“Edgewood” LightHeaded™ Bed
Assembly Instructions www.LightHeadedBeds.com
Model #20217 Full size, Cheshire Cherry
Model #20273 Full size, Black
Model #20211 Full size, White
12/07/2015
1168350 C
Parts List
Part Description Quantity
Blister Pack EQA Contains the hardware required to assemble your new Lightheaded Bed 1
EPM Wood screw 24
EPY Cam-lock 8
EPZ Cam-bolt 8
EQC Fender washer (2 extra) 4
EPN LightHeaded™ headboard panel—ships with LightHeaded™ lighting
component kit already installed. 1
EQB Caprail 1
EPO Right headboard leg 1
EPP Left headboard leg 1
EPQ Footboard 1
EPR Right side rail 1
EPS Left side rail 1
EPT Roll-out slats (12 pieces of wood connected with nylon straps) 1
EPV Center support rail for slats 1
EPW Support legs for center support rail for slats 6
EPU
LightHeaded™ TechBox (contains remote control, power cord, instructions for
use and image changing, and your coupon code for $20) (see separate
LightHeaded™ Lighting Assembly Instructions)
1
Before you begin:
•Consider enlisting a family member or friend to help; it will make assembly easier, faster,
and more fun.
•Layout all of the parts listed below.
•Save all packing materials until assembly is complete to avoid accidentally discarding
smaller parts or hardware.
•You will need a Phillips head screw driver (not included)
Page 1

“Edgewood” LightHeaded™ Bed
Assembly Instructions www.LightHeadedBeds.com
Model #20217 Full size, Cheshire Cherry
Model #20273 Full size, Black
Model #20211 Full size, White
12/07/2015
1168350 C
Step 2
Step 1
1. On a sort surface, carefully lay your LightHeaded™ headboard panel (EPN) face
down. Above the open top lay the caprail (EQB) so that the large surface points
toward the front of the headboard (see illustration).
2. Insert 4 cam-locks (EPY) into the holes on the back of the headboard on left and
right edge (do not insert into the center hole). Point the arrows on the back of
the cam-locks toward the corresponding cam-bolts on the legs.
3. Lay the legs (EPO, EPP) down so that the threaded inserts and holes are pointing
toward the headboard panel.
4. Screw 4 cam-bolts (EPZ) into the plastic threaded inserts on the inside of each leg
(EPO, EPP).
5. Place one washer (EQC) over each pin at the ends of the caprail. Line up the pin
on the end of the caprail (EQB) with the inside of the right leg. At the same time
line up the cam-locks with the cam-bolts. If the cam-bolts do not go into the
holes, check to make sure the arrow on the cam-lock is pointed toward the bolt.
Do not tighten the cam-locks yet.
6. Repeat step 5 with the left leg.
7. Once you have both legs and the caprail connected to the headboard, use a
Phillips head screwdriver (not included) to tighten the cam-locks.
Page 2
1. Open the caprail of your LightHeaded™ headboard (EPQ), then
remove the protective foam insert and attached paper and discard.
2. Your LightHeaded™ light component is pre-assembled in your
headboard and ready to use. Please refer to your LightHeaded™
Lighting Assembly Instructions in the TechBox (EPU) for information
on how to connect power to your light, insert LightHeaded™ Images,
and trouble shoot if necessary.
E
It’s your choice!
Your LightHeaded™ bed can be assembled to use a box spring and mattress set or a mattress only. Don’t worry, you can change it at any
time with a couple simple steps and no tools.
Box Spring & Mattress Mattress only
or
EPN
EPO
EPP
EQB
EPQ
EQC
EQC

“Edgewood” LightHeaded™ Bed
Assembly Instructions www.LightHeadedBeds.com
Model #20217 Full size, Cheshire Cherry
Model #20273 Full size, Black
Model #20211 Full size, White
12/07/2015
1168350 C
Step 4
Step 5
F
Page 3
1. If using a mattress only and your side rails have been
placed into the top two metal pins in the vertical slot on
the headboard and footboard legs, screw 1 long and 1
short support leg (EPW) together. Repeat to make 3
extended legs.
2. Have your assistant lift the middle of the wooden slats;
align the center support rail from headboard to footboard,
using the center set of pre-drilled holes. Screw 1 extended
leg through the center support rail (EPV) and into the
receiver in the middle wooden slat.
3. Replace the slats and move to the foot of the bed and
screw another extended leg through the center support rail
and into the receiver in the end wooden slat.
4. Repeat with final extended leg at the head of the bed.
If you’re using a box
spring and mattress,
hook your wooden
side rails (EPR, EPS)
onto the bottom two
metal pins in the
vertical slot on the
headboard and
footboard legs.
If you’re using a
mattress only, hook
your wooden side
rails (EPR, EPS) onto
the top two metal
pins in the vertical
slot on the headboard
and footboard legs.
Step 3
Rollout wooden slats (EPT) onto your side rails so
that the two end slats lock into place with the wood
blocks near the headboard and footboard.
1. If using a box spring and mattress and your side rails
have been placed into the bottom two metal pins in the
vertical slot on the headboard and footboard legs,
choose the short support legs with cap end (EPW).
2. Have your assistant lift the middle of the wooden slats;
align the center support rail from headboard to
footboard, using the center set of pre-drilled holes.
Screw 1 support leg through the center support rail
(EPV) and into the receiver in the middle wooden slat.
3. Replace the slats and move to the foot of the bed and
screw another support leg through the center support
rail and into the receiver in the end wooden slat.
4. Repeat with the final support leg at the head of the bed.
EPT EPT
EPV
EPV
EPV

“Edgewood” LightHeaded™ Bed
Assembly Instructions www.LightHeadedBeds.com
Model #20217 Full size, Cheshire Cherry
Model #20273 Full size, Black
Model #20211 Full size, White
12/07/2015
1168350 C
Step 6
F
Page 4
Secure each slat into the side rails with the (EPM) wood
screws using a Phillips head screwdriver (not included).
You have now completed the bed assembly.
Your LightHeaded™ Bed comes with a built-in image storage on the
inside of your footboard. This specially designed area allows you to
organize and safely store up to 25 interchangeable LightHeaded™
Images.
Please refer to the Lighting Assembly Instructions contained in your
TechBox. Locate the page titled Using Your LightHeaded Bed for
instructions to easily remove one LightHeaded™ Image from the
headboard and replace it with another.
The LightHeaded™ Image which you just removed from the headboard
can now be placed into the storage area in the footboard and your
LightHeaded™ Image will be ready for the next time you want to
personalize your LightHeaded™ Bed.
On/Off switch
On the back of your LightHeaded headboard, located just below
the hinged top, is an On/Off switch which can be used to toggle
the light component on or off. Please refer to your user manual
in the TechBox for additional information.
Light component positioning hole
Display in your headboard. Store in your footboard.
If, after review of the Lighting Assembly Instructions contained in
the TechBox, you find that your LightHeaded™ Image does not
slide in and out of the headboard with little to no resistance,
we’ve provided a 1" diameter hole located in the center of the
headboard back panel. With your finger, simply apply gentle
pressure to the back of the light component to reposition it, and
your LightHeaded™ Image will slide effortlessly in and out of
your headboard.
EPM
EPM

“Edgewood” LightHeaded™ Bed
Assembly Instructions www.LightHeadedBeds.com
Model #20217 Full size, Cheshire Cherry
Model #20273 Full size, Black
Model #20211 Full size, White
12/07/2015
1168350 C
One Year Limited Warranty
LightHeaded™ Beds warrants that for a period of one year from the date of purchase, this product will be free
from defects in material and workmanship. LightHeaded™ Beds, at its option, will repair or replace the product or
any component of the product found to be defective during the warranty period. Replacement will be made with a
new or remanufactured product or component. If the product is no longer available, replacement may be made
with a similar product of equal or greater value. This is your exclusive warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not
transferable. Keep the original sales receipt. Proof of purchase is required for warranty service. LightHeaded™
Beds dealers, service centers, or retail stores selling LightHeaded™ Beds products do not have the right to alter,
modify, or in any way change the terms and conditions of this warranty.
This warranty does not cover normal wear and tear of parts or damage resulting from any of the following:
negligent use or misuse of the product, use on improper voltage or current, use contrary to the operating
instructions, electronics disassembly, repair or alteration by anyone other than LightHeaded™ Beds authorized
service representatives.
What are the Limits on LightHeaded™ Beds Liability?
LightHeaded™ Beds shall not be liable for any incidental or consequential damages caused by the breach of any
express, implied, or statutory warranty or condition. Except to the extent prohibited by applicable law, any implied
warranty or condition of merchantability or fitness for a particular purpose is limited in duration to the duration of
the above warranty. LightHeaded™ Beds disclaims all other warranties, conditions or representations, express,
implied, statutory or otherwise. LightHeaded™ Beds shall not be liable for any damages of any kind resulting from
the purchase, use or misuse of, or inability to use the product including incidental, special, consequential or similar
damages or loss of profits, or for any breach of contract, fundamental or otherwise, or for any claim brought
against purchaser by any other party.
How to Obtain Warranty Service
We suggest you complete and return the product registration card that was included with your bed. This will help
us to promptly facilitate verification of the date of your original purchase. If you have any questions regarding this
warranty or would like to obtain warranty service, please call [phone] and a friendly Customer Service
Representative will assist you.
Congratulations! Your LightHeaded™ bed is assembled and
you are ready for the real fun.
•Hop online and surf our website LightHeadedBeds.com where you can
apply your $20 gift coupon toward your first LightHeaded™ Image and
personalize your bed.
•Create your own custom images or select from our massive gallery of
amazing images and super characters.
Page 5
Trundle Underbed storage
An optional Twin Trundle bed is
available for purchase at
LightHeadedBeds.com
An optional Underbed Storage Unit
is available for purchase at
LightHeadedBeds.com. Use 1 or
2 for additional storage as needed.
Got questions?
Our friendly LightHeaded™
Customer Service Rep can help you
at 800-225-3865 or e-mail us at
[e-mail].
Assembly videos are available on
You-Tube. Thanks from the folks at
www.LightHeadedBeds.com
