LiftSmart MLI Quick start guide

MLI PARTS & SERVICE MANUAL
Part No. M00971F
Printed in the USA

MLI Industrial Pro Series
Part Number M00971F
Parts & Service Manual
Copyright © 2022 LiftSmart
MLI INDUSTRIAL PRO SERIES MATERIAL LIFT
It is the responsibility of the user to read, understand and obey all safety rules before attempting to perform
maintenance on this equipment. This includes all rules and instructions set forth by the manufacturer, as well
as any local laws and regulations governing the safe use of this equipment.
It is strongly recommended that only trained and authorized personnel perform maintenance on this material
lift.
This manual is intended to be used in conjunction with the MLI Industrial Pro Series Operator’s Manual.
Failure to read, understand, and obey all safety rules in both manuals, and all safety decals/placards
attached to the material lift, may result in serious injury or death.
LiftSmart is dedicated to the continuous improvement of this and all LiftSmart products. Therefore, technical
information contained in this manual is subject to change without notice. Direct any questions regarding
errors or discrepancies in this manual to LiftSmart.
CONTACT US
LiftSmart
1370 Decision Street
Suite A
Vista, CA 92081
Mailing Address:
P.O. Box 4186
Oceanside, CA 92052-4186
Phone/Fax: [phone]
www.liftsmart.NET
[e-mail]
LiftSmart products are protected by US Patent No. 9,388,028 and other patents pending.

MLI Industrial Pro Series
Part Number M00971F
Parts & Service Manual
Copyright © 2022 LiftSmart
1
CONTENTS
1 - SAFETY
2
5 - PARTS (continued)
Personal & Maintenance Safety
3
Mast Assembly (I) - First Mast Assembly
40
Mast Assembly (II) - Center Mast Assembly
2 - INSPECTIONS
4
2011 –2012 Models
44
Daily Inspections
4
2013 - Current Models
46
Visual Inspection
5
Mast Assembly (III) - Front Mast & Carriage
Function Test
5
2011 –2012 Models
48
Quarterly Inspections
6
2013 - Current Models
50
Cleaning the Masts
7
Back of the Mast Assembly
52
Inspecting the Winch
7
Winch Assembly
54
Lubricating the Winch
7
Smart-Latch™ Option
56
Annual Inspections
8
CE Mast Brake (Current Models)
58
Inspecting the Mast Assembly
9
CE Mast Brake (First Generation)
60
Inspecting the CE Mast Brake System
10
Standard Fork Assembly
62
Adjustable Fork Assembly
62
3 - TROUBLESHOOTING
12
Adjustable Flat Fork Assembly
62
Boom Assembly
64
4 - REPAIR
14
Load Platform Accessory
64
Removing the Base
15
Pipe Cradle Accessory
66
Disassembling the Mast
17
Fork Extensions Accessory
66
Assembling the Mast
18
Manual Storage Tube Assembly
66
Replacing a Pulley
20
Cable Assemblies
67
Replacing a Pulley Mount
21
Cable Guard Option
68
Replacing the Cable
22
Retractable Lifting Point Option
68
Replacing the Transport Wheel Option
24
Replacing the Hold Down Bar
24
APPENDIX A: Machine Specifications
69
Assembling the Hold Down Bar
24
APPENDIX B: Torque Specifications
71
5 - PARTS
25
Decals - ANSI
26
APPENDIX C: Inspection Checklist
73
Decals - CE
28
Standard Base and Stabilizers
30
Straddle Base
32
Leg Assembly
34
Load Slider Pad Assembly
36
Transport Wheel Assembly Option
38

MLI Industrial Pro Series
Part Number M00971F
Parts & Service Manual
Copyright © 2022 LiftSmart
1. SAFETY
Failure to follow all safety rules in this manual, in addition to the MLI Industrial Pro Series Operator’s Manual,
and all safety decals/placards attached to the material lift may result in serious injury or death.
Proper training is strongly recommended before attempting to perform maintenance on any mechanical
device.
Before performing maintenance:
❑Read, understand, and obeyall safety rules and instructions in this manual,in addition to the MLI Industrial
Pro Series Operator’s Manual,and all safety decals/placards attached to the material lift.
❑Read and understand warning symbols found in this manual and in the workplace.
❑Obtain, read, and obey all applicable government regulations.
❑Become familiar with the proper operation of the material lift.
❑Technicians should receive instruction before performing maintenance on the material lift.

MLI Industrial Pro Series
Part Number M00971F
Parts & Service Manual
Copyright © 2022 LiftSmart
3
PERSONAL SAFETY
Safetyand continued safe operationof the material
lift should be your highest priority.
Follow these safety rules while operating or
performing maintenance on the material lift:
ALWAYS:
❑Wear personal protective equipment
(PPE), including protective eyewear,
gloves, and steel-toed shoes.
❑Be aware of potential hazards created by
removing components from the material lift
or by lifting or placing loads.
❑Understand and obey all the safety rules
and warnings found in the workplace.
MAINTENANCE SAFETY
Follow these safety rules while performing
maintenance on the material lift:
ALWAYS:
❑Read each procedure carefully before
beginning maintenance on the material lift.
❑Read, understand, and obey the safety
rules described in the MLI Industrial Pro
Operator’s Manual.
❑Choose a work area that is clean, well-lit,
and properly ventilated.
❑Keep sparks and open flames away from
flammable materials such as grease or oil.
❑Tag a damaged material lift and
immediately remove it from service until
repairs are completed according to the
manufacturer’s specifications.
❑Be aware of potential hazards created by
removing components of the material lift
while performing maintenance.
❑Use only the correct tools for the
maintenance procedure.
❑Ensure tools required to perform needed
maintenance are in good working
condition.
Safety alert symbol –used to alert
personnel to potential injury
hazards. Obey all safety messages
that follow this symbol to avoid
possible death or serious injury.
Indicates an imminent hazardous
situation which, if not avoided, will
result in serious injury or death.
Indicates a potentially hazardous
situation which, if not avoided, will
result in serious injury or death.
Indicates a potentially hazardous
situation which, if not avoided, may
cause minor or moderate injury.
Indicates a potentially hazardous
situation which, if not avoided, will
result in machine or property
damage.
Decal/Placard Symbol Legend

Parts & Service Manual
Part Number M00971F
MLI Industrial Pro Series
4
Copyright © 2022 LiftSmart
2. INSPECTIONS
Regular inspection of the material lift will ensure that the equipment is operating safely and effectively.
Performing all preventive/predictive maintenance procedures according to the manufacturer’s
recommendations will extend the life of the material lift and help to ensure safe operation for machine
operators.
While inspecting the equipment:
•Perform all daily, quarterly and/or annual
inspections according to the
manufacturer’s recommendations.
•Perform all quarterly and/or annual
preventive/predictive maintenance
procedures according to the
manufacturer’s recommendations.
•Create a record of all inspections and/or
maintenance performed using the
Scheduled Maintenance and Inspection
Checklist provided in the back of this
manual.
DAILY INSPECTIONS
Perform each of the following inspections daily or
before each use of the material lift:
❑Verify that the MLI Industrial Pro Series
Operator’s Manual is in the storage
container attached to the material lift. The
pages must be legible and in good
condition.
❑Perform a visual inspection of the material
lift for wear or damage.
❑Perform a function test on the material lift
to verify winch is operating correctly, holds
a load, and that the Fork Carriage and
masts raise and lower in the correct
sequence.

MLI Industrial Pro Series
Part Number M00971F
Parts & Service Manual
Copyright © 2022 LiftSmart
5
VISUAL INSPECTION
Perform the following inspections daily or before
each use:
❑Inspect the wheels and casters for excessive
wear or damage.
❑Inspect the material lift for loose, damaged, or
missing fasteners.
❑Inspect the base, legs, stabilizers, masts,
pulleys, and forks for damage and improperly
installed or missing components.
❑Inspect the cable for wear, frays, kinks, or
damage.
❑Verify that the cable is wrapped around the
winch drum at least four times when the Fork
Carriage is fully lowered.
❑Inspect the entire material lift for dents,
damage, excessive rust or corrosion, and
cracks in welds or on structurally critical
components, such as the aluminum masts.
❑Verify that all decals are legible and correctly
attached to the material lift.
WARNING
If any worn or damaged components are
observed or suspected, remove the material lift
from service immediately. Repairs to the
material lift should only be performed by
authorized personnel according to the
manufacturer’s specifications.
FUNCTION TEST
(2-Speed Winch Models)
Perform the following test daily or before each use
to verify that the equipment is not malfunctioning:
❑Shift the winch to the low speed.
❑Firmly grasp both winch handles.
❑Rotate the winch handles toward the mast to
raise the Fork Carriage to its full height.
The winch should operate smoothly without
hesitation or binding. The motion should raise the
Fork Carriage to the top of the Front Mast followed
in order by each adjacent mast.
❑Rotate the winch handles away from the mast
to completely lower the telescopic mast
assembly.
❑Rotate the winch handles one quarter-turn
toward the mast - as if raising the Fork Carriage
- to set the brake
The winch should operate smoothly without
hesitation or binding. Shift the winch to the high
speed and repeat steps above to complete test.
Notice: The handle rotations listed above are
opposite for models equipped with the 1-Speed
Winch.
WARNING
If the equipment malfunctions, remove the
material lift from service immediately. Repairs
to the material lift should only be performed by
authorized personnel according to the
manufacturer’s specifications.

Parts & Service Manual
Part Number M00971F
MLI Industrial Pro Series
6
Copyright © 2022 LiftSmart
QUARTERLY INSPECTIONS
Perform the following inspections quarterly or after every 100 hours of operation. Perform these inspections
in addition to all daily inspections:
NOTE:It is important to perform all the inspections listed to ensure the material lift can be used correctly and
safely. Failure to perform the inspections listed may result in injury or death.
❑Visually inspect the welds for cracks, excessive wear, or corrosion.
❑Inspect the welds on:
▪Fork and other load lifting attachment(s)
▪Base
▪Legs
▪Stabilizers
▪Transport Wheel Option (if equipped)
▪Winch mounting plate
▪Smart-Set adjustment system
❑Clean the masts.
❑Inspect the winch.
❑Lubricate the winch.

MLI Industrial Pro Series
Part Number M00971F
Parts & Service Manual
Copyright © 2022 LiftSmart
7
CLEANING THE MASTS
LiftSmart requires that this procedure be performed
every 200 hours or quarterly, whichever comes
first.
Perform the following steps to clean the masts:
❑Raise the material lift to its maximum height.
❑Visually inspect the inner and outer roller wheel
channels of each mast for foreign material or
debris.
❑As needed, clean the channels of each mast
using a mild cleansing agent.
When cleaning the masts, NEVER:
❑Lubricate the masts.
❑Apply an additional side load or horizontalforce
to a material lift that is loaded and/or raised.
❑Place ladders or scaffold against the material
lift.
INSPECTING THE WINCH
(Refer to winch diagram in Section 5 - Parts)
❑Raise the Fork Carriage halfway to ensure the
winch is operating correctly.
Result: The winch should operate smoothly.
❑Lower the Fork Carriage.
Result: The winch should operate smoothly.
If winch is not operating properly, perform the
following inspections on the winch:
❑Inspect the brake lining plates for excessive
wear.
▪Replace the brake lining plate if it is less
than 1/16 inch (1.5 mm) thick.
❑Inspect the reamed bushings on the shaft for
excessive wear.
▪Replace the reamed bushing if the wall
thickness is less than 1/8 inch (3.1 mm).
❑Inspect the winch assembly for loose,
damaged, or missing fasteners.
▪Tighten or replace fasteners as needed.
▪Tighten the 3/8-16 lock nut that attaches
the reel assembly to 20 ft-lb (27 N*m).
▪Do not over tighten fasteners.
LUBRICATING THE WINCH
Lubricate the gears on the following components of
the winch using automotive grease:
❑The reel assembly.
❑The ratchet wheel.
❑The primary shaft assembly.
❑The intermediate shaft assembly (2-speed
winch models).
ADDITIONAL WINCH LUBRICATION
Lubricate the following winch components with the
lubricant listed:
❑Lubricate the ratchet pawls with 30W oil.
❑Lubricate the reel spacer with automotive
grease.
Injury hazard. This procedure may
require the use of additional access
equipment. Do not place ladders or
scaffolding against the machine.
Performing this procedure without
the proper skills and tools may
result in serious injury or death.
Dealer service is recommended.

Parts & Service Manual
Part Number M00971F
MLI Industrial Pro Series
8
Copyright © 2022 LiftSmart
ANNUAL INSPECTIONS
Lubricate the Casters and Wheels.
Perform the following inspections annually.
Perform these inspections in addition to all daily
and quarterly inspections.
It is important to lubricate casters and/or wheels for
a proper use of the product and to extend its
service life.
❑Inspect the wheels and casters for cracks or
cuts and excessive wear.
❑Lubricate the casters and wheels:
•Using the Zerk fittings, add lithium-based
grease into the bearings of the wheels
and casters until it becomes visible at the
bearing gap.
❑On a level surface, push and steer the
material lift to make sure casters and wheels
roll effortlessly.
Inspect the Painted Surfaces
A visual inspection of the painted areas will assist
in recognizing potentially damaged areas of the
material lift, which will need to be corrected for the
continued safe use of the machine.
❑Visually inspect the painted surfaces of the
material lift for blisters, peeling, rust, fading or
corrosion.
Inspect the Hold Down Bar
Unsafe work areas occur when damage to the MLI
Industrial Pro Series is not discovered.
❑Visually inspect the Fork Carriage and Hold
Down Bar.
❑Check if the Hold Down Bar is operating
correctly.
NOTE: The Hold Down Bar is operating correctly
when it does NOT overstroke the top of the Fork
Carriage and when it prevents the telescopic
mast assembly from extending when the mast is
parallel to the ground.
Inspect the Pulleys, and Cable
This inspection should happen at least annually.
Failure to check the sub-components of the
material lift can lead to serious injuries or even
death.
NOTE: Due to visual obstructions the mastmust be
disassembled to properly and fully inspect the mast
rollers, pulleys, and cable.
1. Disassemble the Mast (refer to related
information in Section 4 of this manual).
2. Inspect the Cable, Pulleys, and related sub-
components and look for the following issues:
▪Kink(s) in the cable.
▪Broken wires.
▪Corrosion.
▪Cracks in the swaged cable end.
▪Damaged pulleys and pulley mounts.
▪Mounting plates are firmly secured.
3. Inspect Mast Rollers (refer to related
information in Section 4 of this manual).
NOTE: If something abnormal or damage is
located during the inspection, remove the
Material Lift from the workplace immediately.
4. Re-assemble the Mast (refer to related
information in Section 4 of this manual).
