Light Efficient Design LED-8088M Series Parts list manual

11.The recessed luminaire can not use with through-branch wiring.
IMPORTANT SAFETY INSTRUCTIONS FOR LED RETROFIT CONVERSION:
FOR USE ONLY WITH HID LUMINAIRES IN ACCORDANCE WITH THE INSTRUCTIONS PROVIDED
WITH THIS RETROFIT KIT.
WARNING - RISK OF FIRE OR ELECTRICAL SHOCK. LED retrofit kit installation requires
WARNING - RISK OF FIRE OR ELECTRICAL SHOCK. Install this kit only in the luminaires
that have the construction features and dimensions shown in the photographs and/or drawings
and where the input rating of the retrofit kit does not exceed the input rating of the luminaire.
WARNING - Do not make or alter any open holes in an enclosure of wiring or electrical
components during kit installation.
WARNING - To prevent wiring damage or abrasion, do not expose wiring to sharp edges of
housing or other sharp surface.
WARNING - Not for use with HID ballast, 120-277VAC(USA)/120-347VAC(Canada) direct
line voltage only.
THIS DEVICE IS NOT INTENDED FOR USE WITH EMERGENCY EXITS.
knowledge of luminaires electrical systems. If not qualified, do not attempt installation.
Contact a qualified electrician.
LED-8088M30 LED-8088M30C 50W 3000K
LED-8088M40 LED-8088M40C 50W 4000K
LED-8088M57 LED-8088M57C 50W 5700K
E39 Mogul
11.9
5.4
Enclosed (Outdoors)

Attach the retrofit lamp to the female socket of the existing luminaire.
To avoid damaging lamp do not over-torque or overtightenlamp.
The E39 mogul female lamp holder shouldhave suitable mounting
strength to securely hold lamp in place.
6
7
LED-8088M30 LED-8088M30C 50W 3000K
LED-8088M40 LED-8088M40C 50W 4000K
LED-8088M57 LED-8088M57C 50W 5700K
