CD5 with Louver
CD5 with Lens
Specifications
Specifications
LS6
Lytetube CD5
Lytetube CD5’s
small size and sleek
design is a sensible
choice for small to
medium spaces.
Lightolier Lighting Systems are modular lighting systems that offer a wide selection of
geometric shapes, architectural profiles, scales and finishes.
Lytetube CD5 can be used a task light, an accent light, for general
lighting or wall washing. Occasionally, there is a need to erect a
pattern of luminaires that won’t overpower the entire room. The
Lytetube CD5 does this with ease. The designer can use all the
accessories to build a custom fitted pattern making Lytetube CD5
a solution to any situation demanding a completely modular
luminaire system.
Lytetube CD5 provides the customer with a wide array of light
distributions to choose from. The ability to rotate the luminaire
through 350 degrees makes it possible to place light nearly any-
where. With its array of features and accessories, Lytetube CD5
provides dependable, flexible lighting. Accessories include many
joining devices including flexible corners, pendant, cable and wall
mounting and shielding options from a prismatic lens to black
louver. The Lytetube CD5 also has provisions for a recessed
Lytespan®track.
Lighting Systems
■
1 Housing: Extruded aluminum. Die-cast end cap mechani-
cally attached with no exposed fasteners. Concealed
access holes in end plate for through wiring.
■
2 Lamping: One, two or three T8 fluorescent lamps, as speci-
fied. Provided by others.
■
3 Reflector: Die-formed semi-specular aluminum.
Rotating Ring (not shown):1 1/8" diameter die-cast zinc alloy
to allow 358 degree housing rotation. Finished in polished
chrome.
Lens: Optional extruded 100% acrylic clear linear
prismatic lens.
Louver: Optional straight blade black louver.
Electrical
Specify 120 volt or 277 volt. 3 conductor, 12 gauge
wire. Color-coded quick connectors allow ease of
connection for joiner modules. For special circuit-
ing, consult factory. Rapid start, HPF, class “P”
thermally protected. PowerSpec HDF dimming
ballast is available.
Mountings
Cable Suspension (not shown) – 4 1/2" diameter
flat canopy finished enamel white, 1/16" diameter
stainless steel aircraft cable adjustable up to 36",
adjustable cable gripper.
Stem Mounting (not shown) – 4 1/2" diameter flat
canopy finished satin chrome, 1/2" diameter satin
chrome stem. Can be cut to length on job. Self-
aligning swivel provides adjustability up to 38
degrees. The stem assembly shall meet or exceed
the requirements set forth in the State of California
Uniform Building Code for suspended lighting fix-
tures installed in seismic zone four.
Finish
Powder coated baked white enamel. Custom colors
available, consult factory.
Options & Accessories
Lens, louver, L, T, X and Inline joiner blocks, retro-fit stem
set, retro-fit cable set available.
Labels
UL, ULc and IBEW.
1
3
2
1
3
2
3 1/4"3 1/4"
3 1/4"
CD5 Indirect or Direct
Report No. LRL 282-5G
CD5-1: 1 lamp T8
50.1% efficiency, 0% ∧100% ∨
CD5-2: Fluorescent luminaire with
track.
For complete performance data please
refer to specification sheets.
Coefficients of Utilization
% Wall Reflectance
50 30 10
078 78 78
169 67 64
262 57 54
355 50 46
449 44 39
544 38 34
640 34 30
736 30 26
833 27 23
930 24 21
10 26 21 17
80% Ceiling Reflectance
20% Floor Reflectance
Room Cavity Ratio
Application Data
Fixture Spacing Footcandles Watt/Sq Ft
50’ x 70’ x 8.5’ Space
8’ x 8’ (64 sq ft /fixture) 20 0.5
8’ x 10’ (80 sq ft /fixture) 9 0.4
12’ x 16’ x 8.5’ Space
6’ x 8’ (48 sq ft /fixture) 18 0.7
8’ x 8’ x 8.5’ Space
8’ x 8’ (64 sq ft /fixture) 12 0.5
Reflectances: 80% Ceiling, 50% Wall, 20% Floor
Light Loss Factor = .75 (.88 BF x 8.5)
Individual Fixtures
1. Order number of FIXTURES (fixture
comes complete with end caps,
mounting hardware and power feeds).
2. Optional – Order LENS or LOUVERS for
number of FIXTURES.
3. Order LYTESPAN TRACK FIXTURES,
if applicable.
Lytespan
Track Adapter
CD5A3
Retro-fit
Stem Set
CD5B3
Retro-fit
Cable Set
CD5C3
Switch
Assembly
CD5S3WH
Accessories
Lens and Louvers
4’ Black Louver
CD5LV
How to specify and order
4’ Prismatic
Lens
CD5PLA
How to Specify
Style Type Shielding
CD5 1 = Fluorescent Blank = none
3 = Track LV = Louver
4 = Fluorescent & Track PL = Lens
Style Mounting Type Length Color Ballast & Voltage
CD5 WH
3= Stem
4= Cable
(must be 3
for track)
1 = fluorescent
3 = track
4 = fluorescent
& track
4 = 64-1/4" overall
9 = 112-1/4" overall
White Blank = T12 Magnetic 120v
2 = T12 Magnetic 277v
E1 = T12 Electronic 120v
E2 = T12 Electronic 277v
E81 = T8 Electronic 120v
E82 = T8 Electronic 277v
HD1 = T8 PowerSpec HDF
Dimming 120v
HD2 = T8 PowerSpec HDF
Dimming 277v
M71 =T8 Electronic
Dimming Ballast 120v
M72 =T8 Electronic
Dimming Ballast 277v
example: CD53PL
example: CD5449WHE82
How to Order
L Block - CD5JWH
T Block - CD5K3WH
X Block - CD5L3WH
1-1/8" Inline Block -
CD5G3WH
3-1/2" Inline Block -
CD5H3WH
Joiner Blocks
For complete ordering instructions and joiner block detail please refer to
specification sheets.
