Light Efficient Design RemPhos RP-SWL-7W-40K-BK-GI User manual

RP-SWL-7W-40K-BK-GI
5
S 5 S Primary LED module S(Secondary
LED module
e a e y a a ea y e A
5
12 FT
3 YEARS
Battery Charging Temp 32°F~
Fi t re perating Temp °F~113°F
Product name
Off Grid LED Solar Wall Pack
User Manual Power/Lumen 7W / 700LM
Dimension
LEDS
Solar Panel 3.7Wp Polycrystalline Silicon
Working Mode 3 Different Lighting Modes
Detection Angle/Area 120°/
Material ABS+PC
Remote Control/Distance 4 Key Infrared Control / <
Beam Angle 80°*100°
IP Degree IP65
Install Height
Lifespan 35,000 hrs
Warranty
Packing 1*Solar light,1*Screws Bag,1*User Manual,
Remote Controller
Adjustable Solar Panel
Replaceable Battery
IP65 Waterproof
ZERO Electricity Cost
PIR Sensor
113°F
Anti-theft Installation
7W/700LM
Specification
Features

ON/OFF will memorize the last mode set
before turning off
The primary LED module will automatically
turn on at dusk and remain at 50% brightness
when the motion sensor is disabled. After 5
hours or when the battery capacity is below
30%, the fixture will switch to Mode .
When motion is detected (within 24ft), the
secondary LED module will turn off and the
primary LED module will turn on to full
brightness (700LM). After 20 seconds of no
motion, the primary LED module will turn off
(to conserve battery). The secondary LED
module will then turn back on.
The primary LED module will turn on to full
brightness (700LM) when motion is detected
in the range of 24ft. Once no motion is
detected for 20 seconds, the fixture will turn
off. The secondary LED module will not turn
on in this mode.
The fixture features a unique optical design to provide safe illumination of the area while
maximizing battery life. The illumination is made up of a primary and a secondary LED
module. The secondary LED module provides a low light level.
Remind:When switching to a different working mode,the lamp will flash one time, which
is normal and indicate that the working mode is changed successfully.
. Please
note the arrow icon on the plate is
upward before fix the screw.
5
5
2.36
2.56
.
.
7.
8. .
Loosen the
screws on the
both sides of
the lamp
Remove the screws on the
side of the mounting plate.
Please press any button on the lamp
to activate the lamp and remote
.
.
.
by
12.05.18 Information is subject to change without notice.
3 Working Modes Installation
Notice & Warning
1. Please install the solar powered lamp in an area with a lot of sunlight. A south facing wall is ideal,
a west facing wall is second best, followed by an east. A north facing wall may not receive enough
sunlight in your area. We recommend a 42-degree angel for the solar panel.
2. Please note that the lighting time of the lamp will depend on the amount of sunshine & weather
conditions in you area.
3. The lamp will light up automatically at dusk.
4. Built in intelligent IC with over-charge, over-discharge & surge protection.
5. The lamp is equipped with an internal battery pack, which is replaceable. Please contact us if you
think that you may need a replacement.
6. If the battery is taken out and put back in or replaced with new ones, please place the solar panel
in sunshine or a strong light to reactivate the lamp.
