Light Emotion LEDBALL6 Operator's manual

www.lightemotion.com.au
LEDBALL6
LED Rotating Ball with 5 x 15w HEX (6-in-1) LEDs.
User’s instruction manual
This manual contains important information about the safe installation and use of this product
Please read this instruction manual carefully before installing or operating
Please keep these instructions in a safe place for future reference
V1.02

1
Contents
1. Safety Instructions 2
2. Installation 3
3. Features 3
4. Product Overview 4
5. Menu Operation 5
6. DMX Table 5
7. DMX Address Setting 7
8. Error Messages 8
9. Rigging 8
10. Cleaning and Maintenance 8
11. Technical Data 9
12. Warranty 9

2
Introduction
Thank you for the purchase of your LEDBALL6 rotating LED Ball by Light Emotion. We are
confident you will be satisfied with your purchase and enjoy many years of use from this
Professional Light Emotion product. Please read these instructions carefully to ensure the
product is well look after and used correctly to avoid any potential problems.
Please note that as part of our ongoing commitment to continuous improvement and product
development, the specifications in this manual are subject to change without notice. Whilst
every care has been taken in the preparation of this manual we reserve the right to change
specifications in the course of product improvement.
What is in the box:
- 1 x LEDBALL6 Lighting Effect
- 1 x Quick lock handle
- 1 x Power Cable
- This user manual and warranty card
1. Safety Instructions:
Please read these instructions carefully. It includes important information about the installation
usage and maintenance of this product.
- Please keep this User Manual for future consultation. If you sell the unit to another user, be
sure that they also receive this instruction booklet.
- Always make sure that you are connecting to the proper voltage and that the line voltage you
are connecting to is not higher than that stated on the sticker of the fixture.
- This product is intended for indoor use only. To prevent risk of fire or shock, do not expose
fixture to rain or moisture.
- Make sure there are no flammable materials close to the unit while operating.
- The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surface. Be sure that no ventilation slots are blocked.
- Always disconnect from power source before servicing.
- Secure fixture to stands, trussing and the like using a safety chain.
- Maximum ambient temperature is 40˚C. Do not operate fixture at temperatures higher than
this.
- In the event of serious operating problem, stop using the unit immediately. Never try to repair
the unit by yourself. Repairs carried out by unskilled people can lead to damage or malfunction.
Please contact the nearest authorized technical assistance center.
- Make sure power cord is never crimped or damaged.
- Never disconnect power cord by pulling or tugging on the cord.

3
- Never carry the fixture directly from the cord. Carry by holding the base of the unit, and only
move when unit is upright.
- Avoid direct eye exposure to the light source while it is on.
2. Installation:
Caution: For safe mounting of this product, please read the following carefully.
- Use the included rapid lock clamp to attach to lighting stand, trussing or bar, together with
safety chain. See section 9 for detailed instructions regarding rigging.
- When mounting the product, do not stand directly underneath the product
- Always use a safety chain when mounting the product on stands, trussing or bars. Make sure
the breaking strain rating of the chain is at least 10 times the weight of the product.
- Make sure there is adequate ventilation around the product.
- This product is designed to be mounted either upright or upside down. It cannot be used in a
side orientation – for example: the product cannot be used with the base mounted on the wall
in a perpendicular orientation. This will cause severe damage to the motor and drive shaft and
could cause the ball to distort and even fall off.
- Never look directly into the LED light sources of the product.
- For indoor use only – do not use outdoors.
- To avoid electrical shock, keep away from rain and moisture.
- Keep out of reach of children.
3. Features
This product is designed as an LED lighting effect and is only intended to be used as an LED
lighting effect for entertainment and display applications. Due to our ongoing commitment to
constantly reviewing and improving products, features and specifications are subject to change
without prior notice.
- LEDs: 5 x 15W RGBWYUV HEX 6-in-1 LEDs with average 50000 hours lifespan
- Beam angle ： 1º
- Beam spot angle ： 1º
- Lenses: 98
- Pan: Infinite (endless rotation)
- Control: DMX, Sound Activation, Stand Alone, Master/Slave
- DMX Channels: 13
- Functions: Continuous rotation, strobing, variable speed rotation, individual colour control
- Electronic strobe rate: 1-25Hz
- Built in colour macros and programs
- IEC input/output, can link 20 units together.
- Weight: 3.65kg
- Packed Dimensions 355x355x485mm

4
4. Product Overview
1. LED Display
2. MODE/ESC button
3. UP button (UP）
4. DOWN button
(DOWN）
5. Enter button (ENTER）
））
）
1. Signal input
2. Signal output
3. ON/OFF switch
4. Fuse 2A
5. Power In
6. Power Out

5
5. Menu operation
Notes:
1. The display flickering slowly indicates the current MENU option. If the display is flickering
quickly, the data shown on the display will become current once entered.
2. During changing the MENU settings, if no input has been received after 10 seconds, the
MENU will return to A001 display and be locked (the last 3 numbers show the DMX address).
The unit will continue to operate in the last program it was set to. To UNLOCK the menu
display, hold down enter for 3 seconds, then press up or down. Again, after no input or change
for 10 seconds or more, the display will lock and revert to A001 display.
6. DMX Channel Allocation and functions table
CH Value Function
1 0-255 Pan continuous rotation
2 0-255 0-30 no function
31-140 Pan continuous clockwise rotation (from fast to slow)
141-145 Stop rotation
146-255 Pan continuous anti-clockwise rotation (from slow to fast)
REST
RESTREST
REST REST
RESTREST
REST RESET
RESETRESET
RESET
rdoF
rdoFrdoF
rdoF rdoF
rdoFrdoF
rdoF DISPLAYREVERSE OFF
DISPLAYREVERSE OFFDISPLAYREVERSE OFF
DISPLAYREVERSE OFF
rdon
rdonrdon
rdon DISPLAY REVERSE ON
DISPLAY REVERSE ONDISPLAY REVERSE ON
DISPLAY REVERSE ON
A
AA
A0
00
001
0101
01 001
001001
001-
--
-512
512512
512 DMX mode
DMX modeDMX mode
DMX mode
AuTo
AuToAuTo
AuTo Au0F
Au0FAu0F
Au0F AUTO mode O
AUTO mode OAUTO mode O
AUTO mode OFF
FFFF
FF
AuTo
AuToAuTo
AuTo AUTO mode ON
AUTO mode ONAUTO mode ON
AUTO mode ON
dFoF
dFoFdFoF
dFoF dFoF
dFoFdFoF
dFoF DEFAULT OFF
DEFAULT OFFDEFAULT OFF
DEFAULT OFF
dFon
dFondFon
dFon DEFAULT ON
DEFAULT ONDEFAULT ON
DEFAULT ON
SOND
SONDSOND
SOND SOUND mode
SOUND modeSOUND mode
SOUND mode
rdoF
rdoFrdoF
rdoF rdoF
rdoFrdoF
rdoF Sound en itivity
Sound en itivitySound en itivity
Sound en itivity
ASTE
ASTEASTE
ASTE Ma t
Ma tMa t
Ma t Ma ter unit
Ma ter unitMa ter unit
Ma ter unit
Alon
AlonAlon
Alon Slave unit
Slave unitSlave unit
Slave unit

6
3 0-255 Pan speed
（ invalid during endless rotation, 226-235. Light OFF when
scanning ， 236-255 ： max speed ）
4 0-255 Red dimming
5 0-255 Green dimming
6 0-255 Blue dimming
7 0-255 White dimming
8 0-255 Yellow dimming
9 0-255 UV dimming
10 0-255 0-15 No function
16-95 Synchronous strobe – strobe speed
96-175 Strobe Flash once per second. Flash Duration from short to long.
176 – 255 Asynchronous strobe: Strobe flash probability from high to low
11 0-255 Master dimming
12 0-255 0-25 No function
26-205 Fixed Colours - each 20 value mean 1 colour (eg 26-45 red)
206-255 Colour changing (changing speed from fast to slow)
13 0-255 Macros (built in programs as below)
0-55 No function
56-75 Sound control ， each sound will switch to next Marcos as below, sound
sensitivity from low to high 40-80%
NOTE: this is not controlled by the sound sensitivity in MENU. The sound
sensitivity setting in MENU is valid for sound function in Auto only
76-105 Red ， clockwise rotation
106-135 Blue, anti-clockwise rotation
136-165 7 colours changing, clockwise rotation
166-195 7 colours changing, anti-clockwise rotation
196-225 7 colours changing, with strobe (strobe 3 seconds ， light on 7
seconds) ， clockwise rotation
226-255 7 colours changing ， with strobe (strobe 3 seconds ， light on 7
seconds) ， anti-clockwise rotation
DMX-512 Control Connection
Using a 3 pin XLR cable, you can connect the product to a DMX controller and then to
other fixtures with 3 pin XLR inputs and outputs. When not using DMX, multiple
fixtures can be connected together and operate under master/slave control. The signal
cable should have two core with shielded cable, the signal connectors are XLR input
and output connectors. Please refer to the below diagram:

7
7. DMX Address Setting
When being used in conjunction with a DMX controller, each fixture must be set a specific
starting address. When receiving signal, fixture will receive channel control signals of this
address from the DMX controller.
For simplicity, the user can use the same address for multiple fixtures but this will result in
each fixture providing exactly the same output and fixtures with the same DMX address cannot
be individually controlled.
To control each fixture individually via DMX, each fixture must have its own unique DMX
address. As this fixture uses 13 DMX channels, each address must be at least 13 apart.
So for example – assuming the first fixture is DMX channel 1, the second fixture would need
to be on channel 14, then the 3
rd
channel 27 and so on. Some DMX controllers may group
fixtures in lots of 16 channels – so in that case, fixture 1 on channel 1, fixture 2 on channel 17,
3 on 33, and so on. Refer to your DMX controllers’ instruction manual on how best to manage
your DMX channel allocation.
Address: 27 Address: 01Address: 14

8
DMX-512 connection with DMX terminator
A DMX terminator helps to reduce ‘noise’ on the DMX chain, and makes the light respond to
control more accurately. It should be plugged in to the last fixture in any chain. For Terminator
connections please see below:
8. Error Messages
In the event of an error or problem within the fixture, the display will show an error message
such as “PAN-ERR”. A pan error could be caused by an obstruction to the rotation of the ball.
If this is the case, power off the unit and clear the obstruction.
With any error message, the unit should be powered off, then turned on again after a few
seconds. If the error message persists, please contact your local dealer for advice or repairs.
There are no user-serviceable parts within this product – do not attempt to open and repair
yourself. Doing so will result in any warranty being voided.
9. Rigging:
Safety-rope
Rapid locking hook

9
Insert the quick-lock fasteners of the first holder into the respective holes on the base of the
product. Tighten the quick-lock fasteners fully clockwise. The mounting bracket can then be
attached to a stand, trussing or lighting bar securely. Be sure to use a safety chain which
connects through the lug with the hole in it on the base and around the trussing or bar on which
the product is being mounted.
10. Cleaning and maintenance
From time to time it is recommended the product is cleaned to ensure maximum light output
and performance. Use a wet cloth to clean the housing as well as the lenses and base. Glass
cleaner is also suitable but alcohol based cleaners and solvents cannot be used as they will
cause damage to the product.
When used in a fixed long term installation such as a venue or club, the unit should be
periodically taken down from the installation and professionally cleaned. Dust build-up within
the unit can cause damage and ultimately failure of components.
11. Technical Data
Input Voltage: AC100-240V 50/60Hz
LED: TX-BGRWIY10B120-001, 15W/LED
Power Consumption: 55w
SPFC power factor correction power supply, PF>0.99, efficiency > 90%
Net Weight: 3.65Kg
Packed Dimensions: 355x355x485mm
12. Warranty
This product is warranted for 2 years from your purchase date. We are confident that this
product will give many years of trouble-free operation but should an unlikely problem arise,
warranty claims must be via the original place of purchase, together with the original purchase
receipt. Please keep both your original purchase receipt and this instruction manual together
and in a safe place for future reference. Should the product be sold within the warranty period,
be sure to pass on both to the new purchaser so they are able to claim warranty should they
need to. We recommend register your warranty online at www.industrygear.com.au.

10
Copyright Light Emotion 2016. E&OE
Exclusively imported by LSW Imports and Distribution
PO Box 887, Kingsgrove, NSW, 2208
[email protected]
www.lightemotion.com.au
1800 643 111 (within Australia)
[phone] (outside of Australia)
