1. Foreword
Congratulations on your purchase of the Raizer.
This is an original user manual for your new Raizer II.
Hereinafter we use the term Raizer for Raizer II, if nothing
else is specifically indicated.
It is important to read this manual before
using the Raizer.
The Raizer is a battery-powered mobile lifting chair which
helps a lying person up to an almost standing position in a few
minutes. The Raizer can be operated by only a single assistant
and requires no physical effort from the assistant aside from
a helping hand. The Raizer is simple to operate by means of
the control panel mounted on the side of the seat, or with
the remote control.
1.1 Electronic version
We offer an online version of the user manual which can always be accessed by scanning the
below QR code or from our website:
https://www.liftup.dk/en/products/accessories/raizer-quick-guides/
Scan to open or download
the user manual

On our website we also offer some helpful videos which will provide you with
information on alarms/signals and troubleshooting, assembly and disassembly of the
Raizer: https://www.liftup.dk/en/products/accessories/raizer-video-guide/
Scan to go to online
videos
