Lightolier Motion or Light Sensor Enclosure OA20-10 User manual

Features
• Can accommodate most manufacturers li ht or occupancy
sensor switch.
• Line or low volta e.
• Fits standard or slot rid ceilin systems.
• Plu -in connection to matin fixture (ordered separately).
• Secures to ceilin "T" (Standard or Slot Grid).
• Ceilin tile hold-down.
• 18 au e steel fascia.
• Mates with 2' x 2' and 2' x 4' recessed fixture products:
Mounting Methods Dimensions
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
11/06
ULM Module UL2F
Page 1 of 2 Motio or Light Se sor E closure
Lightolier a Ge lyte compa y www.lightolier.com
Tech ical I formatio : [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to cha ge details of desig , materials a d fi ish.
© 2006 a Ge lyte compa y Options/Accessories Folio OA20 10
Alter Classic (QVS)
Alter Hi h Efficiency (QHE)
Alter Louver (QVS LV)
Coffaire (CF)
Deepcel (DP)
HP90 (HP)
Mini-Beam (MB)
Mini-Beam HP (MB)
Parabaffle (MP)
Paralyte (PL)
Paraplus (PP)
Prismalyte (PL)
Sidelyte (SM)
Specplus (SP)
Video Tele-Conference (VT)
Vision Smart 2' x 2' (VP/VR)
Vision Smart 2' x 4' (VP/VR)
6.5"
(165mm)
4.5"
(114mm)
exposed t-grid ceiling exposed slot t-grid ceiling
patent pending
4"
(102mm)

Catalog No. Part No. Manufacturer Power
UL2F TR1 DSI Smart 120V Tridonic 120V
UL2F TR2 DSI Smart 277V 277V
UL2F WS1 FS205 24VDC
UL2F WS2 FS305 24VDC
UL2F WS3 FS255 Watt Stopper 120-277VAC
UL2F WS4 FS405 24VDC
UL2F LU1 C R M1 WH 15VDC
UL2F LU2 C SR M1 WH Lutron 15VDC
ULM Module UL2F
Page 2 of 2 Motio or Light Se sor E closure
Job Information Type:
Ordering Information
Orderin Information Explanation of Catalo Number: UL2F-WS1
Specifications
Materials: 18 au e cold rolled steel fascia.
Finish: Flat white.
Housing: 24 au e alvanized steel.
Labels: I.B.E.W.
UL
UL Module
2
Fixture Width:
2= 24"
F
Finish:
F= Flat White
Power
(Voltage)
WS1 = 24VDC
WS2 = 24VDC
WS3 = 120-277VAC
WS4 = 24VDC
TR1 = 120V
TR2 = 227V
LU1 = 15VDC
LU2 = 15VDC
Lightolier a Ge lyte compa y www.lightolier.com
Tech ical I formatio : [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to cha ge details of desig , materials a d fi ish.
© 2006 a Ge lyte compa y Options/Accessories Folio OA20 10
NOTE: Contact Sensor Manufacturer for additional information. Contact factory
(LOL) for other sensors you may want to use.
plug-in connection mates with 2' x 2' / 2' x 4' recessed fixtures completed installation
The ULM Module is an enclosure that will accommodate most manufacturers
motion or dayli ht sensors in either line or low volta e. It is desi ned to
interface and quick connect to most of our 2x4 and 2x2 recessed li htin
fixtures.
The ULM Module creates the convenience of bein able to build a motion or
dayli ht sensor (produced by others) into any of our recessed fixtures
eliminatin the potential errors in how the sensors and fixtures are
electrically connected.
NOTE:
Fixtures and ULM Modules are ordered as separate items. Sensors used and
wirin of fixtures will be based on information provided by specifier.
-
