Lightolier Calculite C6T6A-MHT6RNF User manual

Calculite®HID Adjustable Accent C6T6A-MHT6RNF
Page 1 of 2 6" Aperture, T6, Ceramic Metal Halide, Narrow Flood
20" to 30"
10-5/8"
15"
19-5/8"
22-1/8" (Magnetic)
20-1/4" (Electronic)
19-1/8"
Top View
7" (176 mm) Dia.
5 3/4" (146 mm) Dia.
Features
1. Narrow Flood Upper Reflector: Specular split faceted aluminum;
provides 25° beam. Interchangeable with 12° Spot (MHT6RS) and 40° Flood
(MHT6RF); see spec sheets C6T6A-MHT6RS and C6T6A-MHT6RF.
2. Trim Kit: Low brightness aperture cone; anodized aluminum, self-flanged in
painted white or aperture-matching polished flange. Consult factory for other
finishes.
3. Lamp Shield: High-temperature glass as required by code; captive during
re-lamping.
. Trim Kit Adjustment Mechanism: Provides 40° vertical tilt, 360° horizon-
tal rotation; lockable. EZ-Aim Helical Drive System provides fast and accu-
rate hot aiming with Philips screwdriver.
5. Socket Housing: Galvanized steel, pre-wired with G12 pulse rated socket.
Snaps onto yoke for secure attachment without tools; unitized construction
assures proper alignment of lamp to optics for consistent optical performance.
6. Frame Housing: Steel, 0.029" (22-Ga.), matte black finish. Removable cover
for top re-lamping.
7. Frame Vertical Adjustment Mechanism: Accommodates mounting to
virtually any ceiling system using pre-installed mounting bars, or 1/2" EMT
tubing (by others). Single locking feature secures all adjustments. Alignment
holes and markings allow fixture to be pre-set prior to installation. Final
adjustment can be made from below from inside fixture.
8. Mounting Bars: Galvanized steel, 0.04 " (1 -ga.), pre-installed telescoping
bars extend to 30" long and lock securely into position. Built-in locking tabs
provide positive attachment to common T-bar systems. Self-centering feature
simplifies installation in 24" O.C. grid systems. Attaches to steel or wood
joists without accessories.
9. Retention Springs: Rust resistant springs secure trim for quick, tool-less
installation.
10.Ballast / Cover Assembly: Accessible from below and removable without
tools for inspection and ballast replacement .
11.Junction Box: 0.059" (16-ga.) galvanized steel. UL listed for No. 12 AWG,
90°C through branch circuit conductors. Allows inspection from below.
12.Accessory Holder: Sold separately catalog # CAH6; die-formed steel, matte
black finish, slide-in installation. Accepts up to two 4 3/4" dia. media.
13.Thermal Protector: (Not Shown) Meets NEC and UL requirements. Do not
install insulation above nor within 3" (76mm) of any part of the luminaire.
Electrical
Electronic Ballast: 120 or 277V, 50/60 Hz., encased, high power factor, T.H.D
<15%, thermally and transient protected, RMI/RFI complies with FCC Part 1 on-
consumer equipment, shut-down circuit at end of lamp life, sound rating “A”, -
5°F (-20°F for 150W) minimum starting temperature, Type 1 outdoor rating.
Ballast ANSI Code Voltage Max. Amps Input Watts
39W MH M130 120/277 0.39/0.17 44
70W MH M139 120/277 0.67/0.2 7
150W MH M142 120/277 1.40/0.60 167
Options and Accessories
Chicago Plenum: Consult Factory
Fuse (magnetic ballast): Add suffix F1 or F2 to Frame-In Kit (F1=120V, F2=277V)
Labels
UL (Suitable for Damp Locations), CSA, I.B.E.W.
For 150W, install fixtures with minimum spacing between:
1. Center-to center of adjacent luminaries: 2 feet.
2. Top of luminaire to overhead building member: 1/2 inch.
3. Luminaire center to side building member: 1 foot.
C6A39T6E1 Electronic 120V 39W T6 Ceramic MH
C6A39T6E2 Electronic 277V 39W T6 Ceramic MH
C6A70T6E1 Electronic 120V 70W T6 Ceramic MH
C6A70T6E2 Electronic 277V 70W T6 Ceramic MH
C6A15T6E1 Electronic 120V 150W T6 Ceramic MH
C6A15T6E2 Electronic 277V 150W T6 Ceramic MH
Narrow Flood
Upper Reflector
Ceiling Cutout: 6 9/16” (167mm) Dia.
For Complete Fixture Order: Trim Kit + Narrow Flood Upper Reflector (MHT6RNF) + Frame-In Kit. Each Sold Separately.
Trim Kit + Narrow Flood Upper Reflector Frame-In Kit Lamp
C6T6A + MHT6RNF (Narrow Flood Upper Reflector)
CLW Specular Clear, White Painted Flange
CLP Specular Clear, Matching Flange
CCDW Comfort Clear Diffuse, White Painted Flange
CCDP Comfort Clear Diffuse, Matching Flange
CCZW Champagne Bronze, White Painted Flange
CCZP Champagne Bronze, Matching Flange
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • (50 ) 679- 131 • Fax (50 ) 674-4710
We reserve the right to change details of design, materials and finish.
© 2006 Genlyte Group LLC • B0406

Calculite®HID Adjustable Accent C6T6A-MHT6RNF
Page 2 of 2 6" Aperture, T6, Ceramic Metal Halide, Narrow Flood








5,000
2,500
7,500
10,000
10,000
5,000
15,000
20,000
7,500
15,000
22,500
30,000
30°
60°
30°
60°
30°
60°
30° Aiming Angle
Horizontal Surface
DC FC LW
8' .6' 319 .0' 3. '
10' 5.8' 20 5.0' .3'
12' 6.9' 1 2 6.0' 5.1'
15' 8.7' 91 7.5' 6. '
20' 11.5' 51 10.0' 8.6'
30° Aiming Angle
Vertical Surface
DC FC LW
3' 5.2' 37 5.0' 2.2'
' 6.9' 2 6 6.6' 3.0'
6' 10. ' 109 9.9' . '
8' 13.9' 61 13.2' 5.9'
12' 20.8' 27 19.8' 8.9'
CANDLEPOWER DISTRIBUTION
30° Aiming Angle
Vertical Surface
DC FC LW
2' 3.5' 327 2.7' 1.3'
3' 5.2' 1 5 .1' 1.9'
' 6.9' 82 5.5' 2.5'
6' 10. ' 36 8.2' 3.8'
8' 13.9' 20 11.0' 5.1'
ANGLE WALL
0 572
5608
10 737
15 1373
20 3 77
25 7 17
30 10 51
35 9231
0 5593
5 1881
50 9 5
55 562
60 212
65 6
70 2
75 0
80 0
85 0
90 0
30° Aiming Angle
Horizontal Surface
DC FC LW
8' .6' 198 3.6' 3.1'
10' 5.8' 127 .5' 3.9'
12' 6.9' 88 5. ' .6'
15' 8.7' 56 6.8' 5.8'
20' 11.5' 32 9.0' 7.7'
30° Aiming Angle
Vertical Surface
DC FC LW
3' 5.2' 271 . ' 2.0'
' 6.9' 152 5.8' 2.7'
6' 10. ' 68 8.8' .0'
8' 13.9' 38 11.7' 5. '
12' 20.8' 17 17.5' 8.0'
AIMED 30º. TOWARD WALL
LAMP: 150W T6 MH, PHILIPS
LUMEN RATING: 1 000 LMS.
CBCP: 31 3
Beam Angle: 21
AROMAT 150W ELECTRONIC BALLAST
DATE: MAR 10, 200
CERTIFIED TEST REPORT NO. 2532FR
COMPUTED BY LSI PROGRAM
**TEST-LITE**
AIMED 30º. TOWARD WALL
LAMP: 70W T6 MH, PHILIPS
LUMEN RATING: 6600 LMS.
CBCP: 19503
Beam Angle: 19
AROMAT 150W ELECTRONIC BALLAST
DATE: MAR 13, 200
CERTIFIED TEST REPORT NO. 2526FR
COMPUTED BY LSI PROGRAM
**TEST-LITE**
AIMED 30º. TOWARD WALL
LAMP: 39W T6 MH, PHILIPS
LUMEN RATING: 3 00 LMS.
CBCP: 10 51
Beam Angle: 18
AROMAT 39W ELECTRONIC BALLAST
DATE: MAR 9, 200
CERTIFIED TEST REPORT NO. 2529FR
COMPUTED BY LSI PROGRAM
**TEST-LITE**
30° Aiming Angle
Horizontal Surface
DC FC LW
6' 3.5' 189 2.6' 2.2'
8' .6' 106 3. ' 2.9'
10' 5.8' 68 .3' 3.7'
12' 6.9' 7 5.1' . '
15' 8.7' 30 6. ' 5.5'
39W T6 CERAMIC MH NARROW FLOOD UPPER REFLECTOR
ANGLE WALL
0 1518
5 1673
10 2589
15 991
20 10029
25 16852
30 19503
35 15 67
0 78
5 3109
50 1583
55 635
60 195
65 18
70 0
75 0
80 0
85 0
90 0
70W T6 CERAMIC MH NARROW FLOOD UPPER REFLECTOR
ANGLE WALL
0 2007
5 2615
10 3893
15 7816
20 16207
25 27282
30 31 3
35 25856
0 16177
5 7133
50 260
55 2397
60 971
65 287
70 20
75 0
80 0
85 0
90 0
150W T6 CERAMIC MH NARROW FLOOD UPPER REFLECTOR




(FC) is initial footcandles at center of
beam. Beam length (L) and beam width
(W) are to where the candlepower is
reduced to 50% of the center beam
candlepower. (C) is the distance to the
center of the beam.
Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • (50 ) 679- 131 • Fax (50 ) 674-4710
We reserve the right to change details of design, materials and finish.
© 2006 Genlyte Group LLC • B0406
