Light Efficient Design Solera SL-SAL-OG User manual

LIGHT EFFICIENT DESIGN HEADQUARTERS 188 S. Northwest Highway •Cary, IL 60013
INNOVATION & MANUFACTURING CENTER 30 Log Bridge Road, Building 200 •Middleton, MA 01949
847.380.3540 •led-llc.com
04.08.22 Information is subject to change without notice.
READ CAREFULLY BEFORE INSTALLING THE FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Fixtures must be wired in accordance with the National Electrical Code and all applicable local codes. Proper
grounding is required for safety. This product must be installed in accordance with the applicable installation code
by a person familiar with the construction and operation of the product and hazards involved.
PLEASE NOTE THAT THE PERFORMANCE OF A SOLAR LIGHT DEPENDS ON MANY FACTORS INCLUDING
SOLAR RADIATION, TEMPERATURE, AND OTHER ENVIRONMENTAL FACTORS. DIRTY SOLAR PANELS CAN
SIGNIFICANTLY REDUCE THE CHARGE EFFICIENCY OF SOLAR PANELS. IMPROPER ALIGNMENT OF THE
PANEL, SHADOWS, OR OBSTACLES THAT BLOCK DIRECT SUNLIGHT TO THE SOLAR PANEL CAN CAUSE
POOR PERFORMANCE.
NOTE: THE BATTERY IS DISCONNECTED UNTIL THE 4 PIN CONNECTOR FOR THE SOLAR PANEL
IS CONNECTED. THE LIGHT WILL NOT OPERATE UNLESS THE SOLAR PANEL OR A CHARGER ARE
CONNECTED.
DO NOT OPEN THE FIXTURE HOUSING, AS THERE ARE NO USER SERVICEABLE PARTS INSIDE. IF BATTERY
REPLACEMENT IS REQUIRED, PLEASE CONTACT THE MANUFACTURER.
STEP 1: REMOVE THE CONTENTS FROM ALL THE CARTON
Please be sure to check that everything is in the box.
OG/HYBRID 365 AREA LIGHT
SL-SAL-OG/HYB-50W-XXK-SF-G2
SOLAR
LIGHTS
INSTRUCTIONS
1 x Remote (CU-ALL6)
2 x AA Batteries
1 x Manual
1 x 5mm allen wrench
1 x 6mm allen wrench
1 x Fixture 1 x Sliptter
*(4 set screws pre attached)
STEP 2: SLIPFITTER MOUNTING
a. Adjust the angle of the xture. Align the white
lines w/ numbers and the arrows on the xture.
Loosen the screws and swivel the xture to the
desired angle, then re-tighten the screws.
b. The sliptter mounting ts a 2 3/8” O.D. tenon.
Place the sliptter over the tenon and secure the
xture with the two set screws on the side of the
sliptter.

LIGHT EFFICIENT DESIGN HEADQUARTERS 188 S. Northwest Highway •Cary, IL 60013
INNOVATION & MANUFACTURING CENTER 30 Log Bridge Road, Building 200 •Middleton, MA 01949
847.380.3540 •led-llc.com
04.08.22 Information is subject to change without notice.
STEP 3: WIRING THE FIXTURE (HYBRID ONLY)
The xture permits operation at 120V thru 277V, 50 or 60 Hz
a. Connect the black wire to the line
b. Connect the the white wire to the common
c. Connect the the green wire to ground
OG/HYBRID 365 AREA LIGHT
SL-SAL-OG/HYB-50W-XXK-SF-G2
SOLAR
LIGHTS
INSTRUCTIONS
STEP 4: INSTALL SOLAR PANEL KIT
Install solar panel kit model # SL-SAL-50W-2PANELKIT. This comes in a separate carton.
Installation instructions for the solar panel kit are included in the carton or are available on the
solera solar website.
STEP 5: CONNECT SOLAR PANEL TO FIXTURE
Once the xture is completely installed, plug the cable from the
solar panel to the cable on the back of the xture to activate
the xture. The light will turn on approximately 15- 20 minutes
after sunset.
THE HYBRID 365 FIXTURE WILL PULL FROM LINE POWER WHEN THE BATTERY GETS
TO <20%. THIS IS TO CONSERVE THE LONGEVITY OF THE BATTERY

LIGHT EFFICIENT DESIGN HEADQUARTERS 188 S. Northwest Highway •Cary, IL 60013
INNOVATION & MANUFACTURING CENTER 30 Log Bridge Road, Building 200 •Middleton, MA 01949
847.380.3540 •led-llc.com
04.08.22 Information is subject to change without notice.
OG/HYBRID 365 AREA LIGHT
SL-SAL-OG/HYB-50W-XXK-SF-G2
SOLAR
LIGHTS
INSTRUCTIONS
INTRODUCTION: REMOTE-CONTROL
The default setting is Dusk ‘til Dawn @80% First 2 hours, 50% constant & 80% w/ motion for
the remainder of the night, *remote does not need to be connected or adjusted if your lighting
goals are met.
QUICK START GUIDE
START UP THE REMOTE BY CLICKING ANY
BUTTON
a. The remote has a range of about 24ft
b. The xture will operate in the default mode without using the
remote.
c. You may want to adjust the settings based off your
geographical area to attain more solar powered operation,
rather than pulling from the grid. We can change the settings
by following the below:
DEFAULT OPERATING MODE
a. For the rst 2 hours the product runs at 80% xed output.
b. The next 12 hours, it will run it at 50% idle & 80% when motion is sensed.
c. After motion detector will allow the xture to return to idle state after no motion is
detected for 30 seconds.
d. When the solar panel detects daylight, it will shut off for the day.
CUSTOM SETTING OF TIME AND POWER LEVELS
It is recommended to allow the light to operate under the default settings. If necessary,
the settings can be customized. Please be aware that incorrect settings could cause the
light to

LIGHT EFFICIENT DESIGN HEADQUARTERS 188 S. Northwest Highway •Cary, IL 60013
INNOVATION & MANUFACTURING CENTER 30 Log Bridge Road, Building 200 •Middleton, MA 01949
847.380.3540 •led-llc.com
04.08.22 Information is subject to change without notice.
OG/HYBRID 365 AREA LIGHT
SL-SAL-OG/HYB-50W-XXK-SF-G2
SOLAR
LIGHTS
INSTRUCTIONS
WARNING AND ATTENTION:
1. Before installation, please ensure that the foundation, pole and bracket are strong enough to support the light xture.
2. Position the solar panel to optimize its exposure to sunlight. Always face the equator if possible (solar panel to face south
if located in the northern hemisphere, for example).
3. In order to allow self-cleaning of the solar panels, please have a minimum angle of 15 degrees.
4. Adjust the angle of the panel to optimize exposure to sunlight. Avoid north facing panels in the USA
5. The xture will be active once the solar panel is connected to the xture’s solar panel connector wire.
6. Please make sure that the panel is installed under direct sunlight. The red light should be ashing, indicating that it is
charging.
7. The lighting xture will automatically turn on at night and turn off during daylight. The solar panel acts as a photocell.
8. Please select an operating mode according to the local legislation needs and the local sunshine conditions.
9. The battery of the HYBRID 365 xture will stop charging when the ambient temperature is below -4°F or above 140°F.
The working temperature of the solar xture is -40°F (-40°C) to +140°F (+60°C). When operating in an environment with a
temperature lower than -40°F (-20°C), line voltage will kick in to operate the light.
