EAE EE62C-35T-E Guide

Model No. EE62C-35T-E / EE62C-42T-E
Two Post Lift
Electrical Release
Lifting Capacity 3500KG/4200KG
Installation, Operation
and Parts Manual
Distributed by
Please read this entire manual carefully and completely before installation or operation of the lift.
DATE: 12/03/2021

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
2
IMPORTANT NOTES
Before start up, connecting and operating EAE products, it is absolutely essential that the operating instructions/owner’s manual
and, in particular the safety instructions are studied carefully. By doing so you can eliminate any uncertainties in handling EAE
products and thus associated safety risks up front; something which is in the interest of you own safety and will ultimately help avoid
damage to the device, When an EAE product is handed over to another person, not only the operating instructions but also the
safety instructions and information on its designated use must be handed over to the person.
By using the product you agree the following conditions:
Copy right
The enclosed instructions are the property of EAE or its supplier, and are protected against duplication and reproduction by
copyright laws, international agreements, and other domestic legislation. The reproduction or disclosure of instructions or an extract
thereof is prohibited and offenders are liable to prosecution; EAE reserves the right or initiates criminal proceedings and asserts
claims for damages in the event of infringements.
Warranty
The use of non-approved hardware will result in a modification of our products and thus to the exclusion of any liability or warranty,
even if such hardware has been removed again in the interim.
It is not permissible to make any changes to our products and these are not only to be used together with genuine accessories and
genuine replacement parts. Otherwise any warranty claims will be invalid.
Liability
The liability of EAE is limit to the amount that the customer has actually paid for this product. This exclusion of liability does not
apply to damages caused through willful misconduct or gross negligence on the part of EAE.
All information in this manual is believed to be correct at time of publication.
EAE reserves the right to amend and alter technical data and composition without prior notice.
Please confirm at time of ordering.

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
3
IMPORTANT NOTES ........................................................................................................................................ 2
SAFETY NOTES................................................................................................................................................ 4
1.1 Operation of lifting platforms................................................................................................................................4
1.2 Checking of the lifting platforms............................................................................................................................4
1.3 Important safety notices ........................................................................................................................................5
1.4 Warning labels .......................................................................................................................................................6
1.5 Potential safety risks ..............................................................................................................................................7
1.6 Noise level..............................................................................................................................................................7
PACKING, STORAGE AND TRANSPORTATION ................................................................................................... 8
2.1 The lift was dismantled into the following 3 parts for transportation ..................................................................8
2.2 Storage...................................................................................................................................................................8
2.3 Lifting and handling ...............................................................................................................................................8
PRODUCTS DESCRIPTIONS............................................................................................................................... 9
3.1 General descriptions ..............................................................................................................................................9
3.2 Construction of the lift ........................................................................................................................................... 9
3.3 Technical data........................................................................................................................................................9
3.4 Dimensions...........................................................................................................................................................10
3.5 Safety devices descriptions ..................................................................................................................................12
INSTALLATION INSTRUCTIONS....................................................................................................................... 13
4.1 Preparations before installation ..........................................................................................................................13
4.2 Installation attentions..........................................................................................................................................13
4.3 General Installation Steps....................................................................................................................................14
4.4 Items to be checked after installation. ................................................................................................................22
OPERATION INSTRUCTIONS .......................................................................................................................... 23
5.1 Precautions ..........................................................................................................................................................23
5.2 Operation instructions .........................................................................................................................................23
TROUBLE SHOOTING..................................................................................................................................... 25
MAINTENANCE............................................................................................................................................. 26
Annex 1, Floor plan ....................................................................................................................................................28
Annex 2, Electrical diagrams and parts list................................................................................................................29
Annex 3, Hydraulic diagrams and parts list ...............................................................................................................33
Annex 4 , Mechanically exploded drawings and parts list......................................................................................... 37

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
4
SAFETY NOTES
1.1 Operation of lifting platforms
This lift is specially designed for lifting motor vehicles. Users are not allowed to use it for any other purposes. The applicable national
regulations, laws and directives must be observed.
Only users aged 18 or above who have been instructed on how to operate the lifting platform and have proven their ability to do so
to the owner are to be entrusted with unsupervised operation of lifting platforms. The task of operating the lifting platforms must be
granted in writing.
Before loading a vehicle onto the lift, users should study the original operation instructions and familiarize themselves with the
operating procedures in several trial runs.
Lift vehicle within the rated load. Don’t attempt to raise vehicles with excessive weight.
1.2 Checking of the lifting platforms
Checks are to be based on the following directives and regulations:
Basic principles for testing lifting platforms
The basic health and safety requirements stipulated in the directive 2006/42/EC
Harmonized European standards
The applicable accident prevention regulations
The checks are to be organized by the user of the lifting platform. The user is responsible for appointing an expert or qualified
person to perform checking. It must be ensure that the person chosen satisfies the requirements.
The user bears special responsibility if employees of the company are appointed as experts or qualified persons.
1.2.1 Scope of checking
Regular checking essentially involves performing a visual inspection and a functional test. This includes checking the condition of the
components and equipment, checking that the safety systems are complete and functioning properly and that the inspection log
book is completely filled in. The scope of exceptional checking depends on the nature and extent of any structural modification or
repair work.
1.2.2 Regular checking
After initial commissioning, lifting platforms are to be checked by a qualified person at intervals of not longer than one year.
A qualified person is somebody with the training and experience required to possess sufficient knowledge of lifting platforms and
who is sufficiently familiar with the pertinent national regulations, accident prevention regulations and generally acknowledged
rules of engineering to be able to assess the safe operating condition of lifting platforms.
1.2.3 Exceptional checking
Lifting platforms with a lift height of more than 2 meters and lifting platforms intended for use with people standing under the load
bearing elements of the load are to be checked by an expert prior or reuse following structural modifications and major repairs to
load bearing components.
An expert is somebody with the training and experience required to possess specialist knowledge of lifting platforms and who is
sufficiently familiar with the pertinent national work safety regulations, accident prevention regulations and generally acknowledged

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
5
rules of engineering to be able to check and give an expert option on lifting platforms.
1.3 Important safety notices
1.3.1 Recommend for indoor use only. DO not expose the lift to rain, snow or excessive moisture.
1.3.2 Only use this lift on a surface that is stable and capable of sustaining the load. Do not install the lift on any asphalt surface.
1.3.3 Read and understand all safety warnings before operating the lift.
1.3.4 Do not leave the controls while the lift is still in motion.
1.3.5 Keep hands and feet away from any moving parts. Keep feet clear of the lift when lowering.
1.3.6 Only these properly trained personnel can operate the lift.
1.3.7 Do not wear unfit clothes such as large clothes with flounces, tires, etc., which could be caught by moving parts of the lift.
1.3.8 To prevent evitable incidents, surrounding areas of the lift must be tidy and with nothing unconcerned.
1.3.9 The lift is simply designed to lift the entire body of vehicles, with its maximum weight within the lifting capacity.
1.3.10 Always insure the safety locks are engaged before any attempt to work near or under the vehicle. Never remove safety related
components from the lift. Do not use if safety related components are damaged or missing.
1.3.11 Do not rock the vehicle while on the lift or remove any heavy component from vehicle that may cause excessive weight shift.
1.3.12 Check at any time the parts of the lift to ensure the agility of moving parts and the performance of synchronization. Ensure
regular maintenance and if anything abnormal occurs, stop using the lift immediately and contact our dealers for help.
1.3.13 Lower the lift to its lowest position and do remember to cut off the power source when service finishes.
1.3.14 Do not modify any parts of the lift without manufacturer’s advice.
1.3.15 If the lift is going to be left unused for a long time, users are required to:
a. Disconnect the power;
b. Empty the oil tank;
c. Lubricate the moving parts with hydraulic oil.
WARNING：The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions and
situations that may occur. It must be understood by the operator that common sense and caution are factors which cannot be
built into this product, but must be supplied by the operator.

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
6
1.4 Warning labels
All safety warning labels are clearly depicted on the lift to ensure that the operator is aware of and avoid the dangers of using the lift
in an incorrect manner. The labels must be kept clean and they have to be replaced if detached or damaged. Please read carefully
the meaning of each label and memories them for future operation.

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
7
1.5 Potential safety risks
1.5.1 Main voltage
Insulation damage and other faults may result in accessible components being live.
Safety measures:
Only ever use the power cord provided or a tested power cord.
Replace wires with damaged insulation.
Do not open the operating unit.
1.5.2 Risk of injury, danger of crushing
In the event of excessive vehicle weight, incorrect mounting of the vehicle or on removing heavy object, there is a
risk of the vehicle falling off or tipping up.
Safety measures:
The lift is only ever to be employed for the intended purpose.
Carefully study and heed all the information given in Section 1.4.
Observe the warning notices for operation.
1.6 Noise level
Noise emitted during operating the lift should be less than 70dB. For your health consideration, it is suggested to place a noise
detector in your working area.

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
8
PACKING, STORAGE AND TRANSPORTATION
Packing, lifting, handling, transporting operations must be performed only by experienced personnel with
appropriate knowledge of the lift and after reading this manual.
2.1 The lift was dismantled into the following 3 parts for transportation
Name
Packed by
Dimension(mm)
Weight (kg)
Quantity
Lift （ 42T ）
Steel brackets
2860*570*770
655
1
Lift （ 35T ）
Steel brackets
2860*570*770
622
1
Extending post
Bubble film
1300*400*250
66
1
Power unit
Carton
850*250*350
24
1
2.2 Storage
The packs must be kept in a covered and protected area in a temperature range 0f -10℃to +40℃. They must not be exposed to
direct sunlight, rain or water.
Stacking the packs
We advise against stacking because the packs are not designed for this type of storage. The narrow base, heavy weight and large size
of the packs make stacking difficult and potentially dangerous.
If stacking is unavoidable, use all appropriate precautions:
-never stack to more than 2 meters in height.
-never make stacks of single packs. Always stack pairs of packs in a cross pattern so that the base is bigger and the resulting stack is
more stable. Once the stack is complete, restrain it using straps, ropes or other suitable methods.
A maximum of two packs can be stacked on lorries, in containers, and in railway wagons, on condition that the packs are strapped
together and restrained to stop them falling.
2.3 Lifting and handling
The packs can be lifted and transported only by using lift trucks. Never attempt to hoist or transport the unit using lifting slings.
Opening the packs
When the lift is delivered make sure that it has not been damaged during transportation and that all the parts specified on the
packing list are present.
Packs must be opened adopting all the precautions required to avoid injury to persons (keep at a safe distance when cutting the
straps) or damage to parts of the machine (be careful that no parts are dropped while you are opening the packing)
Take special care with the hydraulic power unit, the control panel and the cylinder.

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
9
PRODUCTS DESCRIPTIONS
3.1 General descriptions
This is chassis supporting vehicle lift for road vehicles.
It is mainly composed by two posts, two carriages, four swing arms and a power and control unit.
It is driven by an electro-hydraulic system. The gear pump delivers hydraulic oil to oil cylinders and pushes upwards its piston. The
cylinder piston drives to raise the carriage and swing arms. It is equipped with mechanical safety locking unit which ensures no risks
of slipping off in case of hydraulic failure.
3.2 Construction of the lift
3.3 Technical data
Model
Lifting capacity
Full rise
Full rise time
(2.2kW motor )
EE62C-35T-E
3500kg
1900mm
Approx.55S
EE62C-42T-E
4200kg
1900mm
Approx.55S
1.Extending post
2.Hydraulic power unit
3.Control unit
4.Swing arm
5.Crossbeam
6.Pulley assembly
7.Steel cable
8.Hydraulic cylinder
9.Carriage

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
10
3.4 Dimensions
Four pieces of two-stage arm

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
11
Four pieces of three-stage arm
Two pieces of three-stage arm and two pieces of two-stage arm

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
12
3.5 Safety devices descriptions
POS.
Description
Function
1
Steel cable
Ensure sure the synchronization for both carriages
2
Mechanical safety locking unit
Catch the carriages in case of hydraulic failure
3
Limit switch
Stop rising movement at maximum safety height
4
Arm locking unit
Ensure the lifting arms are locked and avoid being swinging during lifting process
5
Lifting pad
Safe rubber contact with the wheel base of lifted vehicle
6
Fender
Protect feet from entering into danger areas that may cause pinching or shearing

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
13
INSTALLATION INSTRUCTIONS
4.1 Preparations before installation
4.1.1 Space requirements.
Indoor installation only. Refer to 3.4 for the dimensions of the lift. There must also be a clearance of at least 1 meter between the
lifting platform and fixed elements (e.g. wall) in all lifting positions. There must be sufficient space for driving vehicles on and off.
4.1.2 Foundations and connections
The user must have the following work performed before erecting the lift.
Construction of the foundation following consultation with the manufacturer’s customer service or an authorized service agent.
Routing of the wiring to the installation location. The user must provide fuse protection for the connection. Electrical system
connection must be done by a qualified electrician. Requirements for power supply cable of the installation site: at least 2.5mm2
wire core for 3Ph power and 4.0mm2 wire core for 1Ph power.
Refer also to the corresponding information on the name plate and in the operation instructions. Before doing electrical
connection, make sure the lift is electrically adapt to the local power supply.
Foundations preparations (see Annex 1, floor plan)
To ensure stability and safety under load, the lift shall be installed with the base frame being in direct and firm contact with the
concrete foundation. Don't attempt to fix the base frame directly onto floor with ceramic and other decorated surfaces otherwise
you put the lift into a very dangerous situation.
C25 concrete foundation with a minimum thickness of 200mm.
Surface under the base plates: Horizontal and even (Gradients max. 0.5 %).
Newly built concrete ground must be older than 20days.
4.1.3 Tools and equipment needed for installation
Tool name
Specification
Qty
Electrical drill
With D16 and D18 drill bit.
1
Open spanner
D17-19mm
2
Adjustable spanner
bigger than D30mm
1
Cross socket screw driver
PH2
1
Quick spanner handle adapter/ Ratchet
REB-310
1
Levelling device
1mm accuracy
1
Hammer
10 pounds
1
Truck lift
Capacity more than1000kg
1
Torque spanner
MD400
1
4.2 Installation attentions
4.2.1 Joints of oil hose and wiring must be firmly connected so as to avoid leakage of oil hose and looseness of electrical wires.
4.2.2 All bolts should be firmly screwed up.

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
14
4.2.3 Do not place any vehicle on the lift in the case of trial running.
4.3 General Installation Steps
ONLY TRAINED AND QUALIFIED INSTALLERS CAN PERFORM LIFT INSTALLATION DUTIES.
Step 1: Remove the packaging, take out the carton for accessories.
Step 2: Firstly, put something supporting between the two posts or suspend one of the posts by a crane and then remove the bolts
from the packing frame.
Attention：Please pay special attention not to let the post fall down for it may cause casualty or bring damages to the accessories
fixed in the post.
Step 3: When the first post has been taken away, place something supporter under the second post and then remove the bolts
from the packing frame.
Step 4: Connect extending posts and cross beams
1. Firstly have the extending post firmly secured on to the body posts. This is only necessary when your lift is ordered with extending
posts

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
15
2. Connect the beams and fix the roof protection bumper
Step 5: Fix the standing position for the two posts. (See Annex 1, floor plan)
1. Unfold the package and decide on which post the power unit will be mounted.
2. Draw an outline of the base plate on the ground with chalk and ascertain the position for the post.
Step 6: Connect cross beam.
Make the posts face to each other and the distance between the posts equals to the length of the overhead crossbeam. Fix the beam
to the posts by screw M12×30
Step 7: Erect and secure the post.
1. Make the posts face to each other and the distance between the posts equals to the length of the base plate. Use proper means to
erect the post.
2. Use suitable means to raise the lifting carriage to the first latching position. All the mounting holes in the base plate are then
accessible. Make sure the locking pawl is engaged.
3. Check and align the position of the base plates again.
4. Drill the mounting holes. Remove the drilling dust from the hole.
5. Use a spirit level to check the vertical alignment of the posts. If necessary, place equalizing plates under the base plates.
6. Tighten the nuts. Torque: 80-100Nm.
1.Self-locking nut M6
2.Hex socket cylinder screw M6*35
3.Hex head screw M14*35
4.Flat washer M14
5.Spring washer M14
6.Hex nut M14
7.Car roof protective rod
1.Hex head screw M12*30
2.Spring washer M12
3.Flat washer M12

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
16
Anchoring bolt
A1
(foundation thickness )
A2
(drilling depth)
A3
(anchoring depth)
B
C
M18x160
≥200mm
130mm
105mm
240mm
≤55mm
Step 8: Install the mechanical locking unit.
Fix four safety locking plates and electromagnets with two of them on each post.
A.
Nut
B.
Expansion anchoring bolt
C.
Equalizing plate
1.Orientation block
2.Safety locking plate
3.Electromagnet
4.Cross socket cap head screw M6*12
5.Cross socket cap head screw M6*16
Safety locking plates
Electromagnet

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
17
Step 9: Connect steel cables.
1. Route and fix according to the following diagram of steel cable connection.
2. Use suitable means to raise carriages at both sides to the first latching point. Ensure the both carriages are locked.
3. After the cable being fixed, adjust and make the cables at both sides be with the same tightness. (This could be judged by the
sound caused by mechanical safety locking system during lifting process.)
4. Grease with NO.1 lithium grease (It is a must.)
Step 10: Install the hydraulic system.
Attention: Do not contaminate the hydraulic system when do the connection.
1. Mount the power unit onto the power side post.
1.Hex hut M10
2.Spring washer M10
3.Flat washer M10
4.Anti-shock pad
5.Hex head full swivel screw M10*35

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
18
2. Connect oil hoses according to the following diagram.
Don’t let any solid substance go into the hydraulic line.
Ensure the connectors are screwed tight against leakage.
Step 11: Install the electrical system.
Refer to electrical connection diagram before making the connection.
Attention: electrical system connection must be done by qualified electricians. .
1. Mount the control box on to the power side post.
1.control box
2.hex socket screw M6*15
3.post

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
19
2. Fix the limit switch onto the inside surface of the power side post.
Connect the wire of limit switch with the terminals reserved in the control box.
3.Connect the limit switch fixed at the cross beam.
4. Connect quick connectors between electromagnets.
1.Cross socket flat head screw M5*10
2.Limit switch TZ8108
1.Cross socket flat head screw M4*25
2.Limit switch D4MC1000
Adjustable bolt
Quick connector

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
20
5. Connect the solenoid valve wire and motor wire.
Step 12: Install lifting arms.
Connect the lifting arm and the carriage. The arm pin shafts must be greased at the installation Ensure the arm lock can engage and
release effectively. .
Attention: Install Lifting arms and fix feet protection bars ONLY after the complete assembly has been erected and anchored.
Step 13: Fill with hydraulic oil.
CLEAN AND FRESH OIL ONLY. DON’T FILL THE TANK COMPLETELY FULL.
Lift must be fully lowered before changing or adding hydraulic oil
Prepare 10 liters of anti-abrasion hydraulic oil. The level of oil shall reach the tippets volume mark of the tank.
Add more oil after running the lift for several cycles until the lift can rise to the maximum lifting height.
It is suggested to use HM NO.46 hydraulic oil. When average temperature of the location is below 10℃, use HM NO.32 hydraulic oil.
Change the oil 6 months after initial use and change once per year thereafter.
1.Power unit
2.Motor wire
3.Solenoid valve wire
4.Control box
5.Power supply wire
1.Pulling rod
2.Arm locking unit
1.Pin shaft
2.Long arm
3.Short arm
