Light Sky PL61W3 User manual

E-mail:
n
Add:No.51 Yunfeng Rd,Xinhua Industrial Zone,Xinhua Street,
Huadu District,Guangzhou,China.
PL61W3
USER MANUAL
FLY DRAGON LIGHTING EQUIPMENT CO., LTD
www.lightsky.com.cn
Please read these user manual carefully before use

1
INDEX
Congratulations on choosing our company product! We thank you for your custom.
◆Please note that this product, as all the others in the rich my company range, has
been designed and made with total quality to ensure excellent performance and
best meet your expectations and requirements.
◆Carefully read this user manual in its entirety and keep it safe for future reference.
It is essential to know the information and comply with the instructions given in this
manual to ensure the fitting is installed, used and serviced correctly and safely.
◆My company disclaims all liability for damage to the fitting or to other property or
persons deriving from installation, use and maintenance that have not been carried
out in conformity with this user manual, which must always accompany the fitting.
◆My company reserves the right to modify the characteristics stated in this user
manual at any time and without prior notice.
1.Safety information................................................................................................2
2.Skill specifications and Performance trait .............................................................3
3.Control panel.......................................................................................................4
4.Attachment and Body size...................................................................................5
5.Distance,spot diameter and Illumination diagram....................................................6
6.Mounting and Installation......................................................................................7
7.Power supply and Signal connection......................................................................8
8.Menu setting.......................................................................................................10
9.Channel function.................................................................................................12
10. .................................................................................13Circuit connecting diagram
11.Troubeshooting.................................................................................................14
12.Cleaning and Maintenances...............................................................................15
13. ..........................................................15Duty exonerative and Copyright protection

2
SAFETY INSTRUCTIONS
Notice: To guarantee proper and consistent operation, it is important to follow the
guidelines in this manual. Our company will not accept responsibility for damages
resulting from the misuse of this fixture due to the disregard of the information
printed in this manual.
●1. In order to ensure the light could operate normally, the ambient temperature
couldn't be higher than 40℃ and no lower than-10℃.
●2. Under normal condition, the highest sectional surface temperature may be up to
60 ℃.
●3.These projectors are designed depends on the electric shock protection, the
projector should be connected with the power supply system which connected
ground enough. The projector's ground cable should be connected with the ground
cable of the power supply system as well. The ground mark of the light metal cover
should be connecting with the installation bricked steadily.
●4. Don't use the power cable when the insulation is damaged.
It must be the manufacturer or distributor or the professional person to change
the damaged power cable in order to avoid any dangerous.
●5.Please check the voltage, frequency data of power supply system is suitable for the
mentioned on the projector. Please do avoid the different voltage between them
and burn the projector.
●6.Do not attempt to operate this fixture if the power cord has become damaged or
frayed.
●7.Never open this fixture while in use.
●8.Never look directly into the light source. You risk injury to your retina, which may
induce blindness.
●9.Please be aware that damages caused by modifications to the device are not subject
to warranty.

3
◎ Voltage：AC100~240V 50/60Hz.
◎ Maximum power consumption :190W
◎ LED chip：CREEN 3W White
◎ LED QTY：61PCS
◎ Chip drive current：950mA
◎ LED life：≥50000H
◎ Beam angle:Zoom function min.10°，max.50°
◎ Color：RGB Color system,soft and no flicker,Single ring can be controlled separateiy,
fast marco color system
◎ Strobe:1-30 times/second electronic strobe and random strobe.
◎ Dimmer :65536 class dimmer
◎ Control Mode: DMX512、Stand-alone mode、Mater-Slave mode
◎ Channel: 5CH
◎ Control panel:LED display screen+keypad
◎ Structure：Aluminum material,honeycomb design,high quality cooling system
◎ IP Rate:IP65
◎ Using environment
temperature:-10-40℃, humidity：5%-95%
◎ CE Marking
In conformity with the European Union Low Voltage.
Directive 2014/35/EU and Electromagnetic compatibility Directive 2014/30/EU.
◎ Single carton size：258×335×291MM
◎ N.W.：8.7KG
◎ Carton size：340×340×356MM
N.W：8.7KG G.W：10KG
◎ Light size(6pce）:910×790×500MM
N.W：53KG G.W：86KG
Skill specifications and Perfor mance trait

Control panel
4
POWER IN
POWER OUT
DMX OUTDMX IN
Keypad
Display screen

Attachment and Body size
5
power cord
Body Size---Fig 2
2
1
347
210
291 335
258
◆Each of the six stage lights delivers a power cord and a signal line.

Distance,spot diameter and illumination diagram
6
Distance,spot diameter and illumination diagram
10° （Lux）
50° (Lux)
10 2 00 37 0 0 21 6 0 11 1 0
W2
W1+W2
W1 8 5 00 35 4 0 202 0 104 0
1760
33 6 060 5 016 5 00
22 4 0 830 45 0 13 6
827 249 013 2 0
W1
W1+W2
W2 5 730 054 0142 0
0.55 0.9 1.2
753
Distance(m) 0 1 0
1.75
9.3
6.5 4.8 2.8
10°Diameter(m)
50°Diameter(m)
1m
2m
3m
4m
5m
5m
4m
3m
2m
1m
0m
6m
6m
50°
10°

Mounting and installation
7
Cautions:
For added protection mount the fixtures in areas outside walking paths, seatingareas,
and away from areas were unauthorized personnel might reach the fixture.
Before mounting the fixture to any surface, make sure that the installation area can
hold a minimum point load of 10 times the device's weight. Fixture installation must
always be secured with a secondary safety attachment, such as an appropriate safety
cable. To avoid injury, never stand directly below the device when mounting, removing,
or servicing the fixture.
Mounting points:Overhead mounting requires extensive experience, including amongst
others calculating working load limits, a fine knowledge of the installation material
being used, and periodic safety inspection of all installation material and the fixture.
If you lack these qualifications, do not attempt the installation yourself. Improper
installation can result in bodily injury. Be sure to complete all rigging and installation
procedures before connecting the main power cord to the appropriate wall outlet.
cautton! Be sure a qualified electrician performs all electrical connections.
Mounting:
Our company is fully operational in any mounting position, hanging upside-down, side
mounted, or set on a flat level surface, etc. Be sure this fixture is kept at least 0.5m
(about 1.6feet) away from any flammable materials (decoration etc.).
When clamp mounting; always use and install the supplied safety cable as an added
safety measure to prevent accidental damage in the event of a clamp failure. See the
image below.

8
or
L
N
black
blue
brown
yellow-green
white
green
Conductor Symbol
live
neutral
ground(earth)
Wire Color
(EU models)
Wire Color
(US models)
OUT IN
POWER IN OUT IN OUT
Wire color-coding and power connections：
Power supply and signal connection
1. Power supply
Use the professional plug to connect the projector and main power supply. Please
pay attention to the voltage, frequency the same as the mentioned on the projector.
Suggest each light has separately switched of the power supply so that could turn
on or turn off each projector desultorily.

SCREEN
1
3
2
DMX 512
3 PIN
SIGNAL
SIGNAL
SIGNAL
SCREEN
DMX512
5 PIN
1
2
3
4
5
SIGNAL
PIN3
PIN2
9
DMX IN IN
OUT OUT IN OUT
2.Signal connection
Please use the round 3/5-pin XLR plugs &sockets offered by menu facture to connect the
first projector's output to the second projector' input and connect the second projector's
output to the third device's input. And in the same way for the rest, eventually connect the
last device's output, all the devices are together as the following figure.
The devices' control signal output or input by using the 3/5-pin XLR pug and socket.
If need to long then the communication cable, please make sure the both side of
3/5-pin plug is one to one. (one to one, two to two, three to three). Otherwise, the
communication cable will be interrupted.
Connecting to the control signal line (DMX) - Fig. 5
◎ Please use the round 3 or 5-pin XLR plugs &sockets offered by menu facture to connect the first
projector's output to the second projector' input and connect the second projector's output to the
third projector's input. And in the same way for the rest,eventually connect the last projector's
output,all the projectors are together.
◎The projectors's control signal output or input by using the 3 or 5-pin XLR pug and socket.If need to
lengthen the communication cable,please make sure the both side of 3 or 5-pin plug is one to one .
(one to one,two to two,three to three).Otherwise,the communication cable will be interrupted.The
communicate cable is 2-cord screened cable 75Ω resistance with each core is at least a 0.5mm
diameter.(Caution:All the inside leading wire of 3 or 5-pin XLR plug couldn't touch each other or
plinth).
◎Recommend to use the DMX signal terminator for the installation to avoid the electronic noise dama
-ge the digital control signal.Simply speaking,DMX terminator is an XLR connector with a 120Ω 1/2W
resistor connected across pin 2 and 3.Which is then plugged into the output socket on the last projec
-tor in the chain.Refer to the connection.

10
ESC UP DOWN ENTER
Menu setting
1.Button operation
ESC： ；●Exit Button
UP：Page up or increase；●
DOWN：Page down or reduce；●
ENTER：OK button●
No signal, keep the final state
Level 1 menu note
ADD A.*** Address code Settings
DIM.
CURV
OFF
DIM.1
DIM.2
DIM.3
DIM.4
OFF
CUR.1
CUR.2
CUR.3
CUR.4
Dimmer speed off
DMX.F
HOLD
BLAC
SET
2.Menu operation
Level 2 menu Level 3 menu Level 4 menu
Dimmer speed 1
Dimmer speed 2
Dimmer speed 3
Dimmer speed 4
Dimmer curv off
Dimmer curv 1
Dimmer curv 2
Dimmer curv 3
Dimmer curv 4
No signal, the black field
PRO.1 No signal, Built-in program 1
F.SCE No signal, Custom scenes
D-SP
ZOOM
M-S SLAV
SP.00
MAST
Z.000
Slave machine
Speed of built-in program without DMX signal
Master machine
Focus position without DMX signal

11
INFO
TEM1
LIST
D.000
D.000
C.000
C.000
S.000
S.000
Z.000
F.000
Z.000
V*.00
VERS
LED temperature
The DMX512 value of the console
Displays CPU version number
Level 1 menu
Note
Level 2 menu Level 3 menu Level 4 menu
The DMX512 value of the console
The DMX512 value of the console
The DMX512 value of the console
The DMX512 value of the console
F.SCE
Fixed editing of scenes
Fixed editing of scenes
Fixed editing of scenes
Fixed editing of scenes
Fixed editing of scenes
F.000
default
Factory settings
Factory default
SERV
Keep
Zoom
F.000
MANU
Z.000
S.000
Fuction
C.000
Shutter
D.000 Dimmer
CCT

CHANNEL FUNCTION
10-255
3
4
0-100
00
255 100
50-128 0-50
129-255 51-100
0-9 0-3
10-49
50-89
90-119
120-179
180-249
250-255
4-19
20-34
35-46
47-70
71-98
99-100
20-255 0-100
FUNCTION
%
DMX VALUE
CHANNEL
Zoom
Fuction
Shutter
Dimmer
CCT
NO Function
Reset
No Function
Fast closing, Slow opening,Slow→Fast
Slow closing,Fast opening,Slow→Fast
Slow closing,Slow opening,Slow→Fast
Random strbe，Slow→Fast
Synchronous strbe，Slow→Fast
NO Function
Zoom
12

Circuit connecting diagram
U1
J1
GF5241ASD2
S1 S3 S4
S2
GF5241AS
D1
L
N
+
-
-
+
Dreiver board
LED board
Display board
Switching power supply
Power in
in pu t
LED OUTPUT
W-
R2-
G2-
B2-
W+
R1+
G1+
B1+
R2+
G2+
B2+
B1-
G1-
R1-
DC48V INPUT
J2
J4
PH-4AWB
J3
J1
A13
A12
1
1
1
1
13

TROUBLE DISPOSE
It is recommended some solution for some normal trouble shooting. Any inextricability
problems should always be handling by the professional person. Disconnect the power
supply before maintenance the light.
●LED off：
1.Please check if install the suitable voltage
2.Please check whether the led will reach the end of their life can explode; please
replace a same description led.
3.Please check if the power supply is enough.
4.Please check whether the DMX 512 controller pass the "turn on" order.
●Though the light is lighting, but it couldn't accept the control order:
1.Please check the start code address and the function option are correct.
2.Please check whether the communicate control cable is on good connection or the
cable is too long or interrupt.
3.Please check the control system is not valid, check the signal amplifier of chain
connected is valid.
4.Please check whether the communicate cable is too long or the other equipment is
mutually conjugate.
5.Please arrange the wire well, shorter the signal cable, put the high voltage cable
and low voltage cable separately.
6.Add the signal amplify isolator.
7.Signal cable is used the excellent screening doublet (Resistance 75 OHM）
8.The end of the light end and the end resistance.
●The light can't move:
1.Please check if the power supply is suitable for the light voltage data.
2.Please check the light if they are deformation, inside parts is broken, become wet
etc will lead the loose contact.
14

CLEANING AND MAINTENANCE
DUTY EXONERATIVE AND COPYRIGHT PROTECTION
■1.In order to ensure the projector could work normally. It should be kept
clean always .The lens should also be regularly cleaned to maintain an
optimum light output. Do not use any type of solvent on lens. It will
damage the projector.
■2.Suggestion: The continue usage of the light don't exceed 4 hours. Or it
will shorter the usage of the lamp. Please use the alternative operation
to solve this problem.The fixture power ON time is best not over 48
hours, or it would generate lamp protection procedure.
■3.Please disconnect the power supply when begin to maintenance take
down the light. Please let the parts cool down 10 minute at least then
begin to install.
■4.Please inspect the lens or other moving parts timing and keep them clear
and static. If find anything damaged or looseness must change a lamp or
fix the lamp in order to avoid the accident.
CAUTION!
Disconnect from mains before starting maintenance operation.
◎Any products broken that didn't according to the instruction is not guarantee to
keep it in good repair.
◎The commentary for all the instruction belongs to the supplier in final.
◎No authorize can't copy.
15
