Garage Smart MY LIFTER BASIC LIFTER User manual

BASIC LIFTER

3
4
5
6
7
8
9
11
16
20
22
23
31
TABLE OF CONTENTS
LIMITED LIFETIME WARRANTY
SAFETY INFORMATION
WA R N I NG
ABOUT THE BASIC LIFTER
INSTALLATION GUIDE
REQUIRED TOOLS
PARTS IDENTIFIER
INSTALLATION
MOUNTING BRACKET
POWER ADAPTER
EYELET SCREW
HOOK & PULLEY
APP GUIDE
FAQS

LIMITED LIFETIME WARRANTY
Limited Lifetime Warranty
Garage Smart offers a Limited Lifetime
Warranty on all products. If a defect in the
hardware, or any component thereof, occurs
Garage Smart will repair or replace the system,
or the defective component. There is no cost
to you beyond the cost of shipping the
defective item to us. If your Garage Smart
Product is defective, we will send replacement
parts or, at our option, replace it at no charge
to you after the defective product is returned
to Garage Smart. If we send replacement parts
for your Garage Smart Product, we may use
new or reconditioned parts. If we choose to
replace your Garage Smart Product, we may
replace it with a new or reconditioned one of
the same or similar design.
Who Makes This Warranty
Garage Smart
Who Is Covered
This warranty extends only to the original
purchaser of the product. This warranty is
intended for natural persons only and does not
extend to any corporation, limited liability
company, or commercial entity.
What Is Covered
Any defect in material and workmanship from
personal, normal household use in accordance
with the Owner’s Manual.
Warranty Does Not Cover: This warranty does
not cover installation commercial use, defects
resulting from accidents, damage while in
transit to our service location or
damage resulting from altercations misuses or
abuse, lack of proper maintenance,
unauthorized repair or modifications of the
product, affixing of any attachment not
any such use voids the warranty.
TO THE GREATEST EXTENT PERMITTED
BY LAW, THIS WARRANTY IS IN LIEU OF
AND EXCLUDES ALL OTHER
WARRANTIES NOT EXPRESSLY SET
FORTH HEREIN, WHETHER EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED
TO ANY WARRANTIES OF MERCHANT
ABILITY AND FINESS FOR A PARTICULAR
PURPOSE. Limitation of Liability: THE
SOLE REMEDIES AFFORDED UNDER THIS
WARRANTYARE REPAIR, REPLACEMENT,
OR, IF REPAIR OR REPLACEMENT IS NOT
COMMERCIALLY PRACTICABLE OR
CANNOT BE TIMELY MADE, A REFUND
OF THE PURCHASE PRICE. IN NO EVENT
SHALL THE LIABILITY OF GARAGE
SMART RELATED TO ANY PRODUCT
EXCEED THE PURCHASE PRICE OF THE
PRODUCT. YOUR USE OF GARAGE
SMART PRODUCTS IS AT YOUR SOLE
RISK. GARAGE SMART SHALL NOT BE
LIABLE UNDER ANY CIRCUMSTANCES
FOR CONSEQUENTIAL, INDIRECT,
SPECIAL, OR INCIDENTAL 42 DAMAGES
ARISING FROM OR IN CONNECTION
WITH THE USE OF ANY GARAGE SMART
PRODUCT. (SOME STATES DO NOT
ALLOW THE EXCLUSION OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION
OR EXCLUSION MAY NOT APPLY TO
YOU.)
Other Legal Rights
This warranty gives you specific legal
rights and you may also have other rights
which vary from state to state.
provided with the product, staples through
wiring, pinched or broken wires, broken cables
power outages, use of extension cords, missing
or damaged parts or discounted clearance, final
sale or taped cartons, fire, flood, acts of God, or
failure to follow the Owner’s Manual. This
warranty is the only one we will give on your
Garage Smart Product. There are no other
express warranties.
Where and How to Obtain Warranty Service
You can obtain warranty service from Garage
Smart at the address indicated below. It is your
responsibility to deliver or ship the defective
product to us at your date of purchase and a
description of the claimed defect, prior to the
expiration of the warranty period. To obtain
information regarding this warranty, you may
contact us by mail, email, or phone.
Garage Smart
3000 Sierra Vista Way
Provo, UT 84606
[e-mail] or [phone]
Exceptions and Exclusions
This warranty does not include damage or
defects resulting from misuse, accident, failure
to maintain, or any other causes following your
purchased of the product. Use of the Lifter
system with any other system or components
(including affixing non Garage Smart
attachments or accessories) voids this
warranty. Failure to follow the owner’s manual
in installation or use of the Lifter system voids
the warranty. Unauthorized repair or
modification voids the warranty.
The Lifter system is intended for personal,
indoor, home use. Garage Smart does not
warrant its lift system for commercial use, and
3

SAFETY INFORMATION
1. Read and follow all safety, installation, and operation instructions.
2. Do not operate the Basic Lifter while hands or other body parts are near the system.
3. Do not stand under the Basic Lifter or items lifted by the system.
4. Do not use the Basic Lifter to lift people or animals.
5. Do not use the Basic Lifter to lift or lower items over people or animals.
6. Always balance load before lifting.
7. Total lifting capacity for the Basic Lifter system is 100 lbs.
If your MyLifter cable is tangled, damaged, or bent, STOP using your MyLifter unit
IMMEDIATELY.
4

WARNING
DO NOT install Garage Smart products in any other manner than specified in the
instructions. To avoid risk of electric shock and other potential injury, DO NOT open the
product casing. This product is for indoor use only. Failure to follow these safety
instructions may result in property damage, serious personal injury, or death.
FCC STATEMENT: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This
device may not cause harmful interference, and 2. This device must accept any interference received, including interference that
may cause undesired operation.
Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
RF WARNING STATEMENT: The device has been evaluated to meet general RF exposure requirement. The device can be used in
portable exposure condition without restriction.
5

ABOUT THE BASIC LIFTER
The Basic Lifter is a motorized hoist controlled by your smart device. It allows you to
safely lift your items off the garage floor and onto the ceiling, without lifting more than
a finger. Each hoist lifts up to 100 lbs. when using the included pulley hook. Lifters are
designed to work together. Connect up to four lifters and watch them work as if they
were one, to raise, lower, and store up to 400 lbs. Control your garage storage with the
touch of your finger.
6

INSTALLATION GUIDE
Scan the QR code or follow the link to access the Garage Smart DIY Installation Guides:
https://garagesmart.com/pages/diy-installation
7

REQUIRED TOOLS
•Ladder
•Stud Finder
•Pencil
•Tape Measure
•Drill
•1/2” Socket
•Wrench or Box Wrench
•Phillips Screwdriver
•Safety Glasses
8

PARTS IDENTIFIER: LIFTER
Garage Smart Lifter (x1) QD Pins (x2) Lag Screw (x2)
Lag Washer (x2)
Drill Bit (x1)
Eyelet Screw (x1)
Carabiner (x1)
Pulley Hook (x1)
9

PARTS IDENTIFIER: POWER ADAPTER
Cable Management Screw (x2)
DC Power Cable (x1)
Power Adapter (x1)
Wall Mount Screw (x1)
Universal Mount (x1)
(attached to Power Adapter)
Cable Management Clip (x2)
10

INSTALLATION PART 1: MOUNTING BRACKET
Step 1: Reference Before Mounting Bracket
Decide where to place your Basic Lifter by putting your item in the location you want to
install it.
The Mounting Bracket needs to be installed in the center of a ceiling joist. Center it
above the items intended location.
DO NOT install Mounting Bracket in any other manner than specified in instructions.
It is designed to be secured to flat ceilings only. DO NOT secure to walls or angled
ceilings.
11

INSTALLATION PART 1: MOUNTING BRACKET
Step 2: Locate Ceiling Joists
Use a stud finder to locate the ceiling joist
where you plan to place the Mounting Bracket.
Make sure you have the clearance and adequate
spacing for the hard top you will be lifting.
12

INSTALLATION PART 1: MOUNTING BRACKET
Step 3: Install The Mounting Bracket
Consider which way you want your item and
MyLifter to face, and mount the bracket
accordingly.
Refer to Figures 1.2a and 1.2b for correct
mounting configurations.
Fig 1.2b
Fig 1.2a
13

INSTALLATION PART 1: MOUNTING BRACKET
Step 3: Install The Mounting Bracket, cont.
Place the mounting bracket on the joist. Be sure
to align the mounting holes with the center of
the joist. With a pencil, mark an “X” on the
ceiling where you want the two holes to mount
your Lifter (Figure 1.3).
With a drill and the supplied drill bit, align the
bit on your marks and drill at least a 3" deep
pilot hole into the joist (Figure 1.4). The pilot
hole should drill through the sheetrock and into
the wood ceiling joist.
Fig 1.3
Fig 1.4
14

INSTALLATION PART 1: MOUNTING BRACKET
Step 3: Install The Mounting Bracket, cont.
Tighten the screws with a ½" wrench until the
bracket is snug against the ceiling (Figure 1.5).
As you turn the wrench, you should feel
resistance. If the lag screw turns freely, your
pilot hole is not in the ceiling joist and must be
repositioned on a secure portion of the joist.
Align the MyLifter unit with the mounting
bracket, and insert the two quick-release pins
through the MyLifter unit and mounting bracket
(Figure 1.6).
Fig 1.5
Fig 1.6
15

INSTALLATION PART 2: POWER ADAPTER
Step 1: Placing Power Adapter
Find a suitable location to mount the power
adapter to the wall. Confirm that the AC
cable will reach a power outlet and the DC
cable will reach your MyLifter.
Use the printable screw template to place
the two wall mount screws into the desired
location (Figure 2.1) exactly 2 inches apart
(50.8 mm). Allow the screw heads to
protrude from the wall about ¼” (6.35 mm)
away from the wall. (Figure 2.2)
Fig 2.1
Fig 2.2
16

INSTALLATION PART 2: POWER ADAPTER
Step 2: Placing Power Adapter
Line up the product mounting holes with the
screws as shown. Place the product over the
screws and slide to lock into place.
There is more than one orientation that can
be used.
Fig 2.3
Fig 2.4
17

INSTALLATION PART 2: POWER ADAPTER
Step 3: Secure Wires
1. Peel off sticker backing. (Figure 2.5)
2. Stick the clip where you want it.
(Figure 2.6)
3. Install the screw through the hole
(Figure 2.7) in the center of the clip.
4. Place all wires into the clip. (Figure 2.8)
5. Securely close the clip. (Figure 2.9)
Fig 2.6
Fig 2.5
Fig 2.7 Fig 2.8
Fig 2.9
18

INSTALLATION PART 2: POWER ADAPTER
Step 4: Plug In Power Adapter
1. Plug the AC cable into a power source. (Figure 2.11)
2. Additional AC Garage Smart products may be powered by connecting their
AC cable to the AC outlet on the Power Adapter. (Figure 2.11)
Fig 2.11
Fig 2.10
19

INSTALLATION PART 3: EYELET SCREW
Fig 3.1
Fig 3.2
Eyelet
Screw
Eyelet
Screw
20
