it does not have to be lled for two
further tests.
• •
OPERATION
RECOMMENDED FREQUENCY
1st run every
6 months
every 1/2
year(s)
every
5/10 years

18 (26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
GUIDE RAIL SHOES
The play of the shoes must be 1-2 mm. Major gaps can be made up for, by means of shoe
bearers adjustment; ortogonal gaps require shoe replacement.
• •
GUIDE RAILS
The guide rails must be lubricated by a mix of oil (grade ≥ 220 cst, EP-free) and grease (50-
50).
The lowest piece must be lubricated from the pit.
• •
OIL LEVEL
Let the air escape from the cylinder. Check if the oil level in the cylinder is above the mini-
mum (or covers the pump completely) when the car is staonary at the upper stop.
For topping up, use ISO VG 46 oils.
•• 1

Check the oil injecon lter of the pump and clean it, if necessary.
•• 1
VALVE HYDRAULIC SEAL
(eseguire la prova con olio a temperatura ambiente).
open the throle of the pressure gauge, close the injecon valve and switch the power o
by opening the Driving Force main switch located on the power supply board;
use the manual pump to bring the dispenser to the nominal pressure;
wait for 5 minutes and check for possible pressure drops;
open the valve, close the throle of the pressure gauge and switch the power on.
•• 1
OVERPRESSURE VALVE
Check if the intervenon pressure does not exceed the standard value (1.4 the maximum
stac pressure).
close the injecon valve and open the throle of the pressure gauge;
command the ascent (ex. from an upper oor);
read the maximum pressure value on the gauge (must be ≤ 63 bar);
open the injecon valve and close the throle of the pressure gauge.
•• 1
OPERATION
RECOMMENDED FREQUENCY
1st run every
6 months
every 1/2
year(s)
every
5/10 years

19 (26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
BLOCK VALVE
Check the block valve acvaon with the car fully loaded and staonary at the upper lan-
ding level.
switch the power by opening the Driving Force main switch located on the power supply
board;
remove the calibraon from the downspeed adjuctment screw (as described in the manual
of the hydraulic unit);
press and hold the red “Discesa di emergenza” emergency descent buon and the central
pin of the EVD valve;
the car will stop;
restore the calibraon of the downspeed adjuctment screw (as described in the manual of
the hydraulic unit).
•• 1
OIL PIPING SEAL
Check for possible oil leakage from dierent components: hose break valve, hydraulic unit,
joints, pipes etc.
Verify the good condion of the hose and the related joints.
•• 1
UPPER OVERRUN
Check the safety contact.
send the empty car to the upper oor;
command the ascent, using the manual pump, unl the acvaon of the overun contact
(make several aempts: the contact is acvated when the li does not react to calls).
•• 1
GROUNDING
Verify the eciency of the grounding and the electrical circuit insulaon, as described in the
electrical scheme.
•• 1
LIGHTING
Check the correct funconing of the lighng systems: in the car, in the sha (if foreseen) and
in the control cabinet.
•• 1
OIL FEATURES
Make sure that the oil has preserved the original features. Every two ears, pick up some oil
from the tank, to check its clearness; replace completely, if needed
• 1
OPERATION
RECOMMENDED FREQUENCY
1st run every
6 months
every 1/2
year(s)
every
5/10 years

2:1
2:1
20 (26)
inDOMO HP - Plaorm li
MAINTENANCE INSTRUCTIONS
IM.TEC.027.EN_rev.6.3 - February 2022 All rights reserved
MAXIMUM STATIC PRESSURE WITH FULL LOAD
Make sure that the working pressure has not been changed (fully loaded car).
bring the car to an upper stop;
open the throle of the pressure gauge;
read the indicated value;
close the throle of the pressure gauge.
•• 2
OVERLOAD
Make sure the operaon mode with overloaded car is disabled.
load the car;
bring the car to the rst stop;
open the landing door and enter the car;
close the door;
make sure that the li does not react to the inner not outer commands.
•• 2
PULLEYS
Eect a complete run and make sure that the pulleys rotate onto the pins.
•• 2
SUSPENSION ROPES
Inspect the ropes and the related joints, to detect the presence of broken, worn out or
oxidised elements.
verify if the rope clamps are well closed, both on the side of the car and on the side of the
sha;
check the uniform tension of the two ropes;
Inspect the ropes, to detect the presence of broken, worn out or oxidised wires. Maximum
10 broken wires are acceptable on a 70mm’s rope length ; the secon may be reduced by
2 mm2 maximum due to wear or abrasion (even in absence of broken wires); corrosion or
oxidaon on ropes and joints are NOT acceptable.
•• 2
OPERATION
RECOMMENDED FREQUENCY
1st run every
6 months
every 1/2
year(s)
every
5/10 years
