VP PARABOLIC DVA5G32MS240
Page 1 of 2 20”x 60” RECESSED FLUORESCENT 32 CELL PARABOLIC LOUVER
STATIC AND AIR SUPPLY/ RETURN IES RP24 PREFERRED
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902 Section 2/Folio G09-15
Features
• Meets IES RP-24 Preferred Practice.
• Ideal for intensive VDT use areas.
• Only 4” deep.
• Utilizes CFI Advance Technology Reflector Louver.
• Faceplate made with die-formed 20 gauge steel with edges
hemmed for rigidity.
• Full length air slots with bent edge for rigidity.
• Precise fitting reflector louver.
• Louver securely held with CFI concealed torsiontite spring clips.
• Fixture Efficiency 62.0%.

*Contact factory for availability of louver finishes.
VP PARABOLIC DVA5G32MS240
Page 2 of 2 20”x 60” RECESSED FLUORESCENT 32 CELL PARABOLIC LOUVER
STATIC AND AIR SUPPLY/ RETURN IES RP24 PREFERRED
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902 Section 2/Folio G09-15
Job Information Type:
SPECIFICATIONS
PERFORMANCE: In an installation of 2 lamp 32W luminaires in a room cavity
ratio of 1 reflectance 80% ceiling, 50% wall, 20% floor the C.U. shall not be
less than 0.69. To prevent glare the VCP shall not be less than 88 either length-
wise or crosswise (at 100 fc level) and that the average luminance will conform
with the IES RP-24 preferred standard, and have a fixture efficiency of not less
than 60%.
MATERIALS: Chassis parts are die-formed 22 gauge cold rolled steel. Faceplate
is die-formed 20 gauge cold rolled steel with edges hemmed for rigidity.
LOUVER: Post-anodized aluminum.
FINISH: Louver - Low iridescence specular post-anodized vertical grain sheet or
Low iridescence reflector matte post-anodized vertical grain sheet. Chassis exte-
rior -white baked polyester powder coat.
SPECIFICATIONS (continued)
ELECTRICAL: Rapid start HPF thermally protected class “P” ballast CBM certi-
fied by ETL if K.O. is within 3” of ballast use wire suitable for at least 90°.
LABELS: Listed by CSA/UL.
