ULM MODULE MOTION OR DAYLIGHT SENSOR ENCLOSURE INSTALLATION INSTRUCTIONS
1
© Lightolier 2006 59-31159-000 rinted in U.S.A.
Install the fixture. The Electrical Connector for
the Module must be accessible through the
knockout at the end of the Fixture prior to the
Module being installed.
2REMOVE COVER
Remove the Cover from the Module by loosening
the 2 Screws.
Fixture
Electrical
Connector
Cover
Screw
3MOUNTING AND ELECTRICAL CONNECTIONS
Mount Module to T-Bar, mate Electrical
Connections, install Bushing and install 7/8" lug
if necessary.
Module Module
Electrical
Connectors
Electrical
Connectors
T-Bar (G) T-Bar (T)
Module
Bushing Electrical
Connectors
Module
7/8" lug

4ATTACH COVER
Attach Cover by sliding the Screws from the Cover
over the two Tabs and fasten securely.
Screw Tab
Cover
5DIMENSIONS TO CUT TILE
Cut Ceiling Tile in the center using the dimensions
below.
4-1/8" (105mm)
4-1/8" (105mm)
2-1/16"
(52mm)
2-1/16"
(52mm)
1/4"
(6mm)
3-3/4"
(95mm)
3-1/2"
(89mm)
3-1/4" (89mm)
3-1/4" (89mm)
1-5/8" (29mm)
1-5/8" (29mm)
G-Type Tile
T-Type Tile
Slot Grid
6TILE
Install cut Ceiling Tile.
Cut
Ceiling
Tile
7HD CLI
Adjust HD Clip to ensure Module Fascia sits flush
to Ceiling Tile. Installation is complete.
Module
Fascia
HD Clip
Module
Ceiling
Tile
