Lightcloud Touch User manual

Welcome
1 (844) LIGHTCLOUD
1 [phone]
[email protected]
WE’ RE HER E TO HELP:
Touch
®

Lightcloud is a wireless lighting
control service. The Lightcloud
Touch is a wall-mounted 10"
touchscreen tablet that gives
users a convenient and
customizable interface for
controlling a Lightcloud site.
Hello
Product Features
AC-powered for permanent installation
Customizable zone and scene control
Direct local control for minimum latency
Easy setup from your computer or
mobile device—or just call RAB
Patent Pending
Lightcloud is a wireless lighting
control service. The Lightcloud
Touch is a wall-mounted 10"
touchscreen tablet that gives
users a convenient and
customizable interface for
controlling a Lightcloud site.

Contents
PART NUMBER
LCTOUCH
INPUT
90-264VAC, 0.3-0.5A, 47-63Hz
OPERATING TEMPERATURE
0°C to 40°C
MAXIMUM RELATIVE HUMIDITY
90%
OVERALL DIMENSIONS
10.8” x 7.5” x 0.7”
WIRELESS RANGE
Line of Sight 1000 feet
Obstructions 100 feet
Indoor Rated
Specifications
Lightcloud Touch Instruction Manual
Bracket
Four #6-32 x 3/8”
One #4-40 x 1/8” acting as a screw set
®

What you need
Lightcloud Gateway
A Lightcloud installation requires
at least one Lightcloud Gateway to
manage your devices.
1 (844) LIGHTCLOUD
1 [phone]
[email protected]
WE ’ RE HERE TO HELP:
Lightcloud Controller
(Or similar Lightcloud actuation device)
A Lightcloud installation requires
at least one Lightcloud Gateway to
manage your devices.

Finding a
suitable location
Lightcloud uses a wireless mesh network
to connect devices such as the Touch
to the Gateway. Unlike a WiFi router,
each Lightcloud device may connect
another device to the network. If there
is a clear line of sight between two
Lightcloud devices, they can be placed
up to 1000 feet apart. If the two devices
are separated by ordinary drywall
construction, try to keep them within
100 feet of each other. Brick, concrete
and steel construction may require
additional AC-powered Lightcloud
devices to go around the obstruction.
See the Deployment section of your
Gateway for more information.
Wiring
WHITE / NEUTRAL
GREEN / GROUND
BLACK / HOT

2Inspect the box
1
Setup & installation
OFF
WARNING
OFF
Turn off power
The Touch requires a 2-gang box
with a minimum internal depth of 2”.
WARNING
OFF
2" depth

Setup & installation (cont’d)
34
Remove the Bracket
Pull the tab at the top of the Touch
and slide the bracket off the Touch.
Wire the Power Supply
Black to Hot
White to Neutral
Green to Ground
WHITE /
NEUTRAL
GREEN /
GROUND
BLACK / HOT

Setup & installation (cont’d)
5Install the Bracket
Center the bracket over the
junction box and attach with screws.
6Connect power cable to Touch
Connect the power cable to the
back of the Touch

Setup & installation (cont’d)
Slide Touch onto Bracket
Align bracket tabs with slots on
back of Touch and slide Touch down.
8Tighten Set Screw
Tighten set screw on top of bracket
Don’t over tighten set screw!
7

Setup & installation (cont’d)
Labeling your device
When installing devices, it’s important to keep track of
their Device IDs, installation locations, panel/circuit #s,
dimming function, and any additional notes. To organize
this information, use the Lightcloud Installer Application
(A) or Device Table (B).
Lightcloud Installer Application
Install the LC Installer Application: LC Installer is available
for iOS or Andriod
Scan & Install Lightcloud Devices: Scan each device and assign to
a room. It’s recommended that each device is scanned just before
or just after being wired so no devices are missed. The more notes
that are given, the easier it is to commission the system.
Device Table
For setup and maintenance, we provide two Lightcloud Device
Tables with the Gateway: one that you can attach to your panel
and one to hand off to a building manager. Attach the Device
Identification stickers included with each device to a row,
then write in additional information, such as Zone name, Panel/
Circuit Number, and whether or not a zone uses dimming.
Device Scanner
Enter Manually
PLACE RECTANGLE TO FIT CODE ON LABEL
Scan Device Code
Device Info
SaveCancel
Device ID 0013A20040B62A4A
Location
Zone Name
Dimmable
Power Monitoring
Enter Device
Information
Repeat for
Additional Devices
Devices
Send to RAB
Of
Controller
Of
Sensor
Of
Dimmer
Of
Daylight
Of
Touch
Add Device
ficeLight - ID 0013A20040B62A4A
ficeLight - ID 0013A20040B62A4B
ficeLight - ID 0013A20040B62A4C
ficeLight - ID 0013A20040B62A4D
ficeLight - ID 0013A20040B62A4E
Send to RAB
Device Scanner
Enter Manually
PLACE RECTANGLE TO FIT CODE ON LABEL
Oce
Oce Lights
Send to RAB: Onceall of the devices have been added and
organized,submit the information for commissioning.
Enter Manually
PLACE RECTANGLE TO FIT CODE ON LABEL
Scan Device Code
SaveCancel
Location
Zone Name
Dimmable
Power Monitoring
Enter Device Information Repeat for Additional Devices
Send to RAB
Send to RAB
Enter Manually
PLACE RECTANGLE TO FIT CODE ON LABEL
DEVI CE ID s
ZONE N A ME PA N E L /
CIRC U IT #
9
9a
9b

Setup & installation (cont’d)
10 Power Up
10a Call RAB at 1 (844) LIGHTCLOUD, or email us at [email protected],
to add the Touch to your Lightcloud network.
®
10a

10b Once the Touch has joined your network, you'll see the screen below.
®
10b

Functionality
All Lightcloud products can be commissioned and configured by:
• Logging on to lightcloud.com
• Calling RAB at 1 (844) LIGHTCLOUD
• Emailing us at [email protected]
Configure
1 (844) LIGHTCLOUD
1 [phone]
[email protected]
1Configuring the Touch by calling or emailing RAB

2Configuring the Touch using the web/mobile application
Navigate to https://control.lightcloud.com and log in.
2a2a

Functionality (cont’d)
2Configuring the Touch using the web/mobile application (cont’d)
Click the menu icon in the top left.
2b2b

Navigate to your Site, then click Devices.
2c
Find your Touch device in the Device List on the left.
2d
2c
2d

Functionality (cont’d)
2Configuring the Touch using the web/mobile application (cont’d)
Click the icon to add zone and/or
scene controls to your Touch.
2e In this example, we've configured our
Touch to control two zones and one scene:
2e

Within a few seconds, the tablet UI refreshes to reflect the changes.
2f2f

FCC Information:
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
These limits are designed to provide reasonable protection against harmful interference in a non-residential installation.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference with radio or television reception, which can be determined by turning the equipment off and on, you are encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the antenna.
• Increase the separation between this equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
To comply with FCC RF exposure limits for general population/uncontrolled exposure, this transmitter must be installed to
provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any
other antenna or transmitter.
CAUTION: Changes or modifications to this equipment not expressly approved by RAB Lighting, Inc. may void the user’s
authority to operate this equipment.
