Sauder 420011 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-19
Français pg 20-22
Español pg 23-25
Lot # 506494 08/07/17
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Lift-Top Coee Table
Dakota Pass Collection | Model 420011
It's addicting.

Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
No. 2 Phillips Screwdriver
Tip Shown Actual Size
2-3
4
5-19
20-22
23-25
26
27
Hammer
Not actual size
Skip the power trip.
This time.
Short Screwdriver
(provided)
Now you know
our ABCs.
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C UPRIGHT (1)
D TOP (1)
E2 BOTTOM (1)
F SHELF (1)
H RIGHT FRONT/LEFT REAR LEG (2)
I LEFT FRONT/RIGHT REAR LEG (2)
J PANEL (2)
K SKIRT (2)
L BRACE (1)
M PANEL MOLDING (2)
N SHELF MOLDING (2)
420011 www.sauder.com/servicesPage 2
Adjustable Wrench

Now you know
our ABCs.
Part IdentificationPart Identification
420011www.sauder.com/services Page 3
B
A
C
D
E2
H
I
J
K
K
F
L
M
H
I
J
M
N
N

Hardware Identification
420011 www.sauder.com/servicesPage 4
åScrews are shown actual size. You may receive extra hardware with your unit.
BLACK 9/16" LARGE HEAD SCREW - 24
1S
CAM COVER - 18
13P
CAM DOWEL - 10
2F
HIDDEN CAM - 18
1F CAM SCREW - 8 8F
WASHER - 8
13M
NUT - 8
24M
BUMPER - 6
2M
SUPPORT
BRACKET - 2
37G
BLACK 3/4" MACHINE SCREW - 4
92S
BLACK 1-1/4" MACHINE SCREW - 4
93S
23M LIFT TABLE
MECHANISM SET - 1
METAL BRACKET - 4
4G
SILVER 1-1/8" FLAT HEAD SCREW - 6
10S
SCREW COVER - 6
18P
BLACK 1-15/16" FLAT HEAD SCREW - 10
113S
BLACK 3/4" PAN HEAD SCREW - 2
85S
BUSHING - 2
91M

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push ten HIDDEN CAMS (1F) into the UPRIGHT (C),
BOTTOM (E2), and SHELF (F). Then, insert the metal end
of a CAM DOWEL (2F) into each HIDDEN CAM.
420011www.sauder.com/services Page 5
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Arrow
1F
2F
(10 used)
Do not tighten the HIDDEN CAMS in this step.
Arrow
1F
2F
C
E2
F
Scan this QR code or go to this address:
http://qr.sauder.com/?ID=2073
to watch a video on how to assemble your unit.

Step 2
420011 www.sauder.com/servicesPage 6
8F
å Turn eight CAM SCREWS (8F) into exact holes shown in
the LEGS (H and I).
å Push eight HIDDEN CAMS (1F) into the exact holes shown
in the ENDS (A and B).
Arrow
Arrow
1F
The arrow in the HIDDEN
CAM must point toward the
hole in the edge of the board.
Hole
1F
Arrow
(8 used)
A
B
(8 used)
H
I
H
I

å Fasten the LEGS (H and I) to the ENDS (A and B). Tighten
eight HIDDEN CAMS.
Step 3
420011www.sauder.com/services Page 7
12
B
I
H
Surface with
HIDDEN CAMS
The LEGS will
overhang this edge.
These surfaces
should be even.
A
H
I
Surface with
HIDDEN CAMS
The LEGS will
overhang this edge.
These surfaces
should be even.
These holes
must be here.
These holes
must be here.

Step 4
420011 www.sauder.com/servicesPage 8
å Fasten four METAL BRACKETS (4G) to the PANELS (J).
Use four BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the METAL BRACKETS are even with the
edges of the PANELS.
å Fasten the PANELS (J) to the SHELF (F). Use eight BLACK
1-15/16" FLAT HEAD SCREWS (113S).
BLACK 9/16" LARGE HEAD SCREW
(4 used for the METAL BRACKETS)
1S
4G
4G
J
J
These METAL BRACKETS
should be located here
and facing each other.
J
J
BLACK 1-15/16" FLAT HEAD SCREW
(8 used in this step)
113S
F
Surface with
HIDDEN CAMS

å Fasten the SHELF (F) to the LEFT END (B). Tighten two
HIDDEN CAMS.
å Fasten the PANELS (J) to the LEFT END (B). Use two
BLACK 9/16" LARGE HEAD SCREWS (1S) through the
METAL BRACKETS and into the LEFT END.
Step 5
420011www.sauder.com/services Page 9
BLACK 9/16" LARGE HEAD SCREW
(2 used for the METAL BRACKETS)
1S
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
J
J
F
B
Surface with
HIDDEN CAMS
I
H
Surface with
HIDDEN CAMS

Step 6
420011 www.sauder.com/servicesPage 10
å Slide the SHELF MOLDINGS* (N) onto the notched edges of
the SHELF (F).
å Fasten the UPRIGHT (C) to the SHELF (F). Tighten two
HIDDEN CAMS.
å *U.S. Patent No. 5,499,886
Arrow
Minimum
190 degrees
Maximum
210 degrees
F
C
Surface with
HIDDEN CAMS
Slide the SHELF MOLDING (N)
onto the notched edge.
N
N
Notched edge
Notched edge
The groove
is closer to
this edge.
