LIFTINGITALIA DomoFlex Operating and maintenance instructions
LIFTINGITALIA S.r.l.
1(18)
EN
IM.TEC.074.EN_rev.1.2 - February 2022
example
DomoFlex
Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
2(18)
20220222
IM.TEC.074.EN_rev.1.2 - February 2022 All rights reserved
EN
DomoFlex - Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
1.3 Update p.11 22.02.2022
1.2 General update 10.01.2020
1.1 General update 01.05.2019
1Checks updated, door maintenance added 06.09.2017
Rev. Descripon Date
3(18)
IM.TEC.074.EN_rev.1.2 - February 2022 All rights reserved
EN
DomoFlex - Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
TABLE OF CONTENTS
PURPOSE OF THE MANUAL................................................................................4
PERSONAL SECURITY AND RISK RECOGNITION..............................................................4
MANUAL READING GUIDE ................................................................................5
LIABILITY AND WARRANTY CONDITIONS ...................................................................5
...........................................6
1.1. GENERAL DISPOSITIONS.................................................................................6
.................................................................................7
2.1. PRELIMINARY SAFETY CHEKS ............................................................................7
2.2. PRELIMINARY CHECKS OF THE INSTALLATION SITE.........................................................7
2.3. OBLIGATIONS OF THE INSTALLER .........................................................................7
...............................................8
........................................................................................9
4.1. GENERAL INFORMATION ................................................................................9
4.2. OUT OF SERVICE MODE .................................................................................9
............................................................................10
5.1. IN FRONT OF THE CONTROL BOARD .....................................................................10
5.2. IN THE PIT .............................................................................................11
5.3. INSIDE THE CAR........................................................................................12
5.4. MAINTENANCE OPERATIONS : FREQUENCY AND DESCRIPTION............................................13
.......................................................................16
......................................................................16
..............................................................34
.................................................................................................17
.......................................................................................17
4(18)
IM.TEC.074.EN_rev.1.2 - February 2022 All rights reserved
EN
DomoFlex - Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
SCOPO DEL MANUALE
SICUREZZA PERSONALE E RICONOSCIMENTO DEL RISCHIO
RISK SYMBOLOGY AND PHRASES
NOTICE
READ THIS MANUAL CAREFULLY before installing and using the product. This product must
be installed and put into opera on according to the provisions and regula ons in force. Improper
installa on or improper use of the product can cause damage to people and property, as well as
cause the warranty to lapse.
FOLLOW THE SUGGESTIONS AND RECOMMENDATIONS TO OPERATE IN SAFETY.
Any unauthorised modifi ca on can compromise the safety of the system, as well as the correct
opera on and the life of the machine. If you have any doubts regarding the correct understanding
of the informa on and contents contained in this manual, contact LIFTING ITALIA S.r.l. immediately.
QUALIFIED PERSONNEL: The product covered by this documenta on can only be installed
by qualifi ed personnel, in compliance with the a ached technical documenta on, above all in
compliance with the safety warnings and the precau ons contained therein.
Keep the technical and safety documenta on near the li system.
RISK CLASSIFICATION AND RELATIVE GRAVITY OF DAMAGE
DANGER The symbol indicates that the failure to comply with appropriate safety measures
causes death or serious physical injury.
WARNING The symbol indicates that the failure to observe the corresponding safety
measures can cause death or serious personal injury.
CAUTION The symbol indicates that failure to observe the relevant safety measures can
cause minor or moderate personal injury or damage to the device.
NOTICE It is not a symbol of security. It indicates that the failure to comply with relevant
safety measures can result in property damage.
INFORMATION
This manual contains safety rules that must be observed to safeguard personal safety and to prevent damage to the property.
The indica ons to be followed to guarantee personal safety are highlighted by a triangle symbol while those to avoid material
damage are not preceded by the triangle. The hazard warnings are shown as follows and indicate the diff erent levels of risk in
descending order.
The purpose of this manual is to provide correct informa on on the installa on and correct use of the product, in order to
contribute to personal safety and to the proper func oning of the system. Keep the manual for the en re life of the product. In
the event of a change of ownership, the manual must be provided to the new user as an integral part of the product.
If there are mul ple levels of risk, the danger warning always indicates the highest one. If a warning is drawn with a triangle to
warn to the risk of injury to persons, the risk of possible property damage may also be caused at the same me.
PURPOSE OF THE MANUAL
PERSONAL SECURITY AND RISK RECOGNITION
NOTE:
.
RISK LEVEL
5(18)
IM.TEC.074.EN_rev.1.2 - February 2022 All rights reserved
EN
DomoFlex - Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
GUIDA ALLA LETTURA DEL MANUALE
RESPONSABILITÀ E CONDIZIONI DI GARANZIA:
GENERAL DANGER ELECTRICITY DANGER DANGER FLAMMABLE MATERIAL
DANGER OF FALL BY A LEVEL DANGER SUSPENDED LOADS DANGER OF CRUSHING
OBLIGATIORY TO WEAR THE
PROTECTION HELMET
OBLIGATORY TO WEAR SAFETY
SHOES
OBLIGATORY WEAR THE PROTECTIVE
GLOVES
OBLIGATORY TO WEAR EYE
PROTECTION
OBLIGATION TO WEAR THE AUDIO
PROTECTION OBLIGATORY TO WEAR THE MASK
OBLIGATORY TO WEAR PROTECTIVE
CLOTHES OBLIGATORY TO KEEP CLOSED OBLIGATORY TO CHECK THE
PROTECTIONS
GENERIC PROHIBITION FORBIDDEN TO STEP ON PROHIBITED TO WALK ON OR STOP
IN THIS AREA
WARNING SIGN
MANDATORY SIGN
PROHIBITION SIGN
EMERGENCY AND FIRST AID SIGNS INDICATION SYMBOLS
RESPONSIBILITY OF THE INSTALLER
The elevator / pla orm is produced and intended to be installed as described in the a ached project drawing
and in this manual; any divergence from the prescribed procedure may aff ect the opera on and safety of the
system and cause the immediate cancella on of the warranty.
Any modifi ca on or varia on made to the project and the to the assembly Instruc ons must be documented
in detail and referred to LIFTING ITALIA S.r.l., in order to allow the company an adequate assessment. Under no
circumstances can a modifi ed system be ac vated without the express authoriza on of LIFTING ITALIA S.r.l.
Installers are responsible for ensuring compliance with safety procedures at work and any health and safety
regula ons in force in the country and on the site where the assembly is carried out.
The elevator / pla orm must only be used in the way envisaged by the system and illustrated in the rela ve
manuals (transporta on of people and / or things, maximum loads, cycles of use, etc.). LIFTING ITALIA S.r.l.
assumes no responsibility for damage to persons and property caused by improper use of the system.
MANUAL READING GUIDE
LIABILITY AND WARRANTY CONDITIONS:
NOTE WELL KEEP DRY OBLIGATORY TO CHECK
THE PROTECTIONS
FIRST AID
NOTE:
6(18)
1. DISPOSIZIONI GENERALI E GESTIONE DEL CANTIERE
1.1. DISPOSIZIONI GENERALI
IM.TEC.074.EN_rev.1.2 - February 2022 All rights reserved
EN
DomoFlex - Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
2 x
MAX 50 kg
> 50 kg
IMPORTANT!
SAFETY IN-
STRUCTIONS AND SITE MANAGEMENT
NOTICE
PRELIMINARY CHECKS: Once the packaging has been opened, check that the product is intact and has not been
damaged during transport. Should any anomalies or damage be found, please dispatch them in wri ng on the transport
document to the transport company, giving wri en no ce to LIFTINGITALIA S.r.l.
CAUTION
SAFETY AND SITE MANAGEMENT - OVERALL DISPOSITIONS:
1. Always secure tools and any objects against falling;
2. Pay the utmost a en on to all the steps described in this;
3. While assembling the parts making up the system or a er installa on, be careful of any sharp burrs (machining
residues);
• Before proceeding with the installa on, it is necessary to remove any rubble and material deposited during the
construc on of the sha .
• Only nuts and bolts included in the supply must be used.
• The bags containing the screws must be opened in correspondence with the respec ve opera ng phases indicated in
this manual.
• The instruc ons described in this manual refer to a reinforced sha , to a fastening with mechanical expansion plugs
of the stud type. For the use of plugs in masonry other than the reinforced concrete see the a achment to this
manual. For the sha s with metal framework, we proceed by replacing the plugs with normal screws.
• In these instruc ons and on the wiring diagram, the stops are indicated with 0, 1, (2, 3 etc.), meaning "0" the lowest stop:
the numbers on the push-bu on panels may be diff erent according to the user's needs (for example - 1, 0, etc.).
The assembly must be
performed by a MINIMUM 2
people;
If the load is greater than 50kg, use the hoist
for handling.
NOTE:
that connects its slabs.
GENERAL REQUIREMENTS AND INSTALLATION SITE MANAGEMENT
GENERAL REQUIREMENTS
WARNING
RISK OF ELECTROCUTION:
If they do not meet all the requirements,
7(18)
2. VERIFICHE PRELIMINARI
2.1. VERIFICHE PRELIMINARI DI SICUREZZA
2.2. VERIFICHE PRELIMINARI DEL LUOGO DI INSTALLAZIONE
2.3. OBBLIGHI DELL'INSTALLATORE
IM.TEC.074.EN_rev.1.2 - February 2022 All rights reserved
EN
DomoFlex - Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
PRELIMINARY CONTROLS
PRELIMINARY SAFETY CHECKS
PRELIMINARY CHECKS OF THE INSTALLATION SITE
OBLIGATIONS OF THE INSTALLER
WARNING
BEFORE STARTING THE INSTALLATION/MAINTENANCE, YOU NEED TO:
• Check that the main electrical system is up to standard and provided with adequate
grounding;
• Check the presence of an effi cient ligh ng system at the place of installa on;
• Check the cleanliness of the sha area/pit that there are no liquids (water, oil, ...) on the
bo om;
• Check that the entrances to the work areas are properly closed.
• Check that all the holes and the housings for the electric cables are free, inspectable, well
fi nished and dry;
• Check that there is adequate ven la on for the smoke exhaust;
BEFORE STARTING THE INSTALLATION, YOU NEED TO:
• Arrange a material deposit area near the work area, easily accessible and protected from
the bad weather.
• Prepare any li ing equipment to be used.
• Check the presence of all materials, using the list.
• Check the state of all materials at the me of receipt on site and in case of damage or
missing contact the supplier immediately.
• Periodically check the materials des ned for long storage before installa on to avoid
possible deteriora on caused by incorrect storage.
• Check the completeness of the a ached documenta on.
NOTICE
BEFORE STARTING THE INSTALLATION, CHECK THE FOLLOWING MEASURES AND COMPARE THEM WITH
THOSE ON THE PROJECT DRAWING:
• Width (distance between the side walls)
•
•
• Travel
•
•
•
•
measurements taken by the building contractor.
8(18)
2,5 ÷ 8 mm
13 ÷ 19 mm
6 ÷ 13 mm 6 ÷ 22 mm 2 ÷ 13 mm
5 ÷ 27 mm 5 ÷ 27 mm
3. ATTREZZATURE E MATERIALI NECESSARI PER LA MANUTENZIONE
IM.TEC.074.EN_rev.1.2 - February 2022 All rights reserved
EN
DomoFlex - Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
EQUIPMENT AND MATERIALS REQUIRED FOR MAINTENANCE
TAPE MEASURE
HAMMER
DIGITAL
MULTIMETER
PORTABLE
LAMP
INSULATION
TAPE
RUBBER HAMMER SCISSORS FOR
ELETTRICIANS PLIERS WRENCH
BALL POINT LONG
HEX KEY WRENCH
STEPLESS
RATCHET
SPANNER
SOCKET
WRENCH SPANNER
FLAT BLADE
SCREWDRIVER
PHILIPS
SCREWDRIVER
CORDLESS
SCREWDRIVER DRILL CONCRETE
DRILL BITS
STEE
DRILL BITS
PLATFORM OR FOLDABLE SAFETY
LADDER, 5 STEPS
2X
SIZE
CHRONOMETER
NOTICE
INFORMATION
9(18)
4. VERIFICA DELL’IMPIANTO
4.1. INFORMAZIONI GENERALI
4.2. MESSA FUORI SERVIZIO DELL’IMPIANTO
IM.TEC.074.EN_rev.1.2 - February 2022 All rights reserved
EN
DomoFlex - Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
The plaorm li has been designed to reduce the necessity of periodical maintenance.
The safety components have been cered in accordance with the current regulaons. The plaorm li has been cered in accor-
dance with Machine Direcve 2006/42/CE, to guarantee the maximum realibility of the products and the complete user’s safety.
The actual maintenance requirements comprise a periodical check by an authorized Body, to be eected every two years. We
recommend that maintenance operaons be eected to ensure the correct funconing of the li.
The owner of the li is invited to plan and strictly follow the maintenance operaon schedule. Should any irregularity or trouble
occur, the maintenance personnel must be noed immediately.
a. The stops are indicated as 0, 1, 2, 3, “0” meaning the lowest oor: the COP numbering may be dierent according to the custo-
mer’s needs (example –1, 0, etc.);
b. The other reference documents are as follows:
• Project drawings referred to the li;
• Electrical schemes an instrucons;
• Hydraulic scheme.
c. For threaded xings coupling, please respect the below table.
All the screws used for the li assembly, have been ghtened using the parameters stated in the below table.
SCREW COUPLE MAX (Nm) COUPLE MIN (Nm)
M3 1.2 1.0
M4 2.6 2.1
M5 5.1 4.1
M6 9.0 7.0
M8 21.0 17.0
M10 42.0 34.0
M12 71.0 57.0
M16 175.0 145.0
In case of necessity, consult the table.
TEST PROCEDURE
GENERAL INFORMATION
The following instrucons describe the out of service procedure.
1. Make sure the car is empty;
2. Bring the car to the lowest oor;
3. Wait for the busy signal to be o;
4. Open all the circuits of the power supply board;
5. Check if all the other landing doors are closed correctly;
6. Arrange the “out of service” boards to be placed on all landings.
On compleon of the above listed operaons, the li can be considered out of service, and cannot be used.
OUT OF SERVICE MODE
10 (18)
5. OPERAZIONI DI MANUTENZIONE
5.1. DAVANTI ALL’ARMADIO DI COMANDO
IM.TEC.074.EN_rev.1.2 - February 2022 All rights reserved
EN
DomoFlex - Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
The frequency and the descripon of the operaons are stated in the table, paragraph 5.4. The recommended frequency is referred
to the normal use of the li, which means 1200 runs per month; a more frequent use requires a more frequent maintenance. The
commissioning operaons fare listed in the Installaon Manual; these are to be repeated, should there be a me gap of more than
six months between the installaon and the commissioning dates, or should the service be suspended for more than six months.
Should any element need to be replaced, we recommend using original components from the supplier LIFTINGITALIA S.r.l.
The following maintenance areas have been idened:
1. IN FRONT OF THE CONTROL BOARD;
2. IN THE PIT;
3. ON THE PLATFORM (“CAR”).
The following table shows the maintenance areas in connecon with paragraph 5.4
Maintenance area N. of operaon
In front of the electrical panel 2, 5, 8, 10
In the pit 6, 7, 10, 12, 13, 14
On the plaorm (“car”) 1, 2, 3, 4, 6, 7, 9, 10, 11, 12, 13, 14, 15
Make sure that all the safety measures are taken, before starng to work in the maintenance areas.
NOTICE
IN FRONT OF THE CONTROL BOARD
• disable power by means opening the main switch;
• close the main switch only if required, paying aenon to the safety rules to be followed in presence of components under
power.
WARNING
ELECTRICITY HAZARD:
MAINTENANCE OPERATIONS
11 (18)
A
A
5.2. IN FOSSA
IM.TEC.074.EN_rev.1.2 - February 2022 All rights reserved
EN
DomoFlex - Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
IN THE PIT
* SAFE-PIT = PIT SAFETY
DEVICE
CAUTION
DANGER OF CRUSHING - BEFORE ACCESSING THE PIT IT IS MANDATORY:
•
•
•
I0021.52.1002_rev.6
RISK OF DAMAGE
TO THE SYSTEM
CUT OFF THE POWER SUPPLY ONLY
WHEN THE PLATFORM HAS REACHED
THE FURTHER DOWN FLOOR
PLATFORM MAIN SWITCH
ENTRANCE FORBIDDEN
WITHOUT AUTHORIZATION
ACTIVATE THE SAFETY DEVICE
FROM OUTSIDE THE SHAFT
BEFORE ENTERING INTO THE PIT
WARNING! CRUSHING
PLATFORM MACHINERY
WARNING! CRUSHING
PLATFORM MACHINERY
BEFORE ENTERING INTO THE PIT
• MAKE SURE THE PLATFORM IS OFF-FLOOR
• OPEN THE ACCESS DOOR WITH THE UNLOCK KEY
• IN CASE OF ELECTRIC LOCK, UNLOCK THE LOCK BOLT USING
THE TIP OF A SCREWDRIVER ON THE WHITE BUTTON AND
CHECK THAT WHEN THE DOOR IS CLOSED, IT DOES NOT LOCK
• PL ACE THE MECHANICAL DEVICE FOR THE SHAFT PIT
SAFETYAND ENABLE IT FROM OUTSIDE
• GO INTO THE PIT ONLY WHEN THE ACOUSTIC SIGNAL IS OFF
WARNING! CRUSHING
1. bring the car to one of the upper oors, possibly at the minimum height of 2500mm from
the pit boom and in any case OUT OF THE LANDING FLOOR (red led on the door of the
control panel OFF). In this way, the Safe Pit device can be easily enabled;
2. open the landing door using the unblocking key;
3. as soon as the landing door has been unblocked, a light and sound emergency signal will
be enabled, to remind the maintenance operator of the “Safe Pit” device to be acvated;
ulized a special lever;
4. In the event of an electric lock, release the lock bolt pushing the white buon A by using
the p of a screwdriver and CHECK THAT BY CLOSING THE DOOR IT DOES NOT LOCK;
5. USE DEVICES TO KEEP THE LANDING DOOR OPEN;
6. Acvate the “pit boom safety device” by operang it from the outside;
7. should you have trouble when posioning the Safe Pit device, and should the light and
sound signal sll be on, it means that the car is too close to the pit boom. So, close the
landing door, reset the control board and send the car to the upper oor. Get back to
the previous sequence of steps;
8. as soon as the light and sound signal is deacvated, pit access and maintenance
operaons inside are possible;
9. upon the work completed, leave the pit and close the Safe Pit. The light and sound
signal will be acve again unle the device has returned to the resng posion. Close
the landing door and check it is locked o correctly.
10. Make sure all the landing doors are closed and locked o.
11. Reset the control board in order to put the li into operaon.
12 (18)
5.3. A BORDO DELLA PIATTAFORMA
5.4. VITE DI TRASMISSIONE - VERIFICHE PRELIMINARI E PERIODICHE.
IM.TEC.074.EN_rev.1.2 - February 2022 All rights reserved
EN
DomoFlex - Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
INSIDE THE CAR
TRANSMISSION SCREW - PRELIMINARY AND PERIODIC CHECKS.
The liing plaorm has been designed to ensure an easy access to the drive unit and plaorm shoes.
Follow the below instrucons:
• with the car staonary at one of the stops, open the Mains Supply Switch, press the STOP buon in car and make sure that the
li cannot be commanded from the control board;
• remove the service panel unscrewing the safety screws;
• put the service panel aside;
• eect the necessary operaons on the safety brakes;
• re-posion the service panel and x it with the safety screws;
• unblock the STOP buon in the car, close the Mains Supply Switch and check the correct funconing of the li.
WORKING ON THE BACK SIDE OF THE CONTROL BOARD
WARNING
ELECTRICITY HAZARD:
NOTICE
In case of jointed screws ,
the elastic joint pins
THEY MUST NEVER LEAVE THE
DIAMETER OF THE NUT OF THE
NOTICE
CHECK THE CORRECT LUBRICATION OF THE SCREW
13 (18)
5.5. DESCRIZIONE E PERIODICITÁ DELLE OPERAZIONI DI MANUTENZIONE
IM.TEC.074.EN_rev.1.2 - February 2022 All rights reserved
EN
DomoFlex - Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
1. CAR MOVEMENT
Check the correct car movement and stops using the related commands.
A. from the car: try to send the li to each of the stops (both during ascent and descent),
checking the correct automac stop, with the maximum dierence in height of 10 mm
above or under the landing level;
B. from all the landings: try to call the li, checking the correct automac stop and the “busy”
and “present” lights funconing;
C. make sure that the li cannot be commanded from the COP without the enabling key.
• •
2. EMERGENCY POWER SUPPLY
Check the eciency of the emergency power supply unit, as far as alarm, car emergency
lighng and forced descent to the lowest oor are concerned.
A. bring the car to the upper oor;
B. switch the power o by opening the power supply switch upstream of the electrical panel
(main of the building);
C. car emergency light will be enabled;
D. push the alarm buon: the siren will be acvated;
E. press and hold any call buon: the car will descend and stop at the lowest stop level, then the
door can be opened (sliding doors open automacally).
For baery replacement (baeries inside the control board) follow the below instrucons.
F. open the Driving Force switch;
G. disconnect the baey connectors, trying to avoit shorts;
H. replace baeries and re-connect the connectors;
I. close the Driving Force Switch, disable the control board lighng and repeat test operaons
from A. to E.;
J. dispose of the exhausted baeries bringing them to the authorized points (as special and
dangerous waste).
• •
OPERATION
RECOMMENDED FREQUENCY
1st run every
6 months
every 1/2
year(s)
every
5/10 years
MAINTENANCE OPERATIONS : FREQUENCY AND DESCRIPTION
14 (18)
IM.TEC.074.EN_rev.1.2 - February 2022 All rights reserved
EN
DomoFlex - Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
3. SENSITIVE SAFETY EDGES
Check the eciency of all the sensive safety edges:
A. remain in car and command the ascent;
B. when the plaorm is out of the door zone, acvate the sensive edges, rst on the plaorm
and then on the COP side; the plaorm will stop and remain staonary unl the
obstacle has been removed;
C. repeat with each photocell;
D. repeat inside the door zone.
• •
4. LOCKS
Check the locks of all the landing doors.
A. Check the correct opening-closing movement, with and without the emergency key;
B. Check if the removable bridge on the xed contact, as well as the lock chain in the doorleaf
hole have been assembled properly;
C. Check the independence between the chain contact and the preliminary half-closing contact.
• •
5. EMERGENCY DESCENT HANDLE
Make sure that the manual emergency device works.
A. open the Driving Force main switch located on the Power Supply board;
B. with the plaorm staonary at the upper oor, press the DOWN EMERGENCY buon;
C. open the door using the emergency key and check the plaorm lowering; close the door
• •
6. GUIDE RAIL SHOES
The play of the shoes must be 1-2 mm. Major gaps can be made up for, by means of shoe
bearers adjustment; ortogonal gaps require shoe replacement.
• •
7. GUIDE RAILS
The guide rails must be lubricated by a mix of oil (grade ≥ 220 cst, EP-free) and grease (50-50).
The lowest piece must be lubricated from the pit.
• •
8. TRANSMISSION SCREW
Check the correct lubricaon of the screw. If necessary, lubricate and top up the tray
using the oil suitable for the purpose (for example iso vg-220 ep or higher grade)
• •
9. UPPER OVERRUN
Check the safety contact.
A. send the empty car to the upper oor;
B. acvate the car ascent using the UP buon on the electrical panel, unl the acvaon of the
overun contact (the contact is acvated when the li does not react to calls).
•• 1
OPERATION
RECOMMENDED FREQUENCY
1st run every
6 months
every 1/2
year(s)
every
5/10 years
15 (18)
IM.TEC.074.EN_rev.1.2 - February 2022 All rights reserved
EN
DomoFlex - Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
10. GROUNDING
Verify the eciency of the grounding and the electrical circuit insulaon, as described in the
electrical scheme.
•• 1
11. LIGHTING
Check the correct funconing of the lighng systems: in the car, in the sha (if foreseen) and
in the control cabinet.
•• 1
12. OVERLOAD
Make sure the operaon mode with overloaded car is disabled.
A. load the car;
B. bring the car to the rst stop;
C. open the landing door and enter the car;
D. close the door;
E. make sure that the li does not react to the inner not outer commands.
•• 2
13. ELECTRICAL WIRING
Check the integrity of the lines, either xed and mobile.
•• 2
14. SHAFT CONTACTS
Check the integrity of the following contacts: doorlock block exclusion and oor levelling .
•• 2
15. PLATES - SCHEMES
Verify the presence of the followings schemes and plates:
A. pit plate (danger in case of access, safety devices required;
B. car roof plate (not bearing surface);
C. control board plate (electrical hazard, access forbidden);
D. control board plate (beside the board, emergency procedure);
E. red emergency buon idencaon plate;
F. landing door plate (use reserved to less able people, for public places only);
G. car plate (load, capacity, constructor’s name, emergency descent procedure in case of power
blackout);
H. electrical and hydraulic schemes on the electrical panel (or machine room).
•• 2
16. SPEED - PICKUP - SLOWING DOWN
Make sure the actual parameters match the set values.
•• 2
OPERATION
RECOMMENDED FREQUENCY
1st run every
6 months
every 1/2
year(s)
every
5/10 years
16 (18)
1
1
A
B
6.1. LUMIERE - CHIUDIPORTA MANUALE
6. MANUTENZIONE PORTE DI PIANO
IM.TEC.074.EN_rev.1.2 - February 2022 All rights reserved
EN
DomoFlex - Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
Final Speed
Closing Speed
Final Speed
Closing Speed
· Adjust the force of the end stroke and then the Acceleraon Speed according
to the weight of the door by rotang screw A no greater than 30°÷45°.
· Adjust and periodically check the Closing Speed by rotang screw B no greater
than 30°÷45°.
ADJUSTING THE CLOSING SPEED AND THE FORCE OF THE FINAL STROKE, which
are usually performed using special screws, ARE IMPORTANT, both to adapt perfectly
the acon of the door-closer to the weight of the door on which it is applied, and to
ensure eecve operaon in all seasons. The viscosity of the internal oil actually changes
in relaon to the external temperature.
THEREFORE SUBJECT TO NATURAL SEASONAL VARIATIONS THAT MAY REQUIRE
MINOR PERIODIC ADJUSTMENTS, in order to maintain the eecveness of the
mechanism. The door-closer has 2 dierent adjustments: the closing speed and the force
of the end stroke that is used to overcome the lock latch resistance at the me of closing.
MAX 30° ÷ 45°
LANDING DOORS - MAINTENANCE
LUMIERE - MANUAL DOOR CLOSER
17 (18)
7. PORTE DI PIANO - UTILIZZO DELLA CHIAVE DI EMERGENZA
8. ESECUZIONE DELLE RIPARAZIONI
9. LISTA DELLE PARTI DI RICAMBIO
IM.TEC.074.EN_rev.1.2 - February 2022 All rights reserved
EN
DomoFlex - Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
Opening doors by means of the triangular emergency key may be dangerous. Be extremely careful.
A dierence of height exceeding 30 cm between the car oor and the landing level, may imply a serious risk of falling
inside the sha. Therefore, .
To unblock and open the landing door, rst open the driving force main switch, then insert the safety key in the special hole in the
jamb, then turn the key. Open the door carefully, making sure of the car posirion in respect to the landing.
Upon the operan completed, make sure that all the landing doors are locked and blocked.
The car roof is NOT BEARING. Do not step on the roof nor on its edge.
Usually a damaged frame (especially if the damage was caused by a bending, excessive heat etc.) cannot be replaced. The
damaged parts must be replaced. Only spare parts by LIFTINGITALIA S.r.l. can be used for replacement.
The repair operaons must be carried out by qualied personnel, with the maximum care, to guarantee post repair
eciency.
The following operaons can be carried out directly in place by qualied personnel:
· Sanding down the rust (caused by painng faults) and an-rust layer applicaon;
· Shoes (or parts of shoes) replacement;
· Rope replacement.
Component Q.ty Code
Sliding shoes
Lateral shoes 4F300.05.0002V02
Yoke shoe seals 2F600.05.9057V04
Safety nut 1F352.05.6033
Nut 1F352.05.6031
Trapezial belts 2F352.05.9017
LANDING DOORS - USE OF EMERGENCY KEY
REPAIR
SPARE PARTS LIST
18 (18)
IM.TEC.074.EN_rev.1.2 - February 2022 All rights reserved
EN
DomoFlex - Screw-driven liing plaorm
MAINTENANCE INSTRUCTIONS
Table of contents
Other LIFTINGITALIA Lifting System manuals
Popular Lifting System manuals by other brands
SATA
SATA AE5153EV user manual
MOTORLIJN
MOTORLIJN ML900 manual
Liko
Liko SlingBar Mini 220 Instruction guide
Omega Lift
Omega Lift 28045 Operating instructions & parts manual
AAQ
AAQ AutoLift PP609 Installation manual & operation instructions
Presto
Presto Power Stak PPS2200-62NFO-21 Installation, operation and service manual
